Planning and Licensing for Offshore Renewables Energy David Pratt Project Lead Sectoral Marine Planning for Offshore Renewable Energy Marine Scotland and The Crown Estate Marine Planning Seabed Leasing and Licensing Agency Authority

SLIDE 1

Planning and Licensing for Offshore Renewables Energy David Pratt

Project Lead – Sectoral Marine Planning for Offshore Renewable Energy

SLIDE 2

Marine Scotland and The Crown Estate

Marine Planning and Licensing Authority Seabed Leasing Agency

SLIDE 3

Planning Licensing Science

SLIDE 4

Blues Seas Green Energy – 2011

Plan for Offshore Wind Energy Projects at Licensing Stage

Argyll Array
Islay
Inch Cape
Neart na Gaoithe
Forth Array
Beatrice

25 Medium-Term Areas of Search

– starting point for current Sectoral Plan development process

SLIDE 5

Sectoral Marine Planning Process

Identify / Refine Search Areas Consultation Refine Areas Assess Areas Statutory Consultation Finalise Areas Adopt Areas

SLIDE 6

Marine Resource System (MaRS) – Resource Model

TECHNICAL MODEL

SLIDE 7

Environmental Theme Industrial Theme Socio-cultural theme

Layers included into each theme

SLIDE 8

INDUSTRY ENVIRONMENT HERITAGE

Constraints Models

SLIDE 9

First step?

OFFSHORE WIND WAVE TIDAL

Scoping exercises undertaken in late 2011 – early 2012
Pre-statutory consultation – August 2012

SLIDE 10

Draft Plan & Assessment Stage

Strategic Environmental

Assessment

Strategic Habitats Regulations

Appraisal

Strategic Social and Economic

Impact Assessment

Consultation Analysis

SLIDE 11

Offshore Wind
Wave
Tidal
Planned

Development

SLIDE 12

VMS CHART

SLIDE 13

SCOTMAP CHART

SLIDE 14

Timetable

Published Draft Plans, along with the

Sustainability Appraisal Report, for public consultation in Summer 2013.

Consultation is currently being undertaken

and analysis will be published.

Plans finalised in early 2015

SLIDE 15

What’s in the Draft Regional Locational Guidance?

Shows initial options – areas of search
Explores potential areas for development
Identifies wider baseline information relating to a

wide range of features and activities

Highlights further (non-spatial) information as a

means of exploring key constraints and

pportunities
Next steps – refine in line with ‘Draft Plan’

http://www.scotland.gov.uk/Topics/marine/marineenergy/Planning

SLIDE 16

Draft RLG - Contents

Resource Aquaculture Aviation Bathymetry and Seabed Cultural Heritage Defence Environment

Designated Sites Landscape Designations within Region Marine Mammals, Basking Sharks and Seals Seabirds

Fishing

Commercial Fishing Regional Overview Areas of Search Interaction Fish Processing Activities Wild Salmon and Sea Trout

Infrastructure and Grid Provision

Existing Future

Oil and Gas Planning Ports and Harbours Recreation

Recreational Angling Recreational Boating Scuba Diving Sea Kayaking Small Boat Activity Surfing and Windsurfing Areas of Search

Shipping Social Supply Chain Tourism

SLIDE 17

Initial assessment of potential locations for deep water turbines

Objective: To investigate deep water sites where floating wind turbines could be installed. Principal requirements:

Depth between 80-120 m
Wind resource > 9 ms-1 (mean annual wind speed)
Relative proximity to electrical substation or cable

connection

Relatively low wave activity
Proximity to a harbour
Low constraint level (potential interference with other

users of the sea)

SLIDE 18

2011 Marine Scotland Science Scoping Report

Constraint layer clipped

by depth used to identify potential floating turbine areas Additional Layers: Wind Resource Electrical Substation Cable & Cable Landings Wave activity Proximity to Harbour Constraint level

SLIDE 19

Potential T&D Deepwater Locations

SLIDE 20

SLIDE 21

Planning for Social & Economic Benefit

Scenario Mapping
Masterplanning

SLIDE 22

‘ Tiree Scenario Mapping’

SLIDE 23

Scenario 1 – O&M Base Scenario 2 – Offshore Platform Scenario 3 – Offshore Mothership Scenario 4 – O&M Base / Mothership

SLIDE 24

Scenario 1-4 Projected needs

4 3 2 1

Jobs on Tiree Houses on Tiree

new build

School Pupils

primary & secondary

Built Development Helicopter Flights

per day return flights

Population Growth

SLIDE 25

Scenario Mapping – East and North East Regions

October 2012

Project Partners: East Coast Renewables Marine Scotland The Crown Estate SG Energy SE / HIE Project was focussed on Economic / Supply Chain Benefits & Implications for the Regions

SLIDE 26

Questions?

Further Information -
Offshore Renewable Energy Planning

Webpage

http://www.scotland.gov.uk/Topics/marine/ma

rineenergy/Planning

Offshore Renewable Energy Planning Mailbox
offshorerenewableenergy@scotland.gsi.gov.uk

SLIDE 27

More information / Data Sources

Marine Scotland Interactive
http://www.scotland.gov.uk/Topics/marine/sci

ence

National Marine Plan Interactive
http://www.scotland.gov.uk/Topics/marine/se
