ΘΑΛΑΣΣΙΑ ΕΝΕΡΓΕΙΑΚΑ ΣΥΣΤΗΜΑΤΑ Α.Ε. OFFSHORE ENERGY SYSTEMS S.A.

THE COMPANY

“Offshore Energy Systems SA” (OES SA) was founded with the objective to develop and commercially exploit a series of innovative products, methods and services in the marine and

• ffshore sector, protected by patents the rights of which it

holds. More specifically the company holds patents for the following: a)wave-absorbing systems. b)ride control system for fast and super fast crafts based on air-fed foils of “mixed” structure. c)system for electricity production by exploiting the wave energy. d)Temporary energy storage system in the form of compressed air in air tanks of balloon type anchored at the sea bottom. Under course are also: a patent referring to a self installed Floating Wind Measurement Platform, with a retractable mast of big height. a low cost Floating Wind Platform capable of carrying a high capacity Wind Generator of a combined Tension Leg and spar technology, of mixed structure. a patent for adjustable well covers The width and depth of our research and development efforts give our company the character of an innovation center in the area of marine technology. As a result of these efforts we have a wide production line of innovative and effective products and services which give solutions to a wide range of needs in the onshore and

• ffshore sectors.

The heart of our efforts, which are incorporated in our technologies, products and services, is the innovation and environmental protection. Our strategic target today is the Offshore Renewal Energy sector including wind energy and wave energy. OES has a significant advantage in studying and designing

• ffshore wind farms, acquiring and analyzing measurements
• f wind potential, completing all the necessary studies and

procedures to get a license and in executing projects of this kind. We claim that the future of the renewable energy adventure at sea is the combined exploitation of the wind and wave energy. In this presentation we give a brief description of activities, products and services. For more information please refer to our Technical Data Sheets (TDS) of products and services.

48 KARAOLI & DIMITRIOU STREET, CHALANDRI, ATHENS 152 32, GREECE

• TEL. +302106775003, Fax +302106812770, email: tech@martech.gr

Smart, innovative and effective solutions in the field of sea

Innovative answers to the environmental degradation, to the financial and energy crisis

ΘΑΛΑΣΣΙΑ ΕΝΕΡΓΕΙΑΚΑ ΣΥΣΤΗΜΑΤΑ Α.Ε. OFFSHORE ENERGY SYSTEMS S.A.

AREAS OF ACTIVITIES, PRODUCTS AND SERVICES

“Offshore Energy Systems SA” offers a wide range of products and services which cover the following sectors: (For more information please consult Technical Data Sheets of our products and visit our web space www.martech.gr) FLOATING SYSTEMS Floating pontoons, Floating docks Floating working and recreational platforms Fish cages for open waters Floating masts for lighting and surveillance for fish farms Floating Buoys, anchoring systems BOTTOM SUPPORTED ASSEMBLED WHARVES ON PILES Access bridges, wharfs, platforms on piles Prefabricated systems assembled in situ WAVE ABSORBING SYSTEMS Floating and bottom supported wave absorbers Wave absorbing docks Absorbing apparatus of water beams from ship propulsion systems Shore protection from wave action with wave absorbing systems

OFFSHORE ENERGY SYSTEMS, INCLUDING :

• WIND MEASUREMENTS PLATFORMS

Floating platform with foldable mast of big height Floating wind measurement platform with LIDDAR system Bottom supported wind measurement platform WIND GENERATOR PLATFORMS Bottom supported platforms for shallow waters Floating platforms of mixed structure for deep and very deep waters

• WAVE ENERGY SYSTEMS

Production of electricity by exploiting wave and multiple energy sources Energy storage systems in air tanks in the sea bottom of a balloon type Combine wave absorbing and wave energy extraction systems SHIP SYSTEMS AND SHIP EQUIPMENT Design and production of industrial boats Fish farm auxiliary boats, tugs, fishing boats Small tourist boats , small coastal boats But also Air fed foils of combined structure Stabilizing systems based on air fed foils RESEARCH AND DEVELOPMENT Wave absorbing systems Offshore wind energy systems Energy extraction from waves Energy storage systems Special ship systems PORT OUTFITTING Pedestals for marinas, camping's, fishing and small ports Antipollution systems and equipment Mooring equipment and accessories

48 KARAOLI & DIMITRIOU STREET, CHALANDRI, ATHENS 152 32, GREECE

• TEL. +302106775003, Fax +302106812770, email: tech@martech.gr

Smart, innovative and effective solutions in the field of sea

Innovative answers to the environmental degradation, to the financial and energy crisis

ΘΑΛΑΣΣΙΑ ΕΝΕΡΓΕΙΑΚΑ ΣΥΣΤΗΜΑΤΑ Α.Ε. OFFSHORE ENERGY SYSTEMS S.A.

ENERGY SYSTEMS – RENEWABLE ENERGY SOURCES

Offshore Energy Systems claims to be leader in the energy sector having developed significant technologies in this area. More specifically:

Wind Measurement systems

We can undertake the full design, construction, installation and operation

• f wind measurement systems, data acquisition and analysis in all areas

either land or offshore. More specifically: Floating platform for wind measurements with foldable mast at the real height for deep and very deep waters. Assembled or foldable masts of multiple uses for wind measurement installed at the sea bottom in locations with relatively shallow waters . Assembled or foldable masts for multiple uses installed at land locations Data acquisition and analysis of wind measurements according to the regulations and international standards, preparation of a complete file for licensing of offshore wind farms.

Offshore Wind Farms

Study, design and construction of platforms for the installation of wind generators in offshore areas for a wide range of water depths. More specifically : 1.Platforms supported on the sea bottom in relatively shallow waters capable to carry a high capacity wind generator. 2.Floating Platforms of INFLO technology (INtensive FLOtation), of excessive buoyancy and vertical moorings , capable to be installed in deep and very deep waters and capable of carrying a wind generator of very high capacity.

Systems for temporary energy storage in connection with wind and wave energy exploitation.

We develop systems for energy storage in the form of compressed air, stored in air tanks installed at the sea bottom, capable of storing big quantities of energy. The air tanks are of a balloon type installed at the sea bottom, while the retrieval of stored energy is achieved by exploiting the water pressure at the installation depth. The storage system can work in combination with our Wave Energy Converter, a system under development within our company and which is described in other sections of this presentation. In our wave energy exploitation the system directly produces compressed air which can be stored in the air tanks during the night hours and to be utilized in producing electricity during day hours of high demand. In this case the system can also exploit the daily difference of temperature since during night the air temperature is low while during day the temperature is much higher and can be used to heat the stored air increasing thus its energy content. In wind power excess electricity which cannot be absorbed by the system

• r it is produced at low demand hours can be used to compress air which

can be stored in the sea bottom air tanks. This energy can be used to produce electricity during day hours of high demand in the same way as is done with our wave energy system.

48 KARAOLI & DIMITRIOU STREET, CHALANDRI, ATHENS 152 32, GREECE

• TEL. +302106775003, Fax +302106812770, email: tech@martech.gr

Smart, innovative and effective solutions in the field of sea

Innovative answers to the environmental degradation, to the financial and energy crisis

ΘΑΛΑΣΣΙΑ ΕΝΕΡΓΕΙΑΚΑ ΣΥΣΤΗΜΑΤΑ Α.Ε. OFFSHORE ENERGY SYSTEMS S.A.

OFFSHORE AND COASTAL WORKS

The coastal and offshore areas in Greece consist the vital field where most of human economical and social activity develops. With 16.000 Km of coast line and with the unique island complex of Aegean and Ionian seas this country should be at the edge of sea technology developments , to export technology, not import. The pressure to execute works in the coastal areas has led to monolithic structures, either legal or illegal, which have huge cost, but most importantly huge impacts to the environment. In this context our company has undertaken a serious and systematic effort to develop useful technologies and applications for tackling a large number of problems of this kind. In our products and applications the following are included: 1.Floating wharfs for accommodating small boats (leisure, fishing etc) for the internal layout of ports, marinas, fishing and touristic ports, as well as in protected bays. 2.Floating docks for accommodating large ships and especially Ferry Boats. 3.Floating platforms of intense floatation and vertical moorings with applications in deep waters for fish farms, offshore works in open sea etc. 4.Platforms –wharfs on piles of supported and assembled type with applications in developing accesses to the sea, especially in areas open to the weather. 5.Floating wave absorbers of vertical moorings for creating protected areas with many different applications in developing ports, in protecting existing ports, in protecting shore from corrosion etc. 6.Absorbing docks for tackling the clapotis waves in the interior of existing and new ports. 7.Apparatus for absorbing water beam produced by ship propulsion devices and for protecting docks from underscoring. 8.Open water fish cages for deep and very deep waters 9.Floating anchorages for tankers (oil terminals), large Cruising ships APPLICATIONS Development of protected sea zones for creating marinas, fishing ports, touristic harborages. Shore protection from waves Improvement of the conditions and safety in the interior of existing ports Development of large Ferry Boat mooring facilities Internal layout of ports, marinas, fishing ports with floating pontoons, wharfs on piles, floating docks. Creating open water floating anchoring facilities for various applications Open water Fishing farms

48 KARAOLI & DIMITRIOU STREET, CHALANDRI, ATHENS 152 32, GREECE

• TEL. +302106775003, Fax +302106812770, email: tech@martech.gr

Smart, innovative and effective solutions in the field of sea

Innovative answers to the environmental degradation, to the financial and energy crisis

ΘΑΛΑΣΣΙΑ ΕΝΕΡΓΕΙΑΚΑ ΣΥΣΤΗΜΑΤΑ Α.Ε. OFFSHORE ENERGY SYSTEMS S.A.

SHIP AND SPECIAL OFFSHORE STRUCTURES DESIGN AND PRODUCTION

The Offshore Energy Systems SA possess knowledge, experience and the tools to carry out a complete study and design of ships and special offshore structures according to the customer demands, the rules and regulations, as well as the codes of science and good practices. In our design tools the following are included: AUTOCAD Mechanical Desktop – Electronic development of drawings AUTOSHIP – 3D ship shape development AUTOHYDRO – Stability calculations at all conditions AUTOPOWER – Propulsion calculations AUTOPLATE – Shell expansion, plate design AUTOBUILD – 3D internal stiffening AUTONC – NC cutting and forming machines driving SAP 2000 vs 8.3.4 – Finite element analysis of structures – Strength calculations – static, and dynamic FLOATSIM – Time domain simulations of ship and offshore structures motions, Station Keeping calculations of moored and dynamically positioned systems. MOOR – Quasi static and dynamic calculations of mooring systems WITH THE ABOVE TOOLS AND OUR EXPERTISE WE CAN UNDERTAKE Study and design of new ships based on customer requirements Development of effective ship form and ship lines plans, Hydrostatic calculations, propulsion calculations. Strength calculations based on rules and on analytical methods , Piping and electrical systems design Full construction drawings, parts lists, cutting and forming sketches Study and design of ship modifications , including 3D mapping and the full required studies and drawings, the issue of certificates and licenses Transport and techno economic studies Analysis of transportation networks Defining requirements and ship design parameters Building budged – analysis of exploitation results – complete techno economic study Project financing IN OUR PRODUCTION FACILITIES AND IN ASSOCIATIVE SHIPYARDS WE CAN UNDERTAKE THE PRODUCTION OF Working boats (fish farm support, supply, tug boats etc) Fishing boats and Touristic boats Ferry Boats Single and multi hull, open and closed type Wind measurement and Wind Platforms SPECIAL SHIP SYSTEMS Special foil construction of complex structure Ventilated hydrofoils – Flaps, Propulsion rings, Rudders Automatic Ride control systems based on ventilated hydrofoils

48 KARAOLI & DIMITRIOU STREET, CHALANDRI, ATHENS 152 32, GREECE

• TEL. +302106775003, Fax +302106812770, email: tech@martech.gr

Smart, innovative and effective solutions in the field of sea

Innovative answers to the environmental degradation, to the financial and energy crisis

ΘΑΛΑΣΣΙΑ ΕΝΕΡΓΕΙΑΚΑ ΣΥΣΤΗΜΑΤΑ Α.Ε. OFFSHORE ENERGY SYSTEMS S.A.

RESEARCH AND DEVELOPMENT

Offshore Energy Systems SA is an innovation center which is solely based on its research program for the development of products and services. In fact all our products and services we offer are the product of in house research efforts. Shortly we have developed technologies in the following fields: 1.The Intense Floatation Technology (INFLO Tech) which in fact is an application

• f the Tension Leg principles in day to day floating applications. INFLO technology

has found applications in constructing floating wharves, Floating Platforms for deep waters, in the development of fishing cages for open waters, but also platforms of INFLO tech consist the carriers of the wave absorbing cells of the floating wave absorbers, the wave energy converters of our system for exploiting wave energy. It is also the basis for the floating wind measurement platforms which we have developed, the floating fish farm lighting and surveillance towers, the Wind Platforms that can carry large wind generators for deep and very deep

• waters. However INFLO technology, in our sense is not a simple tension leg

application since it is a combined tension leg and spar technology with inherent capabilities for tuning system natural frequencies and adjust it to the specific environment. 2.The wave absorbing technologies based on the absorbing cells of fin type designed for dispersing the wave by modifying the water particle motion and by producing counteracted waves that diminish the wave energy. At the same time they produce counteracted forces within the cells minimizing the overall forces on the body of the wave absorber. Based on the wave absorbing technology we produce floating wave absorbers on INFLO platforms, floating wave absorbers on free floating platforms, wave absorbing docks of bottom supported type etc. 3.Wave energy exploitation. The system, instead of dispersing the wave energy, as is the case with the wave absorbers, it converts it to compressed air through a mechanism (Wave Converter – WECO) that transforms the stochastic wave movement to a continually useful motion. The system is in many respects innovative and promises low energy costs and reliable operation under all circumstances. 4.Temporary energy storage systems in connection with renewable energy at sea. The system is developed to work with the wave energy system by storing the produced compressed air in air tanks of balloon type anchored at the sea bottom. The system can work also with wind power in a hybrid mode in which electricity produced during night, is stored in the air tanks and used during day, at peak demand, to produce electricity. 5.Ride control system for fast and superfast ships based on ventilated foils of mixed construction. The company holds the rights for a number of patents developed internally which were mentioned elsewhere in this leaflet. Our present research program includes the following projects: 1.System integration for wave energy exploitation (submitted to the General Secretariat for Research and Development of Greece with the participation of CRES). 2.Design and construction of a pilot unit of 500 KW for electricity production from waves. 3.Development of energy storage systems in the form of compressed air in air tanks of balloon type and methods for exploiting multiple renewable energy sources. 4.Construction, testing and operating of a floating platform equipped wit a foldable tower for wind potential evaluation at sea. 5.Development of methodology and software for wind measurements corrections due to movements of a floating platform.

48 KARAOLI & DIMITRIOU STREET, CHALANDRI, ATHENS 152 32, GREECE

• TEL. +302106775003, Fax +302106812770, email: tech@martech.gr

Smart, innovative and effective solutions in the field of sea

Innovative answers to the environmental degradation, to the financial and energy crisis

FOR MORE DETAILS PLEASE : CONTACT US, ASK FOR OUR PRODUCT TECHNICAL DATA SHEETS VISIT OUR WEB SPACE

ΘΑΛΑΣΣΙΑ ΕΝΕΡΓΕΙΑΚΑ ΣΥΣΤΗΜΑΤΑ Α.Ε. OFFSHORE ENERGY SYSTEMS S.A.

PORT OUTFITTING

Offshore Energy Systems SA is cooperating with highly respected foreign companies which produce equipment related to our activities and which allow us to offer integrated and turn key services to our customers. We emphasize on Environmental Protection Systems, which is in line with our philosophy towards the environment and its protection and to systems for marinas and port security as well as boat supply with electricity and water. In connection with our activities in the renewable energy sector we are in close cooperation with wind generators producers as well as producers of photovoltaic panels which we incorporate in many of our products, like floating towers for fish farm lighting and surveillance, wind measurement platforms etc. On the above basis: We represent in Greece, Cyprus and other Mediterranean countries the company TALLY KEY of Denmark which produces systems for boat supply with electricity, water, etc with the smart system of the prepaid card. The system can also be used for access control in marinas, ports in general, camping's or in other installations with security requirements. We represent in Greece, Cyprus and other Mediterranean countries the company LAMOR of Finland which produces antipollution equipment , including: Floating Booms Absorbing materials Skimmers, Pumps and compressors Antipollution boats and vehicles Full antipollution equipment and support. In addition to the above, with direct cooperation with producers in all over the world we can offer: Plastic buoys of various capacities Fenders for a variety of applications Anchoring equipment Floaters for various applications
