TV VA Brightness Adder 09/04/19 EPA Luminance Requirements For products with a luminance in the Brightest Selectable Preset Picture Setting (the greater value of L DEFAULT_RETAIL or L BRIGHTEST_HOME) less than 350 cd/m2, luminance in the

SLIDE 1

TV VA Brightness Adder

09/04/19

SLIDE 2

EPA Luminance Requirements

For products with a luminance in the Brightest Selectable Preset Picture Setting (the greater value
f L DEFAULT_RETAIL or L BRIGHTEST_HOME) less than 350 cd/m2, luminance in the Picture

Setting under which the product qualifies for the ENERGY STAR shall be greater than or equal to 65% of the luminance in the Brightest Selectable Preset Picture Setting, as per the Federal Test Procedure.

For products with a luminance in the Brightest Selectable Preset Picture Setting greater than or

equal to 350 cd/m2, luminance in the Picture Setting under which the product qualifies for the ENERGY STAR shall be greater than or equal to 228 cd/m2, as per the Federal Test Procedure

SLIDE 3

Measured Brightness of Preset Picture Settings

Default 392.47 Setting 1 448.83 Setting 2 452.96 Setting 3 201.16 Retail 500.78 Unit B

Default 380.48 Setting 1 359.02 Setting 2 370.83 Setting 3 283.99 Setting 4 369.21 Retail 397.18 Unit C

Default 346.45 Setting 1 448.43 Setting 2 155.53 Setting 3 462.23 Retail 504.92 Unit D

Default 387.52 Setting 1 337.69 Setting 2 282.23 Setting 3 258.45 Setting 4 334.54 Setting 5 186.45 Retail 334.42 Unit E

Default 337.35 Setting 1 274.75 Setting 2 171.23 Setting 3 339.22 Retail 339.59 Unit A

Default 531.47 Setting 1 727.19 Setting 2 468.71 Setting 3 538.04 Setting 4 524.24 Setting 5 571.66 Retail 716.66 Unit F

SLIDE 4

CTA 2037-B Brightness Measurements

Per CTA 2037-B Tests were conducted with ABC off

Unit Ldefault (nits) Lbrightest Selectable (nits) Lretail (nits) L ratio Measured Power On (W)

A 337.35 339.22 339.59 0.993 45.33 B 392.47 448.83 500.78 0.784 86.58 C 380.48 380.48 397.18 0.958 59.93 D 346.45 462.23 504.92 0.686 69.9 E 387.52 387.52 334.42 1.000 78.5 F 531.47 727.19 716.66 0.731 105.12

SLIDE 5

Potential Adder

Unit Screen Size (in) Display Technology Measured Power On (W) ESTAR 7.0 Limit (W) ESTAR 7.0 Limit + 25% (W)

ESTAR 7.0 + Brightness Adder (W) ESTAR 7.0 Limit + 25% + Brightness Adder (W)

A 43 LED Full Array 45.33 61.96 77.45 81.64 97.13 B 55 LED Full Array 86.58 85.43 106.78 115.03 136.38 C 55 Edge lit w/local dimming 59.93 85.43 106.78 112.88 134.23 D 55 LED Full Array/local dimming 69.90 85.43 106.78 106.75 128.10 E 55 Local dimming 78.50 85.43 106.78 114.14 135.49 F 55 LED Full Array/local dimming 105.12 85.43 106.78 140.05 161.40 Unit Ldefault (nits) Lbrightest Selectable (nits) Lretail (nits) L ratio Measured Power On (W) Power/ Ldefault Ldefault- 228 (nits) Adder

A 337.35 339.22 339.59 0.993 45.33 0.1344 109.35 19.68 B 392.47 448.83 500.78 0.784 86.58 0.2206 164.47 29.60 C 380.48 380.48 397.18 0.958 59.93 0.1575 152.48 27.45 D 346.45 462.23 504.92 0.686 69.9 0.2018 118.45 21.32 E 387.52 387.52 334.42 1.000 78.5 0.2026 159.52 28.71 F 531.47 727.19 716.66 0.731 105.12 0.1978 303.47 54.62

Brightness adder = 0.18 x (Ldefault – 228)

SLIDE 6

Measured Luminance (IEC Test Clip)

Test run with IEC test clip; TV in default setting with ABC off

Unit Screen Size (in) Resolution Display Technology Peak Brightness (nits) Average Brightness (nits) Average Power (W) Power/Brightness A 43 2160 LED Full Array 332.32 69.73 63.65 0.9128 B 55 2160 LED Full Array 435.52 105.32 116.98 1.1107 C 55 2160 Edge lit w/local dimming 380.90 93.71 100.22 1.0695 D 55 2160 LED Full Array/local dimming 433.77 89.95 141.12 1.5689 E 55 2160 Local dimming 288.17 79.98 85.93 1.0744 F 55 2160 LED Full Array/local dimming 534.75 105.74 133.36 1.2612
