AAVISHKAR MACHINERY PVT. LTD. Corporate Presentation AAVISHKAR - - PowerPoint PPT Presentation

AAVISHKAR

MACHINERY PVT. LTD.

Corporate Presentation

Corporate Presentation

Company Overview Product

• Conveying

Products

• Grinding Products
• Crushing Products
• Screening Products
• Classification

Products Services

AAVISHKAR

Company Overview

AAVISHKAR

• I. Profile
• II. Business Model
• III. Market & Strategy

Profile Business Model Market & Strategy Mission:

• We are one AAVISHKAR team committed to global excellence as a client

focused equipment supplier & service company providing competitive & environmentally friendly technologies to the cement & mining industries.

• To achieve excellence in Project Management and Engineering Consultancy.
• Up gradation / improvement as a Catalyst in the Manufacturing process.
• Customer Service with the desired quality, so as to provide value for money.

AAVISHKAR

Company Overview:

For Turn Key Plants we offer:

• Full line engineering & equipment supply
• Individual machines
• Equipment packages
• Spare parts and full range of plant services

AAVISHKAR

AAVISHKAR today is a technology focused process engineering & project execution company. AAVISHKAR has a history over

28 years of building on new

technologies, innovations & high end process to meet global cement industries demand. Our Vision: To become the solutions provider of choice.

AAVISHKAR

Turn-key Projects We handle:

• Cements Plants
• Sugar Plants
• Zinc Oxide Plants
• Copper Extraction Plants
• Refractory Castables Units
• Cement, Lime, Clay And Mineral Calcinations Plants
• Iron Fines Pelletizing Units
• Mineral Grinding And Processing Plants
• Vertical Brick Plants
• Fly Ash Block/ Brick Plants
• Fertilizer Plants

AAVISHKAR

Our Operations Overseas:

• Mining In Indonesia For Zircon & Manganese
• Lime Processing Plant In Sri-Lanka
• Cement Project In Africa
• Gold Processing Unit In Indonesia
• Beach Chrome Beneficiation In Indonesia

Our Operations In India:

Gujarat

Maharashtra Karnataka Tamil Nadu Andhra Pradesh Orissa Chhattisgarh

• W. Bengal

Meghalaya Assam Bihar Jharkhand Rajasthan Madhya Pradesh Punjab AAVISHKAR

Turn-key Projects We handle in INDIA:

AAVISHKAR

Our Presence:

Nepal Zambia South Africa U.A.E. Pakistan Sri Lanka Malawi Bhutan Indonesia Bangladesh

AAVISHKAR

Business Model:

Design Engineering After Sales Service Manufacturing Commissioning Erection

• Basic R&D
• Prototype

Development

• Testing
• Design Process &

Electrical Engineering

• Automation

Services

• Instrumentation
• Control
• Optimization of

components

• Local

Manufacturing with best price solution

• Erection services

for complete production lines or portions of plant.

• Supervision &

project management services.

• Commissioning

service for complete production lines or portions of plants.

• Training and

Supervision service.

• Spares & wear

parts

• Audits
• Process Function
• Mechanical

Equipments

• Electrical and

Automation

• Quality &

Chemistry

• Environmental

Matters

Dedicated Project Management Teams for Capital Projects. Lifetime Customer Account Management. Uniform Quality Through Joint Certification.

The Foundation Stone

AAVISHKAR is not merely equipment manufacturing company or yet another

• rganization in the international equipment market. It is a company that has

emerged and risen from a culmination of success, innovation and growth. AAVISHKAR started as a manufacturing firm on the year 1993, a small sized business, to a modest sized clientele. The quality of products and services rendered to clients resulted in the company gaining a larger client base and expansion of business. The excellent support extended by companies and principals around the globe contributed towards AAVISHKAR establishing itself as a sourcing. Innovating and a major manufacturing company of distinction. AAVISHKAR

Cornerstone To Milestone

The past one-decade has indeed been an outstanding period for AAVISHKAR. The company has grown from strength to strength and has firmly consolidated its position as a market leader. The phenomenal sales performance achieved by its CEO, Mr. Kunal Jena has resulted in AAVISHKAR receiving distinction from renowned companies both national and international. The success story of the company can be attributed to the company's growth and policies, which is totally customer oriented. These have resulted in AAVISHKAR growing from a small enterprise to one of international repute. Continental growth and success led AAVISHKAR to spread its horizons from local to global. The company opened up for international trade. AAVISHKAR now manufactures a large no. of equipments and represents many reputed companies who in turn are leaders in their respective field of business. AAVISHKAR

AAVISHKAR offers its clientele a wide range of quality equipments from its own manufactured range and sourced from reputed companies. Prompt servicing and forwarding ensure that goods are delivered on time. The company has efficient working facilities for any manufacturing. Thus, the client is always assured of availability of any equipment at short notice.

The Silver Platter

AAVISHKAR

A Gilt Edged Policy

AAVISHKAR is a fully customer oriented company and believes strongly in client

• satisfaction. Constant emphasis and commitment to quality products, excellent

service and good client relationship are the hallmarks of its underlying principles. The growing number of its clients bears testimony.

A Brilliant Spectrum

A commitment to providing excellent products has led the management to tie up for a new Research and Development Department, housed in a purpose built

• ffice-cum-factory building.

A fully equipped laboratory with sophisticated equipment and qualified personnel ensures that only the finest products reach customers.

Certifications

AAVISHKAR believes in offering the highest quality products backed up by a proven efficient service and looks forward for its clients to achieve BIS and ISO certification. AAVISHKAR

AAVISHKAR is committed to offering its clients a wide range of value-added products and services. The company is tying up for an in-house, fully equipped R & D department, which produces in – house designs for the paint, ceramic, refractory, cement, sugar, minerals, resins etc. The company is also coming out with its own publication house to cover all these areas and keep informed all entrepreneurs, CEOs and to everyone related to these industries about the latest developments both national and global. The publication will also be informative on availability of raw materials , spares lubricants , government policies etc. It will also have a situations wanted and vacant column, which will be helpful both for the employer and the employee in addition to

• ther articles bearing inspiration for industrial developments.

Many of the equipments are produced in-house from company owned resources to exacting standards. Equipment designed ensures a continued, high quality and quantity as per commitments. The range of products today, is varied but can be broadly classified under ALLUMINIUM based units to ZINC OXIDE plants. AAVISHKAR

Value – Added Products & Services

A Vision Of The Future

The continuous pursuit of quality, innovation and a proven track record of success will pave the path for AAVISHKAR from this decade to next few decades with strong and confident strides. As AAVISHKAR progresses towards its vision of the future, it will work towards enhancing its image as a market leader of the 21st century. AAVISHKAR

Our Equipments

1. Crushing Equipments Single Toggle Jaw Crusher Double Toggle Jaw Crusher Roller Crusher Hammer Mill

• 2. Grinding Equipments

Continuous Ball Mills Batch type Ball Mill Pulverizers

• 3. Screening Equipments

Gyratory Multi Deck Screens Rectangular Multi Deck Screens

• 4. Conveying Equipments

Screw Conveyor Belt Conveyor Pneumatic Conveyor Bucket Elevator Vertical Lifts 5. Pelletizing Equipments Nodulizer/Pelletizer Granulator

• 6. Storage Equipments

Silo Pneumatic Blending Silo

• 7. Feeding Equipments

Table Feeder Vibrating feeder

• 8. Mixing Equipments

Ribbon Blender Pan Mixture Muller Mixture 9. Separating Equipments Erkensator Solemnity Separator

AAVISHKAR

Crushing Equipments

• 1. Single Toggle Jaw Crusher

Single Toggle Jaw crushers are used for primary crushing. Single Toggle Jaw Crusher is designed for exceptionally heavy and continuous applications. Single toggle jaw crushers are provided in heavy and light versions with welded steel housing and a moving jaw in a welded or cast steel version, as well as an eccentric shaft made of high-grade forged steel.

Features and Benefits

High and constant capacity High operational reliability Heavy Duty Forged Crank Shaft Broad range of application Easy replacement of wear and spare parts AAVISHKAR

• 2. Double Toggle Jaw Crusher

Double Toggle Jaw Crusher features hydraulic relief, automatic oil lubrication, and automatic wedge locking systems. We deal in the installations of Fuller-Traylor single and double toggle jaw. The Toggle Jaw crusher has been of extreme use in mining industry. Double toggle jaw crushers are made up of heavy duty fabricated plate frames with reinforcing ribs throughout.

Features and Benefits

High and constant capacity High operational reliability Heavy Duty Forged Crank Shaft Broad range of application Easy replacement of wear and spare parts AAVISHKAR

Crushing Equipments

• 3. Roller Crusher

The Roller Crusher has widely application in the industries of mining, building Materials, chemical industry, metallurgy, etc. The Roller Crusher can crush materials with middle hardness or less than middle hardness into secondary or fine granularity, such as crushing mineral, rocks, coke, coal, slag, scoria, and fire-proof material etc.

Features and Benefits

large feed inlet and high crushing cavity Used for hard and large materials Power consumption for crushing is low AAVISHKAR

Crushing Equipments

• 4. Hammer Crusher

The Hammer Crusher is widely used in the industry of mining, building materials, chemical industry, metallurgies and fodder. The Hammer Crusher can secondary and fine crush materials in middle or less than middle hardness such as barite, limestone, terrazzo, silica and stone, coal, coke, gypsum, aluminum sulfate, slag, etc.

Features and Benefits

Able to produce a wide range of particle sizes work with any friable material and fiber Ease of use Lower initial investment Minimal maintenance needed AAVISHKAR

Crushing Equipments

Grinding Equipments

• 1. Continuous Ball Mill

Continuous type Ball Mill the material is being fed from the one end through its hollow shaft, while the crushed material comes out from the hollow shaft, at the

• ther end. Usually continuous Mills are used when the production rate is required to

be high. Continuous Ball Mill is useful for grinding coarse feed to get fine powder in single continuous operation. It is grinding Ceramics, Cement, Pencil, Paint, Ink, Marble, Coal, Minerals etc. Features and Benefits The cost of installation is low The cost of power required is low It is suitable for materials of all degree of hardness The grinding medium is cheap AAVISHKAR

• 2. Batch Ball Mill

Batch type Ball Mil is widely used in beneficiation, building material and chemical industries. It is suitable for dry-type grinding and wet-type grinding. It is widely applied to the production of cements, silicate products, building materials, fireproof materials, fertilizers, glass, ceramics as well as nonferrous and ferrous metal processing industries.

Features and Benefits

Wet and dry intermittently to mill, mix, discharge material Used for ceramic raw material grinding, quartz, clay, etc. Large processing volume AAVISHKAR

Grinding Equipments

• 3. Pulverizers

Pulverizers are specially designed to deal efficiently and economically with wide range of materials and can be easily adjusted to give the fineness required from a coarse granulation to finely ground powder. Pulverizer Grinding is gradually done from the center of the periphery of the Rotor, allowing heavy pieces of material to be reduced by stages to the fineness power.

Features and Benefits

Low maintenance Labor savings Low consumption of power Affordable price Compact AAVISHKAR

Grinding Equipments

Conveying Equipments

• 1. Screw Conveyor

Screw conveyors have been a popular material handling mechanism. Screw conveyors are used horizontally or at a slight incline as an efficient way to move semi-solid materials. It usually consists of a trough containing either a spiral coiled around a shaft, driven at one end and held at the other, Spiral, driven at one end and free at the other. We have supplied these as a part of larger equipments and replacements.

Features and Benefits

Handling a great variety of bulk materials Have multiple inlet and discharge points AAVISHKAR

• 2. Belt Conveyor

Belt conveyor is the essential device in production line, which can transport materials directly on the belt both regular and irregular shaped objects, large or small, light and heavy successfully. Belt conveyors are designed to the production line according different materials and different environments. Features and Benefits Simple structure and easy to maintenance low cost and energy-saving Long service life AAVISHKAR

Conveying Equipments

• 3. Pneumatic Conveyor

Pneumatic Conveying System is a widely adopted means of transporting dry bulk material either by Vacuum or by Pressure of Air. Depending on the material to be conveyed, the air stream with specific velocity will carry the material to the final destination.

Features and Benefits

Free from contamination Simple and user friendly Speedy transfer AAVISHKAR

Conveying Equipments

• 4. Bucket Elevator

A bucket elevator or grain leg, is called a device that convey flow able bulk supplies

• vertically. It is useful in essential oil mill machinery and consist of buckets, a

belt, to carry the buckets and transmit the pull, device to generate the belt and components for loading the buckets or picking up the material. it is critical accessory for essential oil mill machinery since it can convey mild to heavy supplies at ease.

Features and Benefits

Large Conveying Capacity High Hoisting Height Smooth Transportation of Goods Less Maintenance Long Service Life & Low Driving Power Wide Range of Lifting AAVISHKAR

Conveying Equipments

• 5. Vertical Lifts

It is one type of material lifting equipment by which we can convey material to any height . This is an equipment which in a less space can carry material to any height irrespective of material size, liquid or solid.

Features and Benefits

Takes less space Low power consumption Low Maintenance Can handle any shape or Size AAVISHKAR

Conveying Equipments

• 1. Gyratory Multi Deck Screens

Gyratory Screen generated by a double eccentric weight mounted on both ends of a special vibratory motor mounted vertically. The machine performs any size based separation with the use of wire mesh or perforated sheet. During the process, the products smaller than the mesh aperture falls through the mesh and the oversize materials gets discharges from the outlet spout . The process repeats in the lower deck/s in the case of multi desk screening. This is being effectively used in food, pharmaceutical, chemical industries etc. The diameter, mesh size, number of decks can be varied as per customer requirements.

Features and Benefits

Low power consumption Varied range of application High processing rate per unit area of screen Minimum screen building Ball tray for anti blinding Multi-deck arrangements up to Seven decks

Screening Equipments

AAVISHKAR

• 2. Rectangular Multi Deck Screens

The Rectangular Multi Deck Screen is a kind of sieving equipment of international advanced level, developed by our company on the basis of carrying on the advantages of traditional screens and absorbing the outstanding technology from abroad. It is widely used for grading and screening materials in the following fields: minerals quarry, building materials, water conservancy and hydropower ,transportation chemical industry, smelting and so on.

Features and Benefits

High efficiency, large handling capacity Simple structure and easy maintenance Low consumption, little noise and long life span Small amplitude, high frequency and large obliquity AAVISHKAR

Screening Equipments

Pelletizing Equipments

• 1. Pelletizer/Nodulizer

Pelletizers are the equipment of choice when uniform pellet size and ease of control are important when converting powdered materials into round spherical pellets of 500 micron to 20 mm diameter. The equipment that dries raw ground materials and makes pellets: Starts pelletizer rotating and start feed and discharge conveyors and traveling grates in preburning-ovens. Pelletizers can agglomerate fine, dry feed materials such as chemical powders, limestone, fertilizer, coal fines, cement / lime kiln dust and fly ash as well as wetter materials such as filter / centrifuge cake, minerals, ores, vibrating sludge and pond tailings.

Features and Benefits

High efficiency, large handling capacity Simple structure and easy maintenance AAVISHKAR

Pelletizing Equipments

• 2. Granulator

A rotary drum granulator, a kind of fertilizer equipment, is mainly used to complete granulation process during compound fertilizer production processes. Firstly, add raw materials into the drum. Then the materials will rotate along with drum rotation. Finally, the materials will form into granules under the condition that a certain humidity and temperature is provided.

• Granulation rate reaches 70%. A few bit of reverts with small granularity are available

for new granulation.

• By adopting vapor for material heating, finished

granules feature low water content. Thus the load

• f drier is reduced and production efficiency is

improved.

• Our rotary granulator can help reduce labor

intensity and prolong machinery lifetime.

• Our rotary drum granulator features simple
• peration, large production, low power

consumption and low maintenance cost AAVISHKAR

Storage Equipments

• 1. Silo

Silos are used in many solids handling processes by a wide range of industries. The

• bjective of all silo designs is to obtain reliable and controllable flow of particulate

solids in such processes. However, the fact is that various problems in solids flow

• ccur very frequently in many solids handling processes.

No flow takes place when the outlet of the silo is opened. A stable arch that prevents flow is formed above the outlet. This may happen both with fine powders and coarse solids, and is generally attributed to the development of cohesion in the solids or to mechanical interlocking.

Features and Benefits

large handling capacity Simple structure and easy maintenance Economical AAVISHKAR

Storage Equipments

• 2. Pneumatic Blending Silo

Pneumatic blending is one of the quickest, cleanest and most efficient methods to

• btain homogenous batches of powdered, granular, or abrasive materials in

transporters, atmospheric bins, or storage silos. Unlike a conventional blender, a pneumatic blender puts the user in control by providing the ability to customize a blend. Pneumatic Blenders are equipped with either six or twelve wear-resistant aerators mounted around a housing cone. When the aeration valves are pulsed, gentle blasts of compressed air are injected into the center of an unblended batch at various angles to gently lift the materials upward and outward until the blending target is achieved.

Features and Benefits

Blending action can be optimized Long service lives & require minimal maintenance Quickly and easily repaired or replaced AAVISHKAR

Feeding Equipments

1.Rotary Table Feeder Rotary Table Feeder will consist of a power driven circulated plate rotating directly below a hopper / bunker. A feed collar located immediately above rotating table used in conjunction with an adjustable plough, determines the volume of material discharged. The lower edge of the feed collar will be parallel to the table with a predetermined gap from table top. This arrangement permits equal quality of material to flow under the collar and spread over the table as it resolves. The material is then ploughed off into the discharge chute. Rotary table feeders are most useful for handling materials that are sluggish, tend to interlock or mat and thereby arch over restricted openings Features and Benefits High efficiency of Handling Material Less cost AAVISHKAR

Feeding Equipments

• 2. Vibrating Feeder

Vibrating Feeders provide the most efficient and economical method of conveying bulk materials and, what is more important the simplest and easiest means of controlling the rate of flow or feed. Vibrating Feeders are extensively used in Iron and Steel works, Collieries Quarries, Gas Works, Mines, Chemicals, Pharmaceuticals, Ceramics, Rubber, Clay and Glass Industries for handling all types of materials - big lumps of ore down to fine chemicals - hot or cold - dry or damp - Capacities from 50 grams to 2000 Tons per hour. Vibrating Feeders protect the belt conveyors from damage by feeding the material

• nto the belt conveyors from storage hoppers, silos, surge hoppers and dumpers at a

controlled rate. Features and Benefits stable and long span life reliable operation easy maintenance AAVISHKAR

Mixing Equipments

1. Ribbon Blender Ribbon Blender comprises of a U-shaped horizontal trough and a specially designed Double Helical Ribbon Agitator rotating within. Ribbon Blenders are based on a proven agitator construction that provides a triple mixing action ensuring fast efficient blending. The dimensions and configuration of the ribbons are carefully balanced to provide a movement of material within the container that avoids dead spots and gives rapid product discharge. The outer ribbon displaces the material from the ends to the center while the inner ribbon moves the material from the center to the ends. This counter-current action results in homogenous blending. Features and Benefits Simple structure and easy to maintenance Long service life AAVISHKAR

Mixing Equipments

• 2. Muller Mixture

The Muller type mixer provides additional mixing forces over that of more conventional mixers to assure that the total mixture prepared is of uniform

• consistency. Unlike conventional mixing, mulling provides forces that incorporate

kneading, shearing, smearing, and blending

• f

materials for total uniform

• consistency. This process produces just enough pressure to move, intermingle and

push particles into place without crushing, grinding, or distorting the ingredients. The result is a final mixture of truly uniform consistency in both physical and chemical structure. Mulling is an extension of mixing resulting from the intensification of work forces The work forces are applied via the tread of weighted mulling wheels. The weight, and thereby the mixing efficiency, is controlled through a spring suspension arrangement

• n the wheel that is fully adjustable and allows the user to

increase or decrease the amount of work that is applied to the mixture via the mulling wheel. Features and Benefits less expensive and easier to use initially AAVISHKAR

Mixing Equipments

• 3. Pan Mixture

We offer an extensive range of Pan Mixers with outputs from 400 liters to 3,300

• liters. This makes them suited to a wide range of users, from small builders to ready-

mix plants. Pan Mixers are ideal for mixing mortar and wet and dry screeds. All Pan Mixers in our range can be fed via a variety of methods including a bucket rail system or conventional conveyor belt and radial scrapers. Larger models are fitted with dual mixing sequence and double rotation mixing arms giving a fully homogenized mix within 60 seconds.

Features and Benefits Efficient Mixture High material handling capacity

AAVISHKAR

Separating Equipments

Erkensator and Solemnity Separator: Erkensator is separate mineral’s slurry in two ways. It separate minerals on their properties of bulk density and weight. Heavy weight particles come out from downward outlet and light weight particles come out from upward outlet. Solemnity Separator is a kind of separating machine that classifies big and small mineral granules. It works according to the fact that different granules (with various sizes and weight) sink at different speeds in liquids. It can filter powders grinded from mill and rotate the course materials to the feeding hole of the mill and discharge filtered fine materials though the overflow pipe. Erkensator Solemnity Separator AAVISHKAR

Cement Industries, 57 % Refractory Industries, 21 % Mining Industries, 6 % Allied Industries, 11 % Fertilizer Industries, 2 % Steel Industries, 2 % Sugar Industries, 1 %

Our Foray In Different Industries

AAVISHKAR

Our Machineries Graph:

AAVISHKAR 10 20 30 40 2009-2010 2010-2011 2011-2012 2012-2013

Machines Qty.

Career Graph

AAVISHKAR

Our CAD Designing Pattern

AAVISHKAR

Our 3D Designing Pattern

AAVISHKAR

OBJECTIVES:

GROWTH : To achieve reasonable and consistent growth and to generate resources for developing the infrastructure and expertise in the Company. ORGANIZATIONAL ENVIRONMENT: To develop and maintain an organizational environment for initiative, innovation and productivity , and also to ensure a fair deal to the employees with humane approach. BUSINESS DEVELOPMENT: To generate adequate profitable Business by utilizing the existing resources to the maximum extent DIVERSIFICATION: To maximize generation of business in sectors other than the present sectors.

AAVISHKAR

ETW (USA) & Aavishkar Tie-up (July 30, 2013) Association with SBM, China Clients from Sri-Lanka

904, Akik Complex,

• Opp. Rajpath Club,
• S. G. Road,

Ahmedabad – 15 Gujarat, India. Ph : +91–79–66615059 Fax : +91–79–26870092 Email ID : Mobile :+91 +9825031367

AAVISHKAR

Thank You…

Contact us
