Rural Road Study Presentation to AMSA Randall Trites ROHI Engineering Ltd. Rural Road Study 2 Rating Criteria (Paved Roads) Deformation Edge Break Rutting Flushing/Bleeding Rural Road Study 3 Field Assessment Sheets(Paved Roads)
SLIDE 2
SLIDE 3
Rural Road Study 3
Rating Criteria (Paved Roads)
Deformation Rutting Edge Break Flushing/Bleeding
SLIDE 4
Rural Road Study 4
Field Assessment Sheets(Paved Roads)
SLIDE 5
Rural Road Study 5
Field Assessment Sheets(Paved Roads)
SLIDE 6
Rural Road Study 6
Rating Criteria (Gravel Roads)
Brushing Surface Condition Presence of Water/Ponding Ditches Gravel Condition
SLIDE 7
Rural Road Study 7
Field Assessment Sheets(Gravel Roads)
SLIDE 8
Rural Road Study 8
Field Assessment Sheets(Gravel Roads)
SLIDE 9
Rural Road Study 9
Field Assessment Sheets(Sketch Sheet and Intersections)
SLIDE 10
Rural Road Study 10
Field Assessment Sheets(Motorgrader/Patrol Operators)
SLIDE 11
Rural Road Study 11
Field Assessment Sheets(Motorgrader/Patrol Operators)
SLIDE 12
Rural Road Study 12
Relative Importance of Assessment Criteria(Paved Roads)
Sealed/Paved Road Weightings Factor (%) Deformation 14 Rutting 10 Binder Age 14 Edge Break 10 Edge Drop 6 Flushing 10 Stripping 14 Cracking 12 Patching 10
TOTAL 100
SLIDE 13
Rural Road Study 13
Relative Importance of Assessment Criteria(Gravel Roads)
Unsealed/Gravel Road Weightings Factor (%) Surface Condition 10 Gravel Surface Shape 10 Gravel Condition 10 Fill Section 10 Ditch Depth 5 Ditch Width 3 Ditch Slope 2 Windrows (Lips) 5 Rideability 10 Drainage Performance - Ponding 7 Drainage Performance - Wetlands 3 Brushing 5 Motor Grader/ Patrol Operator Input 20
TOTAL 100
SLIDE 14
Rural Road Study 14
Influencing Factors
- Traffic Growth
- Capacity
- Safety
- Heavy Vehicle Percentage
- Future Mobility Needs as Identified in MDP/Planning Division
- Economic Development/Recreational Needs
- Connectivity to Provincial Highway System
- Future Roadway Classification
- Significance factor
- Any other factors
SLIDE 15
Rural Road Study 15
Influencing Factors
- Traffic Growth 1.5
- Capacity 1.6
- Safety 1.0 for now but increase when sufficient data available
- Heavy Vehicle Percentage 1.6
- Future Mobility Needs as Identified in MDP/Planning Division 1.4
- Economic Development/Recreational Needs 1.6
- Connectivity to Provincial Highway System 1.4
- Future Roadway Classification 1.4
- Significance factor 0.5
- Any other factors as required
SLIDE 16
Rural Road Study 16
Classification
SLIDE 17
Rural Road Study 17
SLIDE 18
Rural Road Study 18
SLIDE 19
Rural Road Study 19
Database
- In Access(Microsoft) Format – for ROHI purposes
- Based on weighting criteria and influencing factors the
correct roads seem to be coming to the top.
- Once migration to county database is complete more
stability and functionality can be added
SLIDE 20
Rural Road Study 20
Next Steps
- Migrate to County GIS Data Base
- Integrate intersection data
- Develop data entry/revision functions to facilitate
database up-keep
- County’s Road Assets to be summarized
