Welcome to CENG! What is Computer Engineering Computer Engineering - - PowerPoint PPT Presentation

0.1

Welcome to CENG!

http://blog.tmcnet.com/blog/rich-tehrani/uploads/facebook-datacenter-electrical-large.jpg http://www.cmu.edu/news/image-archive/Boss.jpg http://prisonerofclass-5933.zippykid.netdna-cdn.com/wp-content/uploads/2013/05/iphone.jpg http://firstcallappliance.com/wp-content/uploads/image/microwave.jpg http://www.engadget.com/2011/02/19/intel-to-spend-5-billion-on-new-14nm-fab-in-arizona-creating-4/ https://www.staples-3p.com/s7/is/image/Staples/s0978329_sc7?$splssku$ http://www.spacex.com/sites/spacex/files/spacex_default.jpg

0.2

What is Computer Engineering

• Computer Engineering is…

– Developing efficient systems that combine hardware, software, and networking to interact with the physical world and/or solve information-based problems – Learning how to design, analyze, implement, and test such systems

Goal of CECS/CENG: To develop engineers who can span the complex inter-relationship of computer hardware and software, creating and designing system solutions

0.3

Today's Digital Environment

Voltage / Currents Transistors / Circuits Digital Logic Processor / Memory / GPU / FPGAs Assembly / Machine Code OS / Libraries C++ / Java / Python Algorithms Voltage / Currents Transistors / Circuits Digital Logic Processor / Memory / GPU / FPGAs Assembly / Machine Code OS / Libraries C++ / Java / Python Algorithms Networks Applications 0.4

Computer Engineering as Abstraction Levels

SW

Controlling Input (Gate ) Output (Drain ) Source

F x y z

+

B A S if (x > 0) then x = x + y - z; a = b*x; Transistors Logic AND gate Functional Units Chips (Processors) Software Code

• -
• -
• - -

1110010101…

Voltage / Currents Transistors / Circuits Digital Logic Processor / Memory / GPU / FPGAs / Networks Assembly / Machine Code OS / Libraries C++ / Java / Python Algorithms Networks Applications

HW

0.5

You Can Do That With Computer Engineering

SW

Voltage / Currents Transistors / Circuits Digital Logic Processor / Memory / GPU / FPGAs / Networks Assembly / Machine Code OS / Libraries C++ / Java / Python Algorithms Networks Applications

HW

Devices & Integrated Circuits (Semiconductors & Fabrication) Architecture (Processors & Embedded HW) Systems & Networking (Embedded Systems, IoT, Networks) Applications (AI, Robotics, Graphics, Mobile) Cloud & Distributed Computing (CyberPhysical, Databases, Data Mining, Machine Learning, etc.)

0.6

Goals of this Course

SW

Voltage / Currents Transistors / Circuits Digital Logic Processor / Memory / GPU / FPGAs / Networks Assembly / Machine Code OS / Libraries C++ / Java / Python Algorithms Networks Applications

HW

• Embedded Systems
• Programming

– C language

• Digital logic

– Hardware design

• Computer Performance

– Understanding and improving performance of systems

• Electronics

– Voltage, current, basic circuit theory

Embedded

0.7

Full Timeout - Syllabus

0.8

Course Advice

• Catch the wave!

– Start early and lay a good foundation in the first few weeks (even on the "easy" stuff) – Don’t let shame or embarrassment keep you from the help you need

• Put in the time

– Achieving mastery takes ______ hours?1

• Play!

– Be active, curious, and engaged

• Don't let "class" get in the way of learning

– Do not be afraid to just try, even if you fail

• Failure breeds far more learning than success

1 From Malcolm Gladwell's Outliers

0.9

CECS Curriculum

EE 457 EE 454 EE 477 CS 170 CS 270 CS 350 CS 310 CS 360 CS 420 CS 445 EE 459 CS 477 Core Concepts

(Programming Languages, Data Structures, Digital Logic Design)

Operating Systems Software Engineering Algorithms, Theory, Cryptography Graphics AI Robotics Integrated Circuits EE 479 Computer Architecture CS 353 Networks & Web Programming EE 354 CS 103 CS 104 CS 201 EE 109 EE 250 EE 451 CS 476 0.10

EE Curriculum

EE/CS 109 EE 354 Core Classes Computer Engineering Electrical Sciences EE 155 EE 250 EE 301 EE 364 EE 202 EE 330

Programming Embedded Systems IoT Linear Systems Probability and Statistics Linear Circuits Electromagnetics

EE 457 EE 454 EE 451 EE 450 CS 445 CS 360 CS 350 EE 459 EE 477

Digital System Design Operating Systems Networks Computer Architecture

• Intro. To System-
• n-Chip
• Intro. To VLSI

Parallel & Distributed Computing Robotics AI Capstone

Circuits, Signals, and Systems Area Electives EE 355

Software Design

0.11

Careers

• Information Technology
• General & High Performance Computing
• Mobile and Networking
• Media & Entertainment
• Automotive
• Robotics
• Aerospace / Defense

0.12

Careers

… and presidents of USC. Our last two presidents, Steven Sample and Max Nikias were both Electrical Engineers.

0.13

Companies

• Information Technology
• Semiconductor & General

computing

• Telecomm and Networking
• Media & Entertainment
• Automotive
• Robotics
• Aerospace
• Startups
• Facebook, Apple, Google, MS
• Intel, IBM
• Qualcomm, Cisco
• EA, Disney, Riot Games
• Ford, Uber, etc.
• JPL, iRobot
• SpaceX, Boeing, Raytheon
• Embark (now Apple), Zboard

2 of the top 10 fastest-growing job markets will be Computer Science and System (CENG) Engineers

* U.S. Department of Labor 0.14

Research/Extracurriculars at USC

• Autonomous Networks Research Group

– Wireless & mobile networks, embedded sensing and processing

• Information Sciences Institute

– AI, Internet, Advanced Processing Systems research

• Institute for Creative Technologies

– Virtual Reality, Graphics, Animation, Games

• Student Orgs

– Makers (http://viterbimakers.usc.edu/) – HackSC, AthenaHacks, SparkSC – IEEE, ACM

0.15

EMBEDDED SYSTEMS

0.16

Digital System Spectrum

• Key idea: Any “algorithm” can be implemented in HW or

SW or some mixture of both

• A digital systems can be located anywhere in a spectrum
• f:

– ALL HW: (a.k.a. Application-Specific IC’s) – ALL SW: An embedded computer system

• Advantages of application specific HW

– Faster, less power

• Advantages of an embedded computer system (i.e.

general purpose HW for executing SW)

– Reprogrammable (i.e. make a mistake, fix it) – Less expensive than a dedicated hardware system (single computer system can be used for multiple designs)

• One of the main points for the whole course:

– Applications and processing can be done in software, custom-designed HW, or some mixture of both – Each one has pros/cons – We will give you the knowledge for how it can be done in both

Computing System Spectrum

Application Specific Hardware (no software) General Purpose HW w/ Software Flexibility, Design Time Performance Cost http://www.xbitlabs.com/images/news/2008-06/nvda_tegra_chip_scheme.jpg

0.17

Processing Logic Approaches

• Custom Hardware

– Logic that directly implements a specific task – Example above may use separate adders and a multiplier unit

• General Purpose (GP)

Processor

– Logic designed to execute SW instructions – Provides basic processing resources that are reused by each instruction

• What if I want to perform:

– X*Y + A*B – What's easiest to redesign?

+ *

Data storage Instruc. Store

ADD X,Y ADD A,B MUL X,A GP Proc. Implementation

• f (X+Y)*(A+B)

+ + *

X Y A B Out Custom HW Implementation

0.18

Embedded Systems

• An embedded system is…

– A special purpose computer that is designed into a larger device to perform some amount of dedicated tasks

• Utilize a microcontroller…

– Laptops or desktops contain a microprocessor – Embedded systems contain microcontrollers – What's the difference?

• Microprocessor is part of a larger computer system w/ RAM and

general purpose I/O

• Microcontroller is a single-chip with RAM and I/O to control

specific electro/mechanical devices

0.19

A Comparison

• Different microprocessor and microcontroller

based systems

PC (Core i7) iPhone (A6 chip) MIPS32 (PIC32MX…) Arduino (ATMega328) Clock speed 3 GHz 1.3 GHz 80 MHz < 20 MHz Data size 64-bits 32-bit 32-bits 8-bits RAM 8 GB 1 GB 16 KB 2 KB Storage 1 TB 32 GB 128 KB 32 KB Cost $1,000 $650 $6.04 $2.88

0.20

Engineering Design

Engineering is Design with Constraints

0.21

Engineering Design

Artist: “We’ll create a spaceship powered by a warp drive.” Engineer: “We need to build a rocket engine that works.” Artists and engineers both design things, but differently.

0.22

What constraints does an engineer face when designing something?

Engineering Design

0.23

What constraints does an engineer face when designing something?

Engineering Design

Cost Performance Reliability Durability Ease of use Weight Power Size Safety Environmental Political Testability

0.24

The constraints may differ depending

• n the product.

Engineering Design

Toy: Cost > Reliability Medical implant device: Reliability > Cost

0.25

APPLICATIONS & TOPICS

Examples we'll learn about throughout the semester

0.26

Decoders

• Decoders are digital circuits that help identify 1-of-N options.
• You might find one in a vending machine and many other

devices.

1 2 3 4 5 6 7 8 9

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 4-to-16 decoder A[3:0] 0 1 2 3 … 15

0.27

Multiplexers

• Multiplexers ("muxes" for short) are digital circuits that help

select one data source and direct traffic in a digital system

• You will find them everywhere in digital systems, for example,

in network routers.

0.28

Controllers and State Machines

• State machines implemented in HW or SW help control many

devices

– You will learn how to design and implement them both in HW and SW

Small Street

Turn Sensor S1 Turn Sensor S2

Overall sensor

• utput

S = S1 + S2 This Photo by Unknown Author is licensed under CC BY-NC-ND

0.29

Embedded Control

• You'll design and implement a stopwatch

with an LCD screen, buttons, etc.

• You'll learn about how to make

hardware devices display things, measure time, make sounds, etc. through our labs

0.30

Hardware Acceleration

• You'll see how hardware can be used to perform

audio, image, and video effects and why hardware is needed to accelerate many of these operations

0.62 0.625 0.63 0.635 0.64 0.645 0.65 0.655 0.66 0.665 0.67

• 0.8
• 0.6
• 0.4
• 0.2

0.2 0.4 0.6 0.62 0.625 0.63 0.635 0.64 0.645 0.65 0.655 0.66 0.665 0.67

• 0.4
• 0.3
• 0.2
• 0.1

0.1 0.2 0.3 0.4

Original signal High pitch tones removed after digital HW filtering

0.31

Computer Processor Design

• You learn about how

computer processor work and interact with memory

• You'll learn about

caching and other performance improving techniques

0.32

COMPUTER ORGANIZATION OVERVIEW

How does your computer work?

0.33

Computer Systems Tour

• How does a SW

program get mapped and executed on a computer

• What components is a

computer composed of and what are their functions

• How does the

architecture affect performance

C / C++ / Java Logic Gates Transistors

HW SW

Voltage / Currents Assembly / Machine Code Applications Libraries OS Processor / Memory / I/O Functional Units (Registers, Adders, Muxes) Start Here End Here

0.34

Software Process

1110 0010 0101 1001 0110 1011 0000 1100 0100 1101 0111 1111 1010 1100 0010 1011 0001 0110 0011 1000 MOVE.W X,D0 CMPI.W #0,D0 BLE SKIP ADD Y,D0 SUB Z,D0 SKIP MUL …

Software Program High Level Language Description Assembly (.asm/.s files) Executable Binary Image if (x > 0) x = x + y - z; a = b*x;

LA $t0,x LW $t1,0($t0) BLE $t1,$zero,SKIP LA $t0,y LW $t2,0($t0) LA $t0,z LW $t3,0($t0) ADD $t1,$t1,$t2 SUB $t1,$t1,$t3 SKIP: MUL … 1110 0010 0101 1001 0110 1011 0000 1100 0100 1101 0111 1111 1010 1100 0010 1011 0001 0110 0011 1000

.c/.cpp files

1110 0010 0101 1001 0110 1011 0000 1100 0100 1101 0111 1111 1010 1100 0010 1011 0001 0110 0011 1000

Object/Machine Code (.o files) Preprocessor / Compiler Assembler Linker Loader / OS Program Executing

A “compiler” (i.e. gcc, VisualC++, etc.) usually performs all 3 steps

0.35

Hardware Components

• Computer hardware can be

classified into three categories

– Processor

• Performs operations on data

– Memory (RAM & ROM)

• Stores data for processing
• Stores software code

(instructions)

– Input/Output Devices

• Supplies and consumes data
• Supplies the program
• Keyboard, Mouse, Monitor, Hard

Drive

• Many variations due to

different performance, cost, reliability, power factors

Processor Memory Output Devices Input Devices

Software Program Data

0.36

Processor

• Performs the same 3-step

process over and over again

– Fetch an instruction from memory – Decode the instruction

• Is it an ADD, SUB, etc.?

– Execute the instruction

• Perform the specified operation
• This process is known as the

Instruction Cycle

Processor Memory

ADD SUB CMP Arithmetic Circuitry Decode Circuitry

1

Fetch Instruction It’s an ADD Add the specified values

2 3

Wires connecting the processor and memory devices

0.37

Memory

• Set of cells that each store a

group of bits

– Usually, 1 byte (8 bits) per cell

• Unique address (number)

assigned to each cell

– Used to reference the value in that location

• Data and instructions are

both stored in memory and are always represented as a string of 1’s and 0’s

11010010 01001011 10010000 11110100 01101000 11010001 … 00001011 1 2 3 4 5 FFFF Address Data Memory Device

0.38

Memory Operations

• Memories perform 2 operations

– Read: retrieves data value in a particular location (specified using the address) – Write: changes data in a location to a new value

• To perform these operations a

set of address, data, and control wires are used to talk to the memory

– Note: A group of wires/signals is referred to as a ‘bus’ – Thus, we say that memories have an address, data, and control bus.

11010010 01001011 10010000 11110100 01101000 11010001 … 00001011 1 2 3 4 5 FFFF 11010010 01001011 10010000 11110100 01101000 00000110 … 00001011 1 2 3 4 5 FFFF 2 10010000 Read Addr. Data Control Addr. Data Control 5 00000110 Write A Write Operation A Read Operation

Processor Processor

System Bus (address, data, control wires)

0.39

Memory Types

• RAM (Random Access Memory)

– Volatile: Contents are lost on power-off – RAM usually refers to memory that can both be read and written quickly

• Flash/ROM (Read-Only Memory)

– Data values are programmed prior to shipping and cannot be rewritten by the processor – Non-volatile: Contents are retained w/o power

0.40

Input / Output

• Keyboard, Mouse, Display, USB devices, Hard Drive, Printer, etc.
• Processor can perform reads and writes on I/O devices just as it

does on memory

– I/O devices have locations that contain the processor can access – These locations are assigned unique addresses just like memory – The value in these locations is the input data or output data that will control the device

Keyboard Interface

‘a’ = 61 hex in ASCII 61 400

Processor Memory

A D C 400 61 READ … 399

0.41

Input / Output

• Writing a value to the video adapter can set a pixel on

the screen

Video Interface

FE may signify a white dot at a particular location … 800

Processor Memory

A D C 800 254 WRITE … 399 254 01

Keyboard Interface

61 400 0.42

Amazon Echo

• Let's try to put all of this into context with an

example

• Let's see what hardware is inside
• Let's think about some of the software

considerations

Many of the terms you see may not be familiar but you will learn about many of them throughout this

• course. By the end of the semester you should

have a good idea of what is going on inside! For now, focus on the categorization of processor, memory, and I/O and how they must talk to each

• ther by doing reads/writes.

0.43

Amazon Echo Hardware [1/3]

• Main Processing board

– [Red] Texas Instruments DM3725CUS100 Digital Media Processor – [Orange] Samsung K4X2G323PD-8GD8 256 MB LPDDR1 RAM – [Yellow] SanDisk SDIN7DP2-4G 4 GB iNAND Ultra Flash Memory – [Green] Qualcomm Atheros QCA6234X-AM2D Wi-Fi and Bluetooth Module – [Blue] Texas Instruments TPS65910A1 Integrated Power Management IC

https://www.ifixit.com/Teardown/Amazon+Echo+Teardown/33953

You will learn more about how the processor and memory are designed.

0.44

Amazon Echo Hardware [2/3]

• Daughterboard with much of the audio I/O devices

– [Red] Texas Instruments LP55231 Programmable 9-Output LED Driver (x4) – [Orange] Texas Instruments TLV320ADC3101 92dB SNR Low-Power Stereo ADC (x4) – [Yellow] Texas Instruments SN74LVC74A Dual Positive-Edge-Triggered D-Type Flip-Flops – [Green] S1053 0090 V6 Microphone (x7)

https://www.ifixit.com/Teardown/Amazon+Echo+Teardown/33953

In your first few labs you will build systems to control LEDs, perform A-to- D conversions (ADC), and learn about "flip-flops"

0.45

Amazon Echo Hardware [3/3]

• Power and speaker I/O board

– [Red] Texas Instruments TPS53312, likely an updated version of the TPS53311 3A Step-Down Regulator with Integrated Switcher – [Orange] Texas Instruments TLV320DAC3203 Ultra Low Power Stereo Audio Codec – [Yellow] Texas Instruments TPA3110D2 15W Filter-Free Class D Stereo Amplifier

https://www.ifixit.com/Teardown/Amazon+Echo+Teardown/33953

Not everything is digital. To produce audible sound we need to worry about voltage/current requirements.

0.46

Amazon Echo Software

• What kind of software do we need?

– Firmware: Software that won't often change and is meant to control the hardware

• Low-level software to control the various hardware

devices (speakers, microphones, etc.)

• Operating system to run and coordinate all the higher

level software apps

• Audio processing software to perform voice

recognition, etc.

– Extensible framework for higher level, networked software that may perform new user-defined skills/apps

0.47

Amazon Echo Software

• Some tasks may be

handled by the hardware/software in the Echo

– Recognition of "Alexa" voice command

• Other requests may

require more information

• r processing capability

than is locally present so it is sent over the Internet to be processed in the cloud

https://developer.amazon.com/alexa-skills-kit "Alexa" 0.48

Reminders

• Take the survey linked on our website under

the Lecture Schedule…Lecture 1

• Attend lab and bring your laptops
• Get the course reader at the book store
• Watch the pre-lecture video on Circuits before

coming to our next lecture
