ACCELERATION OF SMALL SCALE LNG SUPPLY CHAIN INFRASTRUCTURE FOR CENTRAL AND EAST REGION OF INDONESIA

Electricity Condition of Central & East Indonesia

2

• The installed capacity of power plants owned by PLN and IPP spread

across Central & Eastern Indonesia s.d. 2014 is approximately 3,842 MW , with most plants are Diesel

• Diesel Power Plant has several weakness :

1. Small engine capacity 2. High operating cost (+/- USD 0.3/kWh) 3. High emission

RUPTL PLN 2015-2024

(MW)

3

Existing Power Plant Capacities in Indonesia Central Region

439.82 752.64 342.36 62.2 6.49 1120.34 177.85 249.69 288.7 194.82 135 555 219 33 24 410 87 57 124 110 Kalimantan Selatan Kaltim and Kaltara Sulawesi Utara Gorontalo Sulawesi Barat Sulawesi Selatan Sulawesi Tenggara Sulawesi Tengah NTB NTT Total Capacity (MW)

• Req. Additional Capacity (MW)

(Source : RUPTL PLN 2014 – 2024)

4

Natural Gas Production in Indonesia

Production of Natural Gas in Indonesia

Source = SKK Migas – IPA Technical Division Presentation

• From 2002, energy in Indonesia is dominated by gas and this trend will

continue in the future

• Production of natural gas in 2016 is approximately 1350 MBOEPD

5

Increasing of Domestic Natural Gas Demand

• Gas allocation policy prioritizes natural gas to supply domestic market
• The prioritized segments are oil lifting, fertilizer feedstock, power plant,

and industry.

• However, there is limitation of natural gas infrastructure.

Production of Natural Gas in Indonesia

Source = SKK Migas – IPA Technical Division Presentation

6

Limitation of Natural Gas Infrasructure

LNG Facility in Indonesia

Source = Indonesian Gas Association Presentation

LNG Receiving Terminal Location : Benoa, Bali Capacity : 50 MMSCFD

7

PLN’s Power Plant Development Plan

8

COMPANY OVERVIEW

PELINDO III

“To create an efficient energy supply chain in central and east region of Indonesia”

• PT. Pelindo Energi Logistik (PT. PEL) is a subsidiary

company of PT. Pelindo Marine Services, an affiliation of

• PT. Pelindo III, which engaged in provision of energy ,

electricity and logistic.

• PT.PEL have been collaborated with PT. Indonesia Power

in LNG Receiving Terminal Project, for supplying gas to the Dual Fuel Engine Power Plant in Pesanggaran, Bali.

VIRTUAL PIPELINE CONCEPT

9

Existing route Bontang Benoa

EXAMPLE: LNG SUPPLY CHAIN AS POWER PLANT FUEL

10

FSRU Gas Pipeline Power Plant LNG Ship Gas Pipeline LNG Ship Power Plant Land Based LNG Terminal

Gas Fuel Power Plant - Infrastructure

11

LNG Terminal (LNG Supplier) LNG Carrier (LNG Shuttle Vessel) LNG Receiving Terminal Jetty LNG Unloading Facility LNG Storage (Land Base / Floating Storage) LNG Regasification Unit BOG Handling Unit Gas Metering Facility LNG Metering Facility Gas Piping System HSE System

Marine Virtual Pipeline

12

13

PT PEL EXISTING PROJECT

LEMBAR

32 MMSCFD

Pipeline

• r

Trucking

2015-2016

SUPPLY FROM BONTANG

2017

SUPPLY FROM BONTANG

2016

SUPPLY TO LOMBOK

LEMBAR

32 MMSCFD

Best solution to 200MW gas-fired power plant at Benoa of Bali, Indonesia

Gas-fired Power Plant Small scale LNG distribution in Indonesia FSU & FRU (Vs. Land LNG Plant)

• 200MW gas-fired power plant at Benoa of Bali (Ready!)
• Its commissioning operation takes place in December 2015

(preparation period is very limited )

• Required gas volume for 200 MW is 40 mmscfd, equaling 40,800

mmbtu/day (1mmscf = 1,020 mmbtu)

• The residents tend to favor energy supply solutions that are situated

far away from where they live.

• Around 50% lower capital costs in comparison to onshore terminal

costs

• Simple permitting (Land LNG Plant is very limited for the permitting)
• Movable to a new location easily and strategically
• Scalable to expand the capacity by adding more vessel-based

storage without additional regas-capacity

• Short term of the terminal construction
• In consideration to an archipelagic state of Indonesia, small scale

LNG distribution is a best way by using a small scale LNG carrier because, to cross an ocean, supercooling the gas into a liquid that can be loaded on to a ship is a more cost-effective way to move the molecules than natural gas moving by pipeline, which works just find on dry land or short distances underwater

• LNG is more preferable energy than coal because policy of the

anti-pollution (Emission reduction), price competitiveness and technology development of the LNG infrastructure

Best solution to supply natural gas to 200MW gas- fired power plant at Benoa

• f Bali

► a small scale LNG

carrier for LNG transportation and FSU & FRU for LNG storage & Re-gasification

PROJECT BACKGROUND

15

SOUTH TERMINAL JETTY, PORT OF BENOA

South Terminal 206 m Jetty

Indonesia Power South Terminal Gas Pipeline

FSU 2nd Hand LNG Carrier FSU New Built

• Oct. 2015  May 2016 (Period of built New FSU)

Bali Project – Facility Plan BALI PROJECT – FACILITY PLAN

LNG Floating Storage Unit (FSU) LNG Floating Regasification Unit (FRU) Small Scale LNG Carrier

LNG Buffer Tank Re-gasification Unit & LNG Feed Pump LNG Feed Pump Room LNG Ship to Ship with Loading Arm, Flexible Hose

FRU

Steam Vaporizer type Capacity : 50 mmscfd Boiler : Dual Fuel Burner

FSU

CCS : Membrane Mark-III Flex Capacity : 26k cbm Generator : Dual Fuel Engine

LNGC

CCS : Bi-Lobe (IMO-C Type) Capacity : 31k cbm Propulsion : Dual Fuel Engine

Bali Project - Facility BALI PROJECT FACILITY

18

EXISTING LNG TERMINAL AT BENOA, BALI (using new-built storage unit)

19

FLOATING REGASIFICATION UNIT FOR BENOA LNG TERMINAL

20

FLOATING REGASIFICATION UNIT FOR BENOA LNG TERMINAL

21
