NM Oil Conservation Division IPANM Presentation August 3, 2016 David Catanach, Director Oil Conservation Division PRESENTATION OUTLINE Roswell Ground Water Basin Update Marginal Well Shut-In Relief Program Spill & Leak

slide-1
SLIDE 1

NM Oil Conservation Division IPANM Presentation August 3, 2016

David Catanach, Director Oil Conservation Division

slide-2
SLIDE 2

PRESENTATION OUTLINE

  • Roswell Ground Water Basin Update
  • Marginal Well Shut-In Relief Program
  • Spill & Leak Delineation & Remediation

Standards Workgroup

  • Focused Enforcement Efforts
  • Upcoming Issues

NMOCD IPANM Presentation 8-3-16

slide-3
SLIDE 3

ROSWELL GROUND WATER BASIN

  • Large area defined by the State Engineer
  • Approximate area: 105 Miles North to South

33 Miles East to West

  • Within a portion of the RGWB there exists two fresh water
  • aquifers. Shallow Aquifer: 450’ &

Deeper Artesian Aquifer: 1200’-1400’

  • Remaining portion of RGWB: Deeper Aquifer only
  • OCD initially contacted by Representative Townsend
  • Initial reports indicated possible water contamination
  • OCD attended 2 public meetings with Pecos Valley

Conservancy District, Office of the State Engineer & Various legislative members

  • At issue is whether a single casing string set through both

aquifers provides adequate protection

NMOCD IPANM Presentation 8-3-16

slide-4
SLIDE 4 . .·- ._ ' ' i 2.« t..--.c..., , c · C :
  • ·,
: N E W M E X I C O S T A T E E N G I N E E R S A N T A F E , N E W M E X I C O P R E P A R E D T H E U N I T E D I N C O O P E R A T I O N W I T H S T A T E S G E O L O G I C A L S U R V E Y 1 0 6 ° 10 ° T E C H N I C A L R E P O R T 4 2 R O S W E L L B A S I N N E W M E X I C O 1 0 4" T 3 N 2 T 1 l ,

I · · .

I ' w I ' · : i ' : I _ . . , . . ..
  • : -·•-
  • '
I I ' ,••• " i '"

:

'

.!. "

  • t
s

i N -

  • .
L! .. -, I . i./"· f •
  • " -
  • '
  • ,,; 't,. .- - -
: c :
  • 2. _., ·-
  • ,
1
  • - -n- .
. . .. .l
  • -"
'''-· ·--'· - · ·
  • -·"-''·
'-·-',--- :, , ... . . ! N T 1 8 .2 ( 3 5 6 7 !3 9 10 1 1 \
  • ,.,,.
.. 1 2
  • -------- - ---' ----··· -
' ' i 3
  • --- !
1 4 5 1 6 ( 1 7 18 19 20 2 1 +-·• ····-
  • - + - - , -
  • ··-· •·- - ,s
.;::, .... . . j ---·
  • ·
  • · --
,,, ., .. 24 \ [ > , ; ; ,·
  • ' ' ]5 5 ?
25 R 9 E 1 0 11 '<' ·? . · i ) i v,i 1 "t, ' 2' 5 .5

Mtxr co

f a . t n
  • 15
E W 6 T E X AS 1 2 1 3 14 1 6 17 18 19 2 0 2 1 22 23 2 4 . - / 6 ,,,.. '
  • 25
2 6 27 R 2 8 E Base from U. S. Geolog i ca l Su rv ey State base map, 1 :500 , 000 40 MI LE S
  • - - · J
10
  • - - -
  • -
20 30
  • - -
  • - - - -
  • E
X P LANAT I O N

.,,.--·--

  • --··- - -··-
Surface-water d r a i nage d i v ide Lega l boundary of Roswe l l U n d e r g r
  • u
n d Water Bas i n i n 1 97 9 Appr
  • xi
mate l i m i t
  • f a
rt es i an a qu i fer Ap p rox i ma t e 1 i m i t of s ha l l oe1 aq u i f e r

Figure 1 • Map showing the surf ace drainage, legal boundar y , and aquif er New limits Mexic o.

  • f the Roswell ground-wat er basin, sout heastern
'. - -

NMOCD IPANM Presentation 8-3-16

T-5S to T-23S R-21E to R-27E Map of Roswell Ground Water Basin

slide-5
SLIDE 5

ACTIONS TAKEN BY OCD

  • OCD’s primary concern: Protection of fresh water

while not hindering oil & gas drilling activities

  • All APD’s within the RGWB are currently suspended

by emergency order

  • Drilling is allowed within the RGWB provided that

OCD approves revised casing programs

  • OCC hearing will establish:
  • A clearly defined area for the RGWB
  • A definitive casing/cementing program for oil &

gas wells that will continue to provide protection

  • f both aquifers & prevent communication

between these water zones

slide-6
SLIDE 6

RGWB PUBLIC HEARING

  • Case will be presented to the Oil

Conservation Commission

  • Parties to the case include the OCD,

Pecos Valley Conservancy District, COG Operating, Fasken Oil & Ranch, Oxy USA, Inc., Yates Petroleum, Mack Energy, Devon Energy & IPANM

  • August 8: Meeting to schedule hearing
  • Hearing in September or October
slide-7
SLIDE 7

OCD MARGINAL WELL SHUT-IN PROGRAM

  • New OCD program allows operators to

shut-in marginal producing wells during times of low oil & gas prices

  • Program commenced early 2016
  • Will reduce premature plugging of marginal

producing wells

  • Must be conducted in a manner that will

protect fresh water resources

  • 12 Operators; 400-500 Wells

NMOCD IPANM Presentation 8-3-16

slide-8
SLIDE 8

Requirements/Parameters

  • Applicable to wells that are planned to be shut-in
  • r have recently been shut-in due to low prices
  • Must execute an agreed compliance order
  • Must demonstrate economic need
  • After a shut-in period of 15 months (currently

allowed by OCD rules) wells can remain shut-in for an additional 3-year period

  • Wells must demonstrate mechanical integrity by

Bradenhead Test at month 27 and annually thereafter

  • Additional financial assurance may be required
  • Check with BLM & SLO NMOCD IPANM Presentation 8-3-16
slide-9
SLIDE 9

SHUT-IN WELL PROGRAM OCD CONTACT PERSON

DANIEL SANCHEZ OCD Compliance & Enforcement Manager

505-476-3493

NMOCD IPANM Presentation 8-3-16

slide-10
SLIDE 10

Spill & Leak Delineation & Remediation

  • Standards for delineating & remediating

spills & leaks are currently contained within an OCD guidance document

  • Industry is concerned that standards are

not established by rule & are not uniformly enforced within OCD

  • Industry recommendation: Form an

OCD/Industry committee to establish a rule for spill & leak delineation & remediation standards

slide-11
SLIDE 11

SPILL & LEAK DELINIATION & REMEDICATION WORKGROUP OBJECTIVES

  • Develop a rule to replace guidelines
  • Establish delineation protocals for leaks

& spills

  • Establish characterization values
  • Develop timelines for compliance

OCD is in the early stages of identifying workgroup participants

NMOCD IPANM Presentation 8-3-16

slide-12
SLIDE 12

200 180 160 140 120 100 80 60 40 20 6/1/2014 9/29/2014 1/27/2015 5/27/2015

Date

9/24/2015 1/22/2016 5/21/2016

Monthly Reported Releases Statewide

NMOCD IPANM Presentation Leak & Spill Data Recent Data Indicates Spills/Leaks Occurring at a Rate of 4.4 Per Day

slide-13
SLIDE 13

FOCUSED ENFORCEMENT EFFORTS

  • Inactive wells: Rule 19.15.5.9
  • 2,331 Non-compliant wells
  • Letters have been sent to 150 operators

currently out of compliance

  • OCD is requesting operators submit a

plan to bring wells into compliance

  • Enforcement action may be taken

against non-responsive operators

NMOCD IPANM Presentation 8-3-16

slide-14
SLIDE 14

FOCUSED ENFORCEMENT EFFORTS

  • Financial Assurance: Rule 19.15.8.9
  • OCD audit revealed that 151 operators

were in violation of FA

  • OCD has sent out 124 letters to operators
  • Industry response has been outstanding
  • Additional FA in the amount of $472K has

been furnished to OCD by industry as a result of this program

NMOCD IPANM Presentation 8-3-16

slide-15
SLIDE 15

FOCUSED ENFORCEMENT EFFORTS

  • Administrative & Hearing Orders
  • Many administrative & hearing orders

issued by OCD contain certain requirements necessary for approval

  • Issue: Non-compliance with provisions

contained within OCD orders

  • OCD will track order for compliance
  • OCD will send letters to operators for non-

compliance

NMOCD IPANM Presentation 8-3-16

slide-16
SLIDE 16

FOCUSED ENFORCEMENT EFFORTS

  • Illegal dumping of oil field waste
  • OCD & New Mexico Junior College

working to educate industry, public, law enforcement agencies, & district attorneys on issue of illegal dumping of produced water & oilfield waste

  • OCD is establishing relationships with

law enforcement & district attorneys to criminally prosecute cases

NMOCD IPANM Presentation 8-3-16

slide-17
SLIDE 17

UPCOMING ISSUES

  • Delaware Formation Injection (Over

Pressured & Injection into Potentially Productive Horizons)

  • Horizontal Well Rule Revision
  • Streamline Regulations
  • Drilling Activity Across State Lines
  • OCD Proposed Legislation

OCD IPANM Presentation 8-3-16

slide-18
SLIDE 18

David Catanach

Director, NMOCD Energy, Minerals and Natural Resources Department David.Catanach@state.nm.us (505) 476-3468 OCD Website: http://www.emnrd.state.nm.us/ocd OCD Well Information and Operator Data: https://wwwapps.emnrd.state.nm.us/ocd/ocdpermitting/Data/Wells.aspx
