Parallelizing DNA Read Mapping Sunny Nahar What is DNA Sequencing? Finding the base-pairs for the genome. Why is this useful? Tracing evolution. Correlating genes with diseases. Forensics and identification. Current Technology

slide-1
SLIDE 1

Parallelizing DNA Read Mapping

Sunny Nahar

slide-2
SLIDE 2

What is DNA Sequencing?

Finding the base-pairs for the genome.

slide-3
SLIDE 3

Why is this useful?

  • Tracing evolution.
  • Correlating genes

with diseases.

  • Forensics and

identification.

slide-4
SLIDE 4

Current Technology (Shotgun)

  • Split DNA into small pieces (reads).
slide-5
SLIDE 5

Read Mapping

  • Have access to a reference genome.
  • Align reads to reference.
slide-6
SLIDE 6

Computationally Challenging

  • Billions of reads.
  • Fuzzy matching.

○ Handle insertions, deletions, mutations, errors.

  • Multiple mapping locations.
  • Assemble with high probability.
slide-7
SLIDE 7

How do we map a read? (Seed-and-extend Method)

  • Match substrings (seeds) exactly

to the reference.

○ Possible locations.

slide-8
SLIDE 8

How do we map a read? (Seed-and-extend Method)

  • Use edit distance to

determine quality.

○ Dynamic Programming (score based)

■ Needleman-Wunsch ■ Smith-Waterman

  • Choosing less frequent

substrings is important.

slide-9
SLIDE 9

Research Project

  • Improve the speed of the mapper (aligning reads).
  • Develop novel algorithms and heuristics.
  • Low complexity, memory efficient, cache efficient.
slide-10
SLIDE 10

This Presentation

  • Focuses on one part of the pipeline: Seed Selection.

○ Given set of reads, output seeds. ○ These are used to find potential mapping locations.

  • Discuss parallel optimizations and improvements to runtime.
slide-11
SLIDE 11

Parallelizing the Infrastructure

slide-12
SLIDE 12

DNA Read Processing Pipeline

  • 1. Generating the HashTree representation of genome.
  • 2. Building a frequency predictor.
  • 3. Performing seed selection.
  • 4. Pipe results into next stage (edit distance).
slide-13
SLIDE 13

Machine Specs

Test machine:

  • 4 sockets.
  • 10 cores and 256GB RAM (NUMA) per socket.
  • 2 hardware threads per core (Intel Hyperthreading).

○ Memory latency.

  • In total, 1TB RAM with 80 logical threads.
slide-14
SLIDE 14

Generating the HashTree

slide-15
SLIDE 15

Genome Representation

  • Hashtable of Frequency Tries.

○ Each node stores a character and frequency. ○ Hashtable on first 10 letters.

  • Bounded (length 30)
  • ~80GB on disk.
  • String frequency queries.
  • L cache misses.
slide-16
SLIDE 16

Generation in Parallel

  • Reading from disk is sequential.

○ Threads take turn reading. ○ Memory mapped IO removes need for explicit copying. ○ Copied to Kernel page cache as opposed to user memory. ○ Incur TLB misses vs cache misses.

  • Each trie can be independently generated.

○ Only issue is memory allocator. ○ Traditional malloc has a lock. ○ Only need alloc (not free). ○ Implement own allocator which is locality aware. ○ Was initial bottleneck. (2hrs to 10 minutes)

slide-17
SLIDE 17

Generation in Parallel

  • Dynamic work scheduling + greedy allocation.

○ Trie sizes are highly nonuniform. ○ Schedule largest tries first to balance workload. ■ Estimate from filesize.

  • Kernel aware access policies.

○ TLB linear access. ○ File linear access.

slide-18
SLIDE 18

Speedup Graph

slide-19
SLIDE 19

Frequency Predictor

slide-20
SLIDE 20

What is the Frequency Predictor?

  • Access to HashTree is costly (L cache misses)

○ Instead, give an estimated frequency.

  • Reduces to 1 cache miss.
  • Store a table:

○ table[base][L][R] -> base (10 letters) extended to left by L letters, right by R letters.

  • Example: AGCTGACG ATGCTAGCTA GCTCG

○ Lookup table[ATGCTAGCTA][8][5]

slide-21
SLIDE 21

Construction of Predictor

  • Requires traversing through the entire HashTree.
  • Updating a large table

○ Synchronization at same entries. ○ Accomplished with atomic writes.

slide-22
SLIDE 22

Speedup Graph

slide-23
SLIDE 23

Seed Selection

slide-24
SLIDE 24

What is Seed Selection?

  • Given input set of reads, output set of seeds for each read.

○ Based on input parameters. ○ GCAGTCAGTCGATCGATCGATCGTACGTACGTACAGCTAGC TA

  • Algorithms use mix of accesses to HashTree and predictor to

determine seeds.

slide-25
SLIDE 25

Parallelization

  • Selection is parallelized over reads.

○ Per thread data structures, reduced at end.

  • Both the HashTree and Predictor are loaded in memory.

○ Generally sparse accesses. ○ Cache write coherence is not an issue, since only read access to memory. ○ Cache reads create coherence traffic (costly on socket architecture).

slide-26
SLIDE 26

Parallelization

  • Stack memory vs malloc.
  • NUMA degrades performance.

○ Threads closest to HashTree, Predictor perform much faster. ○ Observed up to 2x overhead.

slide-27
SLIDE 27

Speedup Graph

slide-28
SLIDE 28

Questions
