www.elvac.eu Dispatching control system Miroslav Kocur for substation Own products Dispatching control system for enterprise energetics RTU RTUs for control, protection, data acquisition and communication Content Enterprises www.elvac.eu |


slide-1
SLIDE 1

Miroslav Kocur

Dispatching control system for substation

www.elvac.eu

slide-2
SLIDE 2

Dispatching control system for enterprise energetics

Own products

slide-3
SLIDE 3
slide-4
SLIDE 4

RTU

www.elvac.eu | www.rtu.cz

RTUs for control, protection, data acquisition and communication

Content

Own products

Enterprises

slide-5
SLIDE 5

RTU Requirements requirements for data transmission to the dispatching

  • f distribution company

P, Q of all generators P, Q, U, I of all HV/MV transformers Signalling faults of protections Remote control switches of generators

www.elvac.eu | www.rtu.cz

RTUs for control, protection, data acquisition and communication

Dispatching control system for enterprise energetics

Own products

slide-6
SLIDE 6

Dispatching control system for MV/LV substation

Own products

slide-7
SLIDE 7

RTU Requirements for MV/LV (endpoint) substation Compact RTU for MV/LV (endpoint) substation - basic variant Modular RTU for MV/LV (endpoint) substation - option Requirements for MV/LV (loop or nodal) substation Compact RTU for MV/LV (loop or nodal) substation - basic variant Modular RTU for MV/LV (loop or nodal) substation - option

www.elvac.eu | www.rtu.cz

RTUs for control, protection, data acquisition and communication

Content

Own products

slide-8
SLIDE 8

RTU

www.elvac.eu | www.rtu.cz

MV/LV (endpoint) substation

RTUs for control, protection, data acquisition and communication Own products

slide-9
SLIDE 9

RTU Basic 3-phase measurement in four quadrants for active/reactive energy (V, I, P, Q, S, EM) and waveforms of measured voltages 2 digital inputs (door contact, oil level) communication interfaces – GPRS/EDGE/UMTS/LTE or Ethernet Option measuring transformer according standards IEC61557-12, EN50160, class S event record of measured voltages nx LV outlets – 3 phase measurement V, I, P,Q backup power extension of the communication interface (RS-485 or Ethernet)

www.elvac.eu | www.rtu.cz

Requirements for control MV/LV (endpoint) substation

RTUs for control, protection, data acquisition and communication Own products

slide-10
SLIDE 10

RTU Basic 3-phase measurement in four quadrants for active/reactive energy (V, I, P, Q, S, EE) and waveforms of measured voltages 2 digital inputs (door contact, oil level) communication interfaces – GPRS/EDGE/UMTS/LTE or Ethernet Solution Compact RTU7K

www.elvac.eu | www.rtu.cz

The control MV/LV (endpoint) substation

RTUs for control, protection, data acquisition and communication Own products

slide-11
SLIDE 11

RTU Option measuring transformer according standards IEC61557-12, EN50160, class S event record of measured voltages nx LV outlets – 3 phase measurement V, I, P,Q backup power supply extension of the communication interface (RS-485 or Ethernet) Solution Modular unit RTU7M PWRI 230 – BAT 12 (backup power) COMIO-PC2 GSM (GPRS/EDGE/UMTS, Ethernet, RS-232/485) n x EP-3U3I SMC 133 (standards IEC61557-12, EN50160, class S)

www.elvac.eu | www.rtu.cz

The control MV/LV (endpoint) substation

RTUs for control, protection, data acquisition and communication Own products

slide-12
SLIDE 12

RTU RTU7M

www.elvac.eu | www.rtu.cz

The control MV/LV (endpoint) substation

RTUs for control, protection, data acquisition and communication Own products

slide-13
SLIDE 13

RTU Measurement V,I

www.elvac.eu | www.rtu.cz

The control MV/LV (endpoint) substation

RTUs for control, protection, data acquisition and communication Own products

slide-14
SLIDE 14

RTU

www.elvac.eu | www.rtu.cz

MV/LV (loop or nodal) substation

RTUs for control, protection, data acquisition and communication Own products

slide-15
SLIDE 15

RTU Basic 3-phase measurement in four quadrants for active/reactive energy (V, I, P, Q, S, EM) and waveforms of measured voltages 2 digital inputs (door contact, oil level) N x MV outlets – 3 phase measurement V, I, P, Q , indicator fault currents communication interfaces – GPRS/EDGE/UMTS/LTE or Ethernet backup power supply Option measuring transformer according standards IEC61557-12, EN50160, class S event record of measured voltages n x LV outlets – 3 phase measurement V, I, P,Q extension of the communication interface (RS-485 or Ethernet)

www.elvac.eu | www.rtu.cz

Requirements for control MV/LV (loop or nodal) substation

RTUs for control, protection, data acquisition and communication Own products

slide-16
SLIDE 16

RTU

www.elvac.eu | www.rtu.cz

The control MV/LV (loop or nodal) substation

RTUs for control, protection, data acquisition and communication Own products

Basic 3-phase measurement in four quadrants for active/reactive energy (V, I, P, Q, S, EM) and waveforms of measured voltages 2 digital inputs (door contact, oil level) N x MV outlets – 3 phase measurement V, I, P, Q , indicator fault currents communication interfaces – GPRS/EDGE/UMTS/LTE or Ethernet backup power supply Solution Compact RTU74 Power quality analyser SMC 133

slide-17
SLIDE 17

RTU

www.elvac.eu | www.rtu.cz

The control MV/LV (loop or nodal) substation

RTUs for control, protection, data acquisition and communication Own products

Option measuring transformer according standards IEC61557-12, EN50160, class S event record of measured voltages n x LV outlets – 3 phase measurement V, I, P,Q extension of the communication interface (RS-485 or Ethernet) Solution Modular unit RTU7M PWRI 230 – BAT 12 (backup power) COMIO-PC2 GSM (GPRS/EDGE/UMTS, Ethernet, RS-232/485) n x EP-3U3I for LV outlets n x EP-4U4I for MV outlets SMC 133 (standards IEC61557-12, EN50160, class S)

slide-18
SLIDE 18

RTU RTU7M

www.elvac.eu | www.rtu.cz

The control MV/LV (loop or nodal) substation

RTUs for control, protection, data acquisition and communication Own products

slide-19
SLIDE 19

RTU Measurement

www.elvac.eu | www.rtu.cz

The control MV/LV (loop or nodal) substation

RTUs for control, protection, data acquisition and communication Own products

slide-20
SLIDE 20

RTU Measurement

www.elvac.eu | www.rtu.cz

The control MV/LV (loop or nodal) substation

RTUs for control, protection, data acquisition and communication Own products

slide-21
SLIDE 21

RTU Measurement

www.elvac.eu | www.rtu.cz

The control MV/LV (loop or nodal) substation

RTUs for control, protection, data acquisition and communication Own products

slide-22
SLIDE 22

RTU

www.elvac.eu | www.rtu.cz

EP cards with special combinations of inputs

RTUs for control, protection, data acquisition and communication Own products

Other EP card for Zelisko sensors for Rogowski coil According to customer

slide-23
SLIDE 23

RTU

www.elvac.eu | www.rtu.cz

Signaling and HMI panel ERIC151x

RTUs for control, protection, data acquisition and communication Own products

Basic features of unit communication with RTU through RS-485 (or Ethernet) external powering 24V DC touchscreen display 2,8” switch for local and remote control RESET button for reset of indication of fault on lines SELECT button for enabling of control of switching element (it is necessary to press two buttons for control which prevents accidental manipulation) indication cross for active line indication indication of outlet earthing indication of fault, the source of fault can be read on display switches On/Off for each switching element

slide-24
SLIDE 24

RTU

www.elvac.eu | www.rtu.cz

Signaling and HMI panel ERIC1516

RTUs for control, protection, data acquisition and communication Own products

slide-25
SLIDE 25

O Společnosti

Thank you for your attention

www.elvac.eu

Hasičská 53, 700 30 Ostrava - Hrabůvka Czech Republic Tel.: +420 597 407 100 E-mail: sales@elvac.eu www.elvac.eu, www.rtu.cz
