slide-1
SLIDE 1

Intralogistics with Safe and Scalable Fleets of Autonomously Operating Vehicles in Shared Spaces

Where the Intermediate is the Big Step

Achim J. Lilienthal contact:

www.mrolab.eu/achim-lilienthal achim.lilienthal@oru.se

slide-2
SLIDE 2

Intralogistics with Safe and Scalable Fleets of Autonomously Operating Vehicles in Shared Spaces

Where the Intermediate is the Big Step

Intra- Logistics with Integrated Automatic Deployment

www.iliad-project.eu

H2020 project funded by the EC Start: Jan 2017 Duration: 48 months Funding: 7M€ Partners: 9

slide-3
SLIDE 3

Intralogistics with Safe and Scalable Fleets of Autonomously Operating Vehicles in Shared Spaces

Where the Intermediate is the Big Step

Intra- Logistics with Integrated Automatic Deployment

H2020 project funded by the EC Start: Jan 2017 Duration: 48 months Funding: 7M€ Partners: 9

www.iliad-project.eu

slide-4
SLIDE 4

ILIAD in a nutshell

Why the intermediate is the big step

slide-5
SLIDE 5

Concept image

More quickly changing market needs, unforeseeable trends, shorter product life cycles, …

slide-6
SLIDE 6

Flexible intralogistics needed

  • Today’s highly automated goods-to-man solutions
  • require dedicated warehouses,
  • are unsuitable for fresh food, bulky goods, etc.
  • ILIAD’s aim is to provide solutions for flexible intralogistics for the transition to

automation in shared spaces.

slide-7
SLIDE 7

Therefore we need intralogistic systems that are F-RE-SE–QUD–SA-EFF! (1) highly flexible, (2) rock-solid reliable, (3) self-optimising, (4) quickly deployable and (5) safe yet (6) efficient in environments shared with humans.

Flexible intralogistics needed

slide-8
SLIDE 8

Approach

Safety and efficiency by long-term learning and prediction of patterns Easy deployment with semantic mapping On-line, self-optimising fleet management Flexible manipulation Human safety-aware AGV fleets: safe and legible motion planning, human detection and tracking, mutual communication of intent

slide-9
SLIDE 9

Platform (CitiTruck)

Early prototype (APPLE platform at Hannover fair 2015)

slide-10
SLIDE 10

Demonstrators

slide-11
SLIDE 11

Demonstrators

  • Demos at key stakeholders from food distribution sector.
  • Distribution of fresh food products particularly

challenging:

  • sensitive products,
  • short shelf life,
  • rapid response to consumer needs.
  • Food industry largest manufacturing sector in EU:

4.2 million jobs.

slide-12
SLIDE 12

Orkla Foods

Not always well-defined aisle environment Heterogeneous and brittle (and sometimes large or heavy) items to pick.

slide-13
SLIDE 13

NCFM

  • National Centre for Food Manufacturing
slide-14
SLIDE 14

ASDA

Photo credit: Redirack Photo credit: Adrian Welsh

slide-15
SLIDE 15

Easy deployment, long-term operation

Learning, modelling and exploiting flow information

slide-16
SLIDE 16

Learn, model and use dynamics

  • Learn and map how things usually move.
  • Statistical multi-modal flow model.
  • Use for socially compliant motion planning:

less "annoying", safer and more efficient operation.

slide-17
SLIDE 17

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.

FP7 EU project SPENCER http://www.spencer.eu/

slide-18
SLIDE 18

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Using this information can
  • lead to safer and socially more acceptable robot trajectories;
  • allow to plan energy efficient paths for flying robots;
  • improve gas distribution mapping.
slide-19
SLIDE 19

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Statistical multi-modal flow model CLiFF map

(Circular–Linear Flow Field map) – A probabilistic approach for general flow mapping

Enabling Flow Awareness for Mobile Robots in Partially Observable Environments.

  • T. P. Kucner, M. Magnusson, E. Schaffernicht, V. Hernandez Bennetts, and A. J. Lilienthal.

RA-L 2017 (2:2, pp. 1093-1100) / ICRA 2017

slide-20
SLIDE 20

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Statistical multi-modal flow model CLiFF map
  • Local elements are probability distributions of observations V = (θ, ρ)
  • One circular (orientation θ) and one linear (speed ρ) random variable.
slide-21
SLIDE 21

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Statistical multi-modal flow model CLiFF map
  • Local elements are probability distributions of observations (θ, ρ)
  • One circular (orientation θ) and one linear (speed ρ) random variable.
  • Semi-wrapped Gaussian mixtures

Learning CLiFF maps

  • Init: Mean Shift (MS) to determine number of clusters and their positions
  • Use MS clusters to initialize Expectation Maximisation (EM)
slide-22
SLIDE 22

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Statistical multi-modal flow model CLiFF map
  • Local elements are probability distributions of observations (θ, ρ)
  • One circular (orientation θ) and one linear (speed ρ) random variable.
  • Field of semi-wrapped Gaussian mixtures
slide-23
SLIDE 23

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Statistical multi-modal flow model CLiFF map
  • Local elements are probability distributions of observations (θ, ρ)
  • One circular (orientation θ) and one linear (speed ρ) random variable.
  • Field of semi-wrapped Gaussian mixtures
slide-24
SLIDE 24

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Statistical multi-modal flow model CLiFF map
  • Local elements are probability distributions of observations (θ, ρ)
  • One circular (orientation θ) and one linear (speed ρ) random variable.
  • Field of semi-wrapped Gaussian mixtures
slide-25
SLIDE 25

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Statistical multi-modal flow model CLiFF map
  • Field of semi-wrapped Gaussian mixtures
  • Observations in robotics are often sparse

?

slide-26
SLIDE 26

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Statistical multi-modal flow model CLiFF map
  • Field of semi-wrapped Gaussian mixtures
  • Observations in robotics are often sparse

?

slide-27
SLIDE 27

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Statistical multi-modal flow model CLiFF map
  • Field of semi-wrapped Gaussian mixtures
  • Observations in robotics are often sparse
  • => Data imputation to build dense maps from sparse measurements
  • Monte Carlo Imputation (MC)
  • sampling virtual observations from the surrounding
  • tends to preserve multimodal characteristics and keep sharp transitions
  • Nadaraya Watson Imputation (NW)
  • Weighted extrapolation (distance kernel)
  • smooths data and models introduces gradual changes
  • MC performed better than NW on pedestrian data (and is less sensitive to

kernel size) – but results may differ in different applications

slide-28
SLIDE 28

Learn and model dynamics

  • Learn and map how things usually move.
  • Extensive research on mapping geometric structure.
  • Environment typically defined by spatial movement patterns.
  • Statistical multi-modal flow model CLiFF map
  • Field of semi-wrapped Gaussian mixtures
  • Observations in robotics are often sparse
  • => Data imputation to build dense maps from sparse measurements
  • Summary
  • It is possible to accurately represent multimodal (even turbulent) flow

using CLiFF map.

  • It is possible to reconstruct a dense representation based on

sparsely distributed observations.

slide-29
SLIDE 29

Using dynamics models

  • Use for socially compliant motion planning:

less "annoying", safer and more efficient operation.

Kinodynamic Motion Planning on Gaussian Mixture Fields.

  • L. Palmieri, T. Kucner, M. Magnusson, A. J. Lilienthal, and K. O. Arras

ICRA 2017

slide-30
SLIDE 30

Using dynamics models

  • Socially compliant motion planning using CLiFF map
  • Mobile robot motion planning approach: CLiFF-RRT*
  • CLiFF map – provides learned perception prior
  • RRT* motion planner
  • asymptotically optimal sampling-based motion planner
  • considers the robot's kinematic and its non-holonomic constraints

Kinodynamic Motion Planning on Gaussian Mixture Fields.

  • L. Palmieri, T. Kucner, M. Magnusson, A. J. Lilienthal, and K. O. Arras

ICRA 2017

slide-31
SLIDE 31

Using dynamics models

  • Socially compliant motion planning using CLiFF map
  • Mobile robot motion planning approach: CLiFF-RRT*
  • CLiFF map – provides learned perception prior
  • RRT* motion planner
  • => CLiFF map guides sampling in the RRT* planner
  • low costs for paths that comply to the directions of CLiFF-map mixture

components and high costs for paths in opposite directions

slide-32
SLIDE 32

Using dynamics models

  • Socially compliant motion planning using CLiFF map
  • Mobile robot motion planning approach: CLiFF-RRT*
  • CLiFF map – provides learned perception prior
  • RRT* motion planner
  • => CLiFF map guides sampling in the RRT* planner
  • Results are very encouraging
  • Planner generates reasonable ("socially compliant") trajectories
slide-33
SLIDE 33

Using dynamics models

  • Socially compliant motion planning using CLiFF map
  • Mobile robot motion planning approach: CLiFF-RRT*
  • CLiFF map – provides learned perception prior
  • RRT* motion planner
  • => CLiFF map guides sampling in the RRT* planner
  • Results are very encouraging
  • Planner generates reasonable ("socially compliant") trajectories
  • Planner is very efficient (significantly faster than RRT and RRT*) /

very fast convergence

  • Generates higher quality paths (in terms of smoothness and length)

RRT* path CLiFF-RRT* path

slide-34
SLIDE 34

Easy deployment, long-term operation

Ongoing work

slide-35
SLIDE 35

Spatiotemporal mapping

  • Representations and inference for compression of past

experience and prediction of future states with confidence intervals.

  • Learn where and when activities happen.

FreMEn (Krajnik et al., ECMR 2015)

slide-36
SLIDE 36

Predicting patterns

  • Combine inputs from mapping and tracking.
  • Actively update knowledge – plan where and when to

collect data.

FreMEn (Krajnik et al., ECMR 2015)

slide-37
SLIDE 37

Reliability-aware loc. & maps

  • Combining metrics to assess quality of scan registration.
  • Detect mapping errors using learned structural cues.
slide-38
SLIDE 38

Auto-calibration

  • Unsupervised monitoring and (re-)calibration of sensors.
  • Find regions with high information for calibration.

6 DOF – x,y,z,roll,pitch,yaw Optimized timing offset 7 DOF – x,y,z,roll,pitch,yaw,dt

slide-39
SLIDE 39

Safe and human-aware

  • peration

Ongoing work

slide-40
SLIDE 40

Human safety

  • Study human safety in shared environments.
  • Connect injury biomechanics to safe control and

planning.

  • Associate vehicle dynamics to injury safety database.
  • Extend Safe Motion Unit paradigm to vehicle-human and

vehicle-vehicle interaction.

  • Shape vehicle velocity based on
  • humans and vehicles in the environment,
  • environment observability,
  • predictive braking models.
slide-41
SLIDE 41

Human-aware fleets

  • Increase human-robot cooperation safety & efficiency.
  • Detect, track, and analyse people.
slide-42
SLIDE 42

Human-aware fleets

  • Increase human-robot cooperation safety & efficiency.
  • D

etect, track, and analyse people.

slide-43
SLIDE 43

Human-aware fleets

  • Increase human-robot cooperation safety & efficiency.
  • Detect, track, and analyse people.
slide-44
SLIDE 44

Human-aware fleets

  • Increase human-robot cooperation safety & efficiency.
  • Detect, track, and analyse people.
  • => Retenua AB
slide-45
SLIDE 45

Human-aware fleets

  • Increase human-robot cooperation safety & efficiency.
  • Detect, track, and analyse people.
  • Recognise human intentions.
  • Visually communicate robot intentions.
  • Socially normative motion planning.
slide-46
SLIDE 46

Manipulation

Ongoing work

slide-47
SLIDE 47

Manipulation

  • Innovative end-effectors.
  • Perception for dense packets, and plastic wrapping.
  • Control for unwrapping, picking, palletising.
  • Optimise package positions on pallets.
slide-48
SLIDE 48

Fleet management

Ongoing work

slide-49
SLIDE 49

Fleet management

  • Integrated task allocation, motion planning, and coordination.
  • Guaranteed deadlock-free operation.
  • Continuously revise w.r.t. changing requirements.
slide-50
SLIDE 50

Intralogistics with Safe and Scalable Fleets of Autonomously Operating Vehicles in Shared Spaces

Where the Intermediate is the Big Step

Intra- Logistics with Integrated Automatic Deployment

Thanks for your attention!

slide-51
SLIDE 51

Intralogistics with Safe and Scalable Fleets of Autonomously Operating Vehicles in Shared Spaces

Where the Intermediate is the Big Step

Intra- Logistics with Integrated Automatic Deployment

www.iliad-project.eu

H2020 project funded by the EC Start: Jan 2017 Duration: 48 months Funding: 7M€ Partners: 9

This project has received funding from the European Union’s Horizon 2020 research and innovation programme under grant agreement No 732737.

Thanks for your attention!

slide-52
SLIDE 52

Intralogistics with Safe and Scalable Fleets of Autonomously Operating Vehicles in Shared Spaces

Where the Intermediate is the Big Step

Achim J. Lilienthal contact:

www.mrolab.eu/achim-lilienthal achim.lilienthal@oru.se
