SLIDE 1

Product Presentation

V1.7

CONNECTION ELECTRONICS LTD.

SLIDE 2

2

Hardware Components

X200E Enterprise iPBX Server
E800 RFID Phone
E800H RFID Phone
E800HC25 2.5mm Headset Cable Adapter
1-Port T1/E1 Card with Echo Cancellation
2-Port T1/E1 Card with Echo Cancellation
GXW-4108 IP Gateway (8 FXO)

pot- 30 iPBX System

SLIDE 3

3

Headset E800H RFID IP Phone

Support Headset with 2.5mm Connector
Nokia Headset
WH-200
Freemate Headset
DH-7C
DH-027TP
Need E800HC25 Cable Adapter

pot- 30 iPBX System

SLIDE 4

4

X200E iPBX Server

pot- 30 iPBX System

Low Power Intel Atom Dual Core Processes
RAID-1 Enterprise Grade Harddisk
Support PSTN trunk lines, ISDN PRI T1/E1 trunk lines

(IDA-P), SIP trunk lines, HKBN 2B IP trunk lines

Max 150 stations
Max 50 concurrent calls

SLIDE 5

5

E800/E800H RFID IP Phone

pot- 30 iPBX System

Handle Max 4 Calls/Lines
Built-in RFID Reader
Selective Ring Tone
Speakerphone

SLIDE 6

6

Softphone - iaxLite

Install Version

http://www.iaxtalk.com/downloads/iaxlite_setup.zip

Portable Version

http://www.iaxtalk.com/downloads/iaxLite_traveller.zip pot- 30 iPBX System

SLIDE 7

7

Hong Kong Awards for Industries Design Award

pot- 30 iPBX System

SLIDE 8

8

Road Warriors Application

pot- 30 iPBX System

PSTN Internet ITSP LAN E800 RFID IP Phones Public Switched Telephone Network Internet Telephone Service Provider Soft-phone Soft-phone

Office

Broadband Vpot-30 iPBX Telephone lines

Cafe

WiFi

Hotel

SLIDE 9

9

Chain Stores Application

pot- 30 iPBX System

SLIDE 10

10

Branch Offices Application

pot- 30 iPBX System

HK PSTN Internet LAN E800 RFID IP Phone Public Switched Telephone Network

HK Office

Broadband Vpot-30 iPBX Telephone lines China PSTN LAN E800 RFID IP Phone

China Office

Broadband Vpot-30 iPBX Telephone lines

SLIDE 11

11

Demo Unit Setup

pot- 30 iPBX System

SLIDE 12

12

Innovative Features

RFID Login/Logout
RFID Toll Call Control
RFID Attendence
Recording on Demand
Call Record to Email
Conference Call Recording
Preset Extension Recording
Walk-in Conference

pot- 30 iPBX System

SLIDE 13

13

Innovative Features

Phonebook
IP Phone Phonebook
Portal/Web Phonebook
Voice Memo
Voicemail to Email
Extension Anywhere
Remote Extension

pot- 30 iPBX System

SLIDE 14

14

RFID Login/Logout

Scanning RFID Card on IP Phone.
After login, the station become the user’s

extension with all preset features.

After logout, forward the calls to user’s

mobile phone automatically.

One Touch Restore Status.
Station Sharing.
Mobile Users.
One Number Only.

pot- 30 iPBX System

SLIDE 15

15

RFID Toll Call Control

Scan RFID Card to upgrade the dialing

class temporary.

No Account Code Require.

pot- 30 iPBX System

SLIDE 16

16

RFID Attendence

Scanning RFID staff card on IP Phone.
The log record can be used for Time

Attendance System application.

Every IP Phone is a RFID Reader

pot- 30 iPBX System

SLIDE 17

17

Recording on Demand

Press REC softkey to start and stop

recording the call.

Call Record to Email.
An Important Feature for Financial,

Banking, Accounting and Law firms.

Unified Communications Application.

pot- 30 iPBX System

SLIDE 18

18

Conference Call Recording

Recording Conference Calls.
Call Record to Email for records and

meeting memo purpose.

Unified Communications Application.

pot- 30 iPBX System

SLIDE 19

19

Preset Extension Recording

Record All Call of Preset Extension.
Call Record to Email for record.
An Important Feature for Financial,

Banking, Accounting and Law firms.

pot- 30 iPBX System

SLIDE 20

20

Walk-in Conference

Multi-Parties Conference.
Users dial password to enter conference.

pot- 30 iPBX System

SLIDE 21

21

Phonebook

3 Phonebooks per User.
Different phonebooks can be assigned to

each user by Admintration.

Name Search in IP Phone.
Dial by Name.

pot- 30 iPBX System

SLIDE 22

22

Portal/Web Phonebook

Unified Communications Application.
Access by Web Browser.
Mobile Phonebook.

pot- 30 iPBX System

SLIDE 23

23

Portal/Web Phonebook

Auto-bind to User's IP Phone.
3 Phonebooks per User.
Intelligent Name Search.
Dial by Name.
Click to Dial.
Phonebook Editing.
No Software Install.
No H/W & OS Conflict.

pot- 30 iPBX System

SLIDE 24

24

Voice Memo

One Touch Softkey to leave a Voice Memo.
Voice Memo is stored in Voicemail Box.
Voice Memo is sent through Email.
Desktop Recorder.
Face to Face Conversation Recorder.

pot- 30 iPBX System

SLIDE 25

25

Voicemail to Email

Voicemail is sent through Email.
Retrieve voicemail by PC or notebook.
Unified Communications Application.
Mobile Staff.

pot- 30 iPBX System

SLIDE 26

26

Extension Anywhere

User call to the company.
System authenticate user with Caller ID.
No password & account number is

required.

Remote Access Voicemail Box, make IDD

calls, Dial to extension user.....

pot- 30 iPBX System

SLIDE 27

27

Remote Extension/Home Office

Install IP Phone in any remote site.
Connect to Vpot-30 Server through Internet

Boardband connection.

IP Phone become an extension station.
For Remote Office
For Remote Staff/Home Office.

pot- 30 iPBX System

SLIDE 28

28

Other Features

SYSTEM FEATURES

License Management
System Backup
Flexible Dialing-Class/Toll Control: White List/Black List
Softphone Support
Common Speed Dialing
Personal Speed Dialing
Day/Night Mode Greeting Auto-switching
Distinction Ring PatternTone for Incoming/Intercom/callback call
Auto-Attendant / DISA
Easy IP Phone Setup
Data Path Condition Monitor

pot- 30 iPBX System

SLIDE 29

29

Other Features

E800/E800H IP PHONE FEATURES

Built-in RFID Reader
Handling Max 4 calls
LCD Display
Soft Keys
Programmable One Touch Function Keys & Turbo Function Keys
4 Line Keys w/ Three Colors LED
CONF Key w/ Three Colors LED
Transfer Key, Hold Key, Mute Key, Call Log Key
Selective Ring Tone
Speakerphone
Headset Support (E800H)
Upgrade Firmware on LAN

pot- 30 iPBX System

SLIDE 30

30

Other Features

CALL OPERATION FEATURES

Intercom Call / Outgoing Call
Traditional & Mobile Phone Dialing
Second (trunk) dialing tone
Red/Green LED Colour indicate trunk/intercom call
Switching calls w/ Line Keys L1-L4
Call Transfer: Consulting/Blind Transfer/Switch-back
Call Transfer to Trunk
Call Transfer to On-hold Party
Call Park
Call Splitting
Call Waiting
Call Hold

pot- 30 iPBX System

SLIDE 31

31

Other Features

CALL OPERATION FEATURES

Multiple Parties Conference by CONF Key
Mute
Caller Name/Number Display
Group Ringing
Call Pickup – Group
Call Pickup – Extension
Call Reject
Group Pickup
Caller ID Direct Dial Inward
Voicemail Indication

pot- 30 iPBX System

SLIDE 32

32

Other Features

PAGING

Paging to Group
Paging to Individual
Paging to External PA

CALL FORWARDING

Call Forwarding: No Answer
Call Forwarding: Busy
Call Forwarding: All Calls
Call Forwarding to Mobile
Do Not Distrib (DND)
One touch Call Forward to Mobile Phone - Long Press TRANSFER Key
One touch Do Not Disturb - Long Press HOLD Key

pot- 30 iPBX System

SLIDE 33

33

Other Features

CALL LOG

Call Log Display – All Calls
Call Log Display – Missed Calls
Call Log Display – Dialed Calls
Call Log Display – Received Calls
Call Log Redial
Missed Call Indication

pot- 30 iPBX System

SLIDE 34

34

Q&A

………

pot- 30 iPBX System
