GHANA PORTS & HARBOURS AUTHORITY @ PMAWCA Freetown 2017 October 2017 Monitoring Of Port Infrastructure Construction Projects Under Concession TSID GPHA @ PMAWCA Master Ports Planning Port of Tema Port of Takoradi Sekondi Fishing

slide-1
SLIDE 1

@

PMAWCA – Freetown 2017

October 2017

GHANA PORTS & HARBOURS AUTHORITY

slide-2
SLIDE 2

Monitoring Of Port Infrastructure Construction Projects Under Concession

TSID

slide-3
SLIDE 3

Master Ports Planning

Port of Tema Port of Takoradi Sekondi Fishing Port

….Other Ports…. Keta, Aboano, Gomoa Etsibeedu

GPHA – Embracing the Future

Mission: To provide efficient Port facilities and ensure quality services to our Port Users. Vision: To be the Leading Trade and Logistics Hub in West Africa Strategy: …pursue the delivery of quality services and the reduction of port costs to all her Customers.

GPHA @ PMAWCA

slide-4
SLIDE 4

Board of Directors

DG

(Headquarters)

Tema

Fishing Harbour - Tema

Takoradi

Fishing Harbour - Sekondi

XYZ

Keta, Aboano, Jamestown,

GPHA @ PMAWCA

Governance …Directorship

slide-5
SLIDE 5

Board of Directors DG / Headquarters

Tema

Fishing Harbour - Tema

Takoradi

Fishing Harbour - Sekondi

XYZ

Keta, Aboano, Jamestown,

GPHA @ PMAWCA

Governance …Directorship

Port-level Departments

  • level of involvement
  • capacity and responsibility
  • post-execution implementation
  • monitoring / reporting
  • collaboration / review
  • strategic / business intelligence.
  • etc.

Corporate Management Concession Management… inception to execution…

Approvals / Decisions

…impact of large concessions on the small estates…

  • job losses / creation?
  • education / capacity / competence
  • social re-engineering
  • resettlement?
slide-6
SLIDE 6

GPHA @ PMAWCA

Systems of Systems…Concessions are within the existing systems of Infrastructure and Services

Setup of Concessions

Port Authority / Port level Administration Concessions e.g. Tema / Takoradi 1. Container Vessel Handling 2. Dry Bulk – Bauxite, Manganese, Clinker, coal, etc. 3. Liquid Bulk (hydrocarbons) 4. LNGs 5. Other Stevedoring Activities 6. Agreement forms – what

exactly can you put into those agreements? Should we accept anything? Who calls the shots? Terms? Scope? Reporting obligations? Contracting? Local Content?

slide-7
SLIDE 7

GPHA @ PMAWCA

Systems of Systems of …Infrastructure and Services

slide-8
SLIDE 8

0,00 1 000 000 000,00 2 000 000 000,00 3 000 000 000,00 4 000 000 000,00 5 000 000 000,00 6 000 000 000,00 7 000 000 000,00

2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016

Customs [GRA] Collection in GHC: Tema Port only

2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 Tema 425 408 489 147 555 009 525 694 590 147 756 899 824 238 841 989 732 382 782 502 Takoradi 51 042 52 226 57 372 47 828 53 045 56 595 60 746 52 373 61 355 58 093 Total 478 450 541 373 612 381 573 522 643 188 813 494 884 984 894 362 793 737 840 595 100 000 200 000 300 000 400 000 500 000 600 000 700 000 800 000 900 000 1 000 000

GPHA @ PMAWCA

…the Nation’s Invaluable Revenue Platform

slide-9
SLIDE 9

Master Plans …so far ...! in-Port Concessions???

  • a. JICA / OCDI et al., 2001-2002 – average growth rates 5-10%,

recommended development plans.

  • b. HALCROW-US / USTDA/ Nathan Assoc. et al. 2010-2011; not

very different from JICA. Additional emphasis: increased private participation in port operations.

  • c. Royal Haskoning et al., 2012 focused on Cargo Projections,

ultimate Port Inventory for Ghana, etc.

  • d. Sellhorn / HPC et al., 2014-2016: project-oriented MPs being

implemented; projections range 4.5%-11%p.a. growth.

  • e. MTBS/Ayine/ARUP et al., 2015-date: PPP feasibilities and
  • ptions, Tariff Review and Port Commercial Plan
  • f. Others…

…these evolved into various concessions and privatization initiations...!!!

GPHA @ PMAWCA

Port Studies – Feasibilities, Master Plans, Development Programs

slide-10
SLIDE 10

NEW Master Plans …whole Ports / terminals

concessions possibilities.

a.Keta Sea Port & Industrial Park – Cement Plant /

Land Bank / Sea Boundaries

b.VRA / Schenzen Coal-Fired Power Plant and Coal

Handling Port

c.Private Cargo Jetties (Ports) d.THIRD Commercial Port : GPHA / Royal Haskoning et

al., 2013/14 focused on New Port Location and related Infrastructure, etc.

e.Inland Ports… Boankra, Paga, Ouagadougou

  • f. Fish Landing Sites / Fishing Ports.

…How do we handle these…?!!!

GPHA @ PMAWCA

Port Studies – Feasibilities, Master Plans, Development Programs

slide-11
SLIDE 11

Port of Tema

GPHA @ PMAWCA

Port Studies – Feasibilities, Master Plans, Development Programs

slide-12
SLIDE 12

GPHA @ PMAWCA

Projects – Port of Tema Expansion – MPS Concession

Port of Tema …

a. Expansion and Upgrade of the Port of Tema

1. MPS-1 2004 + 20years. 2. MPS-2: 2004+35years (Deed of Amendment in 2015)

b. Concession – Develop & Operate

1. 100%-Container Handling / Operations 2. Stevedores, Storage, Receipt and Delivery Services. 3. Grantor’s Parameters / Design Requirements –

design vessels, drafts, berth orientations, in-harbour disturbance, design life, overtopping, etc., etc.

c. Develop / Construction

1. Contractors / Tendering for Marine Works, Land works and buildings, Cranes, Electrical systems, Water / Sewerage systems, I.T. / SCADA, etc… Permits

…Negotiations…!!!

Form of contract determines the extents of engineering monitoring.

Approve OR Accept …Negotiations…!!! Monitor Heads of Terms and Milestones…

…no significant details in the Concession Agreement

slide-13
SLIDE 13

GPHA @ PMAWCA

Projects – Port of Tema Expansion – MPS Concession

Port of Tema …

  • d. Completion Certificates

1. Fit for Purpose? Specifications. 2. Facilities – Specific, General purpose

  • e. Concession Area Spatial Plan.

1. Container Storage Plans 2. Routes, Services – Security Gates / Fences 3. Equipment capacities / types – STS, RTGs, Yard Trucks, other installations, e.g. Fibre Optics 4. Stevedores, Storage, Receipt and Delivery Services 5. Progress technical reports, photos, site issues and non-commercial reports.

  • f. Political Influence …???

…Negotiations…!!!

Form of contract determines the extents of monitoring.

Approve OR Accept …Negotiations…!!!

GPHA receives drawings and “Approves”!!!

GPHA not involved in 2nd level contracts.

GPHA receives complaints and updates …and GPHA is expected to act... Periodic site visits….

slide-14
SLIDE 14

MPS Concession Area

Port of Tema Upgrade and Expansion Target Design Vessel LOA=367m B=50m; Draft D=16m+ Access Channel: W=250m D=19m T-Basin D=17.4m Design Life???

GPHA @ PMAWCA

Projects – Port of Tema Expansion

slide-15
SLIDE 15

GPHA @ PMAWCA

Projects – Port of Tema Expansion

Port of Tema – Meridian Port Services (MPS) Ltd. Concession

slide-16
SLIDE 16

GPHA @ PMAWCA

Projects – Port of Tema Expansion

slide-17
SLIDE 17

GPHA @ PMAWCA

Projects – Port of Tema Expansion

…over the next 20 years…Port of Tema

slide-18
SLIDE 18

Breakwater Construction Quarry run, Boulders, Haulage Distance vrs volumes 0-10tons; av. 4km, 3.5million cub-m of rock.

GPHA @ PMAWCA

Projects – Port of Tema Expansion

slide-19
SLIDE 19

Dredging of access channel Turning basin, berths and quay wall trenches >7.3million cub-m

GPHA @ PMAWCA

Projects – Port of Tema Expansion

slide-20
SLIDE 20

Reclamation of Terminal Area (>110Hectares; > 10.2million cubic-m of sand, 75% or more from offshore

GPHA @ PMAWCA

Projects – Port of Tema Expansion

slide-21
SLIDE 21

Quay walls construction: 21m caisson-wall, 1400m long, berth furniture: fenders, bollards, ladders, etc.

GPHA @ PMAWCA

Projects – Port of Tema Expansion

slide-22
SLIDE 22

Supplies and Utilities – Water Electricity, Internet, Fuel, Foods Maintenance and Operations, etc.

GPHA @ PMAWCA

Projects – Port of Tema Expansion

slide-23
SLIDE 23

GPHA @ PMAWCA

Projects – Port of Tema Expansion / Road Project

slide-24
SLIDE 24

GPHA @ PMAWCA

Projects – Port of Tema Expansion …precast yards

slide-25
SLIDE 25

GPHA @ PMAWCA

Projects – Port of Tema Expansion …sieving / grading and compaction

slide-26
SLIDE 26

GPHA @ PMAWCA

Projects – Port of Tema Expansion …caisson precast yard

slide-27
SLIDE 27

GPHA @ PMAWCA

Projects – Port of Tema Expansion …temporary rock loading berth

slide-28
SLIDE 28

GPHA @ PMAWCA

Projects – Port of Tema Expansion …caissons cast yard

slide-29
SLIDE 29

GPHA @ PMAWCA

Projects – Port of Tema Expansion …ground improvement / reclamation

slide-30
SLIDE 30

GPHA @ PMAWCA

Projects – Port of Tema Expansion …main breakwater

slide-31
SLIDE 31

GPHA @ PMAWCA

Projects – Port of Tema Expansion

slide-32
SLIDE 32

© ©

Concessions - Takoradi 1. Integrated (Container & Multipurpose) Terminal. 2. Dry Bulk Terminal Operator. 3. Leases / Tenancies / “concessions” within Port estate: Viking, TAKOTEL, SafeBond, Prime Meridian, American Products, BajFreight, Tullow, G.E., Goil, Viking Offshore; etc.,

GPHA @ PMAWCA ….Port of Takoradi Expansion

slide-33
SLIDE 33

© ©

Concessions - Takoradi 1. Integrated (Container & Multipurpose) Terminal. 2. Dry Bulk Terminal Operator. 3. Leases / Tenancies / “concessions” within Port estate: Viking, TAKOTEL, SafeBond, Prime Meridian, American Products, BajFreight, Tullow, G.E., Goil, Viking Offshore; etc.,

GPHA @ PMAWCA ….Port of Takoradi Expansion

slide-34
SLIDE 34

© ©

Completed, and operational Under construction Proposed Additional Works

GPHA @ PMAWCA ….Port of Takoradi Expansion

slide-35
SLIDE 35

© ©

Completed, and operational Under construction Proposed Additional Works

GPHA @ PMAWCA ….Port of Takoradi Expansion

slide-36
SLIDE 36

GPHA @ PMAWCA

Projects – Port of Takoradi Expansion

GPHA @ PMAWCA ….Port of Takoradi Expansion

slide-37
SLIDE 37

GPHA @ PMAWCA ….Port of Takoradi Expansion

slide-38
SLIDE 38

GPHA @ PMAWCA ….Port of Takoradi Expansion

slide-39
SLIDE 39

Security Systems – Port Authority must retain National Security Obligations and demand compliance, reports, etc., from Concessionaires.

10/27/2017

GPHA @ PMAWCA

Data, Info-Security

slide-40
SLIDE 40

Procurement of Marine Crafts

Pilot Launches; Tug Boats; Security Patrol Boats; Diving Pots; etc.

Decision Notice: Technical Specifications, Maintenance Plans, Maintenance Management of Marine Craft. Planning for procurement of >80tBP tugs for new Harbour area, LNG services, etc., for design vessel sizes.

GPHA @ PMAWCA

Projects – Engineering Interests

slide-41
SLIDE 41

GPHA @ PMAWCA

…Monitoring future Concessions

1. Training and Capacity Building – right from the onset …what is to be done? …who shall we send and who will go for us? ..GUIDELINES? But How do we? 2. Collaboration / Cooperation : Inter- agency and Inter-states!!! – GPHA, GRDA, GRCL, GHA, GSA, EPA, Academia ...ALL 3. Check List Structure ..how do we go through development

processes? What’s the ‘checklist’?

4. Integrated Long-Term Development Plans: “Layering” – get the right systems.

5. Data Management – Reporting: Do we get the

correct reports, Financials? Cargo Volumes? etc.

6. Management of Public Perception of Concessions.

slide-42
SLIDE 42

GPHA, Ghana

Contact

....kofori@ghanaports.net…
