Virtual and Augmented Reality

Motion Capture and Animation (01)

• RNDr. Martin Madaras, PhD.

madaras@skeletex.xyz

Outline

2

 Principles of animation  Keyframe animation  Articulated figures  Skeletal animation  Motion capture  Projects…

3

• Ask questions, please!!!
• Be communicative
• www.slido.com #VAR01
• More active you are, the better for you!

How the lectures should look like #1

Manual animation

4

 Stop-motion animation  e.g. Coraline, Wallace & Gromit, etc.

Computer Animation

5

 What is animation?

 Make objects change over time according to scripted actions

 What is simulation?

 Predict how object change over time according to physical laws

Computer Animation

6

 Animation pipeline

 3D Modeling  Articulation  Motion specification  Motion simulation  Shading  Lighting  Rendering  Postprocessing

Keyframe Animation

7

 Define character poses at specific time steps called

“keyframes”

Inbetweening (“tweening”)

8

 Computing missing values based on existing surrounding

values

45

Inbetweening (“tweening”)

9

 Linear (constant)  Ease-in, ease-out

Keyframe Animation

10

 Inbetweening:

 Linear interpolation – usually not enough continuity

Spline Continuity

11

 How to ensure curves are “smooth”  Generally we have three levels of continuity  C0 - The curves meet  C0 & C1 - The tangents are shared  C0 & C1 & C2 - The “speed” is the same

C0 Continuity

12

 Zero order parametric continuity

C0 & C1 Continuity

13

 First order parametric continuity

C0 & C1 & C2 Continuity

14

 Second order parametric continuity

Implications for animation

15

 Linear interpolation is only C0

 Movement changes instantly at keyframes  Very unnatural looking

 We need at least C0 & C1 continuity

 Hermite interpolation  Spline interpolation  “Smoothstep” function

Smoothstep

16

Smoothstep

17

float smootherstep(float edge0, float edge1, float x) { // Scale, and clamp x to 0..1 range x = clamp((x - edge0)/(edge1 - edge0), 0.0, 1.0); // Evaluate polynomial return x*x*x*(x*(x*6 - 15) + 10); }

Keyframe Animation

18

 Inbetweening:

 Spline interpolation – may be visually good enough  May not follow physical laws

Keyframe Animation

19

 Inbetweening:

 Inverse kinematics or dynamics

Articulated Figures

20

 Character poses described by set of rigid bodies

connected by “joints”

Articulated Figures

21

 Well suited for humanoid characters

Keyframe Animation

22

 Inbetweening:

 Compute angles between keyframes

Example: Walk Cycle

23

 Inbetweening:

 Compute angles between keyframes

Example: Walk Cycle

24

 Hip joint orientation

Example: Walk Cycle

25

 Knee joint orientation

Example: Walk Cycle

26

 Ankle joint orientation

Animation Hierarchies

27

 Animate objects in relation to their parent

 Sun matrix is Ms  Earth matrix is MsMe  Moon matrix is MsMeMm

Kinematics and Dynamics

28

 Kinematics

 Considers only motion  Determined by positions, velocities, accelerations

 Dynamics

 Considers underlaying forces  Capture motion from initial positions and physics

Example: 2-Link Structure

29

 Two links connected by rotational joints

Forward Kinematics

30

 Animators specifies angles Θ1 and Θ2  Computer finds position of end effector: X

Forward Kinematics

31

 Joint motion can be specified by spline curves

Joint motion can be specified by spline curves

Forward Kinematics

32

 Joint motions can be specified by initial conditions

Joint motion can be specified by spline curves

Example: 2-Link Structure

33

 What if animator knows position of “end effector”

Inverse Kinematics

34

 Animator specifies end effector positions: X  Computer finds joint angles Θ1 and Θ2

Inverse Kinematics

35

 End-effector positions can be specified by splines

Inverse Kinematics

36

 Problem with more complex structures

 System with equation is usually under-defined  Multiple solutions

Inverse Kinematics

37

 Solution for more complex structures

 Find best solution (eg. minimize energy in motion)  Non-linear optimization

Inverse Kinematics

38

 Forward Kinematics

 Specify conditions (joint angles)  Compute conditions of end effectors

 Inverse Kinematics

 “Goal-directed” motion  Specify goal positions of end effectors  Compute conditions required to achieve goal

39

Character Animation (Linear Blend Skinning) (Skeletal Animation)

Skeletal Animation

40

 Hierarchical graph structure called Skeleton

 Nodes and edges (bones)

Skeletal Animation

41

 Graph structure can be disconnected in space

Real-time skeletal skinning

42

https://www.youtube.com/watch?v=DfIfcQiC2oA

Facial animation

43

 Facial expressions  Lips to speech synchronization  Controllers  Skinning  Morphing

http://www.anzovin.com/products/tfm1maya.html

Reusable animation

44

 One skeleton – different models

http://www.studiopendulum.com/alterego/

Motion capture

45

 Markers on actor’s body  Optical / magnetic sensors  3D reconstruction of markers’ position  Motion mapping

to virtual character

Outline

46

 Principles of animation  Keyframe animation  Articulated figures  Skeletal animation  Motion capture  Projects…

47

• Ask questions, please!!!
• Be communicative
• www.slido.com #VAR01
• More active you are, the better for you!

How the lectures should look like #2

Motion Capture

48

 Capturing of actor’s movement  Natural animation of CG characters

Optical Mocap

49

 Estimation of marker positions

Optical Mocap Problems

50

 Complicated setup  Problems with occlusions  Limited space

Inertial Mocap

51

 Inertial Measurement Unit  Bone rotations from IMU sensors

Mocap Suit Problems

52

 Custom implementation of walking algorithm  Inaccurate for sliding, complex jumping etc.  Recalibration needed over time

Mocap Walking Algorithm

53

Walking Algorithm Fail-Case

54

Optinertial

55

Optical-Inertial Synchronization of MoCap Suit with Single Camera Setup for Reliable Position Tracking VISIGRAPP 2018 (Adam Riečický, Martin Madaras, Michal Piovarči)

Motivation

56

 Combine optical and inertial data  Use camera image to find the actor in the scene  Use data streamed from the mocap suit

Main Idea

57

 Synchronize inertial mocap suit and camera data

 Suit joint rotations  Camera-based position estimation

 Overcome disadvantage of each method  Get reliable position tracking and mocap rotations  How to merge and synchronize the data ?

58

Related work

RGB Camera-based Mocap / Tracking

59

 Multi-view RGB – sum of spatial Gaussians

 Cheung et al. 2003  Stoll et al. 2011

 RGB camera probabilistic methods

 Wojek et al. 2009

 Optical flow + Chamfer matching

 Dimitrijevic et al. 2006  Katz and Aghajan 2008

Related Hybrid Methods

60

 Laser scanner + robot + IMUs

 Ziegler et al. 2011

 Template-based + IMUs + RGB cameras

 Pons-Moll et al. 2017  von Marcard et al. 2016

 Depth camera +IMUs + template

 Helten et al. 2013

Related Work Problems

61

 Mesh templates  Depth cameras  Multiple RGB cameras  Complicated setup  Position estimation only  Our Optinertial system needs only RGB or

monochromatic camera and the suit data

62

Optical-Inertial Synchronization

Our Idea

63

Optinertial Pipeline

64

 Chamfer matching

Actor Image

65

 Distance transform image  Background subtraction / contrast suit color

Optinertial Pipeline

66

 Template image rendering

Mocap Suits

67

 High number of IMUs vs. affordable price

Virtual Scene

68

 Real-time update of the virtual scene  Frame rendering  Camera calibration / pose estimation

Camera Calibration

69

 OpenCV ChArUco board  Estimation of origin/camera position in world space

Base-mesh Rendering

70

 SQM algorithm (skeleton, radii)

 Baerentzen et al. 2012

Base-mesh Rendering

71

 Actor image database  Skinning of base-mesh

Optinertial Pipeline

72

 Minimizing DT for the best match

Actor Movement Detection

73

 Find the best match for actor shift vector  Distance transform minimization

Image-space Optimization

74

 Silhouette + kernel integration

Optimization Implementation

75

 Parallel matrix multiplication on GPU  The best match gives the actor motion vector

Optinertial Pipeline

76

 Skeleton root translation

Results - Video

77

78

Evaluation

Evaluation Scene

79

 HTC Vive ground truth tracking

Evaluation Paths

80

Data Smoothing

81

 Post-processing  Gaussian filtering

Results - Error

82

 Suit walking algorithm vs. our approach

Results – Visualization

83

 Sliding sequence

Conclusion

84

 Optical-inertial tracking and motion capture  Monochromatic camera only  Solid position estimation during jumping and sliding  Our method may produce noisy results, however it can

be improved using Gaussian filtering

Limitations

85

 Camera occlusions are still problem  Fails if subject is too close to camera  Cannot run real-time for higher database sampling

Inertial + Optical Mocap

86

Capturing of Movement During Music Performance Bachelor thesis 2018

• Bc. Dana Škorvánková

Goals

• Implement a framework for

inertial motion capture – forearms, hands, fingers captured while playing the guitar

• Apply the captured motion on

a 3D humanoid character

• Synchronization with optical

mocap – 3D camera

87

Technologies

88

 HTC Vive tracker  3D camera by Photoneo Motion capture glove by

Synertial

Process

 Kinexact

Hand (calibration tool)

 Optical + inertial data synchronization  Datasets recording  Merging BVH files Updating structures Inertial data streamer Attaching hands to full- body animation

89

 Calibration of the

performer‘s hand skeleton

 C++  Update –

compatibility with new structures (representing skeleton – new organization of the skeletal nodes)

Kinexact Hand – calibration tool

root node in-hand nodes

90

Recording datasets

Glove setup

91

Glove + Vive tracker

data visualization

92

Optical + inertial data

Optical data

PhoXi 3D camera by Photoneo

Inertial data

Motion capture glove by Synertial

PhoXi Streamer app

C++

added glove data streaming

Pointcloud + skeleton + BVH

In each frame

skeleton format ?

93

Optical + inertial data

In each frame generating

• model pointcloud
• skeleton pointcloud

+ BVH file (the entire dataset)

94

Optical + inertial data

Reality

MoCap glove

60 fps

PhoXi 3D camera

• ca. 10 fps

(relative to PC performance)

Synchronization not stable

=> Potential future work

95

Captured by PhoXi 3D camera by PhotoNeo

Pointcloud generation

96

Before & after

attaching hands to body skeleton

97

98

Acknowledgements

 Thanks to all the people, whose work is shown here and whose

slides were used as a material for creation of these slides:

Matej Novotný, GSVM lectures at FMFI UK Peter Drahoš, PPGSO lectures at FIIT STU Output of all the publications and great team work Very best data from 3D cameras
