Issued: 27th March 2017 Company Presentation 2017 Aerospace | Defence | Energy | Industrial | Marine | Motorsport Group Structure DIPLOMA PLC The parent company Diploma PLC owns a portfolio of businesses supplying specialised

slide-1
SLIDE 1

Company Presentation 2017

Aerospace | Defence | Energy | Industrial | Marine | Motorsport Issued: 27th March 2017

slide-2
SLIDE 2

The parent company Diploma PLC owns a portfolio of businesses supplying specialised technical products and services, who operate globally in three sectors: LIFE SCIENCES • SEALS • CONTROLS Total FY16 Revenue £382.6m +15% on year The IS-Group part of the business supply specialised wiring, connectors and components used in a range of technically demanding applications. IS-Group turnover £44.7m and ~170 employees over the four locations.

DIPLOMA PLC Group Structure

Indianapolis Swindon and Weston-Super-Mare Stuttgart

slide-3
SLIDE 3

IS-Group, Swindon

IS-Group and IS-Rayfast headquarters are based in Swindon, just ofg the M4. £9m+ inventory value across all locations

  • 33,000 sq ft Warehouse, Swindon
  • ~£5.25m Stock Value
  • ~2400 product lines
  • ~70 employees
slide-4
SLIDE 4

Mission

“To be the Supplier of Choice for Electrical Harnessing Components and Associated Products”

Wire and Cable Tubing Products Harness Components Connectors Earthing Products Electro- Mechanical Additional Products Assemblies

slide-5
SLIDE 5

Aerospace

Key Markets

Defence Industrial Marine Motorsport Energy

slide-6
SLIDE 6

Products Overview

Components Heat Shrink Boots and Transitions Identifjcation Connectors Backshells Multicore Cable Braided Sleeve Lacing Tapes and Cable Ties Splices Terminals and Contacts Wire ASSOCIATED PRODUCTS

  • Bonding leads
  • Relays and contactors
  • Switches and grips
  • Tapes and adhesives
  • Application equipment

Heat Shrink Tubing

slide-7
SLIDE 7

Products #1

Wire and Cable Tubing

Heat-Shrink Tubing

  • Single wall and dual wall, many of

which are AMS-DTL-23053 approved

  • Flexible
  • Fluids and chemicals resistant
  • LFH and Zero Halogen
  • ATUM
  • DR-25
  • HTAT
  • RNF-100 and RNF 3000
  • RW-175E and RW-200 E
  • ZH-150 zero halogen up to 150ºC
  • ZHT zero halogen colours

Non-Shrink Tubing

  • Neoprene
  • Silicone
  • PTFE
  • PVC

Equipment and Airframe

  • Spec 44, 55, 99 and 100 wire
  • BS 3G210 and Nema HP3
  • M22759, M27500 and M81044
  • EN2266, EN2267, EN2713, EN274...
  • BMS 13-48 and BMS 13-60

High Speed Data

  • Ethernet, Cat 5e, 6a and 7
  • Quadrax and USB
  • Databus MIL-1553, CanBus

Coaxial

  • MIL-C-17 as applicable
  • 50Ω RF, GPS, TCAS & 75Ω HD Video
  • Ku and X Band assemblies

Power Cable and Multicore Cable

  • Marine Def Stan 61-12
  • Custom designed

Braided Sleeving

Mechanical Protection

  • Roundit 2000 FR, V0, NX, etc
  • Expando 686 DM, HTNS, Peek, etc

Electrical Insulation

  • GES 40, 100 and Ben-Har 1151

Thermal and Fire Insulation

  • Textalu 1202 and Thermotubix

Aerospace Electromagnetic Shielding

  • Raybraid and HBT99 tubular metal

screening braids, ofgering up to 99%

  • ptical coverage
  • Wraparound ‘Roundit’ screening braid
slide-8
SLIDE 8

Products #2

Moulded Parts

Heat Shrinkable Boots

  • Micro boots
  • Lightweight ‘InstaLite’ boots
  • Uncoated or adhesive lined

Transitions

  • ‘Y’, ‘T’ and multi-branched

Materials

  • Fluids and chemicals resistant
  • LFH and Zero Halogen
  • High temperature

Glands and Feedthroughs

  • KTKK, TCFS/TCFR, CES etc

Wire to wire splicing

  • CWT, B-155, D-1744
  • D-406 and D-436
  • RoHS compliant

Terminals and Disconnects

  • B-106, SGRT

Shield Termination

  • RoHS compliant
  • SAE-AS83519 approved
  • M83519 qualifjed
  • NAS 1747 approved

Coaxial Cable Termination

  • RoHS compliant.
  • CWT, B-155, D-607, B-046, etc

Shielded Contacts

  • D600 series for MIL-DTL

Terminals and Splices Connectors & Backshells

Connectors

  • MIL-DTL-38999 Series III and EN3645
  • MIL-DTL-26482 Series II
  • MIL-DTL-83723 Series I and II
  • ARINC 809, BACC65, EN4165
  • Deutsch 369 and DMC-M series
  • DT Series family from Deutsch

Backshells

  • Screened and unscreened
  • Braided tail, Tinel-Lock, Band-Strap,

Constant-Force Spring etc...

  • Dust caps and accessories
slide-9
SLIDE 9

Products #3

Earthing Products

Bonding leads

  • Round, Rope, Flat, High Flex etc...
  • EN4199 standards for aerospace and

defence applications

  • Airbus ASNE0088 to 0092, Typhoon,

PAN6619, LN9264, CSP48 and AGS2097

  • Custom build

Metal braids

  • Power shunts
  • Flat and round braids, plus custom

Cable Ties

  • Nylon, Tefzel, Stainless Steel etc
  • Mil ref MS3367*
  • Cable tie mounts etc
  • Harness clips, mounts etc

Protective Edging

  • Spring-Fast M22529/2
  • GEPR, Rayrim and TPEM

Lacing Tapes / Over-braiding Yarn

  • CID-A-A-5208* (MIL-T-4345)
  • Nylon MIL-T-713
  • Nomex MIL-C-572

Cable Management Wire / Cable Markers

Heat Shrinkable and Tie On

  • Commercial grade and military grade
  • Fluid (Diesel) resistant, D-SCE
  • LFH and Zero Halogen, HX-SCE and

ZHD-SCE Adhesive Labels

  • Self laminating polyester and PVF
  • Continuous polyester and metallised
  • Tamper evident

Hardware and Software

  • T200, TE3112 thermal printers etc
  • WinTotal software
  • Thermal transfer ribbon and printer

accessories

slide-10
SLIDE 10

Products #4

Swaged Products such as

  • Latch release cables
  • Wire rope & lanyard assemblies

Assemblies

  • Fly and tail leads

Over-Braiding custom services

  • Cables, conduits, hoses, armouring,

screening etc... If you have a need please ask

Assemblies Additional Products

Adhesives and Tapes

  • Including performance epoxy and

sealant tape solutions from TE Connectivity

  • High temperature epoxy and ceramic

solutions (up to 3000ºC) from Cotronics Application Equipment

  • To help install the products we can

supply, from heat guns to crimp tools Relays and Contacts

  • Miniature M39016*
  • Crystal Can M39016*, M5757
  • Mid range M8353, M6106
  • Time delay M83726 and others
  • High Voltage M6106 and others
  • High Current EV100, EV200, CAP etc...
  • Commercial EN61373 and EN50155

Switches and Grips

  • Mil Spec QPL’d
  • Toggles, Pushbutton, Rocker, Slide,

Joysticks and Grips

  • Hall Efgect
  • Custom build options

Electro-Mechanical

slide-11
SLIDE 11

Key Supplier Partners

slide-12
SLIDE 12

Dedicated Customer Service

Key Account Managers - 10 strong experienced team for site visits, covering UK and EMEA. Technical Support - 3 dedicated technical support specialists, available by telephone, email and shortly via online chat. Internal Sales Team - 16 office based personnel for your enquiries, orders and sales support.

slide-13
SLIDE 13

Added Value Services

  • Cut piece tubing and sleeving
  • Wire and cable spooling
  • Pre-print services for heat shrinkable

wire and cable markers, tie on markers and adhesive labels

  • Kitting solutions

Cutting, Spooling & Pre-Print Logistics

  • Offjce hours 08:00 to 17:30
  • UK Next Day Delivery, stocked items
  • 98%+ OTD
  • Flexible MOQ’s
  • Component Kitting
  • KanBan + Consignment Stock
  • Component Sampling

Supply Chain Solutions

  • IS-Group satellite warehouse facilities in

Germany and USA

  • Long term agreements
  • Bufger stock.
  • Call ofg and scheduled delivery options.
  • Lead time reduction
  • Vendor reduction, reducing overall

costs.

slide-14
SLIDE 14

IMPROVED Website Coming Soon

Users will be able to easily search products based on a number of difgerent technical attributes and compare similar products and stock holding.

www.is-rayfast.com

Q u i c k Q u e s t i

  • n

? A S K U S

i

Chat Online

slide-15
SLIDE 15

We are fully committed to complying with the latest quality approvals for the customers and markets that we serve, including...

Quality Management System EN 9120:2010 ISO 9001:2008 EN 9104-001:2013

Airbus Helicopters | BAE Systems | Bombardier | GKN Aerospace | Leonardo | RS Components | Farnell | Safran | Thales | Ultra Electronics | Zodiac Aerospace

Issued Part of the ZODIAC AEROSPACE GROUP David Bayliss Director of Business Improvement For and on behalf of Zodiac Interconnect UK Limited First Approval Date: 05/03/2008 (This document will remain the property of Zodiac Interconnect UK and must be surrendered upon request) ZODIAC INTERCONNECT UK LIMITED 220 BEDFORD AVENUE SLOUGH SL1 4RY Company: IS RAYFAST LTD Address: 2 Lydiard Fields

SHIP TO STOCK APPROVAL CERTIFICATE

Approval No: 086/R011 This is to certify that: -

,

By:

SWINDON Wiltshire SN5 8UB

Having completed assessment, are approved to supply the materials, products and services detailed below SCOPE:

UK

Stockholding and Supply of: Heat shrinkable tubing, marker sleeves & cable ties from quality assured sources with lot traceability. Approval is given subject to contjnued compliance with requirements and conditjons of approval as issued and in force at any tjme

Quality / Customer Approvals

Certificate of Registration

Q U A L I T Y M A N A G E M E N T S Y S T E M This is to certify that: I S
  • R
a y f a s t L t d 2 L y d i a r d F i e l d s S w i n d
  • n
S N 5 8 U B U n i t e d K i n g d
  • m
Holds Certificate Number: R S 4 1 1 and operates a Quality Management System which complies with the requirements of EN 9120:2010 (technically equivalent to AS9120A) and ISO 9001:2008 and is assessed in accordance with EN 9104-001:2013 for the following scope: The stockholding and supply of high performance interconnect, electromechanical, fasteners and associated products from quality assured sources. Additional services such as kitting, printing, pre-scoring and cutting are provided. For and on behalf of BSI: Frank Lee, EMEA Compliance & Risk Director Original Registration Date: 01/08/1988 Issue Date: 23/01/2016 Reissue Date: 23/01/2016 Expiry Date: 14/09/2018 Page: 1 of 1 This certificate was issued electronically and remains the property of BSI and is bound by the conditions of contract. An electronic certificate can be authenticated online. Printed copies can be validated at www.bsigroup.com/ClientDirectory Information and Contact: BSI, Kitemark Court, Davy Avenue, Knowlhill, Milton Keynes MK5 8PP. Tel: + 44 845 080 9000 BSI Assurance UK Limited, registered in England under number 7805321 at 389 Chiswick High Road, London W4 4AL, UK. A Member of the BSI Group of Companies.
slide-16
SLIDE 16

THANK YOU ANY QUESTIONS?

www.is-rayfast.com | sales@is-rayfast.com | +44 (0)1793 616700 | +33 (0)1 75 90 92 42
