Rail Systems Rail Track Ballast Rail Track Ballast Group 7 Mr.Teeraphob Ueacharoensab 5813023 ME4 Mr.Pongsapak Lawapiledchaikul 5813034 ME4 Mr.Kotchanut Jaroenjit 5813206 ME4 What is Rail Track Ballast? Railway Track Component of Railway
SLIDE 2
SLIDE 3
Mr.Teeraphob Ueacharoensab 5813023 ME4 Mr.Pongsapak Lawapiledchaikul 5813034 ME4 Mr.Kotchanut Jaroenjit 5813206 ME4
Group 7
Rail Track Ballast
SLIDE 4
What is Rail Track Ballast?
SLIDE 5
Railway Track
SLIDE 6
Component of Railway Track
SLIDE 7
Railway tracks
Railway tracks is consist of two parallel steel tracks and lays steadily on the railway
- sleepers. It provides direction guidance and alignment for vehicles.
SLIDE 8
Rail fastening system
Rail fastening system is used to fix rails to railway sleeper.
SLIDE 9
Sleeper is a rectangular support for the rails in railroad tracks. Sleepers are traditionally made of wood, but concrete is now also widely used, especially in Europe and Asia.
Sleeper
SLIDE 10
Ballasted tracks
Ballasted track is a type of traditional railway tracks. Generally, laying ballast under the railway sleepers to reduce the stress on the ground. A layer of gravel was laid between ground and railway sleeper to form the ballast bed.
SLIDE 11
Subgrade
Subgrade(soil) is the native material underneath a constructed road or railway track.
Subgrade
SLIDE 12
Hand-on Activity
SLIDE 13
TEAMWORK
Folding Glueing Railway Setting
SLIDE 14
Component of Railway Track
SLIDE 15
Sleeper & Rail
SLIDE 16
Ballast
SLIDE 17
Ballast Shoulder
Left
Right
SLIDE 18
Sub-ballast Left
Right
SLIDE 19
Soil (Filling) Left
Right
SLIDE 20
Natural Ground
Left
Right
SLIDE 21
Tools
- Glue
- Scissor
- Popsicle sticks of sleepers
- Wood Sticks of rails
- Wire holder
- Screw
- Watercolour
