Providing LNG Supply and Bunkering Solutions

USCG Sector Delaware Bay LNG Bunkering Workshop Margaret Kaigh Doyle

AGENDA

• LNG as Marine Fuel - Why, When, Who
• What is Small Scale LNG
• Developing Infrastructure to support LNG as

Fuel

• Small Scale LNG in Jacksonville, Florida
• The Talleyrand Model – Applicability to the

Northeast

2

LNG AS MARINE FUEL DRIVEN BY ECONOMIC AND REGULATORY FORCES

3

Fuel Cost Spread Emissions Regulation

Shift to LNG as Marine Fuel

4

• The Baltic Sea, the North

Sea, the English Channel, and the coastline of North America are Emission Control Areas (ECAs) where special emission limits apply.

• In October 2016. IMO

members adopted a reduced maximum of 0.5%

• f sulphur content in

marine fuels by 2020.

• Until that deadline, ships

are allowed to use marine fuels with up to 3.50% sulfur which is the current global cap.

5

• Technical/Space

challenges

• High opex
• Effluent
• HFO scarce in the

future

• Low capex

compared to newbuild

• Zero capex
• Need scrubbers to

meet NOX Tier III requirements

• Fuel availability
• High opex

Risks

• Infrastructure
• High capex
• More

containment space needed

LNG MGO SCRUBBERS + HFO

Three Options for ECA Compliance

• Low opex
• Meets SOX,

particulate and NOX Tier III requirements

Fixed Pricing

LNG o

• ffers P

Price Assu Assurance Throughout V Value C Chain

6

WHO IS BULLISH ON LNG ?

7

Fuel Cost Spread Emissions Regulation

• Lloyd’s Register, predicts there will be 653 LNG-powered ships
• f all types by 2025, including 25 cruise ships. LR also

predicted that LNG will account for 11% of cruise ships built during the period, the highest adoption rate of any type of vessel.

• “DNV GL’s assessment of the existing rules, standards and

guidelines shows that from a legal point of view, there are no remaining major showstoppers for the use of LNG as fuel - both for seagoing vessels and inland waterway vessels – nor for the deployment of LNG bunker facilities,” Martin Layfield, global segment leader of the Gas Value Chain, DNV GL – Oil & Gas.

8

• Harvey Gulf International – Currently operating DF
• ffshore vessels
• Tote Maritime – Currently operating DF

Containerships

• BC Ferries – Currently operating DF Ferries
• Transport Desgagne –Taken Delivery of DF Product

Tanker

• Crowley Maritime - Awaiting Delivery of DF

ConRo vessels

• Carnival Cruise Lines – Committed to DF Passenger

Ships

• Matson – Committed to DF Containerships for

Jones Act Fleet

• Pasha Hawaii – Committed to DF Containerships
• AET – Announcement to build DF Aframax Tankers

2017 LNG Fueled Vessels “North American Snapshot”

WHAT IS SMALL SCALE LNG?

9

Emissions Regulation

MULTIPLE SUPPLY PATHS AVAILABLE

10

Liquefaction LNG Trucking Storage LNG Barge Bunkering Vessel Bunkering Vessel

Supply Point Bunkering Port

LNG Rail Shore to Ship Ship to Ship Ship to Ship Rail/Truck to Ship

11

The biggest challenge for the growth of LNG- powered cruising is the rudimentary infrastructure for distributing it at

• ports. “We have to build

it,” Tom Strang, Senior Vice President for Maritime Affairs at Carnival said of an LNG delivery

• infrastructure. “

Travel Weekly, 9/11/16

• The Energy & Minerals Group (EMG) is a private

investment firm with over $15 billion under management.

• EMG targets equity investments of $150 million to $1 billion

in the energy and minerals sectors focused on hard assets that are integral to existing and growing markets.

• Eagle LNG is developing end-to-end LNG solutions

for small-scale export and domestic consumption.

• Eagle LNG Partners is wholly owned by Ferus Natural

Gas Fuels, a portfolio company of the Energy Minerals Group (EMG).

1

1

MAXVILLE In-Service Q2 2017 TALLEYRAND MARINE TERMINAL In-Service Q3 2017 JACKSONVILLE EXPORT FACILITY FERC Permitting

Eagle’s facilities in Florida are strategically located near abundant gas supply, interstate pipelines, transportation hubs and a community receptive to the use of LNG. 1 14

VESSEL LOADING DOCK STORAGE TANK ONE of THREE “TRAINS” TANKER & ISO LOADING

JACKSONVILLE PLANT & TERMINAL – 2019

Liquefaction: 1,650,000 GPD (6,060 m3/d), 550,000 GPD/train Storage Size: 12,000,000 Gallons (45,420 m3)

1

MAXVILLE LNG FACILITY

In service: Q2 2017 Initial Liquefaction: 87,000 GPD (330 m3/d) Max Liquefaction: 200,000 GPD (760 m3/d) Storage Size: 1,000,000 Gallons (3,800 m3)

1

TALLEYRAND LNG BUNKER DEPOT

In service: Q3 2017 Storage Size: 500,000 Gallons (1,890m3) Scalable Storage Capacity

1

A MODEL FOR THE NORTHEAST?

18

• In 2016 Volkswagen announced that it would be chartering two

LNG-fueled ships which will replace two of the nine vessels using heavy fuel oil from 2019 onwards.

• These vessels will be used exclusively for its round trip scheme

across the North Atlantic serving the markets of Canada, the USA, Mexico and Europe.

IS THERE ROOM FOR EVERYONE?

19

THANK YOU FOR THIS OPPORTUNITY

Margaret Kaigh Doyle margaretdoyle@eaglelng.com 508-889-7747
