Adaptive FPGA-based Database Accelerators – Achievements, Possibilities, and Challenges

Daniel Ziener and Jürgen Teich

Database Acceleration – Overview

Daniel Ziener | 07.03.2017 | Dagstuhl | FPGA-based Database Accelerators – Achievments, Possibilities, and Challenges 2

Idea: Translate each SQL query into an FPGA-based accelerator circuit through run-time assembly

• f dynamically reconfigurable hardware modules

SELECT Price, Volume FROM Trades WHERE Symbol=“UBSN“ INTO UBSTrades a: Symbol = USBN WHERE a SELECT Price, Vol.

Trades UBSTrades

W

=

S

a Trades UBSTrades FPGA DynSoC Hardware Module Library SQL query

Database Acceleration – Architecture

Daniel Ziener | 07.03.2017 | Dagstuhl | FPGA-based Database Accelerators – Achievments, Possibilities, and Challenges 3

FPGA Host I N O U T Reconfigurable Area I N O U T Reconfigurable Area

• Reconf. Manager

Library > < A N D SELECT * FROM table WHERE age > 20 > SELECT * FROM table WHERE salary > 10000 AND year < 1990 PCIe

A N D

> < Data > > < A N D

Database Acceleration – Overview Module Library

• Each partial area consists of 16 slots

Daniel Ziener | 07.03.2017 | Dagstuhl | FPGA-based Database Accelerators – Achievments, Possibilities, and Challenges 4

Module Operator Coverage Number of Slots Throughput Restriction Arithmetic (+,-, ) Comparators (<,>,=,≠) Bitwise functions (AND, OR, NOT, XOR, ...) 2 1 Sample/Cycle Aggregation SUM(), MIN(), MAX(), COUNT() 2 1 Sample/Cycle Reorder Reorder Attributes of a tuple 4 1 Sample/Cycle Join Hash and Merge Join

• 1 Sample/Cycle

Sort line for sorting 2 KB (64 KB) data 16 1 Sample/Cycle Sort tree merges sorted block

• 1 Sample/Cycle
• Each reconfigurable area consists of 16 slots
• 4 reconfigurable areas available on our prototype

Database Acceleration – Lessons Learned

• High processing throughput achievable
• Pipelined modules have a throughput of 2 GByte/s per reconfigurable

area (125 MHz x 16 Bytes)

• The throughput is independent of the number of concatenated modules
• I/O turns out to define the bottleneck
• PCIe Gen2 x4: 1.7 GByte/s
• Only one interface to feed all reconfigurable areas
• Flexibility is the key feature
• For each query different decisions can be taken at run-time
• All processing alternatives can be executed on the same static system

Daniel Ziener | 07.03.2017 | Dagstuhl | FPGA-based Database Accelerators – Achievments, Possibilities, and Challenges 5

Hash Join Merge Join Row- based Column- based

New Architecture: 12.8 GByte/s and 64 Bytes per Clock Cycle New Architecture: DDR3 Memory: 12.8 GByte/s

Database Acceleration – New High-Performance Architecture

Daniel Ziener | 07.03.2017 | Dagstuhl | FPGA-based Database Accelerators – Achievments, Possibilities, and Challenges 6

FPGA Reconfigurable Area Incoming queries > Database Tables =

B L O O M

Align- ment Unit Host Hash Join + Aggr. Conf. Manager time Query analysis + filter configuration Data processing Data processing Data processing Data processing FPGA Host

Database Acceleration – Results (FPT’15)

• Comparing Energy/Power consumption of an Intel Core i7 with our

approach based on an embedded Xilinx Zynq-SoC

• Analysis of example query based on the TPC-DS benchmark (1 GB

scale), including restrictions, aggregations, and joins

Daniel Ziener | 07.03.2017 | Dagstuhl | FPGA-based Database Accelerators – Achievments, Possibilities, and Challenges 7

Accl@ Zynq ARM – MySQL Intel i7 – MySQL Execution time 44.2 ms 6900 ms 420 ms Overall energy 190 mJ 1.47 J 5.33 J Improvment texe 156 9.5 Improvment Energ. 7.72 27.97

Database Acceleration – Results (FPT’15)

• Comparing Energy/Power consumption of an Intel Core i7 with our

approach based on an embedded Xilinx Zynq-SoC

• Analysis of example query based on the TPC-DS benchmark (1 GB

scale), including restrictions, aggregations, and joins

Daniel Ziener | 07.03.2017 | Dagstuhl | FPGA-based Database Accelerators – Achievments, Possibilities, and Challenges 8

Accl@ Zynq ARM – MySQL Intel i7 – MySQL Execution time 44.2 ms 6900 ms 420 ms Overall energy 190 mJ 1.47 J 5.33 J Improvment texe 156 9.5 Improvment Energ. 7.72 27.97 More Information: [1] D. Ziener, F. Bauer, A. Becher, C. Dennl, K. Meyer-Wegener, U. Schürfeld,

• J. Teich, J. Vogt and H. Weber. FPGA-Based Dynamically

Reconfigurable SQL Query Processing. ACM Transactions on Reconfigurable Technology and Systems (TRETS), vol. 9, no. 4, Article 25, July 2016. [2] A. Becher, D. Ziener, K. Meyer-Wegener and J. Teich. A Co-Design Approach for Accelerated SQL Query Processing via FPGA-based Data Filtering. In Proceedings of 2015 International Conference on Field-Programmable Technology (FPT '15), Queenstown, New Zealand, December 7--9, 2015.

Current Database Management Systems

• Database management systems are multi-user systems
• Different queries with different complexity have to be processed on

different data at the same time

• Response time is very important
• Bunch of different operations
• Query processing
• Sorting
• Data analytics
• Data update
• Changing load scenarios over time
• E.g., day: query processing; night: data analytics

9 Daniel Ziener | 07.03.2017 | Dagstuhl | FPGA-based Database Accelerators – Achievments, Possibilities, and Challenges

HW Accelerators for Big Data Applications

• Current software solutions
• Multi-Core server systems with many nodes
• On each core, data processing is done with data or time slices
• Advantages:

OS support (task switching, mapping onto processing places) Easy to extend with new operators or analytic functions

10 Daniel Ziener | 07.03.2017 | Dagstuhl | FPGA-based Database Accelerators – Achievments, Possibilities, and Challenges

Question: How can we achieve such a flexibility for HW-based accelerators?

Library > < & Host FPGA

PCIe/ CAPI SATA

SSDs

• Ext. Memory
