Overlay Metal/ Inter-dielectric layers/BCB/Cu Bump Workshop

2

Contributors

Contributions

– Jerry Beene

• Sr. Photolithography Engineer

– Roberta Hawkins Sr. Photolithography Engineer – Amy Zhou

• Sr. Photolithography Engineer

– HT. Chen

• Sr. EBEAM Engineer

– Martin Ivie

• Sr. Photolithography Engineer

– Harold Isom Engineering Manager

Confidential & Proprietary

3

Agenda

Agenda

– Overlay Metals and Interconnects

• Process Flow
• MET0-

– Evaporation and Liftoff – PVD Sputtering and Electroplating

• NIT1-Interlayer Dielectric (ILD)

– PECVD

• MET1-MIM CAP

– Etching

Dry Wet

• NIT2- CAP

– PECVD

• MET2-Air Bridge
• Final Over-Coat

– BCB – Copper Bump

4

Overlay Metal-Interconnects and Dielectrics

Overlay metals may be used to increase metal conductivity or to form other

features such as transmission lines, inductors and bottom capacitor plates. Dielectric films may be applied for encapsulation or capacitor formation. A second or even third metallization can be used to form other connections. – Requirements

• High electrical conductivity, good adhesion, effectiveness as a diffusion

barrier, effectiveness as an etch stop.

• High electrical conductivity can be met with four metals, gold, aluminum,

silver and copper.

Dielectric films are used for encapsulation, for capacitor dielectrics and

crossover insulators. – Requirements

• There are generally just a couple of dielectrics used in GaAs Processing:

Si3N4, and SiO2 and sometimes Ta02.

• Si02 have a lower dielectric constant and are good cross-over, Si3N4

because of the higher dielectric constant are better suited for capacitors.

Williams, Modern GaAs Processing Methods

Confidential & Proprietary

5

Process Flow

Ohmic/Alloy Isolation Wide Recess Gate Pattern Gate Fabrication Nitride 0 TaN Resistors Metal 0 Nitride 1 Cap Top Plate Nitride 2 Metal 1 Air Bridge Post Metal 2 Protective Overcoat Saw Street Etch DC Probe Wafer Thinning Via Etch Backside Metal Backside Plate RF Probe Chip Separation Final Visual * * * * * * * Optional Steps

6

MET0 (First layer Metal)

1st-Metal (MET0)

• Sputter TiWN /Ti Barrier
• Sputter Ti//Pt/Au/Ti Seed layer.
• Coat/Align/Develop to Pattern 1st-Metal
• ADI Inspection
• ASH Descum to prepare for Plate
• Gold-Plate, Resist-Strip, Seed-Deplate and Clean
• (This can also be a evaporated metal)
• ACI Inspection
• Measure Metal CD’s

Barrier/Seed Etch (if not evaporated)

• TiWN/Ti Barrier strip in LAM590
• AEI Inspection
• Resist Strip
• Deveil to remove post-etch Polymers
• Spin/Rinse/Dry
• ACI Inspection

Confidential & Proprietary

Provides metal interconnect; overlay ohmic metal, underlay plating (increases sheet conductivity). Used to contact TaN resistors. Can also be used as the bottom plate in the capacitor. First Layer metals can use a variety of deposition methods: Sputtering (PVD), Evaporation, PECVD and electroplating.

7

Methods for Deposition

Different Methods

– Growth

• Thermal Oxidation (SiO2), Titanium Nitride

– Spin on Films

• Spin on Dopants (SOD), Spin on Glass (SOG)

– Deposition

• Chemical Vapor Deposition (CVD)

– APCVD (atmospheric pressure) – LPCVD (low pressure) – PECVD (plasma enhanced) – Epitaxial Growth (single-crystal films)

• Physical Vapor Deposition (PVD)

– Sputter – Evaporation

• Electroplating

Confidential & Proprietary

8

PVD-Evaporation

Physical Vapor Deposition (PVD) –

Evaporation: – Vaporize a metal using thermal energy @ low pressure

An Evaporation system includes the

following: – High vacuum chamber and high vacuum components – Evaporation source: Filament, Electron beam, or Flash hot plate

Evaporation is Inferior to Sputtering:

– Difficult to do alloys – Step coverage – Adhesion

Confidential & Proprietary

9

Evaporation /Lift-Off

Evaporated metal is deposited on top of the resist rather than using the

resist as an etch mask.

Requires an overhang to form a break between the metal on the resist and

substrate.

Called lift-off because if the wafer is soaked in solvent, the resist will

dissolve and metal is left free to lift-off.

10

Components of a Evaporator

Confidential & Proprietary

11

Evaporation and Liftoff

Confidential & Proprietary

Source : Temescal

12

Common Lift-Off Methods

Method Advantages Disadvantages

Positive or Negative Tone

Bi-layer High resolution 1st layer planarizes. Expensive material. Requires non standard EBR chemistry. Requires high temp bake. AZ-5214E-IR Single coat Temperature sensitive. Requires UV flood expose. Etch assisted High resolution Unusual for substrate to allow etching

Positive Only

Developer Soaks Lip at top allows thick lift-offs Does not work for all resists.

Negative Only

AZ NLOF High resolution Single coat Difficult to strip Ammonia bake Requires specialized oven for ammonia.

13

Simple Bi-layer

Coat PMGI and hot plate bake Develop Stepper expose Coat resist and hot plate bake

14

Bi-layer for Undercut Control

Coat PMGI and hot plate bake Develop PMGI Stepper expose Coat resist and hot plate bake Develop resist DUV expose

15

AZ5214 Partial Image Reversal (Positive)

Coat and hot plate bake Short flood expose and bake To crosslink exposed resist Stepper expose Develop

16

AZ5214E Image Reversal (Negative)

Coat and hot plate bake Stepper expose Cross linking bake Develop UV Flood Expose

17

Etch Assisted lift-off

Coat and hot plate bake Develop Stepper expose Etch

18

Developer Soak

Develop Stepper expose Coat resist and hot plate bake TMAH Soak

19

nLOF Lift-off

Coat and hot plate bake Stepper expose Cross linking bake Develop

20

Ammonia Bake

Coat and hot plate bake Stepper expose Ammonia bake Develop UV Flood Expose

21

Lift-Off Challenges

The processes tend to be complicated. Small resist lines can suffer adhesion loss due to the undercut. The degree of undercut can be difficult to monitor without cross section. Evaporated metal will be shifted within the resist opening as distance is

increased from the wafer center.

22

Sputtering

Confidential & Proprietary

Process Concerns with Sputtering:

– Hillock Growth: Excess heat generated by the plasma can cause hillock growth, grains which relieve the stress in the film by growing upward. – Poor Step Coverage due to physical nature

• f the process.

– Contamination Metal Step Coverage

Deposition 23

1000A Ti Deposited in Back Via (pre-plate)

23

PVD and Sputtering

Physical Vapor Deposition (PVD) - Sputtering:

– Use plasma energy to blast small fragments from a target. – Purely physical process, no chemical reaction occurs. – Reverse of physical etching (sputter etch), used at the beginning of the sputter process to remove native oxides.

Where is Sputtering Used?

– Because it is a physical process, almost any material can be sputtered (CVD is limited to materials that can be chemically created). – In III-V processing, sputtering is most

• ften used to deposit seed metals before

electroplating Interconnect or create barrier layers:

Confidential & Proprietary

24

Electroplating

There are two main gold plating baths in

industry today, cyanide based and non- cyanide baths containing either sulfite or thiosulfate as the primary electrolyte. The cyanide bath is by far the dominant of the two.

Gold (Au) is ionized in the solution at the +1

• xidation state. The gold is plated using the

wafer as a cathode attracting the positively charged gold ions to the surface and reducing them to Au(s).

Operation of the gold electroplating bath

involves constant monitoring of key process parameters, which include gold reflectivity, film stress, and film thickness.

Confidential & Proprietary

Advances in Gold Metallization at Motorola's Compound Semiconductor Fab (CS1) Chad M. Becker, William Rummel*, Dr. Paul Ocansey

25

Plating Issues

Confidential & Proprietary

• Problem Description

– The haze comes from two sources: Incomplete deplate leaving behind Au islands and un-removed TiW from the barrier wet etch – Au Islands create leakage paths and have created scrapped material. This is the same failure as EMODE which resulted in the loss of 180 wfrs. – TiW residue is not known to cause yield loss, but cannot be distinguished between Au islands.

26

Cause and effect Diagrams for Plating Issues

Confidential & Proprietary

Source: Paul Ocansey

27

NIT1 (First Interlayer Dielectric, ILD)

Interlayer dielectrics (ILD) can be used

for a variety of applications such as encapsulation, insulating two metalization layers (MIMS). As well as capacitors

Key characteristics : Dielectric constant

is dependent on deposition method and parameters. If a dielectric film is too thin, there will be a larger amount

• f pinholes if it is too thick then the

parasitic capacitance will increase.

The formation of the film can affect

saturation current, breakdown voltage as well as other parameters.

Confidential & Proprietary

28

PECVD (ILD’s)

Two primary PECVD Chemistries

– TEOS

• Source is Liquid TEOS...Si(OC2H5)4
• Used exclusively to deposit SiO2.
• Most common.

– Silane

• Source gas is Silane...SiH4
• Used to deposit SiO2 and Si3N4.

Deposition is carried out in six general steps

• 1. Molecules are broken down into their

constituent atoms to form reactant radicals.

• 2. Reactants diffuse to the surface of the wafer.
• 3. Reactants are adsorbed on the wafer

surface.

• 4. Chemical reaction starts as reactants meet.
• 5. By-products are desorbed.
• 6. Unreacted effluent and by-products are

pumped away.

Confidential & Proprietary

PECVD Mechanism

Ionization:

• 1. e
• + AB

AB + + 2e

• Dissociation:
• 2. e
• + AB

A + B + e

• Excitation / Relaxation:
• 3. e
• + A

A * + e

• 4. A

* A + Photon Where “AB” = a common diatomic molecule and “ * ” indicates an excited state.

29

MET1-MIM CAP

Confidential & Proprietary

• MET1
• Sputter TiWN Barrier
• Sputter Ti/Au Seed layer.
• Coat/Align/Develop to Pattern 1st-Metal
• ADI Inspection
• ASH Descum to prepare for Plate
• Gold-Plate, Resist-Strip, Seed-Deplate and Clean
• (This can also be a evaporated metal)
• ACI Inspection
• Measure Metal CD’s
• Barrier/Seed Etch (if sputtered/Plated)
• TiWN/Ti Barrier strip in LAM590
• AEI Inspection
• Resist Strip
• Deveil to remove post-etch Polymers
• Spin/Rinse/Dry
• ACI Inspection

30

Etching

Etching removes material through physical or chemical methods When photoresist or other masking medium is used, etching can replicate

this pattern into the film.

In III-V, etching is used to generate patterns and remove various materials

such as: – Silicon Nitride – EPI Layers – Silicon dioxide of various forms (thermal, LPCVD and PECVD) – Metals – GaAs, GaN, AlN, AlGaAs

31

Dry Etching

Confidential & Proprietary

32

Dry Etching

Confidential & Proprietary

33

Etch Requirements

Must Control the amount of material being removed Control key parameters that control replication

– Dimensions (Critical dimensions) – Selectivity (which material is etched) – Minimize defects

Control the amount of damage to underlying material Control the amount of un-etched, veils, or other material left on

the etched wafer

34

Etching

What is Etching?:

– 1. The PERMANENT part of the

patterning sequence.

Transfers the pattern in the

photoresist into the underlying layer.

– 2. Removal of a “blanket” film (no

patterning) whose purpose is done

sacrificial oxide nitride used to define transistor

active areas

Two Main Types of Etch Processes:

– 1. Wet Chemical Etching – 2. Plasma (or “Dry”) Etching

Confidential & Proprietary

35

Wet Etching

Wet Etching

– Two basic mechanisms occur:

• Diffusion-limited or mass

transport etching

• Reaction-rate/surface limited or

kinetically limited etching – Almost all GaAs etchants first oxidize the surface and then dissolve the

• xide, removing some of the gallium

and arsenide atoms

• H2SO4-H2O2-H20 is a good

example – Almost all wet etches are isotropic

Confidential & Proprietary

36

Important Characteristics of Etching

Confidential & Proprietary

37

Capacitor Dielectric /Etch Stop/Lift off

Capacitor Dielectric and Etch-Stop

Metal Dep.

800Å Si3N4 Dep (Capacitor

Dielectric)

Coat/Align/Develop to define Etch-

Stop Metal on Capacitor

ADI Inspection Evaporate Ti/Au film for Etch-stop

and Seed-Layer (This can also be plated)

Metal Etch-Stop Lift-Off Lift-off unwanted Etch-stop/Seed

metal with resist.

Spin/Rinse/Dry AEI Inspection

Confidential & Proprietary

38

PECVD-ILD’s

Plasma-enhanced chemical vapor

deposition (PECVD) is a process used to deposit thin films from a gas state (vapor) to a solid state on a substrate. Chemical reactions are involved in the process, which

• ccur after creation of a plasma of the

reacting gases. The plasma is generally created by RF (AC) frequency or DC discharge between two electrodes, the space between which is filled with the reacting gases.

Collisions occur creating numerous

species…electrons atoms, cations, and free

• radicals. Free radicals are very reactive and

are the primary reason for PECVD. Collisions are either elastic or inelastic. Inelastic collisions are of the most value because it is in these that the following reaction types occur.

• A. Ionization B. Dissociation C.Excitation

Confidential & Proprietary

Parallel Plate Reactor

39

Applied Materials P5000

Confidential & Proprietary

Upper Electrode Bottom Electrode “Susceptor”

40

Sequence of Events

Confidential & Proprietary

• 1. Wafer is placed in chamber on Lift Pins.
• 2. Robot retracts from chamber.
• 3. Chamber slit valve closes.
• 2. Lift pins lower wafer on to the susceptor.
• 3. Reactant gases flow in through the Lid

Assembly.

• 4. Time is allowed for gas flow stabilize.
• 5. RF power is turned on and plasma is

ignited.

• 6. Thickness is determined by the amount of

time.

• 7. RF power and gases are turned off.
• 8. Chamber is pumped down to remove

residual gas.

• 9. Lift pins raise wafer off of susceptor.
• 10. Robot removes wafer from chamber.

41

MET2-Air Bridge

Confidential & Proprietary

42

Air Bridge Requirements

The 1st resist layer must be thermally stable enough to

withstand the 2nd layer processing. Any movement will damage the seed metal.

• The resist can be stabilized by a hard bake, electron cure, or by

using a high Tg negative resist.

Stepper alignment marks must have openings in the 1st resist

• r they will be invisible after the seed metal.

The 1st resist layer should not have a retrograde profile or a

“lip.”

• What’s good for lift-off is bad for seed metal. Any discontinuities can

isolate the area from plating.

• The plating can surround and trap solution if the 1st resist layer is

thin and the opening is narrow when compared with the plated metal thickness.

43

Air Bridges

Air Bridges are used for crossing metal lines where low capacitance

is desired. The most common is connecting FET source pads.

An air bridge is formed by two litho layers.

– The 1st layer temporarily leaves resist to form the bridge support. The seed metal is then deposited. – The 2nd layer defines the lines. – The 2nd resist layer, seed metal, and 1st resist are then removed, leaving an air bridge.

44

Air Bridge Aspect Ratio

Short and wide air bridges will need gaps to aid

removal of the 1st resist layer.

– Whatever process used to stabilize the 1st layer will likely make it difficult to strip. – The gaps also help resist coats after the bridge is formed. Air can get trapped during the coat and expand to a bubble during the soft bake.

• Prewetting the wafer to break the surface tension will also help

prevent bubbles.

Long and thin air bridges can be flimsy.

– Even water pressure from sawing can rip up these bridges when they are close to the streets.

45

Final Protective Overcoat

Confidential & Proprietary

46 Confidential & Proprietary

Initial Goals for Low-K Project at beginning of development of BCB process

Develop a process to:

– add scratch protection – underside mechanical ‘support’ for air bridges – minimize electrical effects from subsequent package over-molding. \

47

Overview of BCB Process and Release Status

BCB overcoat process are

intended to improve the PO and BCB adhesion to the second level metal (MET2)

– Addition of a 500-Ǻ evaporated titanium layer over the top of MET2 – Replacement of the tensile-stress 2000-Ǻ SiN protective overcoat (PO) deposited at 250C with a compressive stress PO deposited at 350C. – Uniformity Target of 7um

Confidential & Proprietary

FIB cross section of air bridge showing complete BCB underfill of airbridge as well as BCB thickness over the span.

48 Confidential & Proprietary

FIB cross section and layout sketch of BCB overcoat profile of an PO style bond pad. BCB encroachment of pad measured at 1.0um.

3MI PO Pad Layout Rules

MET1 MET2 BCB N0/N1/N2/PO 2KPO

49 Confidential & Proprietary

3MI PO Pad Layout Rules

FIB cross section and layout sketch of BCB overcoat profile of an PO style bond pad. BCB encroachment of pad measured at 2.2 µm. MET1 MET2 BCB 8KPO

50

First backside pattern is used to create the alignment marks for subsequent patterns. HMDS improved resist adhesion on backside of Silicon Carbide wafers. Pattern is aligned by looking through clear SiC wafer.

– Nickel hard mask required to withstand etch process – Reverse image patterning leaving resist pads instead of

• penings.

– Advantage: Resist itself not a factor during the etch. – No resist residues resulting from etch.

Circular resist pads define the vias

for nickel plating.

Nickel hard mask will be plated

around the resist pattern.

Resist will then be removed. SiC and GaN will be etched with

high density plasma using the nickel as the hard mask.

Resist Pattern

51

Cu/Sn Wafer Bumping

Copper/Tin Plated Bumps for flip chip packaging

– Wafer is bumped on frontside; die is flipped during packaging – Air bridge protection with LOR resist – 85 micron thick resist processing for Cu/Sn bump plating

52

Wafer Bumping for Flip Chip Packaging

Air bridge protection (Microchem LOR30B) Under-bump metallization (TiW/Cu)

– Adhesion – Step coverage – Electrical continuity, plating contacts

Thick resist patterning

– Chemically amplified resist (Shin-Etsu 7120m) – Coat uniformity – 85 um thick resist – Contact/proximity printing (difficult alignment) – Long exposures, long bake times – Sidewall slope depends on mask/wafer contact

Cu/Sn plating Resist removal Seed metal etch

– Minimization of undercut

Bump shear testing

53

Pre-bump pattern after resist develop

LOR30B clear coat protects airbridges during Cu bump processing. Postive resist is coated, baked, and exposed. TMAH developer develops resist and etches LOR30B. Poor LOR30B coat (rework) Good coat, expose, & develop

54

During development of this process, some areas plated poorly, as if disconnected from

• ther parts of wafer.

Discovered poor step coverage of seed metal over LOR30B pattern. Step Coverage Issues resolved by reflowing LOR30B.

Seed metal step coverage problem due to LOR30B sidewall slope

Seed metal step coverage problem due to LOR30B sidewall slope

55

No reflow Reflowed 90 sec @ 230C. Reflowed 180 sec @ 230C. Chose this as new standard process. Reflowed 300 sec @ 230C.

Seed metal coverage greatly improved with LOR30B reflow

56

Focused on bottom of resist Focused on top of resist Chemically amplified resist, 85 microns thick. Must control top and bottom diameter of resist to define bump shape.

Cu Bump Resist Pattern
