Cyberscurit des sous-stations lectriques IEC 61850 Thse CIFRE Malle Kabir-Querrec Content Introduction & Objectives Context: the IEC 61850 standard IDS for ICS: State of the art IEC 61850 specification of an

SLIDE 1

Cybersécurité des sous-stations électriques IEC 61850

Thèse CIFRE Maëlle Kabir-Querrec

SLIDE 2

gipsa-lab

Content

Introduction & Objectives
Context: the IEC 61850 standard
IDS for ICS: State of the art
IEC 61850 specification of an intrusion detection

function

A rule-based implementation
Conclusion

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 2 / 14

SLIDE 3

gipsa-lab

Interconnection with more global and open networks Exposure to cyber vulnerabilities & threats

Needs of dedicated digital security measures

Closed networks

Security through isolation

ICS are part of SAS (Substation Automation System)

Introduction

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 3 / 14

Aspirations for interoperability & ever growing complexity of technologies IEC 61850 – Communication networks and systems for power utility automation Proprietary protocols

Security through obscurity

Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

SLIDE 4

gipsa-lab

PhD research project

CIFRE convention GIPSA-lab + Euro-System (nov.

2013 nov. 2016)

Cybersecurity of smart-grid control systems
Specify an IEC 61850 intrusion detection function for

IEDs (Intelligent Electronic Devices)

Implement and test it
Propose other cybersecurity functionalities

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 4 / 14 Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

SLIDE 5

gipsa-lab

Context: IEC 61850 standard “Communication networks and systems for power utility

automation”

Substation Automation

Systems (SAS) are key to the grid protection.

Intelligent Electronic

Devices (IED)

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 5 / 14 Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

Automa- tion ICT IEC61850 Power grid SMART-GRID

SLIDE 6

gipsa-lab

Context: IEC 61850 standard “Communication networks and systems for power utility

automation” The IEC 61850 standard specifies communication in terms of Syntax - Semantics - Performance

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 6 / 14

OSI mapping of IEC 61850 protocols IEC 61850 communication architecture

Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

SLIDE 7

gipsa-lab

Context: IEC 61850 standard “Communication networks and systems for power utility

automation” IED services are based on an

bject-oriented model for

data and functions.

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 7 / 14

IEC 61850 data object modeling

Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

SLIDE 8

gipsa-lab

State of the art

IDS for ICS

IDS: Monitoring a network or a system activity to detect attempts to gain unauthorized access or to cause damages.

Host-based or network-based
Signature-based/Blacklisting or Anomaly-based/Whitelisting

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 8 / 14 Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

SLIDE 9

gipsa-lab

State of the art

Anomaly-based IDS for ICS (1)

State approach

Fovino I. N, Coletta A., Carcano A., Masera M. 2012. Critical State-Based Filtering System for Securing SCADA Network Protocols. Jin X., Bigham J., Rodaway J., Gamez D., Phillips C. 2006. Anomaly detection in electricity cyber infrastructures.

Communication approach
Rules

Premaratne U., Samarabandu J., Sidhu T., Beresh R., Tan J.-C. 2010. An Intrusion Detection System for IEC 61850 Automated Substations.

Statistical models

Sekar R., Gupta A. K., Frullo J., Shanbhag T., Tiwari A., Yang H., Zhou S. 2002. Specification-based anomaly detection: A new approach for detecting network intrusions. Cheung S., Dutertre B., Fong M., Lindqvist U., Skinner K., Valdes A. 2007. Using model-based intrusion detection for SCADA networks.

Implementation as a dedicated device

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 9 / 14 Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

SLIDE 10

gipsa-lab

State of the art

Anomaly-based IDS for ICS (2)

SAS specificities to be used to design a tailored IDS:

Embedded systems
Real-time constraints
Dedicated communication protocols
Fixed network topology & known mechanisms

Diallo D., Feuillet M. (ANSSI) 2014. Détection d'intrusion dans les systèmes industriels: Suricata et le cas de Modbus. Hong J., Liu C.-C., Govindarasu M. 2014. Integrated Anomaly Detection for Cyber Security of the Substations.

Network-based anomaly detection function relevant for broadcast packets

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 10 / 14 Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

SLIDE 11

gipsa-lab

Specification of an IEC 61850 intrusion detection function

Building new functionalities must follow rules to ensure the interoperability the IEC 61850 standard aims at. The new IDS function specification… … compatible with the IEC 61850 standard

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 11 / 14

IEC 61850 IDS model

Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

SLIDE 12

gipsa-lab

Implementation of this IEC 61850 IDS

Using an open source rule-

based NIDS, Suricata

Automatic rule generation

Source address is not in the accepted list. For a given GoID, the sequence number of the received GOOSE message has not been incremented compared to the previous one.

Run and test it on our G-

ICS platform, dedicated to cybersecurity and interoperability of ICS

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 12 / 14

G-ICS (GreEn-ER Industrial Control systems Sandbox)

Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

SLIDE 13

gipsa-lab

Conclusion & perspectives

IEC 61850 specification of an intrusion detection

function

Implementation of a rule-based intrusion detection

module + automatic rule generation

Further work: other cybersecurity functions such as

mapping of the communication architecture, resource availability, encryption…

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 13 / 14 Introduction IEC61850 standard State of the art Spec of IDS Implementation Conclusion

SLIDE 14

gipsa-lab

Questions & comments

RESSI 2015 21/05/2015 Maëlle Kabir-Querrec 14 / 14
