MICROALGAE CULTURE (4) MICROALGAE CULTURE (4) BIO301 Prof Michael Borowitzka S&C1.48 Limits to Growth Nutrients N (as nitrate, ammonia, urea) P Fe Si (diatoms) Supply of inorganic C (CO 2 /HCO 3 - )

slide-1
SLIDE 1

MICROALGAE CULTURE (4) MICROALGAE CULTURE (4)

BIO301 Prof Michael Borowitzka S&C1.48

slide-2
SLIDE 2

Limits to Growth

  • Nutrients

– N (as nitrate, ammonia, urea) – P – Fe – Si (diatoms)

  • Supply of inorganic C (CO2

/HCO3

  • )
  • Mixing (turbulence & shear)
  • Light (except for heterotrophic culture)
  • Temperature
slide-3
SLIDE 3

Flask Cultures

slide-4
SLIDE 4

Flask Cultures

slide-5
SLIDE 5

Carbuoy

slide-6
SLIDE 6

Tubular Airlift Reactor

slide-7
SLIDE 7

Commercial-Scale production Systems

slide-8
SLIDE 8

Chlorella production - Taiwan

slide-9
SLIDE 9

Chlorella production - Indonesia

slide-10
SLIDE 10
slide-11
SLIDE 11

Rores - Kolar, Karnataka, India

slide-12
SLIDE 12

Spirulina Production Ponds, India

slide-13
SLIDE 13

Earthrise Spirulina plant – Calipatria, California Curtesy – Ahma Belay

slide-14
SLIDE 14

NatureBeta Dunalialla plant, Eilat, Israel curtesy – Ami Ben Amotz

slide-15
SLIDE 15

Pleurochrysis carterae productivity – Perth, WA Ash-Free DW Lipid CaCO3

slide-16
SLIDE 16

Hutt Lagoon; WA

slide-17
SLIDE 17
slide-18
SLIDE 18

Whyalla; SA

slide-19
SLIDE 19

Dunaliella & β-Carotene

  • β-Carotene formation depends on (a) total

irradiance and (b) salinity

  • Optimum salinity for growth ~ 22% NaCl
  • Optimum salinity for β-Carotene formation

> 30% NaCl

  • Nutrient limitation
slide-20
SLIDE 20

Tank Culture - Hawaii

slide-21
SLIDE 21

Cascade System – Trebon, Czech Repiblic

slide-22
SLIDE 22

Covered Ponds USA

slide-23
SLIDE 23

Bag culture in Aquaculture Hatchery Bag Culture -

slide-24
SLIDE 24

curtesy – Ephraim Cohen Haematococcus ‘tube’ culture in Israel Bag Culture - Israel

slide-25
SLIDE 25

1000 L pilot-scale BIOCOIL at Murdoch University

slide-26
SLIDE 26

Pilot Biocoil – Luton, UK

slide-27
SLIDE 27

Comercial Haematococcus plant: Israel

slide-28
SLIDE 28

Tubular Photobioreactor China

slide-29
SLIDE 29

Pilot CO2 bioremediation plant operated by Greenfuel Technologies Corporation, USA at MIT.

slide-30
SLIDE 30

Haematococcus plant

  • perated by Algatech Ltd,

Kibbuz Ketura, Israel

slide-31
SLIDE 31
slide-32
SLIDE 32

Alveolar panels

slide-33
SLIDE 33

Capital Cost Running Cost Cell Yield Relia- bility Shallow Ponds *(1) * * ** (2) Raceways *** ** ** ***(2) Cascade System **** ** **** ***(2) Tubular Photobioreactor ****** **** *** **** Fermenter ******* ***** (3) ****** *****

1Depends on land & water cost as very large pond area required; 2The range of species which can be cultured is very limited; 3Heterotrophic culture is VERY much cheaper as no light required.

slide-34
SLIDE 34

Economics Bioreactor Design, Engineering & Process Control Algal Physiology, Biochemistry & Molecular Biology Photosynthetic efficiency, Secondary metabolism, ‘Stress’ tolerance, Strain improvement Light supply, Gas exchange, Turbulence, Temperature control, Materials, Harvesting, Downstream processing New applications, marketing, formulation, packaging
