SLIDE 1

Technical Team Meeting

August 12, 2013

CDOT I-70 Mountain Corridor | HDR Engineering, Inc.

STATE OF COLORADO

DEPARTMENT OF TRANSPORTATION REGION 1 I-70 MTN CORRIDOR PROGRAM

425A CORPORATE CIRLCE - GOLDEN, CO 80401 (720) 497-6900 (OFFICE), (720) 497-6901 (FAX)

I-70 EB Peak Period Shoulder Lane Project

Project Number: NHPP 0703-401 Project Code: 19474

slide-2
SLIDE 2

 Introductions  Where we have been  Where we are  Where we are going  Glossary of terms

Meeting Agenda

8/12/2013 I-70 PPSL Technical Team Meeting #3

2

 Left versus right  Roadway width  Issue-Specific Criteria

 Widening to the

median versus Clear Creek

 Auxiliary lanes

slide-3
SLIDE 3

Background

Where We’ve Been

  • Finalized Context Statement
  • Finalized Core Values
  • Developed Critical Issues and Project Evaluation Criteria
  • Issues heard from Clear Creek County at July 22 meeting

 Is PPSL compliant with the ROD, especially considering

planned infrastructure improvements such as pullouts, rebuilding acceleration and deceleration lanes and replacing bridges?

 How does CDOT intend to address the safety concerns?

Concerns about access for emergency vehicles; room for broken down vehicles, creating unsafe conditions.

 Is an EA more appropriate than a CatEx? Specific concerns are

related to consideration of alternatives and to enforceable mitigation

 Interim/temporary—Will there be a written commitment to an

end date or triggers for when a more permanent solution will be implemented?

 Not convinced that passive management will keep everyone

safe.

 How can economic viability and livability of CCC communities

be protected/enhanced?

8/12/2013 I-70 PPSL Technical Team Meeting #3

3

slide-4
SLIDE 4

Background

Where We Are

  • Left versus Right
  • Roadway Width

8/12/2013 I-70 PPSL Technical Team Meeting #3

4

slide-5
SLIDE 5

Background

Where We Are Going

  • CSS issues tracking schedule
  • CSS issues tracking checklist

8/12/2013 I-70 PPSL Technical Team Meeting #3

5

slide-6
SLIDE 6

CSS Tracking Schedule

8/12/2013 I-70 PPSL Technical Team Meeting #3

6

slide-7
SLIDE 7

CSS Tracking Checklist

8/12/2013 I-70 PPSL Technical Team Meeting #3

7

CSS: Operability Left vs. Right PPSL Feasibility Review CSS: Roadway Definition Median Widening vs. Creek Encroachment Roadway Width Auxiliary Lanes Snow Removal CSS: Structural Components SH 103 Bridge Bridges in General Retaining Walls Noise Abatement (if needed) AGS CSS: Integral Components Emergency Response Location of Pull-Outs Off-Peak Operations Signage Managed Lane Access Aesthetics Water Quality/ Drainage Greenway Noise Initial Environmental Findings Class of Action ROD Compatibility Interim Definition Safety

slide-8
SLIDE 8

Glossary of Terms and Acronyms

  • Acceleration Lane—A lane adjacent to the primary travel lane that allows drivers to accelerate

before merging into traffic on the main road.

  • Auxiliary Lane—Along a highway an auxiliary lane connects entrance and exit ramps, with the

entrance ramp or acceleration lane from one interchange leading to the exit ramp or deceleration lane of the next.

  • Deceleration Lane—A lane adjacent to the primary travel lane that allows drivers to pull off the

main road and decelerate safely in order to turn or exit without slowing the traffic behind.

  • EOP—Edge of pavement
  • General Purpose Lane—A traffic lane that does not have any restrictions, such as time of

day or type of vehicle that may use the lane.

  • Managed Lane—In this case, the managed lane operates during a peak period and traffic

utilizing that lane will be required to pay a toll.

  • Peak Period Shoulder Lane—This is a lane of traffic that may function either as a shoulder

and a managed lane or a shoulder and a general purpose lane, depending on left versus right .

8/12/2013 I-70 PPSL Technical Team Meeting #3

8

slide-9
SLIDE 9

Left Versus Right

8/12/2013 I-70 PPSL Technical Team Meeting #3

9

slide-10
SLIDE 10

Best Practices

8/12/2013 I-70 PPSL Technical Team Meeting #3

10

  • Priced Dynamic Shoulder

Lane (PDSL)

  • Retrofit that converted right

side bus-only shoulder lane to left side PDSL to avoid ramp conflict area

  • MnDOT working to convert

260 miles of bus-only shoulder lane to PDSLs

MnDOT

I-35W

slide-11
SLIDE 11

Best Practices

8/12/2013 I-70 PPSL Technical Team Meeting #3

11

  • Right-side only bus lane

 Bus yields to merging

traffic at on- and off-ramps (bus drivers are specially trained)

  • Left side managed lane
  • Managed through active traffic

management

US 36

slide-12
SLIDE 12

Best Practices

8/12/2013 I-70 PPSL Technical Team Meeting #3

12

  • Right side priced dynamic

shoulder lane for general purpose traffic

  • Full ramp reconfigurations to

accommodate safe acceleration/ deceleration during peak and

  • ff-peak operation
  • Extensive signs and active traffic

management

MnDOT

I-494 (design phase)

slide-13
SLIDE 13

Best Practices

8/12/2013 I-70 PPSL Technical Team Meeting #3

13

  • Right side PPSL for general

purpose traffic

  • No special accommodations at

low volume entrance ramps

  • Provides advanced signing on

ramps to warn motorists

  • Provides emergency turnouts

approximately every ½ mile

  • As a result of a fatal accident new

larger warning signs were added

MassDOT

I-93

slide-14
SLIDE 14

Interchange Applications—Existing Condition and Left Side

8/12/2013 I-70 PPSL Technical Team Meeting #3

14

Left Side

  • Add acceleration lane
  • Estimated 11 signs
  • Requires 103 bridge replacement

Existing

Approximate Existing Edge

  • f Travel Lane

Approximate Existing Edge

  • f Travel Lane

Off-Peak Shoulder

  • No general purpose lanes shifts

between on-peak and off-peak

slide-15
SLIDE 15

Interchange Applications— Existing Condition and Right Side

8/12/2013 I-70 PPSL Technical Team Meeting #3

15

Right Side

  • Possibility to avoid

acceleration lane

  • Estimated 25 signs
  • Increased safety concerns
  • Possibility to modify

Highway 103 bridge

  • General purpose lanes shift

from on-peak to off-peak

Off-Peak General Purpose Lanes Off-Peak Shoulder

slide-16
SLIDE 16

Interchange Options

SH 103: Existing Condition

8/12/2013 I-70 PPSL Technical Team Meeting #3

16

slide-17
SLIDE 17

Primary Differentiators

8/12/2013 I-70 PPSL Technical Team Meeting #3

17

Right Side

  • Possibility to avoid

acceleration lane

  • Estimated 25 signs
  • Increased safety

concerns

  • Possibility to modify 103

bridge

  • General purpose lanes

are shifted between on- peak and off-peak

Left Side

  • Add acceleration

lane

  • Estimated 11 signs
  • Requires 103 bridge

replacement

  • Reduces potential of

head on collisions during off-peak

  • Maintains rumble

strips on right side

  • f shoulder
slide-18
SLIDE 18

Evaluation Matrix

8/12/2013 I-70 PPSL Technical Team Meeting #3

18

See Handout

slide-19
SLIDE 19

Segments

8/12/2013 I-70 PPSL Technical Team Meeting #3

19

  • Segment 1: Empire Junction
  • Segment 2: Lawson
  • Segment 3: Downieville/Dumont
  • Segment 4: Fall River
  • Segment 5: West Idaho Springs
  • Segment 6: SH 103
  • Segment 7: East Idaho Springs
  • Segment 8: Twin Tunnels
slide-20
SLIDE 20

Roadway Width

8/12/2013 I-70 PPSL Technical Team Meeting #3

20

slide-21
SLIDE 21

Typical Sections

8/12/2013 I-70 PPSL Technical Team Meeting #3

21

slide-22
SLIDE 22

Segment 1: Empire Junction Critical Section

8/12/2013 I-70 PPSL Technical Team Meeting #3

22

slide-23
SLIDE 23

Segment 2: Law son Critical Section

8/12/2013 I-70 PPSL Technical Team Meeting #3

23

slide-24
SLIDE 24

Segment 3: Dow nieville/Dumont Critical Section

8/12/2013 I-70 PPSL Technical Team Meeting #3

24

slide-25
SLIDE 25

Segment 4: Fall River Critical Section

8/12/2013 I-70 PPSL Technical Team Meeting #3

25

slide-26
SLIDE 26

Segment 5: West Idaho Springs Critical Section

8/12/2013 I-70 PPSL Technical Team Meeting #3

26

slide-27
SLIDE 27

Segment 6: SH 103 Critical Section

8/12/2013 I-70 PPSL Technical Team Meeting #3

27

slide-28
SLIDE 28

Segment 7: East Idaho Springs Critical Section

8/12/2013 I-70 PPSL Technical Team Meeting #3

28

slide-29
SLIDE 29

Roadw ay Width and Retaining Walls

8/12/2013 I-70 PPSL Technical Team Meeting #3

29

Total Length

2000 4000 6000 8000 10000 12000 14000 ~6,400 ft ~12, 600 ft Feet

Total Length of Walls

40 ft 42 ft

slide-30
SLIDE 30

Roadw ay Width and Retaining Walls

8/12/2013 I-70 PPSL Technical Team Meeting #3

30

Maximum Height

0.0 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0 9.0 ~ 4.0 ~ 8.9 Feet

Maximum Height of Walls

40 ft 42 ft

slide-31
SLIDE 31

Roadw ay Width and Retaining Walls

8/12/2013 I-70 PPSL Technical Team Meeting #3

31

Total Area

5000 10000 15000 20000 25000 ~8,000 ft ~25,000 ft Square Feet

Total Area of Walls

40 ft 42 ft

slide-32
SLIDE 32

Safety

8/12/2013 I-70 PPSL Technical Team Meeting #3

32

  • Driver comfort
  • Lane width
  • Shoulder width
  • Curves
  • Weather
  • Speeds
  • Driver expectation
slide-33
SLIDE 33

Primary Differentiators

8/12/2013 I-70 PPSL Technical Team Meeting #3

33

Pros Cons 40 ft Width

  • Requires 2 feet of widening
  • Maximum wall height of 2.6 4.0

feet

  • Requires 9 less retaining walls (11

total)

  • Requires 50% more feet of walls

(over 6,300 ft)

  • Requires approximately 50% less

total wall length

  • Substandard lane widths
  • Inconsistent with driver expectancy
  • Additional safety concerns

42 ft Width

  • Standard lane widths
  • Consistent with driver expectancy
  • Requires 4 feet of widening
  • Maximum wall height of 8.9 feet
  • Requires 9 more retaining walls (20

total)

slide-34
SLIDE 34

Evaluation Matrix

8/12/2013 I-70 PPSL Technical Team Meeting #3

34

See Handout

slide-35
SLIDE 35

Issues Schedule

Schedule will be used to determine when critical issues will be discussed at the Technical Team meetings.

8/12/2013 I-70 PPSL Technical Team Meeting #3

35

slide-36
SLIDE 36

8/12/2013 I-70 PPSL Technical Team Meeting #3

36

  • Widening to the median or creek
  • Auxiliary lanes

Technical Team input

  • n Issue-Specific

Criteria

slide-37
SLIDE 37

W eek No. Mon Tues W ed Thurs Fri

1 FHWA Afternoons CCC Commission I-70 Coalition Board 10-12 2

PPSL PLT/ TT - Morning

FHWA Afternoons CCC Commission AGS PLT Incident Mgmt/ I-70 Coalition 3 FHWA Afternoons CCC Commission Commission CDOT Accountability Commission 470 Meeting (Afternoon) 4

PPSL PLT/ TT - Morning

FHWA Afternoons CCC Commission T&R PLT Twin Tunnels TT I-25 Region 4

PLT & TT Recurring Meeting Tim e

Meeting Dates

August 26—Idaho Springs September 9—Golden September 23—Idaho Springs All meetings begin at 9:00 a.m.

Meeting Locations: Split between Golden and Idaho Springs

8/12/2013 I-70 PPSL Technical Team Meeting #3

37

slide-38
SLIDE 38

Technical Team Meeting

August 12, 2013

CDOT I-70 Mountain Corridor | HDR Engineering, Inc.

STATE OF COLORADO

DEPARTMENT OF TRANSPORTATION REGION 1 I-70 MTN CORRIDOR PROGRAM

425A CORPORATE CIRLCE - GOLDEN, CO 80401 (720) 497-6900 (OFFICE), (720) 497-6901 (FAX)

I-70 EB Peak Period Shoulder Lane Project

Project Number: NHPP 0703-401 Project Code: 19474

THANK YOU!
