TOSHIBA Steam Turbine November, 2007 TOSHIBA PLANT SYSTEMS & SERVICES CORPORATION 1 INTRODUCTION 2 PARTNERSHIP WITH TOSHIBA Conventional Combined Work with TOSHIBA Geothermal Fuel Cell as a member of TOSHIBA Group Nuclear Hydro

SLIDE 1

TOSHIBA Steam Turbine

November, 2007 TOSHIBA PLANT SYSTEMS & SERVICES CORPORATION

SLIDE 2

INTRODUCTION

SLIDE 3

Power Business

(approx. 150MW /unit)

Independent Business by TPSC Work with TOSHIBA

as a member of TOSHIBA Group

Nuclear Conventional Combined Fuel Cell Geothermal Hydro Co-Gen Combined Conventional Green Energy

PARTNERSHIP WITH TOSHIBA

SLIDE 4

EPC Project :

TPSC can be most competitive to be an EPC Contractor.

BOP Supply :

TPSC can change the scope of supply according to Customer's Business Structure, i.e. TPSC can supply a part of power plant equipment upon Customer's requirement.

STG Supply :

TPSC supplies Turbine Generator set.

THERMAL POWER SYSTEMS & SERVICE DIVISION

Under "ONE THROUGH CAPABILITY," Thermal Power Division targets following three (3) businesses.

SLIDE 5

FULL RANGE CLIENT SERVICE

Feasibility Study Planning / Design Procurement Erection / Installation Test / Commissioning Maintenance Service

Manufacturing

（TOSHIBA)

SLIDE 6

Overseas sales & marketing network

Toshiba de Venezuela Toshiba International Corp.(TX, SF - USA) Shanghai Rep. Office Toshiba China Co.,Ltd. (Beijing(HQ), Shanghai) TAPL (Philippines) Toshiba International Corp.(Australia) TAPL (Indonesia) TAPL (Singapore(HQ)) TAPL (Malaysia)

TAPL (Thailand)

Toshiba Gulf FZE (Dubai) Toshiba International (Europe) Ltd.(UK) Toshiba India Private Ltd. Moscow Rep.Office Johannesburg Rep.Office Toshiba Info., Industrial & Power Sys. Taiwan Corp. Toshiba do Brasil (Rio & Sao Paulo)

TAPL: Toshiba Asia Pacific PTE.,Ltd

20 offices in 16 countries

SLIDE 7

TOSHIBA STEAM TURBINE EXPERIENCE

SLIDE 8

Toshiba Turbine Cumulated Experience

500 500 1, 1,000 000 1, 1,500 500 2, 2,000 000 1950 1950 1960 1960 1970 1970 1980 1980 1990 1990 2000 2000 Cum umul ulative e Num umber er 40 40 80 80 120 120 160 160 Cumulati ative ve Outp tput( t(GW)

For Geothermal

Supercritical

For Nuclear For Combined Cycle

50 GW 1, 1,000 000 1, 1,500 500

For Simple Cycle

First Steam Turbine delivered in 1927

Output : 139.1 GW Number : 1,807

As of

f Jan.
n. 2005

2005

SLIDE 9

THERMAL POWER PLANTS SUPPLIED BY TOSHIBA IN THE GLOBAL MARKET

Total: 1,834 Units, 145,013MW (As of Mar. 2006)

PRD PRD-KGG KGG-AAH00702 AAH00702

Canada 1,427MW U.S.A 19,373MW Mexico 2,512MW Costa Rica 55MW Antigua 18MW Brazil 155MW Venezuela 1,418MW Argentina 14MW Korea 2,138MW 2475MW Philippines 1,114MW Thailand 348MW Australia 11,852MW Indonesia 2,950MW Malaysia 2,605MW Sri Lanka 6MW India 1,002MW South Africa 118MW Botswana 33MW Nigeria 56MW Egypt 1,764MW Cyprus 120MW Lebanon 130MW Bahrain 65MW Kuwait 4,254MW Iran 255MW Bangladesh 41MW China 9,248MW

Puerto Rico

214MW Pakistan 137MW

Papua New Guinea

135MW Nauru 0.1MW Myanmar 0.9MW

Japan

79,346MW

942MW

Bulgaria

177MW Italy 990MW

SLIDE 10

MEDIUM / SMALL CLASS STEAM TURBINE

SLIDE 11

Exhaust LP IP Extraction HP

Extraction LP IP HP

R H

BACK PRESSURE TURBINE EXTRACTION CONDENSING TURBINE REHEAT CONDENSING TURBINE ◆ For small electrical

utput and large

thermal output ◆ Exhaust is applicable for process steam, district heating etc. ◆ Low initial cost without condenser ◆ Wide variety of electrical / thermal output combination to meet the demand of clients. ◆ One or plural internal pressure controlled extraction is applicable for process steam, district heating etc. ◆ External control and non- controlled extraction is also applicable for process and feedwater heaters. ◆ For larger electrical

utput

◆ Tandem compound or Single cylinder ◆ Internal / external control extraction and non- controlled extraction applicable for process and feedwater heaters.

SLIDE 12

HIGH-RELIABILITY, HIGH-EFFICIENCY STEAM TURBINE

◆ Impulse design and inherently rugged compartment-type construction ◆ Compact shell-mounted control valve construction in high-pressure section ◆ High-pressure steam inlet construction ◆ True center support construction of the casing and nozzle diaphragms ◆ Spring-backed shaft packing ◆ Double-sheet spool-type extraction control valves ◆ Solid rotor, flexible shaft construction ◆ Tilting pad journal bearing ◆ Tapered-land type thrust bearing ◆ Horizontal split, casing, nozzle, and packing construction ◆ LP and HP EHC control system with high control accuracy ◆ Standard block design

SLIDE 13

Reheat Condensing 24units not larger than 300MW

Electrical Output (MW)

EXPERIENCE of TURBINE TYPE / ELECTRICAL OUTPUT

Extraction Condensing 93units Straight Condensing 124units Reheat Extraction Condensing 25units Back Pressure with/without Extraction 81units

1000 300 200 100

SLIDE 14

BACK-PRESSURE TURBINE

Rated Output : 25,000kW Main Steam Pressure : 11.3MPag Main Steam Temperature : 538℃ Back Pressure : 1.27MPag

AUTOMATIC-DOUBLE-EXTRACTION BACK-PRESSURE TURBINE

Rated Output : 35,000kW Main Steam Pressure : 5.9MPag Main Steam Temperature : 440℃ Extraction Pressure : 1.23 / 0.69MPag Back Pressure : 0.27MPag

SLIDE 15

CONDENSING TURBINE

Rated Output : 38,000kW Main Steam Pressure : 2.9MPag Main Steam Temperature : 390℃ Exhaust Pressure : 5.07kPa abs.

CONDENSING TURBINE (2 casing type)

For large capacity condensing turbine Rated Output : 100,000kW Main Steam Pressure : 8.6MPag Main Steam Temperature : 510℃ Exhaust Pressure : 8.00kPa abs.

SLIDE 16

REHEAT TURBINE (axial flow)

Suitable for combined cycle and low floor installation plants Rated Output : 200,000kW Main Steam Pressure : 12.7MPag Main Steam Temperature : 538℃ Reheat Steam Temperature : 538℃ Exhaust Pressure : 8.63kPa abs.

REHEAT TURBINE (2 casing type)

For large capacity reheat turbine Rated Output : 500,000kW Main Steam Pressure : 16.6MPag Main Steam Temperature : 538℃ Reheat Steam Temperature : 538℃ Exhaust Pressure : 10.2kPa abs.

SLIDE 17

AUTOMATIC-DOUBLE-EXTRACTION CONDENSING TURBINE

Rated Output : 30,000kW Main Steam Pressure : 10.0MPag Main Steam Temperature : 538℃ Extraction Pressure : 1.18 / 0.59MPag Exhaust Pressure : 8.63kPa abs.

AUTOMATIC-DOUBLE-EXTRACTION REHEAT TURBINE (2 casing single exhaust flow type)

Rated Output : 149,000kW Main Steam Pressure : 16.6MPag Main Steam Temperature : 566℃ Reheat Steam Temperature : 538℃ Extraction Pressure : 3.5 / 0.69MPag Exhaust Pressure : 5.07kPa abs.

SLIDE 18

AUTOMATIC-EXTRACTION REHEAT TURBINE (2 casing double exhaust flow type)

Rated Output : 300,000kW Main Steam Pressure : 13.9MPag Main Steam Temperature : 535℃ Reheat Steam Temperature : 535℃ Extraction Pressure : 0.25MPag Exhaust Pressure : 6.27kPa abs.

Extraction Control Valve (Butterfly Valve)
