PROCESS LEVEL ENERGY MANAGEMENT TEAM ON ASH HANDLING PLANT MEMBERS: R K OJHA, LEADER ROMIT MOHAPATRA, MEMBER K V REDDI, MEMBER DILIP DAS, MEMBER NALCO AT A GLANCE SOLAR POWER PLANT CORPORATE OFFICE WIND POWER PLANT BAUXITE MINES

SLIDE 1

SLIDE 2

PROCESS LEVEL ENERGY MANAGEMENT TEAM ON ASH HANDLING PLANT

MEMBERS: R K OJHA, LEADER K V REDDI, MEMBER ROMIT MOHAPATRA, MEMBER DILIP DAS, MEMBER

SLIDE 3

NALCO AT A GLANCE

CORPORATE OFFICE

BAUXITE MINES ALUMINA REFINERY ALUMINIUM SMELTER CAPTIVE POWER PLANT ROLLED PRODUCT UNIT PORT FACILITIES WIND POWER PLANT SOLAR POWER PLANT

SLIDE 4

SALIENT FEATURES

BAUXITE MINES:

 Area od deposit – 16Sq.KM  Resource – 310 MT  Capacity – 68.25 Lakh TPA  Transport – 14.6KM long cable belt conveyor

ALUMINA REFINERY:

 Capacity – 22.75 Lakh TPA  Atmospheric pressure digestion  Pre-desilication & inter-stage cooling for higher productivity  Co-generation –4X18.5MW power

ALUMINIUM SMELTER:

 Capacity – 4.60 Lakh TPA  180KW Cell technology  Micro-processor based pot regulation system  Ingot, wire rod, billet, strip casting

CAPTIVE POWER PLANT:

 Capacity – 1200 MW  Micro-processor based burner management system  Automatic turbine run-up system  Specially designed barrel type high pressure turbine

ROLLED PRODUCT UNIT:

 Capacity – 50000 MT/ annum  Products – Cold rolled sheets, coils from continuous caster route  Technology – FATA Hunter of Italy

PORT FACILITIES:

 Location: Visakhapatnam  Export - Alumina  Import – Caustic Soda  Mechanised storage and ship handling facilities

WIND POWER PLANT:

 Capacity – 50.4 MW, A.P., commissioned in Dec’2012  Capacity – 47.6 MW, Rajastan, commissioned in Jan’2014

SOLAR POWER PLANT:

 Capacity – 260 KW  Commissioned roof top solar power plant at Corporate Office

SLIDE 5

ALUMINA REFINERY

ALUMINA MAKING PROCESS STEAM GENERATION PROCESS

BOILERS:

Make – M/s BHEL Capacity – 4 Boilers of 200TPH – 1 Boiler of 250TPH Type - VU40, Bi-drum, natural circulation, oil/ p.f. fired, fixed tangential corner fired

TURBOGENERATORS:

Make – M/s BHEL Capacity – 4 TGs’ of 18.5MW Type - Extraction back pressure TG Higher cycle efficiency due to co-generation

SLIDE 6

BOILER

AIR PRE-HEATER ESP

AIR

FUEL

WET ASH SYSTEM ASH POND

DM WATER

PROCESS FLOW DIAGRAM

STEAM DRY ASH COLLECTION FLY ASH SILO CHIMNEY FLUE GAS

PRAYASH QC 6

ECONOMISER

SLIDE 7

WET ASH DISPOSAL SYSTEM

BLR #3

BLR #2

BLR #1

BLR #4 BLR #5

BOTTOM ASH HOPPER

LINE - 1 5 2 3 4

STAGE 1 STAGE 2 STAGE 3

STREAM#6

AIR PREHEATER ECONOMISER

BOILER BLOW DOWN ESP PRAYASH QC 7

STREAM#5 STREAM#4 STREAM#3 STREAM#2 STREAM#1

SLIDE 8

ASH POND

ASH DISPOSAL PUMP HOUSE

ASH SLURRY PIT ASH SLURRY PUMP

SLIDE 9

UPGRADATION OF ASH SLURRY PUMPS

SLIDE 10

ASH DISPOSAL PUMP HOUSE

NO. OF STREAMS : 03
ASH SLURRY PUMPS: 09NOS
SERIES PUMPING
CAPACITY: 635M3/HR
HEAD: 44MTRS
MOTOR: 150KW
NO. OF STREAMS : 03
ASH SLURRY PUMPS: 09NOS
SERIES PUMPING
CAPACITY: 350M3/HR
HEAD: 50MTRS
MOTOR: 110KW

ADPH-I ADPH-II

SLIDE 11

ADPH-I

ORIGINAL PUMP
EFFICIENCY : 67%
POWER CONS : 120KW
UPGRADED PUMP
EFFICIENCY : 76%
POWER CONS : 106KW

UPGRADATION OF ASH SLURRY PUMP IN STREAM-1 OF OLD ADPH

SLIDE 12

POWER SAVING

INSTANTANEOUS POWER SAVING : 14KWH
POWER SAVING PER DAY : 336KWH
POWER SAVING PER ANNUM : 122640 KWH
SAVING OF POWER @Rs 3.20/- : Rs 3,92,448/- (PER

PUMP PER ANNUM)

SAVING OF POWER FOR ONE STREAM:Rs 11,77,344

/- (PER ANNUM)

SLIDE 13

CALCULATION OF PAY BACK PERIOD

COST OF REPLACEMENT OF ONE PUMP : Rs 6,15,282/-
COST OF REPLACEMENT OF ONE STREAM : Rs 18,45,846/-
SAVING OF POWER FOR ONE STREAM:Rs 11,77,344 /- (PER

ANNUM)

PAY BACK PERIOD : 1.6 YEARS

THE PAY BACK PERIOD IS ABOUT ONE YEAR APART FROM IMPROVED LIFE OF COMPONENTS

SLIDE 14

EFFICIENCY OF PUMP

WATER HORSE POWER SHAFT HORSE POWER

SLIDE 15

REASON FOR INCREASE IN HYDRAULIC EFFICIENCY

FLOW PATTERN CHANGED FROM RADIAL

FLOW TO MIXED FLOW

TWISTED VANE IMPELLER
MODIFIED HYDRAULIC ASSEMBLY

SLIDE 16

MIXED FLOW TWISTED VANE IMPELLER MODIFIED HYDRAULIC ASSEMBLY

SLIDE 17

CONCLUSION

EFFICIENCY INCREASED BY 9%
POWER SAVING PER STREAM – 122.64 MW
NET SAVING IN TERMS OF MONEY – Rs. 11,77,344 /-
