The world of Hermann Schnierle GmbH

▪ 2016 sales: 17,15 Mio. Euro ▪ 2016 staff: 161

Company Profile

sales & staff

▪ Hermann Schnierle, managing director (6,4%) ▪ Martin Schnierle, managing director (51%) ▪ Rainer Höfele, managing director (32,6%) ▪ Andrea Schnierle, participator (10 %)

Management

▪ establishment 1966 ▪ family-run company ▪ company location in Gersthofen (Augsburg)

Company information

Milestones on our way into the wheeled mobility market

▪ 1966: Foundation as upholstery firm by Hermann Schnierle ▪ 1990: Start of own production of seats for minibuses (Pioneer in production of coach seats with integrated 3-point belts) ▪ 2003: Construction of own test facility, certified by TÜV Rheinland, TÜV Süd (TÜV Automotive), RDW (NL), UTAC (FR), DTC (CH etc.) Opening into the mobility market by launching our seats on tested aluminium floor system and fast-lock-foot system, followed by providing wheelchair and passenger restraint systems ▪ 2010: Launch of patented ROLLIBOX, the comfortable vehicle transport solution for passengers with and without wheelchairs Followed by development of belt pillar with headrest ▪ 2015: Growing demands of mobility solutions lead us to the decision to acquire Schnierle Safety Belts GmbH (former Schneeweis), with own seat belt production ▪ 2017: Further development of our belt pillar with headrest results now in the SAFETRANS (tested for M1 + M2)

Impressions

Production Seating Systems Located in Gersthofen (Augsburg)

Impressions

Production Safety Belts Located in Laufen (near Salzburg)

Key areas of expertise

Seating Systems

• M1
• M2
• Motorhome seat
• Special seats
• Ambulance seats
• Orthopaedic d.s.
• Leg systems
• Accessories

Installation and expansion systems

Installation kits:

• Aluminiumfloor

systems

• Rail-In floorsystem
• Quick Out
• Quick Out 2
• Universal rail

systems Expansion kits:

• Steps
• Luggage racks

Vehicle solutions for the handicapped

• RolliBox
• Wheelchair restraint

systems

• Beltpillar with

headrest Expansion kits:

• Wheelchair ramp
• Wheelchair lift

Custom vehicle modifications Upholstery

Product range Seating Systems

▪ Seat Systems ▪ Leg Systems ▪ Wheelhouse Superstructure ▪ Accessories

Floor Systems

• Alusystem Floor
• Rail In Floor

Solutions for Handicapped People

▪ Rollibox ▪ Belt Pillar with Headrest ▪ Wheelchair Restraint Systems ▪ Steps, Ramps & Lifts

Safety Belts

▪ Static Belt ▪ 3 Point Belt ▪ H Belt ▪ Emergency locking Retractor (ELR)

Customer structure

Represented countries

You can find our products in these countries:

▪ Austria ▪ Benelux (Belgium, Netherlands, Luxemburg) ▪ Czech Republic ▪ Denmark ▪ Finnland ▪ France ▪ Italy ▪ Norway ▪ Slowenja ▪ Spain ▪ Sweden ▪ Switzerland ▪ Turkey ▪ United Kingdom

Product range Seating Systems

Floor Systems

Aluminium Floor System Rail-In Floor System

Everything in place - Everything on board - Ready for use Ideal for a wide range of transportation solutions:

Solutions for Handicapped People

✓ wheelchair restraint systems are stowed away neatly ✓ Incorrect handling is virtually impossible ✓ Length of wheelchair slots can be individually

adjusted

✓ Quicker and easier handling than standard systems ✓ 3-point belt system can be adjusted for wheelchair

passengers

✓ Slideable seats with low backs (good visibility) ✓ Combined transportation of passengers with/without

wheelchairs

✓ Lighter and cheaper than competitive systems ✓ Easy installation ✓ Vehicle floor can be easily cleaned

Belt Pillar with Head Rest

The safety system for wheelchair users Benefits

✓ Optimal belt routing close to the body

✓ Protection through headrest in the event of crash ✓ Easy handling and operating ✓ Easy-cleaning (headrest of artificial leather material) ✓ Belt pillar can be configured for right and left side ✓ System suitable for our floor systems (Aluminium and Rail-In) ✓ Headrest can be rotated by 180° and extended sideways by

130mm

The further development of our headrest system for wheelchair users SAFETRANS

Benefits

✓ Combines the benefits of our previous headrest with

comfortability and safety features

✓ TÜV tested system ✓ Passes the design regulation restrictions of ISO 10542 ✓ Suitable for our foot systems and also on sliding

bridge

✓ System suitable for WAV´s

Future-proof system

Benefits Quick Secure

✓High safety through 4-fold-fitting with double lock devices ✓Excellent tensioning through retractor wheels with 24 teeth ✓High product lifecycle trough metal housing ✓Buckles from sector large-scale series production (Honda) ✓High flexibility through application on our floor systems, (tested on all common van types) ✓Constant production monitoring through in-house pulling test facility (extended pulling force of up to 70%) ✓TÜV test certificate in accordance with ISO 10542 and DIN 75078-2 standards

Wheelchair Restraint Systems The COMFORT system The STANDARD system

Heavy Duty Wheelchair Restraint System

Our new and innovative Heavy Duty Wheelchair Restraint System Maxi – an awesome and ingeniously simple development ! A system with a patented crash absorber for all wheelchairs:

▪

Mechanical wheelchairs

▪

Electric wheelchairs (scooters)

▪

Wheelchairs with integrated lap belt

✓ Heavy load system tested with 20 G (dynamic) and wheelchair weight

• f 160 Kg (↔ 85Kg acc. to ISO) provides high safety in case of crashes

✓ System tested with integrated lap belt (adjustable belt system with

straps)

✓ Aluminium floor and Rail-In system tested with 200 KG.

In case of a front crash the force can be transmitted to the belt system for reducing and absorbing and thus the crash effect for the passenger becomes attenuated.

Steps, Ramps & Lifts

Some main features:

✓Supplied complete with wiring loom, integrated

electronics, warning light for the driver, buzzer, door switch and universal mounting brackets

✓M1 (20G) tested ✓Emergency opening from inside the vehicle ✓Light operation by gas spring support ✓Auto lock for easy operation without Quick out

locking System for quick disassembly of the ramp

Thank you for your attention.

Contact details Hermann Schnierle GmbH Dieselstrasse 43 86368 Gersthofen ➢ T + 4 9 8 2 1 2 9 9 9 3 - 0 ➢ F + 4 9 8 2 1 4 7 1 7 0 5 ➢ i n f o @ s c h n i e r l e . d e ➢ w w w . s c h n i e r l e . d e
