D E L I V E R I N G I N N O V A T I O N Dynamic Spectrum Arbitrage (DSA) Radio Club of America Nov 21 st 2015 1 1 1 Dynamic Spectrum Arbitrage (DSA) Intro DSA Decouples Spectrum ownership and wireless service Allows wireless

slide-1
SLIDE 1

D E L I V E R I N G I N N O V A T I O N

1

Dynamic Spectrum Arbitrage (DSA) Radio Club of America Nov 21st 2015

1 1

slide-2
SLIDE 2
  • DSA Decouples Spectrum ownership and wireless service
  • Allows wireless operators to lease excess capacity to other wireless
  • perators and MVNOs and monetize underutilized resources

– Competitors – Non-traditional – Roaming Partners

  • Making excess capacity available for lease dynamically

– Rivada DSA Technology allows for a dynamic bandwidth open access marketplace – Will lead to Commoditization of Spectrum (a whole new industry)  Possible enhancement to the present licensing process used by regulators (FCC)

Dynamic Spectrum Arbitrage (DSA) Intro

2

slide-3
SLIDE 3
  • DSA does not require provisioning the uSIM on the subscriber

handset

  • DSA does not require a mobile application or modification to the OS
  • n a subscriber handset
  • DSA enables dynamic usage consumption and tracking in geographic

defined areas

  • DSA works with multiple subscriber OS platforms such as Android

and iOS

  • DSA fosters innovations in wireless technology adoption

Dynamic Spectrum Arbitrage (DSA) Intro

3

slide-4
SLIDE 4

Imitation is the highest form

  • f flattery…
  • LSA (Licensed Shared

Access)

  • Delivers the equivalent of

DSA without a marketplace to maximize the value of dynamically shared spectrum

Technology Overview

4 4

slide-5
SLIDE 5

OMC/NMS Dynamic Spectrum Controller DSL Policy Controller OMC/NMS Dynamic Spectrum Controller Wireless Network Wireless Network

DPC and DSC

  • Network Operator identified by PLMN-id

5

Technology Overview

slide-6
SLIDE 6

Dynamic Policy Controller (DPC)

  • Coordinates resource allocations between networks

Dynamic Spectrum Controller (DSC)

  • Manages Lease for Lessee or Lessor network

Bid Manager (GAA)

  • Creates Lease parameters
  • Bidding entry for Lessee

Element Management Systems (EMS)

  • Separate EMS for each DPC and DSC
  • Used to configure DPC or DSC
  • Performs O&M Function for DPC or DSC

Arbitrage Entity (AE)

  • Interface between DSA and Trading Platforms
  • Publishes Leases
  • Informs DPC to deliver lease

DSA Nodes

6

slide-7
SLIDE 7

DSAFlex

Improves DSA Architecture flexibility

  • DSAFlex = flexible integration approach by offering several approaches

– DSAX : X Interfaces – DSA9 : MOCN approach (100% 3GPP) – DSA-Lite : Pure Roaming (100% 3GPP)

  • DSA9 and DSA-Lite architecture do not need the X interface Service Packs (SP)
  • DSA-X remains Rivada’s preferred integration approach for the long term

7

Technology Overview

slide-8
SLIDE 8

DSAX

  • Optimal solution, as it has all

the features and capabilities for DSA

  • Requires Software Packs (SP)

to be implemented in OEM nodes

Technology Overview

8

AE DPC

DPC O&M/EMS P-GW MME S-GW HSS PCRF SPR eNB G x Sp P-GW MME S-GW HSS eNB PCRF SPR Sp

s10 X h Xe Xm Xh Xe Xm S6a S6a S8 S8

Lessor LTE Network Lessee LTE Network Security Gatway Security Gatway Security Gatway Security Gateway Security Gateway

DSC O&M/EMS O&M O&M OFCS OFCS

Lessee DSC Lessor DSC

X g a a

DSC O&M/EMS

Xgd

GAA Bid Manager

X g d Xgaa

GAA Bid Manager

Commodity Exchange Commodity Exchange

slide-9
SLIDE 9

DSA9

  • Uses RAN Sharing approach

between networks (MOCN)

  • DSA implemented using existing

OEM features

  • Enables Rivada open access

marketplace

  • No SP or X interfaces required
  • 100% 3GPP Standards approach

Technology Overview

9

P-GW MME S-GW HSS PCRF SPR eNB Gx Sp

Lessor LTE Network Lessee LTE Network Security Gateway Security Gateway

O&M

S 1

  • M

S !

  • U

S1-M S !

  • U

OFCS P-GW MME S-GW HSS PCRF SPR Gx Sp O&M OFCS

Lessee Lessor eNB S1-M C

Commodity Exchange

DPC

DPC O&M/EMS

Lessee DSC Lessor DSC

Xgaa Xgaa

Security Gatway

Xa

Security Gatway Security Gatway

DSC O&M/EMS DSC O&M/EMS

Xgd

AE

Commodity Exchange GAA Bid Manager

Xgd

GAA Bid Manager

X2 X 2

slide-10
SLIDE 10

DSA-Lite

  • Pure Roaming process
  • Roaming is supported by all

OEMs and Wireless operators today

  • Enables Rivada open access

marketplace

  • 100% 3GPP Standards approach
  • MVNO approach

Technology Overview

Commodity Exchange DPC

DPC O&M/EMS

Lessee DSC Lessor DSC GAA Bid Manager GAA Bid Manager

P-GW MME S-GW HSS PCRF SPR eNB G x Sp P-GW MME S-GW HSS PCRF SPR Sp

X d Xd

Lessor LTE Network Lessee LTE Network

Security Gatway Security Gatway Security Gatway Security Gateway Security Gateway

DSC O&M/EMS DSC O&M/EMS O&M

S8 S8

OFCS O&M OFCS

S1-M S!-U

eNB

10

slide-11
SLIDE 11

DSA Lease Grid

11

1 4 5 3 6 7 8 9 Sector or Cell Grid Region 202 Sub Sector Cell Region (BU) 201 Cell Site Level 203 Region 1 204 2

(0,0,0) (1,0,0) (0,1,0) (1,1,0) (1,1,1) (0,1,1) (1,0,1) (0,0,1) Bandwidth Unit (BU) A B C

Broadband Orthogonal Resource Grouping

3,0,0 3.2.0 0,0,0 0,0,z1 2,0,z1 2,2,z2

slide-12
SLIDE 12

GAA

12

slide-13
SLIDE 13

DSA IPR

13

Financial Domain Policy Domain Network Domain Subscriber Domain

AE DPC O&M/EMS

Security Gatway Commodity Exchange OTC 8717929- Telecom Exchange (TCE) for Dynamic Spectrum Arbitrage

DPC GAA

Security Gatway Security Gatway

GAA

Security Gatway Security Gatway

DSC P-GW MME S-GW HSS eNB PCRF

S6a S8

Lessee LTE Network O & M O F C S DSC O&M/EMS P-GW MME S-GW HSS eNB PCRF

Xe Xm S6a S8

Lessor LTE Network O & M O F C S

Security Gatway Security Gatway

DSC DSC O&M/EMS

M i c O n / O f f M i c O n / O f f M i c O n / O f f Smart Phone Relay Relay 8068808- Service Access during emergency for wireless handsets (uSIM/PRL) 8086280- Wireless Relay Network (Class1 Dev1) 8280344-Dynamic Telephone Directory for Wireless Handsets 8275349-Tiered Priority Access to Communication Network Resources- reserviing resources 8611848-Tiered Priority Access to Communication Network Resources- Advanced Roaming capability for emergency communication 8892066-Pre-Empting a non TPA user in place of a TPA user and allocating radio resources for TPA specific use 9094899- DSA using Grid System enabling a subscriber to use resourses that are leased in a geographic area 8934439-DSA/Grid Negotiating a resource leasing scheme between networks and coordinating a handover between leasee and lessor networks based on geographic boundaries defied in the lease parameters. 8711721-Dynamic Spectrum Arbitrage for allocating telecom resources from one telecom network to another 8279786-DSA for a Public Safety System 8670403-DSA resource pooling allocation for leasing 8964685- DSA one network auctions part of its network resources to another network following a set of predetermined rules including capacity, network boundry, network quality of service (QoS), a geodedic parameters along with time and duration of the resources being made available. 8837418-Dynamic QoS for DSA where Lessor DSC communicates with lessee PCRF to adjust QoS of lessee subscribers on lessor network 9094958- DSA where the subscriber profile is changed for leasing indicating if it is elibable for DSA and services it is allowed with it profile including QoS 9088989 - Methods and Systems for Dynamic Spectrum Arbitrage -Congestion Management. Tiered priority and throttling bandwdith Xe 13/664,819- Tiered Priority eNB user and resource throttling 14/287,088-Dynamic Spectrum Arbitrag DSA Policy driven QoS_V0.1 14/287/090-Method and System for Dynamic Spectrum Arbitrage DPC to DSC inteface communication 14/287092-DPC to DSC bidding information communication 14/287/097-DSA Data context and management at DSC and DPC 14/287/099 -DSA - Geoboundaries and UE selection for HandIn 14/591,095-DSA for Availabile Spectrum Assignments 14/287/105- DSA eNB Transition States 14/287,108 DSA HeNB Femto Cell 14/287/111 DSA Mobility Management 13/627,576- Communication Relay Module – Body Worn 13/627666-Video and Communication Relay Module Relay Data from one device to another 13/668,511-Enhanced Display for Breathing Apparatus Masks 8787944 – eLBS – improved location using mobiles to group together through triangulation 14/293,056- eLBS -location position improvement GPS (3D) 62/089937 - ELBS logic flow and Psuedo Waypoint 62/102853- ELBS Trilateration Process 14/690712- ELBS Kalman Filter in eLBS, eLBS Communication Flow between peer devices 14.735210 - eLBS Dead Recking process 14/703,204 Methods and Systems for GAAs 14/713,358 Methods and Systems for DSA with a Mobility Load Banacer Gateway 62/133844 Method and System for a Flexible Dynamic Arbitrage System (DSA Flex) Xm

Location Improvement First Responder Financial Domain Policy Domain Network Domain Device Domain

2015202708 Methods and Systems for DSA – Pooling Resources

Handset

13.910790- Diverse Multiple Carrier Aggregation on Handset 62/114,956 Transportation Resource Grouping and Reallocation 14/740,596 DSA Cell Selection and Virtual Bid (QoS and User Profile) 14/740520 – DSA User Profile Mangement 14/807975Method and System for Broadband Orthogonal Resource Grouping (BORG) 14/843072 Method and Systems for Wireless Telecom Fracking Social Economics (WTF) 14/823294- eLBS 3D with no GPS 14/823,244 - eLBS with no Geospacial System Available (3D) 14/834758- eLBS Mobile Grouping 3D 14/834790 eLBS using and External Location Based Server 62/179239 – DSA and MVNe

Handset

8934373-DSA with mobile using different frequency bands and utilizing multiple networks to achieve service
slide-14
SLIDE 14

DSA is covered under the following patents that have been granted both domestic US and international. Other patent applications have been filed as well. 8068808 , 8086280 , 8,280,3448275349 ,8279786 , 8611848 ,8670403 ,8711721,8717929, 8,787,944 8837418 ,8892066 ,8934439 ,8934373 ,8964685 , 13/773,725 ,2013/01213, 2012296566 , 1469429 325864, 2,843,913 , 2014101509 ,9,088,989

14

Patents

14

slide-15
SLIDE 15

Thank-you Questions?

Clint Smith PE CTO Rivada Networks www.rivada.com

15

Q&A

15
