Timbers Water and Sanitation District TWSD NEW SANITATION SYSTEM Public Meeting, Project Needs Assessment December 15, 2016 Timbers Water and Sanitation District Agenda Introductions Reason for Public Meeting Sanitation System

slide-1
SLIDE 1

Timbers Water and Sanitation District

TWSD NEW SANITATION SYSTEM

Public Meeting, Project Needs Assessment December 15, 2016

slide-2
SLIDE 2

Timbers Water and Sanitation District

Agenda

  • Introductions
  • Reason for Public Meeting
  • Sanitation System
  • Current Sanitation System
  • What’s wrong with the current system?
  • How do we fix it?
  • What’s it going to cost & How do we pay for it?
  • What are the next steps?
  • Questions about the sanitation system
  • Information Session
  • Fees and taxes for 2017
  • Water System Renovations/Improvements

December 15, 2016 2

slide-3
SLIDE 3

Timbers Water and Sanitation District

Agenda

  • Introductions
  • Reason for Public Meeting
  • Sanitation System
  • Current Sanitation System
  • What’s wrong with the current system?
  • How do we fix it?
  • What’s it going to cost & How do we pay for it?
  • What are the next steps?
  • Questions about the sanitation system
  • Information Session
  • Fees and taxes for 2017
  • Water System Renovations/Improvements

December 15, 2016 3

slide-4
SLIDE 4

Timbers Water and Sanitation District

Board Members and Staff

  • Board Members
  • Ronald Krall, President
  • Gary Osteen, Vice-President
  • Dusty Atkinson, Treasurer
  • Ash Lesniak
  • Brock Knez
  • Staff
  • Jodi Lightfoot, District Manager
  • Kasey O’Halloran, Assistant District Manager
  • Ellen Dalton, Administrator (outgoing)
  • Tim Gibbons, Water System Operator
  • John Fitzgerald, Sanitation System Operator
  • Consultant
  • Mary Andre, P.E., Civil Design Consultants, Inc.

December 15, 2016 4

slide-5
SLIDE 5

Timbers Water and Sanitation District

Monthly Meetings

  • Second Monday every month
  • 5:30pm start
  • Offices of Sharp, Steinke, Sherman and Engle
  • 401 Lincoln Avenue

December 15, 2016 5

slide-6
SLIDE 6

Timbers Water and Sanitation District

Website

  • www.timberswater.org
  • Notices
  • Board meetings
  • Agendas
  • Minutes
  • Governing documents

December 15, 2016 6

www.timberswater.org

slide-7
SLIDE 7

Timbers Water and Sanitation District

Agenda

  • Introductions
  • Reason for Public Meeting
  • Sanitation System
  • Current Sanitation System
  • What’s wrong with the current system?
  • How do we fix it?
  • What’s it going to cost & How do we pay for it?
  • What are the next steps?
  • Questions about the sanitation system
  • Information Session
  • Fees and taxes for 2017
  • Water System Renovations/Improvements

December 15, 2016 7

slide-8
SLIDE 8

Timbers Water and Sanitation District

Reason for Public Meeting

  • Need to replace existing sanitation system
  • New system must be approved by the Colorado

Department of Public Health and Environment (CDPHE)

  • We expect to receive state funding
  • Public Meeting is required as part of approval and funding

process

  • Board needs your input and support

December 15, 2016 8

slide-9
SLIDE 9

Timbers Water and Sanitation District

Agenda

  • Introductions
  • Reason for Public Meeting
  • Sanitation System
  • Current Sanitation System
  • What’s wrong with the current system?
  • How do we fix it?
  • What’s it going to cost & How do we pay for it?
  • What are the next steps?
  • Questions about the sanitation system
  • Information Session
  • Fees and taxes for 2017
  • Water System Renovations/Improvements

December 15, 2016 9

slide-10
SLIDE 10

Timbers Water and Sanitation District

CURRENT SANITATION SYSTEM

December 15, 2016 10

slide-11
SLIDE 11

Timbers Water and Sanitation District

Sanitation System Components

  • Collection System
  • Treatment
  • Biological Treatment
  • Disinfection
  • Discharge

December 15, 2016 11

slide-12
SLIDE 12

Timbers Water and Sanitation District

TWSD Current Sanitation System

  • Over 45 years old
  • Collection System
  • 1.4 miles of asbestos cement pipe; 800 feet PVC pipe
  • Treatment
  • Headworks with manual solids removal
  • Two lagoon system
  • First (Treatment) lagoon: lined, baffled, 2-cell biological treatment
  • Chlorination chamber: disinfection
  • Second (Storage) lagoon: unlined, storage of treated water
  • Discharge
  • Spray irrigation

December 15, 2016 12

slide-13
SLIDE 13

Timbers Water and Sanitation District

December 15, 2016 13

C D C

Engineers and Planners “ ”

slide-14
SLIDE 14

Timbers Water and Sanitation District

December 15, 2016 14

slide-15
SLIDE 15

Timbers Water and Sanitation District

December 15, 2016 15

slide-16
SLIDE 16

Timbers Water and Sanitation District

December 15, 2016 16

slide-17
SLIDE 17

Timbers Water and Sanitation District

What’s wrong with the current sanitation system?

  • Not validly permitted
  • To obtain valid permit, system has to meet current standards

December 15, 2016 17

slide-18
SLIDE 18

Timbers Water and Sanitation District

What’s wrong with the current sanitation system?

  • Not validly permitted
  • To obtain valid permit, system has to meet current standards
  • Collection system is failing

December 15, 2016 18

slide-19
SLIDE 19

Timbers Water and Sanitation District

December 15, 2016 19

C D C

Engineers and Planners “ ”

slide-20
SLIDE 20

Timbers Water and Sanitation District

Flows through the collection system

December 15, 2016 20

slide-21
SLIDE 21

Timbers Water and Sanitation District

December 15, 2016 21

slide-22
SLIDE 22

Timbers Water and Sanitation District

December 15, 2016 22

slide-23
SLIDE 23

Timbers Water and Sanitation District

December 15, 2016 23

slide-24
SLIDE 24

Timbers Water and Sanitation District

What’s wrong with the current sanitation system?

  • Not validly permitted
  • To obtain valid permit, system has to meet current standards
  • Collection system is failing
  • Treatment system is failing

December 15, 2016 24

slide-25
SLIDE 25

Timbers Water and Sanitation District

December 15, 2016 25

slide-26
SLIDE 26

Timbers Water and Sanitation District

December 15, 2016 26

slide-27
SLIDE 27

Timbers Water and Sanitation District

December 15, 2016 27

slide-28
SLIDE 28

Timbers Water and Sanitation District

December 15, 2016 28

slide-29
SLIDE 29

Timbers Water and Sanitation District

December 15, 2016 29

slide-30
SLIDE 30

Timbers Water and Sanitation District

December 15, 2016 30

slide-31
SLIDE 31

Timbers Water and Sanitation District

December 15, 2016 31

slide-32
SLIDE 32

Timbers Water and Sanitation District

What’s wrong with the current sanitation system?

  • Not validly permitted
  • To obtain valid permit, system has to meet current standards
  • Collection system is failing
  • Treatment system is failing
  • Discharge system is unreliable
  • Insufficient capacity
  • Irrigation system in disrepair

December 15, 2016 32

slide-33
SLIDE 33

Timbers Water and Sanitation District

December 15, 2016 33

slide-34
SLIDE 34

Timbers Water and Sanitation District

How do we fix this?

  • Replace the collection system
  • Construct a new treatment system
  • Renovate the existing discharge system or replace it with

surface water discharge

December 15, 2016 34

slide-35
SLIDE 35

Timbers Water and Sanitation District

Considerations

  • Cost
  • Construction
  • Operating
  • Reliability
  • Longevity
  • Simplicity
  • Experience with the components in our climate
  • Timeliness of Completion
  • CDPHE acceptance

December 15, 2016 35

slide-36
SLIDE 36

Timbers Water and Sanitation District

Replacement of the collection system

  • Options considered
  • Line the existing pipes
  • Low pressure collection system
  • Gravity system
  • Gravity system selected
  • Simplicity
  • Reliability

December 15, 2016 36

slide-37
SLIDE 37

Timbers Water and Sanitation District

New Treatment System

  • Options considered
  • Replacement of existing lagoons
  • Mechanical Plants

December 15, 2016 37

slide-38
SLIDE 38

Timbers Water and Sanitation District

Replacement of existing lagoons would require

  • Replacement and maintenance of the lower 3185 feet of

the collection system

  • Construction of 3 new lagoons
  • Haul away of waste material during construction
  • Renovation of discharge system
  • Acquisition of addition to land easement to include service

road and potentially enlarge spray irrigation field

December 15, 2016 38

slide-39
SLIDE 39

Timbers Water and Sanitation District

Mechanical Treatment Plants

  • Two kinds
  • Sequencing Batch Reactor
  • Advantex Packed Bed Media Filtration System
  • Selected Fluidyne ISAM Sequence Batch Reactor
  • Many installations at our elevation or above, and in our climate
  • Tolerant of variable flows
  • Simple to operate
  • Many CDPHE approved installations
  • Small footprint: 14’ x 40’ tank, 24’ x 60’ foot building
  • Comparable acquisition and operating costs to alternatives
  • No odor
  • Minimal operating noise

December 15, 2016 39

slide-40
SLIDE 40

Timbers Water and Sanitation District

Sequencing Batch Reactor

December 15, 2016 40

slide-41
SLIDE 41

Timbers Water and Sanitation District

December 15, 2016 41

Images from www.fluidynecorp.com

Eagle Travel Center, Cameo, CO

slide-42
SLIDE 42

Timbers Water and Sanitation District

December 15, 2016 42

slide-43
SLIDE 43

Timbers Water and Sanitation District

Mechanical Treatment Plants

  • Two kinds
  • Sequence Batch Reactor
  • Advantex Packed Bed Media Filtration System
  • Selected Fluidyne ISAM Sequence Batch Reactor
  • Many installations at our elevation or above, and in our climate
  • Small footprint
  • Tolerant of variable flows
  • Comparable acquisition and operating costs
  • Simple to operate
  • Many CDPHE approved installations
  • Small footprint and acceptability for surface discharge

allowed consideration of an alternative site

December 15, 2016 43

slide-44
SLIDE 44

Timbers Water and Sanitation District

December 15, 2016 44

C D C

Engineers and Planners “ ”

slide-45
SLIDE 45

Timbers Water and Sanitation District

December 15, 2016 45

slide-46
SLIDE 46

Timbers Water and Sanitation District

Proposed Upper Site

December 15, 2016 46

Engineers and Planners

Civil Design Consultants, Inc.

I:\2623.002C Timbers WWTF\Drawings\General Drawings\T-WWTP Upper base.dwg, 11x17, 12/12/2016 5:17:04 PM, ANSI full bleed B (11.00 x 17.00 Inches), 1:1
slide-47
SLIDE 47

Timbers Water and Sanitation District

Proposed Upper Site Plan

December 15, 2016 47

slide-48
SLIDE 48

Timbers Water and Sanitation District

Options

Treatment Method New Lagoons Fluidyne SBR AdvanTex Existing Site X X X New Upper Site X X

December 15, 2016 48

slide-49
SLIDE 49

Timbers Water and Sanitation District

Options - Costs

Treatment Method New Lagoons Fluidyne SBR AdvanTex Existing Site $3.09M $3.59M $3.66M New Upper Site $3.05M $3.19M

December 15, 2016 49

Treatment Method New Lagoons Fluidyne SBR AdvanTex Existing Site $25k $17k $12k New Upper Site $17k $12k Construction Annual Operating

slide-50
SLIDE 50

Timbers Water and Sanitation District

Options - Costs

Treatment Method New Lagoons Fluidyne SBR AdvanTex Existing Site $3.09M $3.59M $3.66M New Upper Site $3.05M $3.19M

December 15, 2016 50

Treatment Method New Lagoons Fluidyne SBR AdvanTex Existing Site $25k $17k $12k New Upper Site $17k $12k Construction Annual Operating

slide-51
SLIDE 51

Timbers Water and Sanitation District

Selected Option

December 15, 2016 51

Treatment Method New Lagoons Fluidyne SBR AdvanTex Existing Site $3.09M New Upper Site $3.05M $3.19M

Requires long term maintenance and future replacement of lower collection system; does not

  • vercome problems of

winter maintenance and natural intrusion Close proximity to water treatment plant; advanced treatment system compared to lagoons; CDPHE acceptance and large experience base; elimination of lower collection system; return of current site to natural habitat Close proximity to water treatment plant; advanced treatment system compared to lagoons; CDPHE acceptance; elimination of lower collection system; return of current site to natural habitat

slide-52
SLIDE 52

Timbers Water and Sanitation District

Option proposed in PNA

  • Collection system: Gravity, upper system only
  • Treatment system: Fluidyne ISAM SBR at new upper site
  • Discharge system: surface to McKinnis Creek

December 15, 2016 52

slide-53
SLIDE 53

Timbers Water and Sanitation District

How do we pay for the new system?

  • District has already approved taking on $2M in debt to

finance construction (May, 2014)

  • Financed by property taxes
  • Average annual increase per home/unit estimated at ~$1100 based on

current state loan terms

  • Actual increase dependent upon assessed value
  • Board has had meetings with state funding agencies
  • Board intends to seek balance of funding through state

grants

December 15, 2016 53

slide-54
SLIDE 54

Timbers Water and Sanitation District

What happens next?

  • Intent:
  • Complete necessary permits, acquisition of land, and CDPHE

approval of final plans and funding applications in time to bid project for construction in summer 2018

  • If CDPHE approvals and funding allow, collection system

replacement could be done summer 2017

  • Immediate next steps
  • Completion of income survey
  • Permits, variances and land acquisition for upper site
  • CDPHE approval of PNA
  • Submission of funding application for engineering costs by April

December 15, 2016 54

slide-55
SLIDE 55

Timbers Water and Sanitation District

Agenda

  • Introductions
  • Reason for Public Meeting
  • Sanitation System
  • Current Sanitation System
  • What’s wrong with the current system?
  • How do we fix it?
  • What’s it going to cost & How do we pay for it?
  • What are the next steps?
  • Questions about the sanitation system
  • Information Session
  • Fees and taxes for 2017
  • Water System Renovations/Improvements

December 15, 2016 55

slide-56
SLIDE 56

Timbers Water and Sanitation District

Agenda

  • Introductions
  • Reason for Public Meeting
  • Sanitation System
  • Current Sanitation System
  • What’s wrong with the current system?
  • How do we fix it?
  • What’s it going to cost & How do we pay for it?
  • What are the next steps?
  • Questions about the sanitation system
  • Information Session
  • Fees and taxes for 2017
  • Water System Renovations/Improvements

December 15, 2016 56

slide-57
SLIDE 57

Timbers Water and Sanitation District

2017 Taxes and Fees

  • TWSD Property Taxes
  • Total revenues essentially unchanged from 2016
  • Minor differences due to changes in assessed valuation
  • Fees

December 15, 2016 57

2015 2016 2017 Change

Water Only $1,022 $1,017 $1,143 $126 Water and Sanitation $2,351 $1,798 $2,294 $496 Availability of Service Water Only $511 $508 $571 $63 Water and Sanitation $1,175 $899 $1,147 $248

slide-58
SLIDE 58

Timbers Water and Sanitation District

Agenda

  • Introductions
  • Reason for Public Meeting
  • Sanitation System
  • Current Sanitation System
  • What’s wrong with the current system?
  • How do we fix it?
  • What’s it going to cost & How do we pay for it?
  • What are the next steps?
  • Questions about the sanitation system
  • Information Session
  • Fees and taxes for 2017
  • Water System Renovations/Improvements

December 15, 2016 58

slide-59
SLIDE 59

Timbers Water and Sanitation District

Water System Renovations/ Improvements - 2017

  • Water Tank Renovation
  • Fire Hydrant renovation
  • Water Meters

December 15, 2016 59

slide-60
SLIDE 60

Timbers Water and Sanitation District

Water System Renovations/ Improvements

  • Water Tank Renovation
  • Repair and replacement of overflow pipe
  • Exterior and interior painting
  • Addition of second entry
  • New, protected ladder
  • Addition of a vent
  • Requires use of a temporary storage tank
  • Approximately $200,000 project; 2/3 funded by state grant
  • Timing: early summer 2017
  • Fire Hydrant renovation
  • Water Meters

December 15, 2016 60

slide-61
SLIDE 61

Timbers Water and Sanitation District

Water System Renovations/ Improvements

  • Water Tank Renovation
  • Fire Hydrant renovation
  • 2 Fire Hydrants
  • Cost ~$45,000; funded by state grant
  • Water Meters
  • All individual homes; Timbers Condo as one unit; Villas as one unit
  • Enables leak detection in distribution system and every metered

unit

  • Eventual switch from flat fee to use fee for water
  • Cost ~$45,000; funded by state grant

December 15, 2016 61

slide-62
SLIDE 62

Timbers Water and Sanitation District

QUESTIONS

December 15, 2016 62

slide-63
SLIDE 63

Timbers Water and Sanitation District

THANK YOU

www.timberswater.org copies of the PNA Jodi Lightfoot: jlightfoot@hotmail.com 970-846-2476 Ron Krall: krallrl@msn.com 484-744-1575

December 15, 2016 63
