CEAG Notlichtsysteme GmbH CEAG Notlichtsysteme GmbH 1906 2014 1 CEAG Notlichtsysteme GmbH O. H. Chao Regional Sales Manager (South East Asia) 2 CEAG Notlichtsysteme GmbH Crouse - Hinds Bussmann Lighting $500 M $400 M $ 1200 M (1897)

slide-1
SLIDE 1

1

CEAG Notlichtsysteme GmbH

CEAG Notlichtsysteme GmbH

1906 2014

slide-2
SLIDE 2

2

CEAG Notlichtsysteme GmbH

  • O. H. Chao

Regional Sales Manager (South East Asia)

slide-3
SLIDE 3

3

CEAG Notlichtsysteme GmbH

A Strong Collection of Businesses With a Long History of Product Quality and Innovation

Crouse - Hinds $500 M (1897) Bussmann $400 M (1914) Lighting $ 1200 M (1956) Power System $800 M (1911) B-Line $300 M (1969) Wiring Devices $300 M (1890) Menvier $400 M (1975) Power Tools $300 M (1967) Hand Tools $400 M (1864)

slide-4
SLIDE 4

4

CEAG Notlichtsysteme GmbH

CEAG Notlichtsysteme GmbH - the plant

  • Soest
slide-5
SLIDE 5

5

CEAG Notlichtsysteme GmbH

Why Not UPS

  • What are the problems

– Discharge Lighting – Heat Dissipation – Battery Life – Overload Capability

slide-6
SLIDE 6

6

CEAG Notlichtsysteme GmbH

Discharge Lighting

  • Most Discharge lighting takes a prolonged

period of time to strike the lamp and does not comply with Standards Set at 5 seconds

  • UPS manufacturers claim “NO-BREAK output

solves this, but it is WRONG

slide-7
SLIDE 7

10

CEAG Notlichtsysteme GmbH

1

Discharge Lighting WAREHOUSE

OFFICE MCB 1 MCB 2

230V OUTPUT LOAD 230V

Normal Operation Fire Breaks Out

slide-8
SLIDE 8

11

CEAG Notlichtsysteme GmbH

1

Discharge Lighting WAREHOUSE

OFFICE MCB 1 MCB 2

SUPPLY FAIL

SHORT CIRCUIT

OUTPUT LOAD 230V

Supply Failure

slide-9
SLIDE 9

12

CEAG Notlichtsysteme GmbH

1

WAREHOUSE OFFICE MCB 1 MCB 2

SUPPLY FAIL

SHORT CIRCUIT

OUTPUT LOAD

0V

LOSS OF EM LIGHTS DARKNESS

Discharge Lighting

OVERLOAD

slide-10
SLIDE 10

13

CEAG Notlichtsysteme GmbH

1

Discharge Lighting

WAREHOUSE OFFICE MCB 1 MCB 2

SUPPLY FAIL

SHORT CIRCUIT

OUTPUT LOAD

230V

MCB FAULT CLEARS (approx 5 sec’s) DISCHARGE LAMPS WARM UP

slide-11
SLIDE 11

14

CEAG Notlichtsysteme GmbH

  • Where

discharge lighting schemes are required, it is recommended to use separate secondary non-maintained emergency lighting

  • r alternate fluorescent lighting for emergency

escape lighting. Discharge Lighting Design

slide-12
SLIDE 12

15

CEAG Notlichtsysteme GmbH

Battery Lifetime Active stand-by operation Vs Passive Stand-by

BATTERY CHARGER INVERTER (RUNNING) BATTERY HEAT HEAT UPS / ACTIVE STANDBY STSTEM (INVERTER PERMANENTLY RUNNING) BATTERY CHARGER INVERTER (RUNNING) BATTERY NO HEAT GENERATED HEAT STATIC INVERTER STSTEM (INVERTER PASSIVE STANDBY)

CONSTANT CHARGE AND DIS-CHARGE CONSTANT TRICKLE CHARGE ON DEMAND

slide-13
SLIDE 13

16

CEAG Notlichtsysteme GmbH

Heat Dissipation

BATTERY CHARGER INVERTER (RUNNING) BATTERY

HEAT

HEAT UPS / ACTIVE STANDBY STSTEM (INVERTER PERMANENTLY RUNNING) BATTERY CHARGER INVERTER (RUNNING) BATTERY NO HEAT GENERATED Negligible HEAT STATIC INVERTER STSTEM (INVERTER PASSIVE STANDBY)

UPS – STATIC INVERTER POWER LOSS

slide-14
SLIDE 14

17

CEAG Notlichtsysteme GmbH

Heat Dissipation

  • A 30 kW UPS system will continuously dissipate

about 3KW of heat.

  • If electricity costs HK$0.9 per unit then the running

costs will be: $0.9 X 3 x 24 x 365 = HK$23,652 per year

  • For a static inverter costs will negligible
slide-15
SLIDE 15

18

CEAG Notlichtsysteme GmbH

Summary

  • Designed for emergency

lighting requirement

  • >10 yrs
  • Negligible
  • 200% for 10 seconds,

125% for 20 minutes

  • Adapted for emergency lighting

requirement

  • ~ 3-5 years
  • Loss Energy
  • 125-150% momentary only
  • Design
  • Lifetime
  • Heat

Dissipation

  • Overlaod

Capability

CBS Typical UPS

slide-16
SLIDE 16

19

CEAG Notlichtsysteme GmbH

t I U

Battery Charger Self contained luminaires - construction

Mains

slide-17
SLIDE 17

20

CEAG Notlichtsysteme GmbH

Battery

6 3 9 6 3 9 12 12

18 month 32 month 24 month 36 month 28 month

slide-18
SLIDE 18

21

CEAG Notlichtsysteme GmbH

OGi-V batteries Influence of temperature, life expectancy

Life expectancy as a function of the battery temperature

10 20 30 40 50 60 1 2 3 4 5 6 7 8 9 10 11 12 13[years]

[°C]

slide-19
SLIDE 19

22

CEAG Notlichtsysteme GmbH

Our Philosophy

Each safety luminaire is important - it can save human´s health and life

  • monitor each luminaire
  • automatic testing
  • connection to BMS
  • use the advantages of central-

battery systems. Innovation in Emergency-Lighting is increasing safety in buildings

slide-20
SLIDE 20

37

CEAG Notlichtsysteme GmbH

slide-21
SLIDE 21

38

CEAG Notlichtsysteme GmbH

CBS : AC CBS : DC

slide-22
SLIDE 22

39

CEAG Notlichtsysteme GmbH

DC SYSTEM

Cable entry from the bottom Cable entry from the top 3-pole terminals with neutral disconnector Change - over module 24 x SKU 2 x 3 A CG-S Controller,DC/DC converter, charger, 2 x SKU 2 x 3 A CG-S Load break switch, mains Load break switch, battery AC fuses for substations DC fuses for substations 2,5A boost charger

slide-23
SLIDE 23

40

CEAG Notlichtsysteme GmbH

  • Higher initial cost (Product, Space)

System Disadvantage CBS

  • Battery service life time up to 10 years (at 20oC)
  • All relevant tests are carried out automatically
  • Suitable for high and low luminaires power
  • Low maintenance work and follow-up cost
  • Software user friendly
  • Maintain, Non-Maintain & Switching Mode in ONE circuit
  • Individual Circuit Protection (with SKU fuse relay)
  • No need Converter from DC to AC (Less Battery Capacity)

System Advantage CBS

DC SYSTEM

slide-24
SLIDE 24

41

CEAG Notlichtsysteme GmbH

Cost of Emergency - Lighting

DC SYSTEM

slide-25
SLIDE 25

42

CEAG Notlichtsysteme GmbH

Conventional Installation

Maintained mode c1 Maintained mode c1 Non-maint. mode c2 Non-maint. mode c2 Switched maintained mode c3 Switched maintained mode c3

3 final circuits !

DC SYSTEM

slide-26
SLIDE 26

43

CEAG Notlichtsysteme GmbH

S = Switching T = Technology A = Advanced R = Revision Z B - S

DC SYSTEM

slide-27
SLIDE 27

44

CEAG Notlichtsysteme GmbH

Only 1outgoing circuits necessary !

Non - maintained mode Maintained mode Switch maintained mode

the STAR Technology (Switching Technology Advanced Revision)

  • Savings in installation
  • Easy planning
  • Full flexibility
  • Easy programming
  • Connection to BMS and LON
  • Visualitzation by computer

(CG Vision.)

DC SYSTEM

slide-28
SLIDE 28

45

CEAG Notlichtsysteme GmbH

Compact system Non - Compact system Substation

slide-29
SLIDE 29

46

CEAG Notlichtsysteme GmbH

Internal modules and wiring

DC SYSTEM

slide-30
SLIDE 30

47

CEAG Notlichtsysteme GmbH

 Change Over Relay 1x6A / 2x3A

/ 4x1.5A

  • intelligent switch over relays
  • separate AC and DC fuses
  • emergency operation even without controller

 Control unit: ST-S

  • Programming
  • Monitoring
  • Logbook

 Charger

  • 2.5A charging current
  • temperature controlled charging method
slide-31
SLIDE 31

48

CEAG Notlichtsysteme GmbH

Display of 4 x 20 characters lines, contrast and brightness are adjustable through the program Display of:

  • date / time
  • charging fault
  • deep discharge protection
  • battery voltage
  • battery charge current (+)
  • battery discharge current during test or failure (-)
  • manual reset
  • function test
  • time-delayed emergency light on mains return

(remaining time in minutes)

  • luminaire fault with specific location data.
  • insulation fault stating faulty circuit
  • failure MDB (location data)
  • fault information
  • programming information

ZB-S: Control module

slide-32
SLIDE 32

49

CEAG Notlichtsysteme GmbH

STAR - Technology

ZB - S

220V

1111111... 1 2 3 4 5 6 20 0101000...1

Non-maintained mode Maintained mode Switched non-maintained mode L N PE

5A

230 V 50 Hz

2 x 5A

DC SYSTEM

slide-33
SLIDE 33

50

CEAG Notlichtsysteme GmbH

Function Test / Battery Mode

1 2 3 4 5 6 20 Battery supply

220V 2 x 5A L N PE 5A 230 V 50 Hz Address / location

slide-34
SLIDE 34

51

CEAG Notlichtsysteme GmbH

ZB-S DALI EVG

D U D

2L-CG-SB

U O U

D1 D2

O

D1 D2

Switch / dimmer Daylight sensor DALI-Controller

Features :

  • New, with Tridonic DALI/DSI function !
  • Unique selling proposition against competitors !
  • Due to integration in a high design light management,

especially for design buildings, like museums

New development: DALI-module 2L-CG-SB

Application

DC SYSTEM

slide-35
SLIDE 35

52

CEAG Notlichtsysteme GmbH

L6 L5 L4 L3 L2 L1

ZB-S 26C6, battery inside the cabinet; 90Ah battery, for the load of 240 luminaires, each of 2x28W and 60 EXIT signs of 10W, dimension per cabinet: H x W x D 2000 x 800 x 600 80 x (2x28)W + 20 x 10 W EXIT sign 80 x (2x28)W + 20 x 10 W EXIT sign 80 x (2x28)W + 20 x 10 W EXIT sign ZB-S 26C6, battery inside the cabinet; 90Ah battery, for the load of 240 luminaires, each of 2x28W and 60 EXIT signs of 10W, dimension per cabinet: H x W x D 2000 x 800 x 600 80 x (2x28)W + 20 x 10 W EXIT sign 80 x (2x28)W + 20 x 10 W EXIT sign 80 x (2x28)W + 20 x 10 W EXIT sign

slide-36
SLIDE 36

53

CEAG Notlichtsysteme GmbH

L6 L5 L4 L3 L2 L1

ZB-S 26C6, battery inside the cabinet; 90Ah battery, for the load of 240 luminaires, each of 2x28W and 60 EXIT signs of 10W, dimension per cabinet: H x W x D 2000 x 800 x 600 L6: 80 x (2x28)W + 20 x 10 W EXIT sign 80 x (2x28)W + 20 x 10 W EXIT sign ZB-S 26C6, battery inside the cabinet; 90Ah battery, for the load of 240 luminaires, each of 2x28W and 60 EXIT signs of 10W, dimension per cabinet: H x W x D 2000 x 800 x 600 80 x (2x28W) + 20 x 10 W EXIT sign 80 x (2x28)W + 20 x 10 W EXIT sign 80 x (2x28)W + 20 x 10 W EXIT sign 80 x (2x28)W + 20 x 10 W EXIT sign

slide-37
SLIDE 37

54

CEAG Notlichtsysteme GmbH

L2 - L23

PC monitoring software: CG Vision

L6 L5 L4 L3 L2 L1

slide-38
SLIDE 38

55

CEAG Notlichtsysteme GmbH

DC SYSTEM

Sub-station 16mm2 of AC & DC Cable CBS & Battery 1.5mm2 cable to lighting

HK Science Park

slide-39
SLIDE 39

56

CEAG Notlichtsysteme GmbH

Tamar HK Gov.天馬艦政府總部

slide-40
SLIDE 40

57

CEAG Notlichtsysteme GmbH

New development: CGVision

Features :

  • Implementation of new CGLine !
  • Constant implemantation of

new features to save the unique selling advantages New Features :

  • Extensive print menu
  • Timer menu
  • Extensive logbook function
  • Building layout as option
slide-41
SLIDE 41

58

CEAG Notlichtsysteme GmbH

Dubai 1994

EML - Market 100 %  Self Contained luminaires 0 %  Central Battery Systems EML - Market 2004 - 80 %  Central Battery Systems End 2007 – 100% must use in CBS

Dubai 2004

slide-42
SLIDE 42

59

CEAG Notlichtsysteme GmbH

Dubai Tower 2008 Water Cube New Bangkok International Airport 7 Star Hotel

slide-43
SLIDE 43

60

CEAG Notlichtsysteme GmbH

Allianz Arena, Munich, Germany (2006 World Cup)

Veltins Arena, Schalke, Germany

slide-44
SLIDE 44

61

CEAG Notlichtsysteme GmbH

Athens International Airport Düsseldorf International Airport New Bangkok International Airport Dubai International Airport

slide-45
SLIDE 45

62

CEAG Notlichtsysteme GmbH

The National Museum of China Airbus (Tianjin) Final Assembly Co., Ltd.

slide-46
SLIDE 46

63

CEAG Notlichtsysteme GmbH

Tamar HKU Science Park

slide-47
SLIDE 47

64

CEAG Notlichtsysteme GmbH

slide-48
SLIDE 48

65

CEAG Notlichtsysteme GmbH
