Panel Discussion

Industrial IoT Application Powered by Edgelink

Cindy Huang, Product Manger, Advantech IIoT Group

Topics Panelist Equipment Management from Software Visualization Perspective Jack Yang Software Product Manager Advantech IIoT LoRa IOT Applications for Smart Cities Nisha Lin Product Manger Advantech IIoT Remote Management & Operation for PCB Machine Terry Fang Manager , System Integration Dep. Weltall Tech Secure Asset Tracking Solution David Wynegar Lead Solutions Architect i4DM

Equipment Management from Software Visualization Perspective

Jack Yang, Software product manager, WISE-PaaS/IIoT Advantech IIoT

What is Equipment Oriented ?

Equipment Oriented Management

EdgeLink Block: Generator WISE.M+ Generator Profile

Scattered Tag Data: Readable Parameters:

• Generator’s Power
• Generator’s Temp.
• Generator’s Status

Management Perspective Object Oriented Grouped Scattered Tags of Data

Using Equipment Twins

Parameters associated with twin

• bjects are categorized.

Historical data automatically archived. Data source in dashboard uses same hierarchy mechanism makes dashboard editing more friendly

• Readable naming for management
• Customized function extensions
• Backend data analysis
• Data statistics and calculations

Ventilation Status Temp. Power

With Aid of WISE.M+

With Aid of WISE.M+

Using Profiles

Benefit for configuration

• Fast duplicate connection setup
• Instant dashboard visualization

+

I.APPs combined

New Cooler Unit Automatically applied

Flexible Alarm Management

+

I.APPs: Alarm, Notification, and Vibration Analysis

+ Benefit for alarm recipients

• Customized alarm text for

preemptive actions.

• Composition of information

text whereas alarm value

• nly.

Information regarding to alarm composed to valuable information and send!

Grouped Management

I.APPs: Grouped Alarm Analysis, Consumption Analysis, Grouped Status, and Grouped Loading Analysis

Benefit for Management

• One-page grouped analytical view.
• Flexible combination of management I.APPs.

Application industry：Water Treatment Edge / SRP：

• ADAM3600 , WISE-4471 , ECU-1152
• WISE-PaaS/WISE.M+

Case background： Water Treatment plant domestic sewage , Industrial waste Application area： Kaohsiung , Thsinchu in Taiwan

Successful Case

• Besides dashboards

– We visualize not only results – But also the management mind

• Visualized Management in mind

 In terms of calculation  In terms of alarms  In terms of notification messages

Conclusion - Visualized management

LoRa IOT Applications for Smart Cities

Nisha Lin, Product Manger, Advantech IIoT

Why LoRa

Connect devices up to 2-5Km in Urban regions or 15Km in suburban distance to build up wide area network

Long Distance (5 ~ 15 km)

Protocol designed specifically for low power consumption extending battery lifetime over years

Low Power Consumption

Embedded end-to- end AES128 encryption

High Security

Reduces costs three ways: infrastructure investment,

• perating expenses

and end-node sensor

Low Cost

ETH, RS485, I/O

Wifi /LTE 4G

VPN

Advanced Routing

Application server

+

Router +

+

Concentrator Network server

Sensor Node

BB-WSW Series WISE-4610 Series WISE-2410 Series 3rd-party node

IoT Platforms

How LoRa Perform Seamless Integration and Management

WISE-6610

Intelligent Connectivity for Smart City

Urban Environment Water Treatment Renewable Energy Intelligent Agriculture Factory Automation Environment Monitoring Urban Environment Water Treatment

LoRa Node

Remote Building Management

17

Application

• Remotely monitoring the

apartment. There are wireless SENSORS in each

• apartment. Each apartment will have

temperature sensor, entrance door lock and continue to add fire alarm and water leakage control sensor Solution

• Collecting The sensor data by Advantech

LoRaWAN gateway and processing to Wise-PaaS/EdgeLink

• Bidirectional communication to control and

have command from WISE-6610 gateway to sensor node

• Door Lock Sensor
• Temperature Sensor
• Fire Alarm Sensor
• Humidity/Thermal Sensor

EdgeLink agent Node-RED VPN

WISE-6610 LTE

Remote LAN

Smart City / Intelligent Building WISE-6610 (LoRaWAN Gateway) LoRa Sensing Node (BB-WSW Series)

• LoRa sensor nodes and gateways are

implemented for water, temperature, and air quality management.

• Sensor nodes need to be outdoors where

the environmental conditions can be harsh.

• Install node to collecting data from water

level gauge of water tower, Anemometer

• n Roof top, smoke detector at engine

room.

• Daily data processing to cloud server for

timely monitoring.

• With LoRa deployment to reduce

maintenance cost and prevent any issue happened.

• Low-power consumption, long-distance

transmission capability, and battery design.

Application

Intelligent Building Management Systems

LoRa Nodes for Water Level Gauge & Anemometer

• n Roof Top

LoRa Nodes for Temperature Sensor & Smoke Detector @Engine Room

Smart Station WISE-6610 (LoRaWAN Gateway)

• Smart station display air quality, weather

information, Temperature, event information etc.

• Install LoRa gateway with LTE in Smart

station for data collecting and remote control street light to save energy cost.

• Daily data processing to cloud server

through LTE for timely monitoring.

• With LoRa deployment to reduce

maintenance cost and prevent any issue happened.

• Low-power consumption, long-distance

transmission capability, and wide area coverage

Application

Smart Station-Smart lighting

Display Board

LoRaWAN Gateway

Lighting Camera

Smart City / Packing Application WISE-6610 (LoRaWAN Gateway) LoRa Packing Sensor Node

• LoRa sensor nodes and gateways are implemented for

Parking Spaces Availability Monitoring

• Sensor nodes need to be outdoors where the

environmental conditions can be harsh.

• They also need to be small, waterproof, and industrial-

grade.

• Collecting Bosch LoRaWAN Parking Sensors data and

processing data to customer cloud database and dashboard

• From collected data can know packing space usage rate

and packing billing can through packing sensor to calculate packing fee.

• LTE and Router function supported to perform various

Data management

Application

Collecting Parking Space Status

Energy and Environment

• The system must be able to function under high humidity and handle

acute changes in temperature

• Provide timely reporting on environmental conditions.

Application

• LoRaWAN Nodes in remote areas are connected to

sensors for data transmitting via LoRa technology to LoRaWAN Gateway.

• The gateway receives and passes data to the PC

for server and SCADA management.

• A switch collects and organizes data from many

gateways prior to passing the data to a PC.

• With sufficient sensor data, the system can assist in

analyzing the severity of a flood and what action items are required.

Solution

Flood Monitoring and Warning System

Wzzard LRPv Node (LoRa Private Node) SmartSwarm 243 (LoRa Private Gateway) LoRa sensing node

Smart Agriculture

Application Solution

Smart Irrigation System

WISE-6610 (LoRaWAN Gateway) LoRa Sensing Node (BB-WSW Series)

• Approximately 50% of irrigation water is estimated to be wasted due to evaporation or

runoff.

• The most efficient approach to irrigation is to use water only when necessary, to use the

exact required amount, and to ensure that the plants are watered correctly.

• LoRa sensing Nodes in remote areas are connected to sensors for

data transmitting data via LoRa technology to a WISE-6610 LoRaWAN Gateway.

• The gateway receives and passes data to the PC

for server and SCADA management.

• A switch collects and organizes data from

many gateways prior to passing the data to a PC.

• With sufficient sensor data, the system can assist in

analyzing the current irrigation situation and make appropriate decisions on when and where to release water as well as how much water should be used.

LoRa sensing node
