SLIDE 1
New Concepts in Voltage Grading
Jens M. Seifert BU LIKE Lapp Insulators GmbH, Germany
New Concepts in Voltage Grading JENS SEIFERT New Concepts in - - PowerPoint PPT Presentation
New Concepts in Voltage Grading JENS SEIFERT New Concepts in - - PowerPoint PPT Presentation
New Concepts in Voltage Grading JENS SEIFERT New Concepts in Voltage Grading Jens M. Seifert BU LIKE Lapp Insulators GmbH, Germany Content Introduction Characteristics of Microvaristor/Epoxy Composite Computational Verification
SLIDE 2
SLIDE 3
2
INMR 2015 Munich
Content
- Introduction
- Characteristics of Microvaristor/Epoxy Composite
- Computational Verification (FEM Simulations)
- Experimental Verification
- Summary
SLIDE 4
3
INMR 2015 Munich
Content
- Introduction
- Characteristics of Microvaristor/Epoxy Composite
- Computational Verification (FEM Simulations)
- Experimental Verification
- Summary
SLIDE 5
4
INMR 2015 Munich
Introduction
Main Features for Bushing Improvement:
- Damping of High Local Electrical Field Stresses
no partial discharges proctect from accelerated material aging
- Compact Design less requirement of space
- Eco-Friendly Design less 𝐓𝐆𝟕 is required
- Economical Design less material cost
SLIDE 6
5
INMR 2015 Munich
Concept of Design
Realisation using non-linear field grading material: µVar/epoxy
a) conventional bushing b) compact bushing with µVar
𝐞𝟑 ≈ 𝟏. 𝟖𝐞𝟐
SLIDE 7
6
INMR 2015 Munich
Content
- Introduction
- Characteristics of Microvaristor/Epoxy Composite
- Computational Verification (FEM Simulations)
- Experimental Verification
- Summary
SLIDE 8
7
INMR 2015 Munich
µVar Filled Epoxy
Morphology of µVar Fillers: µVar functional particle:
- each particle has the non-linear property
- ZnO-particles with Sb-Bi interphase
- Semiconductor with respect to field stress
- Switching field stress depends on grain size
- f ZnO
- µVar powder require a carrier matrix
ZnO grain Sb-Bi interphase
SLIDE 9
8
INMR 2015 Munich
µVar Filled Epoxy
Electrical properties of µVar filled epoxy resin with diff. contents:
75 wt% is required
SLIDE 10
9
INMR 2015 Munich
µVar Filled Epoxy
Temperature influence:
no significant influence of temperature
thermal stable
SLIDE 11
10
INMR 2015 Munich
Content
- Introduction
- Characteristics of Microvaristor/Epoxy Composite
- Computational Verification (FEM Simulations)
- Experimental Verification
- Summary
SLIDE 12
11
INMR 2015 Munich
Modelling Setup
A Simulated 550kV Bushing: 2D FEM-Simulations:
- Based on EQS (Electro-quasi-
static) approximation
- Both capacitive and resistive
effects are considered
- Allow virtual prototypical
design with low cost
SLIDE 13
12
INMR 2015 Munich
Simulation Results
- 33.3 %
SLIDE 14
13
INMR 2015 Munich
Simulation Results
The length of the µVar/epoxy layer should not be too short!
SLIDE 15
14
INMR 2015 Munich
Simulation Results
The thickness of the µVar/epoxy layer has almost no influence
SLIDE 16
15
INMR 2015 Munich
Content
- Introduction
- Characteristics of Microvaristor/Epoxy Composite
- Computational Verification (FEM Simulations)
- Experimental Verification
- Summary and Outlook
SLIDE 17
16
INMR 2015 Munich
Experimental Setup
Test Setup in HV Laboratory (Lapp Insulators GmbH)
µVar/Epoxy layer
SLIDE 18
17
INMR 2015 Munich
Experimental Results
Partical discharge measurement
(according to IEC standard 60137)
Voltage (RMS) Partial Discharge Partial Discharge
nominal voltage (318 kV)
< 1pC < 1pC
test overvoltage (476 kV )
<5 pC <5 pC
test overvoltage (710 kV ) 1 min.
5.5 pC-126 nC 5.5 pC-126 nC
SLIDE 19
18
INMR 2015 Munich
Experimental Results
Temperature measurement
(using an infrared camera)
Voltage (RMS) Time Temperature Increase
nominal voltage (318 kV)
20 min. 0.3 °C
test overvoltage (476 kV )
10 min. 7 °C
SLIDE 20
19
INMR 2015 Munich
Experimental Results
Temperature measurement
(using an infrared camera)
Image of temperature increase after approx. 10 mintes. start: 23 °C end: 30.2 °C
SLIDE 21
20
INMR 2015 Munich
Content
- Introduction
- Characteristics of Microvaristor/Epoxy Composite
- Computational Verification (FEM Simulations)
- Experimental Verification
- Summary
SLIDE 22
21
INMR 2015 Munich
Summary
- The first compact bushing featuring with µVar/epoxy
component
- Microvaristor/epoxy composite with above 75 wt% has
an obvious nonlinearity
- Using µVar/epoxy layers in bushing are able to reduce
high electric field stress
- This approach allows to design the bushing compactly
(eco-friendly and economical design)
- Design of compact bushing featuring µVar/epoxy via
FEM has been successfully demonstrated
- Design via FEM confirmed by high-voltage tests
