ALIMERV TEAM ZOG PROCTOR MEMBERS POPINARA MORRIS VINCENT SCHNEPS SCANCARELLO ARCH 2330 | Building Technology III FINAL TEAM V-MAZ BUILDING Fall 2016 PRESENTATION Prof. Paul King PROJECT SELECTION & ANALYSIS PROJECT SELECTION


slide-1
SLIDE 1

FINAL TEAM V-MAZ BUILDING PRESENTATION TEAM MEMBERS

ZOG POPINARA

MORRIS SCHNEPS ALIMERV PROCTOR

VINCENT SCANCARELLO

ARCH 2330 | Building Technology III Fall 2016

  • Prof. Paul King
slide-2
SLIDE 2

PROJECT SELECTION & ANALYSIS

ZP

PROJECT SELECTION & ANALYSIS

slide-3
SLIDE 3

PROJECT SELECTION & ANALYSIS

ZP

The structural grid is not shown but you get a clear understanding how everything is aligned, however for the selections highlighted in the figure to the right, one cannot know for sure if those are columns or if they act as mullions. Note that the area shaded in red should contain a expansion joint because that certain area of the building extends to the higher floors while other areas do not. This becomes more clear in the floor plans and sections.

slide-4
SLIDE 4

PROJECT SELECTION & ANALYSIS

ZP

Floor to floor are about 12 feet which are perfect for a design but can cause problems when thinking about a split level as you see here highlighted in red. The area highlighted in yellow shows the vertical circulation. Its important to note that you do have the right amount of egress stairs but they are not enclosed properly. Also vertical and horizontal mechanical shafts are not included in section drawings, however they exist in the floor plan. (Locker room floor)

slide-5
SLIDE 5

PROJECT SELECTION & ANALYSIS

ZP

Problems with Egress Stairs.

  • 1. Stairs are not enclosed properly.
  • 2. Door directions are all wrong except in

the first floor plan where they lead you out

  • f the building.
  • 3. There are no doors leading you out of the

building in the bottom stair therefor , its not considered an egress if you cant exit out of the stairs (CASE).

  • 4. Some stairs lead directly to rooms/office

space.

  • 5. Stairs do not contain doors wherever you

see a red question mark.

  • 6. Not clear if area highlighted in green is

an elevator or a vertical shaft.

slide-6
SLIDE 6

PROJECT SELECTION & ANALYSIS

ZP

Problems with Circulation In the floor plan you can see the pool is located in the first floor as soon as you enter. That can be a problem for the circulation and also for design purpose. Would someone want to go to the locker room floor , change then come back up to swim. Pool is also too small according to code, an Olympic sized swimming pool should contain minimum dimensions of

slide-7
SLIDE 7

STRUCTURAL PROPOSAL

ZP

Spans between grid line A-B and 1-2 are 8’, to show the cantilevered split level. B-C span 32’ C-D span 36’ (for pool and skylight, also nothing supported above) D-E span 28’. 2-3 spans 18’ and the rest of the grid lines all span 20’.

slide-8
SLIDE 8

STRUCTURAL PROPOSAL

ZP

Typical Floor Plan contains a central courtyard you can look down in the pool. Its missing a garden which is now moved

  • n the roof of the first floor.

Also you can see the placing of the Rockwall climbing has changed to help circulation through and around.

slide-9
SLIDE 9

STRUCTURAL PROPOSAL

ZP

Basement to first floor = 12’ 1st floor to second floor= 14’ 2nd Floor to 3rd Floor= 16’ 2.5-3.5 = 14’ 3rd Floor to 4th Floor= 14’

slide-10
SLIDE 10

STRUCTURAL PROPOSAL

MS The basement has a double height area for the pool, therefore columns must be placed on the perimeter.

slide-11
SLIDE 11

STRUCTURAL PROPOSAL

MS Basement to 1st floor = 12’ 1st floor to 2nd floor= 12’ 2nd Floor to 3rd Floor= 12’ 2.5-3.5 = 12’ 3rd Floor to 4th Floor= 12’

slide-12
SLIDE 12

STRUCTURAL PROPOSAL

VS A to B = 8’ 1” B to C = 32’ 0” C to D = 32’ 0” D to E = 24’ 6” E to F = 7’ 6” 1 to 2 = 8’ 0” 2 to 3 = 12’ 0” 3 to 4 = 20’ 0” 4 to 5 = 20’ 0” 5 to 6 = 20’ 0” 6 to 7 = 20’ 0”

slide-13
SLIDE 13

STRUCTURAL PROPOSAL

VS Floor to Floor Heights Basement – First = 12’ 0” First – Second = 14’ 0” Second – Third = 14’ 0” Third – Fourth = 14’ 0” Fourth – Roof = 14’ 0” Roof – Parapet = 4’ 0”

slide-14
SLIDE 14

STRUCTURAL PROPOSAL

AP

slide-15
SLIDE 15

MECHANICAL PROPOSAL

MS Lighting Fixtures Air Return Air Supply Sprinklers

slide-16
SLIDE 16

MECHANICAL PROPOSAL

VS

Reflected Ceiling Plan Including..

  • 24” x 24” Acoustic Hung Ceiling Tiles
  • 24” x 24” Air Supply Vents
  • 24” x 24” Air Return Vents
  • 24” x 24” Lights
  • Sprinklers
slide-17
SLIDE 17

ZP

MECHANICAL PROPOSAL

slide-18
SLIDE 18

EGRESS PROPOSAL

Show a typical floor plan and a section from your Revit drawings. The section should be cut where it will clearly shows the vertical stairs. You may require more than one. If your team has all used the same solution then you only need to show one slide, that can be shared by the team. If different team members proposed different solutions then each team member shows their own slide. Floor plan: Highlight (use color-yellow) the location of the stairs and elevators and the egress corridors. Indicate (use color-red) 1 hour rated corridors &the 2 hour rated stair

  • enclosures. Be certain that all doors open in the direction of egress.

Section: Highlight (use color-yellow) the stairs. Indicate the horizontal routes and vertical routes for egress.

Credit Initials

slide-19
SLIDE 19

EGRESS PROPOSAL

MS First Floor Level Plan Level 1 to 2.5 Section Basement to Level 4 Section

slide-20
SLIDE 20

EGRESS PROPOSAL

VS First Floor Plan Stair Section Elevator Section

slide-21
SLIDE 21

COMPOSITE MATERIALS PROPOSAL

VS North East West South

slide-22
SLIDE 22

INDIVIDUAL DETAILS PRESENTATION

ARCH 2330 | Building Technology III Fall 2016

  • Prof. Paul King

MORRIS SCHNEPS

slide-23
SLIDE 23

MS

CURTAIN WALL DETAIL

slide-24
SLIDE 24

MS

STRUCTURE

slide-25
SLIDE 25

MS

WATER PROOFING

slide-26
SLIDE 26

MS

FIRE STOPPING

slide-27
SLIDE 27

MS

THERMAL

slide-28
SLIDE 28

MS

COMPOSITE

slide-29
SLIDE 29

INDIVIDUAL DETAILS PRESENTATION

ARCH 2330 | Building Technology III Fall 2016

  • Prof. Paul King

ZOG POPINARA

slide-30
SLIDE 30

ZP

FAÇADE DEVELOPMENT AND DETAILS

slide-31
SLIDE 31

ZP

FAÇADE DEVELOPMENT AND DETAILS

slide-32
SLIDE 32

INDIVIDUAL DETAILS PRESENTATION

ARCH 2330 | Building Technology III Fall 2016

  • Prof. Paul King

VINCENT SCANCARELLO

slide-33
SLIDE 33

CURTAIN WALL DETAILS

VS Materials Shown

slide-34
SLIDE 34

EXTERIOR WALL DETAILS

VS Materials Shown

slide-35
SLIDE 35

FIRST FLOOR PLAN

VS
