Adak Behin Niroo

www.adakbn‐co.com

PRODUCTS

 LOW VOLTAGE SWITCHGEARS  MEDIUM VOLTAGE SWITCHGEARS

PRODUCTS

 LOW VOLTAGE SWITCHGEARS

www.adakbn‐co.com

SIVACON TECHNOLOGY

• High Standard
• Type‐Tested
• Know‐How
• Image &

Resources

• High Flexibility
• Close Customer

Contact

• Regional

Experience

PROXIMITY TO THE COSTUMER WORLD TRADE NAME

www.adakbn‐co.com

The key features of SIVACON 8PT

• Short‐circuit capability Ipk to 375 kA
• Optional cable entry from top or bottom
• Modular design of device compartments
• Generous device unit depth for multipurpose installation
• Type‐tested standard modules (TTA) from Siemens
• 3 and 4‐pole busbar system up to 7400 A
• Uniform busbar position at the top of the unit
• Models available using withdrawable, plug‐in & fixed technology
• Single‐fronted or double‐fronted layout

www.adakbn‐co.com

door 25 mm side panel 2 mm rear panel 2 mm partition sheet (inside) 2 mm frame

Surface treatment:

• ptionally powder‐coated, wet painted or galvanized

Material: sheet steel in the following thicknesses: Frame: 2.5 mm Enclosure: 2.0 mm Degrees of protection IP 30, IP 40, IP 42 Ventilated to IEC 60529: IP 40, IP 54 Unventilated

www.adakbn‐co.com

BUSBAR SYSTEM TYPES

BUSBAR ON TOP BUSBAR AT REAR

www.adakbn‐co.com

SIVACON for all Applications in the Low‐Voltage Network

Applicable as current classes A: Power Center A 7400A B C C: Sub distribution Board Motor Control Center Process Automation B: Main Distribution Board 4000A 3200A Applicable as current classes A: Main Distribution Board 3200A B: Sub distribution Board 1250A A B

www.adakbn‐co.com

FCB

Functions: Incoming, outgoing feeders and couplings

• Current range from 630A to 6300A
• Cubicle width: 600, 800, 1000, 1200mm
• Degrees of Protection: IP42 … IP54
• Internal separation: 1, 3a, (2b, 4b for FCB1)
• Equipped with withdrawable or fixed mounted ACB
• Reliable travel of the circuit breaker

while the door is closed

• Cable/busbar connection optionally
• from above or below

www.adakbn‐co.com

Functions: Outgoing feeders in fixed‐mounted design

OFF 1…4

‐ Any combination of modular cable feeders ‐ Easy replacement of cable feeders after deenergizing the switchboard ‐ Devices are connected without the need for drilling or punching ‐ Easily accessible connections for quick

www.adakbn‐co.com

Vertical distribution busbar & modular cable feeders

‐Current range: up to 630A / feeder ‐Internal separation: 1… 4b ‐Rated current vertical busbar: 1400A ‐Max. busbar size: 2x40x10 ‐ Cable connection compartment at the right side in the cubicle ‐Fused and non‐fused design ‐ No. of poles device: 3‐ & 4‐pole

www.adakbn‐co.com

Functions: Outgoing feeder fixed mounted design switchable fuse disconnectors

‐ Fuse‐switch disconnectors make for optimum packing density ‐ Rated current: 630A / feeder ‐ Vertical busbar system with rated current: 2800A ‐ Maximum busbar size: 2x100x10 ‐ Cubicle width: 600, 800, 1000mm ‐ Internal separation: 1, 2b ‐ High component density up to 25 plug‐in modules per cubicle (OFFD1, Horizontal connection) ‐ Cable connection compartment at the right side (OFFD1) & rear side (OFFD2) in the cubicle

OFFD

www.adakbn‐co.com

OFPD

Functions: Outgoing Feeder Cubicles in In‐line Plug‐in Design

‐ Rated current: 630A / feeder ‐ Rated current vertical busbar: 2100A ‐ Busbar size: 1x80x10 (3‐ & 4‐pole) ‐ Cubicle width: 1000, 1200mm ‐ Degrees of Protection: IP41 ‐ Internal separation: 1, 3b, 4b ‐ High component density up to 34 plug‐in modules per cubicle ‐ Cable connection compartment at the right side in the cubicle

www.adakbn‐co.com

Functions: Motor feeders & outgoing cable feeders plugged in design

OFPM

‐ Current range: outgoing cable feeders up to 630A / motor feeders up to 250KW ‐ Cubicle width: 1000mm ‐ Degrees of Protection: IP42 … IP54 ‐ Internal separation: 2b, 4a ‐ High component density up to 22 plug‐in modules per cubicle ‐ Cable connection compartment at the right side in the cubicle ‐ Fused and non‐fused design

Plug‐in bus system

‐Integrated protection against electric shock ‐ safe‐to‐touch (IP20B) ‐ 3 and 4pole versions possible ‐ Tap openings in a modular grid of 25 mm ‐ Rated current up to 1200 A ‐ Short‐circuit strength

Ipk up to 163 kA Icw up to 65 kA, 1 s up to 50 kA, 3 s

‐ Lateral guides for a reliable plugging

www.adakbn‐co.com

Plug‐in units & cable connection

‐ Free assembly of devices or device combinations ‐ Free combination of plug‐in units in the cubicle ‐ Non fused motor feeders up to 11 kW in 75 mm module height up to 45 kW in 125 mm module height ‐ With and without current metering ‐ Instrument panel for measure‐ and control devices directly in the door ‐ Cable connection for Power circuits: direct at the switching device Control circuit: at terminals ‐ 400 mm wide cable connection compartment

Functions: Motor control center in withdrawable unit design

OFW

• Motor and cable feeder up to 630 A

(fused and non‐fused)

• Cubicle width: 600, 1000mm
• Degrees of Protection

In connect pos.: IP42 … IP54 In disconnect & test pos.: IP30

• Internal separation: 3b, 4b
• Up to 17 withdrawable units
• Cable connection compartment

at front or rear

• Alteration of compartment size possible

without having to shutdown the switchboard

D POSITION TEST POSITION CONNECTED POSITION ‘I’ DISCONNECTED POSITION ‘0’ POSITION

‐ Integrated protection against electric shock, safe‐to‐ touch (IP20B) ‐ 3‐ and 4‐pole versions ‐ Tap openings in a modular grid of 25 mm ‐ Rated current up to 1200 A ‐ Short‐circuit strength Ipk up to 163 kA Icw up to 65 kA, 1 s up to 50 kA, 3 s

High safety optimum cable connection compartment

‐ Cable connection compartment at the rear with cable

gland box

‐ High form of internal separation up to Form4 Type7 acc. to

BS EN 60439 (gland box per functional unit)

Vertical busbar system

Withdrawable units

‐ Standardised design in 8 module heights (100, 150, 200,

300, 400, 500, 600, 700mm)

‐ Motor feeders fuse‐less up to 11kW in 100mm module

height only

‐ Control plugs up to 40‐pole with bus contact optionally

(PROFIBUS‐DP with Win‐SIMOCODE PRO V)

‐ Plenty of space for auxiliary equipment by possibility of

fitting components at the rear

Withdrawable units

‐ Insertion support for easy moving of the withdrawable

units > 250 A

‐ Control panel for measuring instruments and actuating

devices directly on the withdrawable unit

‐ Simple conversion of with‐drawable compartments without

shutdown of switchboar

‐ Lockable disconnected position for safe operating at the

load

Functions: Reactive power compensation

‐ One controller module and one or more capacitor module(s) ‐ Cubicle width: 800mm ‐ Degrees of Protection: IP42 ‐ Internal separation: 1, 2b ‐Non‐choked power factor correction‐unit 4RY up to 500KVAR per unit ‐ Choked power factor correction‐unit 4RF up to 300KVAR per unit

PFC

Functions: Cubicle for customised solutions

‐ Various installation components ‐ Cubicle‐high doors or compartment doors ‐ Compartmentalization ‐ Vertical distribution busbar 3 and 4 pole ‐ Rated current up to 1200 A ‐ Rated peak withstand current Ipk :up to 163 kA Icw :up to 65 kA

CCS

Functions: Corner cubicle

Corner Cubicle

FCB

‐ Current range from 630A to 3200A ‐ Cubicle width: 400, 600, 800mm ‐ Degrees of Protection: IP41 … IP54 ‐ Equipped with withdrawable or fixed mounted ACBs ‐ Reliable travel of the circuit breaker while the door is closed

Functions: Incoming, outgoing feeders and couplings

FCB1 FCB1 FCB1 FCB1 BC L BC T

FCB Types

Functions: Outgoing feeders in fixed‐mounted design

OFF

Door with inspection window With door ‐ Rated current: up to 1400A ‐ Cubicle width: 400, 1000mm ‐ Degrees of Protection: IP30, IP40 … IP54 ‐ Equipped with fixed mounted design

Functions: Outgoing feeder fixed mounted design switchable fuse disconnectors

‐ Rated current: 630A / feeder ‐ Vertical busbar system with rated current: 1560A ‐ Maximum busbar size: 1x60x10 ‐ Cubicle width: 600, 850mm ‐ Degrees of Protection: IP31, IP41 … IP54 ‐ Fused design

OFFD

Functions: Outgoing Feeder Cubicles in In‐line Plug‐in Design

‐ Rated current: 630A / feeder ‐ Vertical busbar system with rated current: 2100A ‐ Maximum busbar size: 1x80x10 ‐ Cubicle width: 1000, 1200mm ‐ Degrees of Protection: IP41 ‐ Fused design

OFPD

SIGNED, SEALED & DELIVERED SAFETY

Reference standard: IEC 60439‐1

• Verification of temperature rise limits by test
• Verification of dielectric properties by test
• Verification of the short‐circuit withstand

strength by test

• Verification of the protective circuit
• Verification of clearances and creepage

distances

• Verification of mechanical operation
• Verification of the degree of protection
• Verification of the glow test

Type Tested for the world’s most onerous environments

Glow Test According to IEC 60439‐1 Internal Arc Containment Test According to IEC 61641‐1 Earth quaked Tested Vibration Tested

Internal arc testing

Special test to IEC 61641 (Report)

• r VDE 0660 Part 500, supplement 2

Arc strikes in circuit‐breaker panel Burning duration U = 690V + 5% Icw = 52KA tp = 310ms

Data acquisition sheets

BUSBAR AT REAR BUSBAR ON TOP

Engineering, drawings & documentation

Quotation Generating, Order Engineering, Manufacturing, Assembling

PRODUCTS

 MEDIUM VOLTAGE SWITCHGEARS

PRODUCTS

Medium Voltage Sw itchgears

The ABN MV sw itchgear is a com pact vacuum circuit breaker sw itchgear for the m edium voltage range. ABN MV is developed prim arily for substations, pow er plants and industrial electrical distribution w here com pact functionality, m odern design, safety and durability are needed. I n the versatile furnishing of the sw itchgear, com ponents from the best m anufacturers in the field are used. The MV product fam ily’s circuit- breakers are used as a m ain com ponent. The cubicle structure, insulation and bushings are designed to enable custom ised technical and econom ical solutions.

PRODUCTS

Medium Voltage Sw itchgears

Due to its static and rigid fram e, ABN MV is easy to m ove and transport even

• ver longer distances. The rigid fram e does not cause tension in the bus ducts
• r the sw itchgear connections. The sw itchgear is type tested and arc tested to

I EC/ EN standards. The unit’s rated voltages are 7 .2 kV, 1 2 kV, 2 4 kV, therm al short-circuit resistance 3 1 .5 kA ( 3 sec) and rated current 6 3 0 -2 5 0 0 A. The sw itchgear is designed for safe use: all functions are perform ed behind closed doors, the breaker and earthing sw itch are m echanically locked together, and the function unit is equipped w ith blocking plates to prevent faulty operation.

Service and Expertise At ABN w e rem ain close and in touch w ith our custom ers. For us, it is im portant to listen to the custom er, to be flexible to their needs, and to be a reliable and responsible partner. Our operations are based on decades of experience in the field coupled w ith the enthusiasm and innovative creativity of new -generation expertise. W e develop and m anufacture all of our core products in-house. W e continuously develop our

• perations to ensure w e rem ain able to offer our custom ers ever m ore efficient,

reliable and environm entally friendly products and solutions. CORPORATE RESPONSI BI LI TY Corporate responsibility is a vital part of our day-to-day operations. Our responsibility is grounded in law and integral to our values and strategy.

THE ABN APPROACH

OPERATI ONAL POLI CY

Quality – The bedrock of our business The quality

• f our

products and operations is based on consistent quality m anagem ent throughout our organisation. Our operations are defined by our I SO 9 0 0 1 :2 0 0 8 com pliant quality system , and is annually audited by QA TECHNI C. I n addition to quality system auditing, our production and products are also subject to annual quality assurance assessm ent by QA TECHNI C Ltd.
