River Suir Sustainable Transport Bridge

Elected Representatives Presentation | July 12th, 2018

River Suir Sustainable Transport Bridge

BACKGROUND:

• Waterford City and County Council is working to progress

the key infrastructural upgrades necessary to underpin the functional viability and future success of the North Quays.

• The proposed upgrades include the following:
• Sustainable Transport Bridge
• South Plaza
• Consultants Roughan & O’Donovan were appointed to

progress the scheme through the statutory approvals stage.

Roughan & O’Donovan Consulting Engineers

River Suir Sustainable Transport Bridge

SDZ Scheme Master Plan:

FERRYBANK SDZ BOUNDARY NORTH QUAY SOUTH QUAY PROPOSED RIVER SUIR SUSTAINABLE TRANSPORT BRIDGE

River Suir Sustainable Transport Bridge

CORE OBJECTIVES:

• Connectivity– historic and future, south & north quay
• Concept– simple, elegant and sympathetic
• Public Amenity– link between Waterford & New Ross Greenways
• Safety and Comfort for users

KEY REQUIREMENTS:

• Public amenity affording greater appreciation and enjoyment of the River Suir
• Provide a simple, elegant and efficient solution
• Convey a reduced perceived length of the bridge
• A 25m opening section to permit river traffic
• Appropriate control location and structure for opening bridge
• Design for pedestrians, cyclists and a courtesy bus
• Wind protection
• Protection bollard on both sides of the river

Presentation Title Here

PROPOSED SOLUTION

Presentation Title Here

PROPOSED SOLUTION HOW DID WE ARRIVE HERE?

River Suir Sustainable Transport Bridge

CONNECTIVITY: Linking North and South Quays

• Reviving historical link
• Transform River Suir from a barrier to a conduit
• Accessibility:
• Train and bus stations
• SDZ– retail/ commercial/ residential
• Residential– Ferrybank etc…

River Suir Sustainable Transport Bridge

CONNECTIVITY: Interface with South Plaza

River Suir Sustainable Transport Bridge

CONNECTIVITY: Interface with South Plaza

Roughan & O’Donovan Consulting Engineers

River Suir Sustainable Transport Bridge

CONCEPT: Structural Form

• Preservation of existing views
• Topography
• Link to River Suir
• Minimise physical footprint
• Slender, aesthetic design
• Environmental concerns

CONCEPT: Development of the Bridge Outline

River Suir Sustainable Transport Bridge

PUBLIC AMENITY: A new way to experience the River Suir

River Suir Sustainable Transport Bridge

SAFETY AND COMFORT:

• Viewing/ resting platforms
• Splayed ends
• Wind shielding
• Feature lighting
• CCTV to discourage loitering
• Delineation
• Street furniture and finishes
• Planting

River Suir Sustainable Transport Bridge

Roughan & O’Donovan Consulting Engineers

River Suir Sustainable Transport Bridge

ADDITIONAL FACTORS CONSIDERED:

• Existing marina
• Loss of car parking
• Vessel collision impact
• Mixed use of the bridge
• Interface with North Quay Development
• Environmental impacts

Presentation Title Here

River Suir Sustainable Transport Bridge

BRIDGE DETAILS:

• Shared space for pedestrians, cyclists, courtesy bus
• Total length 207m (5 Spans)
• Slender steel bridge deck
• Concrete piers
• Reduced maintenance
• Opening bascule, 25m wide navigable channel

PUBLIC CONSULTATION PROCESS

• Key aspects
• Opportunity for Project Team to answer questions from

the public

• Invitation for submissions and
• bservations
• Open to public
• Brochure distributed
• When
• 18th July, from 4pm to 8pm
• Where
• The Granary building, WIT School of Architecture,

Merchants Quay, Waterford

River Suir Sustainable Transport Bridge

THANK YOU FOR YOUR ATTENTION Questions & Answers
