Returned truck wash out tank Drained reclaimed water tank for - PowerPoint PPT Presentation

Dec 26, 2023 •242 likes •342 views

Returned truck wash out tank Drained reclaimed water tank for settlement Wash out water tank pumped into Filter Press Small 3 plate press operating at 1L/s Reclaimed water Before and After Filter Press Reclaimed water Before and After Filter

Returned truck wash out tank
Drained reclaimed water tank – for settlement
Wash out water tank pumped into Filter Press Small 3 plate press operating at 1L/s
Reclaimed water Before and After Filter Press
Reclaimed water Before and After Filter Press
Filter Cake of cement and other fines on plate 1 of 4 After one hour = 3,600L of filtered water
• Operation of a Filter Press allows re-use of the wash out water without the need for long settlement periods in a tank. • Reduced maintenance costs with reduced usage of vacuum trucks for cleaning out settled tank solids. • Minimal maintenance required • Diaphragm pump runs on compressed air • Unit available in manual or automatic ram operated press
When the Filter Press is combined with a WAM CONSEP concrete reclamation system the truck wash out can be reclaimed down to:  Large Aggregate – Stone  Small Aggregate – Sand  Clean Water (Filquip CO2 PH Neutralisation system may be required)  Cement Fines
