SLIDE 1
Los Angeles County Metropolitan Transportation Authority
Metro Rail System
Present and Future November 9, 2017
1
Metro Rail System –
2016
New Line Extensions
Metro Rail System Present and Future November 9, 2017 1 Metro Rail - - PowerPoint PPT Presentation
Metro Rail System Present and Future November 9, 2017 1 Metro Rail - - PowerPoint PPT Presentation
Los Angeles County Metropolitan Transportation Authority Metro Rail System Present and Future November 9, 2017 1 Metro Rail System 2016 New Line Extensions 2017 Metro Rail Facts-at-a-Glance 6 Lines 93 Stations 105 Route
SLIDE 2
SLIDE 3
2017 Metro Rail Facts-at-a-Glance
- 6 Lines
- 93 Stations
- 105 Route Miles (17.4 miles subway)
- 364 Rail Cars (104 Subway, 260 Light Rail)
- 348,505 Average Weekday Ridership
- 111,458,473 Annual Ridership
- Service Hours
- 4:30am – 1:00am Sunday- Thursday
- 4:30am – 2:00am Friday- Saturday
- $1.75 general fare (2 hours)
SLIDE 4
Under Construction
- Crenshaw/LAX LRT Transit Project – Crenshaw/
Exposition to the Green Line (October 31,2019)
– 8.5 miles, 8 stations – LAX APM Station at 96th St.
- Regional Connector LRT Project – 7th St./ Metro
Center to 1st/Alameda (2021)
– 1.8 miles, 3 stations
- Purple Line Subway Segments 1 and 2 –
Wilshire/Western to Century City
– 6.5 miles, 5 stations (2024)
SLIDE 5
Preparing to Submit Full Funding Grant Agreement (FFGA)
- Purple Line Subway Segment 3 – Century City
to UCLA/Westwood/Veterans Admin. Hospital
– 2.6 miles, 2 stations (2026)
SLIDE 6
Metro Rail System -
2021
Regional Connector Crenshaw Line
SLIDE 7
Metro Rail System -
2026
Purple Line
SLIDE 8
Metro Rail Regional Destinations
2026
- Downtown Los Angeles
- Exposition Park/USC/Culver City
- Santa Monica
- Long Beach
- Wilshire (Beverly Hills/Century City/Westwood)
- Hollywood/San Fernando Valley
- Norwalk/Redondo Beach
- Crenshaw District/LAX
- San Gabriel Valley
- East Los Angeles
SLIDE 9
MEASURE M PROJECTS METRO RAIL: CIRCA FY2025-FY2047
FY25 Gold Line Foothill Extension Phase 2B: Azusa to Claremont (Montclair) (Foothill Construction Authority) FY27 East San Fernando Valley Light Rail Project: Orange Line to Sylmar via Van Nuys Bl. FY28 West Santa Ana Branch Light Rail Project Phase 1: Artesia to Green Line FY30 Green Line South Bay Light Rail Extension: Redondo Beach to Torrance FY33 Sepulveda Pass Transit Corridor Project Rail Phase 1: San Fernando Valley/Orange Line to Westwood FY35 Gold Line Eastside Extension Project Phase 2: East Los Angeles to either El Monte or Whittier FY41 West Santa Ana Branch Project Phase 2: Green Line to Union Station / Downtown Los Angeles FY47 Crenshaw Line Northern Extension Project: Exposition Line to Red Line via Purple Line
SLIDE 10
MEASURE M PROJECTS METRO RAIL: CIRCA FY2048-FY2067
FY52 Green Line Extension Project: Norwalk to Santa Fe Springs Metrolink Station FY57 Gold Line Eastside Extension Project Phase 3: East Los Angeles to either El Monte or Whittier FY57 Orange Line Bus Rapid Transit to Light Rail Transit Conversion Project: Warner Center to North Hollywood FY57 Sepulveda Pass Transit Corridor Project Rail Phase 2: Westwood to 96th St. /LAX Station via Exposition Line FY67 Lincoln Line BRT to LRT Conversion: 96th St. /LAX Station to Santa Monica FY67 Orange Line Light Rail Extension Project: North Hollywood to Pasadena FY67 Vermont Transit Corridor Project: Wilshire to Green Line
SLIDE 11
