2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

UNICOS implementation in ISOLDE

Sebastien Blanchard TE/VSC

Interlocks, Controls and Monitoring Section

1 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

Overview

NS

• ISOLDE (On-Line Isotope Mass Separator) is a CERN facility dedicated to the

production of radioactive ion beams for nuclear and atomic physics.

• ISOLDE Vacuum controls drive:
• Vacuum Pumps, Gauges, Valves

(up to five stages of pumping)

• Exhaust System (volatile radioactive elements present in the exhaust

gases)

• Venting System - Automatic venting and re-pumping (Several automatic

intervention per month)

• ISOLDE Vacuum controls are based on
• Siemens S7 PLCs
• WinCC OA (PVSS) SCADA applications.

2 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

ISOLDE Facilities

NS

front-end front-end post accelerator separators 50 meters

Vacuum Control System: 2010: Renovation of ISOLDE Front-Ends, Separators and Experimental hall 2011: Renovation of REX-ISOLDE post accelerator 2014-15: Controls for the new HIE-ISOLDE line ISOLDE + REX: 46 Beam Vacuum Sectors ~ 100 Pumps Vacuum Pressures Specifications:

High Vacuum (10-7mbar) Except EBIS : Ultra High Vacuum (10-11mbar)

3 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

ISOLDE Typical Vacuum Sector

NS

BEAM VACUUM SECTOR

GAUGES

OTHER SECTORS

OTHER SECTORS VENTING SYSTEM EXHAUST SYSTEM: GAS STORAGE OTHER SECTORS OTHER Pump Groups

PRIMARY PUMP GROUP CRYO PUMP GROUP TURBO PUMP GROUP PRIMARY PUMP GROUP

OTHER BEAM VACUUM SECTORS SECTOR SECTOR Ventillation Duct Radiation Protection Lab

TURBO PUMP GROUP

4 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

PROCESSES CONTROL SCHEMA

NS

Client Process (Pump or Sector) Pump or Storage Process

Pump “Token” Request Gives “Token” Enable Client Valve opening

Client Process (Pump or Sector)

Pump “Token” Request Gives “Token” Enable Client Valve opening

Beam Vacuum Sector Process Turbo Pump Process Cryo Pump Process “Token” Primary Pump Process Primary Pump Process Storage Pumps System Process Request “Token” Other Vacuum Sector Processes “Token” Request Request Request Request Request Allows Allows Allows Allows Allows Allows

5 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

ISOLDE Vacuum Controls Architecture

NS

Profibus Active Gauges

6 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

Hardware Interlocks

NS

…

Complete list in the User Manual : https://edms.cern.ch/document/1083275 Layout of control racks: https://edms.cern.ch/document/1083960 Location of control crates: https://edms.cern.ch/document/1083958

In order to reduce costs, controls crates are installed close to the vacuum devices, so the control crate location number is rather large

For NEXT Vacuum Control System keeping the same HW Interlocks schema:

• Direct from TPG300 Relay
• Via dedicated HW Multiplexer/Interlocks Crates
• Using PLC Output (Slow/Processes Interlocks)
• Monitoring all the Status of HW Interlocks generated by vacuum controls (this

functionnality shall be updated)

7 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

ISOLDE Hardware Architecture

NS Controllers Restricted access Vacuum sectors

Profibus-DP Network

Controllers Located next to the vacuum equipments

Advantage : Reduce Cabling Price Disadvantage: Scattered HW Controls

8 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

Software PLC/SCADA: UNICOS-CPC Framework

NS Process Logic Specifications

PLC Software Code UNICOS-CPC (1) Baseline Library Excel file Specifications(2) SCADA Objects Vacuum Layout Vacuum Baseline Functions Library for UNICOS-CPC(2) Grafcet Functions(2) UNICOS-CPC(1) Generator

SCADA Panel Templates(2)

SCADA Project PLC Project

PLC Functions Templates(2) UNICOS-CPC(1) SCADA Framework PLC Based Code (UNICOS- CPC) Compilation

(1) UNICOS-CPC (UNified Industrial COntrol System) Framework developed by CERN Industrial Controls&Engineering Group to produce easily full control and monitoring applications (2) PLC functions, Grafcet functions and “vacuum” library were created especially for the vacuum system of ISOLDE.

9 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

PVSS Main Panel

NS

Monitoring: With 1 Sight you can check that Vacuum Status is OK !

10 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

PVSS Panel: Steppers

NS 11 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

PVSS Panel: Diagnostics

NS

Start/Open Interlock (Open disable): Stop/Close Interlock (Full interlock):

12 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

PVSS Panel: Exhaust System

NS

Volatile radioactive elements present in the exhaust gases : All the pumping gases are stored

From backing pumps stage

13 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

Operation Feedback: Issues during automatic restart of the Vacuum System

NS

After system interrupt (Ex: Power Cut) the System automatically restarts. Reminder: Due to the possible presence of volatile radioactive elements into beam sectors, the pumping gas is stored into tanks.

 The system has a lot of timeout to avoid filling exhaust tanks with gas pumped

coming from leaks. These timeouts active Full Stop alarms (need to be acknowledge to restart) and Temporary Stop alarms. These Full Stops cause automatic restart interrupt. Updated in 2011 and 2012

• 1. Timeouts are parameterized and fit to each sector characteristics
• 2. Some Full Stops are re-qualified to Temporary Stops

For new development

• A. Minimized Full Stops and Alarms numbers

14 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

Operation Feedback: Issues with complex processes

NS

Some processes had complex steppers and logics  cause some interrupts Updated in 2012

• 1. Process has been simplified and the seldom operation is now manual

Examples of updates:

• Penning gauges automatic switch Off by PLC only in case of Venting

Request

• Restart and Regeneration of cryo pumps have been simplified
• ...

For new deployments

• A. Keep processes and steppers as simple as possible
• B. Keep manual the seldom task

15 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

New Project HIE ISOLDE

NS

Cryo RF Modules

16 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

New Project HIE ISOLDE Vacuum Controls Cryo Module layout

NS

x 6 Cryo Module Sectors

17 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

New Project HIE ISOLDE Vacuum Controls Architecture

NS 18 of 19

2013-03-05 ISOLDE Vacuum Controls (CERN-GSI WS), S. Blanchard TE-VSC-ICM

New Project HIE ISOLDE Vacuum Controls Architecture

NS

Profibus-DP Network Profibus-DP Network for Gauges

Still don’t know if beam vacuum sectors will be completely or partially restricted areas, so 2 locations for vacuum control crates is foreseen… not so close from vacuum devices!

Cryo Module Sector x 6

Signal Cables

Transfert Lines

Experiments

Sig Cables

19 of 19
