Missile Defense Radar through Real-Time Electromagnetic (EM) Simulation Injection Ted.Selig@FishEye.net GTC 2016 Source MDA.mil Fylingdales Phased Array Radar Source: www.mda.mil Phased Array Radar Antenna Face Source: www.loc.gov Behind of

SLIDE 1

Missile Defense Radar through Real-Time Electromagnetic (EM) Simulation Injection

Ted.Selig@FishEye.net GTC 2016

SLIDE 2

Source MDA.mil

SLIDE 3

Fylingdales Phased Array Radar

Source: www.mda.mil

SLIDE 4

Phased Array Radar Antenna Face

Source: www.loc.gov

SLIDE 5

Behind of Phased Array Radar Antenna

Source: www.loc.gov

SLIDE 6

Example Radar Signal Processing Computers and Operator Display

SLIDE 7

These complex systems come challenges?

SLIDE 8

Radars have a lot of Custom Hardware

Expensive, limited spares
Part of Deliverables
Not available for sustainment,

demos, modernization

Quickly becomes obsolete

Custom Hardware Makes Radar Expensive and Complex

SLIDE 9

Testing Radars is Challenging

Sensor Systems require input signals but may be hard to create in a lab where development occurs Live Tests are Expensive and Hard flight test, test at sea, remote test Realistic scenarios are Difficult.

SLIDE 10

So what is new?

SLIDE 11

SLIDE 12

Performance of Calculating Simulated Targets 1m2 Sphere + Noise

A Traditional PC

50,000

100,000 150,000 PC (3.4GHz Intel 4-core) Super Computer (SGI 3900) 5,322 127,376 Simulated Targets (Glints per Second)

Signal Processing Computer ($3M)

SLIDE 13

FishEye’s Real-Time Massive Parallel Framework Enables Real-Time Radar Model & Simulation

1,000,000

2,000,000 PC (3.4GHz Intel 4-core) Super Computer (SGI 3900) GPU (VREX ON k20) 5,322 127,376 2,328,598 Simulated Targets (Glints per Second)

Traditional $3M Computer A Traditional PC Massive Parallel

n $10k

Commercial Hardware

SLIDE 14

GPU Make Inexpensive & Upgradable Radar Possible

$3,000,000 & Custom $10,000 & Off-the-Self Super Computer + Custom Hardware Off-the-shelf Computer + GPU

SLIDE 15

Virtual REX

Sensor Innovation over the Entire Life-Cycle Simulate

Clutter, Ground, Atmosphere, Targets, Antenna

I&Q Commands Status Timing

Sensor Under Test

VREX Injects Real-Time Simulated Electromagnetic Signal into Sensors

VREX General Simulator

VREX

SLIDE 16

VREX Simulator Configuration

Time Sync (NTP) {Downtowner} NTP Server GPS

(Radar Front End Simulator) {Halfway} Archive Config

VREX

RTTK

Network Hub

(Radar Back End) {Ambassador} Archive Config Signal Processor RTTK Archive Config Data Processor RTTK Script

Real-Time Analysis RTTK Matlab

1Gb 100Mb Key

SLIDE 17

VREX Demo FishEye Lab Configuration

Time Sync (NTP) {Downtowner} NTP Server GPS (Radar Front End Simulator) {Halfway} Archive Config

VREX

RTTK Network Hub (Radar Back End) {Ambassador} Archive Config Signal Processor RTTK Archive Config Data Processor RTTK Script Real-Time Analysis RTTK Matlab

1Gb 100Mb Key

Back-End Front-End Time-Sync (NTP)

SLIDE 18

VREX Back End

VREX & RTTK Demo

(Radar Front End) (Radar Back End) Signal Processor Data Processor Initiation Commands Status I&Q Sync Virtual Receiver/Exciter (VREX) (Radar Front End Simulator)

Archive Config Obs Scenario Equipment Simulator

External Simulators

Equip Scenario

VREX Standard Interface Interface Binder – Actual Radar ICD

Antenna Transmitter Receiver Target Environment Waveform Digital Module Beam Steer RTTK View Models

SLIDE 19

GPUs Keeping Real-Time

Real-Time Fast Too Slow

SLIDE 20

Radar through Real-Time Electromagnetic Simulation

Test in Lab
Improve Radar Performance
Lower Cost, Risk, and

Schedule

Design and Demo Next

Generation

More for Le$$

SLIDE 21

Ted.Selig@FishEye.Net

www.Fisheye.Net/VREX +1-978-394-1644 Contact me to exchange ideas or if I you think I can help your plans.

Synthesizing the world’s real-time data.
