Role of the Gateway in Delivering End to End IoT Solutions

Anatoli Levine Spirent Communications

2 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Agenda  Internet of Things at a Glance  Power of IoT  Implementing IoT - Needs and Challenges  Role of IoT Gateways  Spirent Solutions for IoT Developers

Internet of Things at a Glance

4 Spirent Communications PROPRIETARY AND CONFIDENTIAL

 M2M – Machine to Machine  IoT – Internet of Things  IoE – Internet of Everything Internet of Things Basics - Terminology

5 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Internet of Things Basics - Numbers

60,000,000,000

Estimated number of connectable devices in 2020 (60 Billion)

1,000,000,000,000

Estimated number of sensors in 2020 (1 Trillion)

1,600,000,000,000,000,000,000

Estimated M2M/IoT data volume in 2020 (1.6 Zettabytes)

$150B - $19T

Range of M2M/IoT Revenue estimates in 2020

6 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Internet of Things Basics - Standards

100s

SDOs

100s

Standards

• neM2M

IEEE P2413 MQTT CoAP LwM2M TR-069 IEEE 802.15.4 ITU-T SG20

7 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Internet of Things Basics – Ecosystems, Operating Systems, Clouds, …

100s

• f

8 Spirent Communications PROPRIETARY AND CONFIDENTIAL

9 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Power of IoT

10 Spirent Communications PROPRIETARY AND CONFIDENTIAL

M2M/IoT Is All About…

“things” DEVICES DATA SERVICE ANALYTICS CONTROL

11 Spirent Communications PROPRIETARY AND CONFIDENTIAL

IoT/M2M Verticals  Connected Home (a.k.a. Smart Home)  Connected City (Smart City, Smart Meters, Smart Energy, Smart Buildings)  Connected Car (autonomous car, V2V, V2X)  Healthcare  Transportation (Logistics, Tracking)  Oil and Gas  Industrial Internet  Agriculture

12 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Implementing IoT - Needs and Challenges

13 Spirent Communications PROPRIETARY AND CONFIDENTIAL

IoT Implementation: Success factors  Proper Network access  Security!  Support for multiple ecosystems  Proper solution architecture for data, management and control  Focus on Interoperability

14 Spirent Communications PROPRIETARY AND CONFIDENTIAL

 Multitude of standards and competing frameworks  Standards keep evolving and will be for a foreseeable future  Critical needs:

 Support multiple access/transport protocols  Support wide range of connectivity protocols  Security  Support multiple platforms and ecosystems  Enable application developers  Ease of deployment – enable SPs  Enable universal analytics access  Remote diagnostics and monitoring

Challenges for IoT Solution Implementers

15 Spirent Communications PROPRIETARY AND CONFIDENTIAL

 Interconnect

 Multiple ecosystems will coexist  Enable devices to connect to any platform

 Aggregation and control

 Manage the data – not all data can/should hit the network

 Create an Edge/”Fog” elements as needed  Any designated device can become the control point/hub/gateway as needed IoT Implementer Needs

IoT Gateway

17 Spirent Communications PROPRIETARY AND CONFIDENTIAL

IoT Gateway Deployment Architecture

SP Cloud IoT GW B IoT GW A

18 Spirent Communications PROPRIETARY AND CONFIDENTIAL

IoT Gateway Functions

 Edge intelligence

 Data Aggregation  Local IoT solution logic implementation  Network/external resources usage optimization

 Security

 Incoming  Outgoing

 Interoperability

 Solution level  Protocol level  Semantic

 Management and control for all connected IoT devices

19 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Spirent Solutions for IoT Developers

20 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Client Products & Projects SIP Server Products & Projects

Turnkey Solutions - Professional Services

eVident Network Monitoring

SIP Server Frameworks

SIP Server Core Presence & Events B2BUA

Client Framework ICE MSRP A-RTP

Protocol Toolkits

Diameter IMS SIP Suite H.323 MEGACO

BFCP

XDM SIP Developer Suite

ProLab Testing & Validation Technology

IoT Frameworks

IoT Mediator IoT Device Framework IoT Product & Projects

WebRTC Framework

WebRTC Interconnect

Spirent Developer Tools Solution Portfolio

21 Spirent Communications PROPRIETARY AND CONFIDENTIAL

M2M/IoT: Devices and Servers

22 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Common Service Functions

Common Service Functions

Application Service Layer Mgmt Communication Handling Data Management and Repository Device Management and Diagnostics Discovery Group Management Location Network Integration/Device Triggering Registration Security Charging and Accounting Subscriptions and Notifications

23 Spirent Communications PROPRIETARY AND CONFIDENTIAL

IoT Client Device Framework - Architecture

Hardware and OS Level Network Abstraction/Transport Adapters Spirent M2M Core

Configuration/ Provisioning APIs Device Abstraction APIs CSF APIs

Application M2M/IoT Protocol Adapters OIC AllJoyn

• neM2M

OMA LwM2M …

Security Extensions Analytics Enabler Testing and Diagnostics Extensions

24 Spirent Communications PROPRIETARY AND CONFIDENTIAL

 Events management



Queue processing



Prioritization



Notifications

 Peer Discovery  Upstream service discovery/registration  Device abstraction  Device management



Control integration



Provisioning



Triggering



Diagnostic

 Data aggregation  Statistics, diagnostics, monitoring and reporting

Spirent M2M Core functions

Application …

25 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Application … Application …

Use Case – Sensors and Gateways

Application … SP

• neM2M

26 Spirent Communications PROPRIETARY AND CONFIDENTIAL

IoT Client Device Framework Solution Highlights

Future-Proof

Universal support for multiple standards, current and future, protocol abstraction

Customizable, Flexible, Optimized

Constrained environments, layered APIs, best-in-class performance, OS-agnostic, full source code

Insurance Policy for Device Manufacturers

Support for multiple standards – no need to chose one now, security, reliability, commercial grade, support for full range of devices from Sensors to Gateways, remote diagnostics and monitoring

27 Spirent Communications PROPRIETARY AND CONFIDENTIAL

Questions? Need additional information? http://www.spirent.com/Solutions/Internet-of-Things http://www.spirent.com/Products/DevTools/IoT-Client-Device-Platform Email: Anatoli.Levine@spirent.com
