Cryogenic Instrumentation & Slow Controls (CISC)

Overview & Status

Sowjanya Gollapinni (UTK)

CISC Scope Review Meeting CERN, June 19, 2019

CISC Primary goals

• DUNE CPV and other physics goals require at least a decade of running the

FD during which time we don’t have access to the interior of the cryostat

• Environmental conditions that present risks to the detector must be detected

and reported quickly and reliably during this time

• Each element of CISC contributes to the DUNE physics program

primarily through the maintenance of high detector live time

• CISC provides comprehensive monitoring for all detector elements, and

for LAr quality and behavior (can be used to constrain detection efficiency and fiducial volume), and a control system for many of the detector components

• ….plus many special cases

2

3

(from Glenn; format modified)

Physics Connections

CISC Scope

(Single-Phase)

• Joint consortium for SP and DP
• This talk only focusing on “CI” in CISC
• General strategy: For all systems, design

validation and testing at ProtoDUNE-I (ongoing) and ProtoDUNE-II (anticipated)

LBNF scope

4

Pressure Meters (GAr; LBNF)

CISC Organization

• G. Horton-Smith
• C. Palomares
• S. Gollapinni, A. Cervera
• C. Lane
• A. Habig
• S. Gollapinni
• H. Liao,
• P. Fernandez
• J. Maricic, J. Bian
• M. Dolinski,
• A. Hahn,

(D. Montanari for LBNF)

• A. Habig, J. Haigh
• C. Mariani
• G. Horton-Smith, F. Blaszczyk

5

Spain (2), UK (2) and USA (15)

6

CISC Organization

Spain (2), UK (2) and USA (15)

7

CISC Organization

• Continuing contract with SDSU to perform fluid

flow simulations needed for the consortium for ProtoDUNE and FD, for both SP and DP

• Became a member of the consortium recently to

better integrate into CISC activities

• In communication with Erik Voirin for

confirmations/verifications on simulations

CFD Simulations

CISC Scope (SP Vs DP)

SP DP

Note: DP not as advanced as SP — final configuration and some design aspects need more work

8

Pressure Meters (GAr; LBNF) Pressure Meters (GAr; LBNF)

CISC (SP Vs DP)

• Longer drift length in DP (12 m); much higher electric potential than SP
• Space along long sides is larger than SP, but less along the short sides
• The cryostat and the cryogenics design is the same as SP — good thing!
• GAr instrumentation to understand behavior of LEM mechanical structure
• Many things yet to be finalized, e.g.
• A nominal port map with final standard assignments is not yet available
• Not all detector element designs are finalized — hard to understand mechanical

clashes and other installation interfaces

• Disclaimer: Given the above, we had to make some assumptions (e.g. port

locations) for DP which needs to be confirmed later once more information is available.

9

TDR Status

• TDR progress on track,

meeting all deadlines!

• Both SP and DP drafts

currently under LBNC review, submitted on May 3

• Costing and interface

documents going through final review TDR draft SP DP 1st draft 30-Nov-18 5-April-19 2nd draft 11-Jan-19 1-May-19 LBNC-1 25-Jan-19 3-May-19 LBNC-review-1 28-Feb-19 N/A 3rd draft 15-April-19 N/A Collaboration Internal review 3-May-19 3-May-19 LBNC-2 3-May-19 TBD LBNC-review-2 TBD TBD

10

Note: The CISC scope and plans presented today follow what we have in the TDR currently plus some additional studies to further motivate the systems

Purity Monitors

• Purity Monitors (in cryostat) — not replaceable
• Quick, but localized, purity measurement
• Used to constrain fluid flow simulations
• Measure purity stratification (if any)
• Primary use for operations (e.g. monitor LAr filling) and data quality checks
• Can raise alarms about cryogenics systems
• can aid calibration and recirculation studies by benchmarking some purity values
• most useful during commissioning & early data taking — not required to survive the

lifetime of the experiment but would be great if they did!

• Purity Monitors (inline) — replaceable
• Immediate alarms about cryogenics systems (gas analyzers also provide alarms for

this)

• Can be replaced and thus can be maintained for the lifetime of the experiment

11

Purity Monitors @ ProtoDUNE

• Purity Monitors are deployed in both PD-SP and PD-DP
• Currently, PD-SP and PD-DP are using slightly different designs and

distribution:

• Cryostat: PD-SP uses 3 monitors/string and a gold photocathode; Inline: 0
• Cryostat: PD-DP uses 2 monitors/string and gold & silver photocathodes; Inline: 0
• PD-SP validated the design and currently performing data analysis

ProtoDUNE-SP

12

ProtoDUNE-SP

Includes statistical errors (see backup)

Purity Monitors @ FD

13

PrM PrM

Use opposite set of human access ports

• Use the same design as PD-SP; Total 8 monitors (6 in cryostat and 2 inline)
• The exact locations of deployment and suitable ports is yet to be finalized for cryostat monitors
• One PrM string on east and one on west — provides two reference points in the cryostat and each vertical

string with monitors at different heights enables addressing any stratification issues

• Need dedicated ports for straight deployment — No ports currently assigned for this, so human access

ports are the current option

• Inline monitors located before and after LAr filling
• Some improvements planned such as longer drift purity monitors to increase the range of measured lifetime

values, improved light source etc. — The PD-SP-II and PD-DP-II runs post-LS2 will provide opportunities to test improved designs.

Charge Questions: Purity Monitors

14

Detailed talk by Jianming Bian in the dedicated Purity Monitors talk in the afternoon

Temperature Monitors

• High precision 3D temperature map of the cryostat is useful to understand the behavior of
• LAr recirculation
• Purity prediction far from PrMs, using CFD simulations validated with temperature

measurements

• Cryostat membrane behavior in cold
• All of which impact physics (electron lifetime, drift velocity and thus FV etc.)
• Extrapolate from ProtoDUNE-SP. Three types of devices — each has a specific purpose
• Static T-Gradient Monitor: Vertical array with laboratory calibration
• Dynamic T-Gradient Monitor: Vertical array with in-situ calibration
• Individual sensors (roof, wall, floor, ullage): Coarser horizontal 2D array with varying

precision

15

Purpose of various Thermometers

(Slide from A. Cervera)

16

Thermometry @ ProtoDUNE-SP

(From Anselmo)

ProtoDUNE-SP Detector

17

Validation @ ProtoDUNE-SP

Static T-gradient system Several calibration methods being deployed (laboratory Vs pump on/off) 2-3 mK relative precision achieved Comparison to CFD has reasonable agreement, more work ongoing to better understand boundary conditions e.g. pressure, heat load etc.

18

Update with most up-to- date plots from ACV

(From Anselmo)

19

Baseline Thermometer distribution @ FD-SP

Maximum sensor configuration, probably not all needed (see alternative configuration in backup)

To-do: update with the less-busy version from Anselmo

Baseline Thermometer distribution: FD-SP Vs FD-DP

20

Distribution yet to be finalized, expect might need fewer thermometers in the end

FD-DP FD-SP

*Dynamic T-gradient thermometers not shown in DP — yet to be understood

To-do: for the top one, update with the less-busy version from Anselmo

Thermometer arrays in GAr in DP

• Temperature in gas phase (b/n liquid surface and CRP) is important to monitor in

DP as it effects LEM gain calibration — Static T-gradient profilers in LAr can be used for this

• Also, as in PD-DP

, the region above the CRP (about 40 cm) will be instrumented to understand the behavior of mechanical structure — 20 arrays with 8 sensors/array (with increasing pitch)

• Unlike LAr, the temperature variation

in GAr is rapid w.r.t. height so 0.1K relative precision is sufficient

21

ProtoDUNE-DP

Thermometry Validation @ ProtoDUNE

• For FD-SP, Static and Dynamic T-Gradient profilers are being validated at

PD-DP

• From Filippo, 03/07/19, talk
• n PD-DP instrumentation
• For FD-DP, there are no

T-Gradient profilers deployed in LAr in PD-DP, so needs to be validated in post-LS2 PD-DP-II run

22

Charge Questions: Thermometers

23

Detailed talk by A. Cervera and J. Maricic

• n various types of Thermometers

Cameras

Two types of cameras

• Cold cameras (fixed)
• permanently deployed in the cryostat
• primary usage during filling
• Inspection/warm cameras (movable)
• replaceable over the lifetime of the experiment
• Main purposes: Monitor HV systems, inspect

detector components

24

ProtoDUNE-SP

• PD-SP:
• 11 cameras deployed
• 3 designs (2 cold, 1 warm)
• PD-DP
• 11 cold cameras will be tested in the

current run

• Design closely follows the vacuum tight

PD-SP camera design from Bo ProtoDUNE-DP

Cameras@ProtoDUNE

• All ProtoDUNE cameras gave useful views
• Performance criteria being established
• Keeping good focus is a performance issue
• For warm cameras, longevity is another important

aspect, depends on replaceability, will need R&D

25

Acrylic Vacuum tight

PD-SP inspection (warm) camera in acrylic tube before installation

Cameras@FD

• Current plan: 3 warm and 12 cold cameras
• Exact locations/ports yet to be finalized
• Longevity is an important feature for the FD for warm cameras

26

One key specification Full Coverage with 12 cold cameras in the FD

(8 in corners 4 in long edge centers)

Charge Questions: Cameras

27

Detailed talk by G. Horton-Smith in the dedicated Cameras talk in the afternoon

Pressure Meters

• Measuring pressure in GAr is important for DP as it effects gas density and

therefore the LEM gain calibration

• Also, the absolute temperature in the liquid varies with the pressure in GAr, so

this provides a better picture of temperature gradients and CFD simulations

• Measurement accuracy: within at least

0.1% needed

• Standard industrial pressure sensors

can be used

• Pressure meters @ ProtoDUNE:
• We will follow the same model as

ProtoDUNE SP/DP: two pressure sensors and a pressure switch are installed in a dedicated flange (see the image on the right)

28

ProtoDUNE

Pressure Meters @ FD

• For the FD, the plan is to double the ProtoDUNE system for redundancy — two

flanges with pressure meters on opposite sides of the cryostat

• Pressure meters cost pretty minimal: M&S <$2k per unit (based on ProtoDUNE)
• Requirements from TDR:
• LBNF will also have (comparatively lower precision) absolute/relative

pressure sensors — provides redundancy, independent measurements and cross checks.

29

Level Meters

• Main goals:
• Monitor cryostat filling
• Precise level sensing during stable operations
• Provide information for safety interlocks (e.g. HV)
• Alignment of detector elements with liquid

(The level meters are complemented by vertical thermometer arrays and cameras)

30

Level Meter Type (Scope) Precision Primary Purpose Comment Differential Level Meters (LBNF) 14 mm During LAr filling PD-SP/DP use the same design which will be used in the FD Capacitive Level Meters (CISC) < 5 mm Finer tuning of LAr; safety interlocking; cross-check with LBNF level meters High-Precision Capacitive Level Meters (CRP) < 1 mm For sub-mm control of LAr surface Level meters attached to the inner membrane of the cryostat High-Precision Capacitive Level Meters (CRP) < 1 mm For controlling CRP alignment with liquid

Level Meters — overview

31

Level Meter Type (Scope) Precision Primary Purpose Comment Differential Level Meters (LBNF) 14 mm During LAr filling PD-SP/DP use the same design which will be used in the FD Capacitive Level Meters (CISC) < 5 mm Finer tuning of LAr; safety interlocking; cross-check with LBNF level meters High-Precision Capacitive Level Meters (CRP) < 1 mm For sub-mm control of LAr surface Level meters attached to the inner membrane of the cryostat High-Precision Capacitive Level Meters (CRP) < 1 mm For controlling CRP alignment with liquid

• PD-SP and PD-DP use different designs
• PD-SP: 1m long, commercially bought meters
• PD-DP: 4m long, custom-built by CERN
• For the FD-SP and FD-DP,
• we will use the PD-DP design as baseline
• The PD-DP-I run will validate the system

Level meters cost is very minimal: M&S <$1500/unit

(based on PD-DP)

CISC Sub-system summary

(from ProtoDUNE to DUNE)

Sub-system

Quantity (ProtoDUNE-SP) Quantity (ProtoDUNE-DP)

Quantity (FD-SP) Quantity (FD-DP) Baseline design Purity Monitors 3 (cryostat) 0 (inline) 2 (cryostat) 0 (inline) 6 (cryostat) 2 (inline) 6 (cryostat) 2 (inline) PD-SP Static Profilers 2 6 6 PD-SP Dynamic Profilers 1 2 (ideal) 1 (minimal) 2 (ideal) 1 (minimal) PD-SP Individual Sensors 38 Ask Filippo? 175 (max.) 127 (min.) 148 (max.) ?? (min.) PD-SP GAr Temp. Arrays Ask Filippo? 20 arrays (8 sensors/ array) PD-DP Capacitive Level Meters 1 (1m long; commercial) 1 (4 m long; custom built) 2 2 PD-DP Pressure Meters 3 3 6 6 PD-SP & PD-DP Cold Cameras 8 (2 designs) 11 (1 design) 12 12 PD-SP & PD-DP Warm Cameras 3 (1 design) 3 3 PD-SP & PD-DP

32

Summary: ProtoDUNE Validation

Sub-system PD-SP-I PD-DP-I PD-SP-II PD-DP-II Purity Monitors

✔ ✔ * ✔

Static Profilers

✔ ✔ * ✔

Dynamic Profilers

✔ ✔ * ✔

GAr Temp. arrays

✔ ✔

Level Meters

✔ ✔

Pressure Meters

✔ ✔

Gas analyzers

✔ ✔

Cameras

✔ ✔ ✔ * ✔ *

33

* = improved designs

Backup

34

35

Purity Monitors (backup)

36

Purity Monitors (backup)

Purity Monitor Requirements

37

Add table from TDR and highlight top-level requirements

Static T-gradient Monitor Design @ FD-SP

(From Anselmo) 38

Faraday cage for high fields in DP

Conceptual design stage — under development

39

Example shown: Static T-gradient Thermometer system

Dynamic T-gradient Monitor Design @ FD-SP

(From Jelena) 40

Thermometer distribution @ FD-SP (alternative configuration)

41

Thermometry Requirements

42

Add table from TDR and highlight top-level requirements

CISC Interfaces

Only showing SP here. For DP , we have CRP and DP-PDS in addition to what is listed here

43

CISC Risks

(only listing Medium-level risks post-mitigation)

44

Key CISC Milestones (SP)

45

Key CISC Milestones (DP)

46

Costing Summary

• Add a summary cost table (per unit and total for FD-SP) in

case of questions

47
