Santee Court Market & Food Hall Concept Los Angeles, CA Essex Property Trust July 11 2017
Contents Site Plan 3 Market | Bldg. 700 4 Concept Diagram Imagery Plan Conceptual Interior Views Program Summary Food Hall | Bldg. 718 10 Concept Diagram Imagery Plan Conceptual Interior Views Program Summary
Buildings 700 & 718 Site Plan LOS ANGELES STREET BLDG 718 BLDG 700 7 TH STR E ET COURTYARD SEAT COUNT BLDG 700 263 BLDG 718 210 FUTURE PROPOSED TRA S H COURTYARD 77 BUILDING BY OTHERS SCALE 1/32” = 1’-0” 0 8 16 32 64 July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 3
Building 700 Market Concept FOOD HALL ACCESS FUTURE RESIDENTIAL VIEW 2 R R R R E E E E S S S S T T T T A A A A C U U U U O R R R R R M A A A A T N N N N M A T T T T T B U L N E A S L VIEW 1 July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 4
Building 700 July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 5
Building 700 First Floor Plan Food Vendor Common Area Restrooms Service Operations Roof Deck Plan 6 5 E D Notes: 1. Trash facility to be remote 2. Employee lockers/changing rooms to be remote 3. Plans are conceptual in nature and not based off of a fi eld survey. SCALE 1/16” = 4 8 16 32 0 July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 6
Building 700 Conceptual Interior Views July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 7
Building 700 Conceptual Interior Views July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 8
Building 700 Program Summary BUILDING 700 AREA ALLOCATION PROPOSED - S111 Area Total Sq. Ft. % of Space Common Area FFE Inter 3849 33.7% Rest Rooms 528 4.6% Common Walk In 597 5.2% Common Scullery 280 2.4% Operations 154 1.3% Food Total Sq. Ft. Avg. Sq. Ft. Service by Type per Unit Food Service w/Bar (seating) 5523 48.3% 11 5,523 502 Grab n' Go 498 4.4% 3 498 166 11429 100% Total Food Service Units 14 Total Food Service Square Footage 6,021 53% % of Overall Space PLUMBING COUNTS Bathtubs/Sh Drinking Occupant Total Occupants By Water Closets Urinals Lavatories Other Total Sq. Ft. owers Fountains Load Factor Occupants Gender Male Female Male Female Common Areas (A-2) 2 3 1 1 1 0 1 1 service sink or laundry tray 3849 30 128.3 129 64.2 65 Food Stalls/Behind Counter (B) 1 2 1 1 1 0 1 1 service sink or laundry tray 6455 200 32.3 33 16.1 17 Storage (S-2) 1 1 0 1 1 0 1 1 service sink or laundry tray 597 5000 0.1 1 0.1 1 4 6 2 3 3 0 3 3 service sinks or laundry trays 10901 163 SEATING COUNTS Counter 122 Common 141 Patio 24 287 July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 9
Building 718 Food Hall Concept DECK EXTENSION RESTAURANT R E T N U O E C L B A T L A N U H M M C O C N U L July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 10
Building 718 July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 11
Building 718 First Floor Plan Food Vendor Common Area Restrooms Service Operations Notes: 1. Trash facility to be remote 2. Employee lockers/changing rooms to be remote 3. Plans are conceptual in nature and not based off of a fi eld survey. SCALE 1/16” = 4 8 16 32 0 July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 12
Building 718 Conceptual Interior Views July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 13
Building 718 Conceptual Interior Views July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 14
Building 718 Conceptual Interior Views July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 15
Building 718 Program Summary BUILDING 718 AREA ALLOCATION PROPOSED - S111 Area Total Sq. Ft. % of Space Common Area FFE Inter 3449 34.6% Rest Rooms 668 6.7% Operations 90 0.9% Food Total Sq. Ft. Avg. Sq. Ft. Service by Type per Unit Food Service w/Bar (seating) 5758 57.8% 7 5,758 823 9965 100% PLUMBING COUNTS Bathtubs/S Drinking Occupant Total Occupants By Water Closets Lavatories Urinals Other Total Sq. Ft. howers Fountains Load Factor Occupants Gender Male Female Male Female Common Areas (A-2) 2 3 1 1 1 0 1 1 service sink or laundry tray 3449 30 115.0 115 57.5 Food Stalls/Behind Counter (B) 1 1 1 1 1 0 1 1 service sink or laundry tray 5848 200 29.2 30 14.6 Storage (S-2) 0 0 0 0 0 0 0 0 service sink or laundry tray 5000 0 0 0 3 4 2 2 2 0 2 2 service sinks or laundry trays 9297 145 SEATING COUNTS Counter 60 Common (interior) 150 Patio 53 263 July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 16
Alley Conceptual Exterior View July 2017 | Essex Property Trust, Inc. | Santee Court | Market Concept | 15087 17
