Craver Road Study

UNC Charlotte February 24, 2010

Project Description

• Student Union opened August, 2009
• Vehicle/Pedestrian conflicts in front of

Student Union due to excessive pedestrian volumes

– Safety issues for pedestrians – Traffic flow issues for vehicles along Craver Road

Student Union Crossing

Student Union Crossing

Student Union Crossing

Student Union Crossing

Project Description

• Two Analysis Scenarios

– Short term solution: installation of traffic/pedestrian signal at Student Union crossing

• How will a signal work at this crossing? For

vehicles? For pedestrians?

– Long term solution: closure of Craver Road to non-essential through traffic

• How can closure be implemented? What effects

will closure of Craver Road have on the rest of campus?

Study Area

STUDENT UNION

1 2 3 4 5

N

Data Collection

• Three Peak Periods

– 7:00 AM – 9:00 AM – 10:00 AM – 1:00 PM – 4:00 PM – 6:00 PM

• Traffic Counts at 5 study intersections
• Pedestrian Counts at Student Union
• Video Data
• Wednesday November 18th, 2009

Traffic Analysis Procedure

UNSIGNALIZED INTERSECTION SIGNALIZED INTERSECTION LEVEL OF SERVICE AVERAGE CONTROL DELAY PER VEHICLE (SECONDS) LEVEL OF SERVICE AVERAGE CONTROL DELAY PER VEHICLE (SECONDS)

A B C D E F 0-10 10-15 15-25 25-35 35-50 >50 A B C D E F 0-10 10-20 20-35 35-55 55-80 >80 Highway Capacity Manual - Levels of Service and Delay

• Synchro 7
• SimTraffic
• Sidra Intersection 3.2
• Based on HCM Methodology

Existing Traffic Volumes

Volume Adjustments – Craver Road Closure

• Service Vehicles [Counted]
• Drop-off Traffic [30% of Remaining Trips]
• Source/Sink Traffic [10% - West End of

Craver Rd., 30% East End]

• Diverted Trips

– Video data – pseudo origin-destination study to attempt to determine travel patterns

Existing Traffic Volumes With Closure

Future Campus Growth

• Future analysis year of 2015
• In referring to Master Plan and anticipated

campus growth, a compound annual growth rate of 3% was used

Future Traffic Volumes With Closure

LOCATION

A P P R O A C H

LANE CONFIG. WEEKDAY PEAK HOUR LEVEL OF SERVICE AM Mid-Day PM

Approach Overall Approach Overall Approach Overall Cameron Boulevard and Phillips Road EB NB SB

1 LT-RT 1 LT-TH 1 TH-RT C1 A2

• N/A

C1 A2

• N/A

D1 A2

• N/A

Cameron Boulevard and Phillips Road (Signalized) EB NB SB

1 LT-RT 1 LT-TH 1 TH-RT A A A A A A A A B B A A

Cameron Boulevard and Craver Road WB NB SB

1 LT-RT 1 TH-RT 1 LT-TH C1

• A2

N/A C1

• A2

N/A D1

• A2

N/A

Craver Road and Student Union Crossing (Signalized)* EB WB NB/SB

1 TH 1 TH [PEDS] A A A A A A A A A A A A

Mary Alexander Road and Craver Road EB NB SB

1 LT-RT 1 LT-TH 1 TH-RT B1 A2

• N/A

B1 A2

• N/A

B1 A2

• N/A

Mary Alexander Road and Cameron Boulevard EB WB NB SB

1 LT-TH-RT 1 LT-TH-RT 1 LT-TH-RT 1 LT-TH-RT B B A C B B C B C C D C C C C

• Existing (2009)

Conditions

• Synchro Capacity

Analysis Results

• Student Union Signal

analysis completed using Sidra Intersection 3.2

Capacity Analysis

• Existing (2009)

Conditions With Craver Road Closure

• Synchro Capacity

Analysis Results

Capacity Analysis

LOCATION A P P R O A C H LANE CONFIG.

WEEKDAY PEAK HOUR LEVEL OF SERVICE AM Mid-Day PM

Approach Overall Approach Overall Approach Overall

Cameron Boulevard and Phillips Road EB NB SB 1 LT-RT 1 LT-TH 1 TH-RT C1 A2

• N/A

C1 A2

• N/A

E1 A2

• N/A

Cameron Boulevard and Craver Road WB NB SB 1 LT-RT 1 TH-RT 1 LT-TH C1

• A2

N/A

B1

• A2

N/A

C1

• A2

N/A

Mary Alexander Road and Craver Road EB NB SB 1 LT-RT 1 LT-TH 1 TH-RT B1 A2

• N/A

B1 A2

• N/A

B1 A2

• N/A

Mary Alexander Road and Cameron Boulevard EB WB NB SB 1 LT-TH-RT 1 LT-TH-RT 1 LT-TH-RT 1 LT-TH-RT B B B C

C

C C C D

C

F C C C

E

• Existing (2009)

Conditions With Craver Road Closure

• Synchro Capacity

Analysis Results

• Roundbout analysis

completed using Sidra Intersection 3.2

Capacity Analysis

LOCATION

A P P R O A C H

LANE CONFIG. WEEKDAY PEAK HOUR LEVEL OF SERVICE AM Mid-Day PM

Approach Overall Approach Overall Approach Overall

Cameron Boulevard and Phillips Road / Craver Road (Signalized) EB WB NB SB 1 LT-TH-RT 1 LT-TH-RT 1 LT, 1 TH-RT 1 LT, 1 TH-RT A B A A A B B A B B B B B B B Mary Alexander Road and Craver Road EB NB SB 1 LT-RT 1 LT-TH 1 TH-RT B1 A2

• N/A

B1 A2

• N/A

B1 A2

• N/A

Mary Alexander Road and Cameron Boulevard (Unsignalized) EB WB NB SB 1 LT-TH-RT 1 LT-TH-RT 1 LT-TH-RT 1 LT-TH-RT B B B E D E F D F F F E D E F Mary Alexander Road and Cameron Boulevard (Signalized) EB WB NB SB 1 LT, 1 TH-RT 1 LT-TH-RT 1 LT-TH-RT 1 LT-TH, 1 RT A B A A A A B B A B B A C A B Mary Alexander Road and Cameron Boulevard (Roundabout)* EB WB NB SB 1 LT-TH-RT 1 LT-TH-RT 1 LT-TH-RT 1 LT-TH-RT A A B B B B B B B B B B B A B

Recommendations

• Cameron Boulevard and Phillips Road /

Craver Road

– Signal at existing Phillips Road intersection expected to work well and increase safety – Future signal at proposed re-alignment of Phillips Road with Craver Road expected to work well

• Northbound and southbound left turn lanes

recommended on Cameron Boulevard

Recommendations

• Craver Road Improvements

– Signalization of Student Union Crossing expected to work well

• Low cycle length
• Pedestrians as main line

– Craver Road Closure concept drawing

• Provides closure with access for University

vehicles

• Would fit within current infrastructure
• Pedestrian friendly
• Construction cost estimate - $780,000

Craver Road – Roundabout Concept

Craver Road – Roundabout Concept

Craver Road – Roundabout 2

Craver Road – Roundabout Concept

Craver Road – Roundabout 2

Recommendations

• Cameron Boulevard and Mary Alexander

Road

– Long delays/queues as expected with Craver Road Closure as unsignalized intersection – Roundabout and Signalization both adequate solutions – Roundabout concept drawing

• Provides adequate capacity
• Would fit within current infrastructure
• Attractive entrance to campus
• Construction cost estimate - $340,000

Craver Road – Roundabout Concept

Questions/Discussion?
