slide-1
SLIDE 1

Lecture 26 – Browser Security

Stephen Checkoway Oberlin College Some slides from Bailey's ECE 422

slide-2
SLIDE 2

Documents

  • Browser's fundamental role is to display documents comprised of
  • HTML
  • JavaScript
  • Style sheets (CSS)
  • Images
  • Sounds
  • Movies
  • Plugin content
  • Flash
  • SilverLight
  • QuickTime
  • …
slide-3
SLIDE 3

Document Object Model (DOM)

  • The browser allows scripts to
  • add/modify/delete/style the DOM elements
  • make changes in response to user actions (e.g., clicks)
  • submit forms
  • browse to a new document altogether
  • Scripts in one document can modify another document
  • We say that Document A scripts Document B
slide-4
SLIDE 4

Scripting other documents

  • Very powerful capability and without constraints would be dangerous
  • Consider having attacker.com open while logging into chase.com
  • If attacker.com can script chase.com, what could happen?
slide-5
SLIDE 5

Clearly we need separation

  • This is Risk #3 from last time
  • Same Origin Policy (SOP)
  • Goal: Partition documents into equivalence classes that can script each
  • ther (including reading each others' content)
  • Each document is assigned an origin and documents can script other

documents in the same origin

  • We construct the origin from the URL
slide-6
SLIDE 6

From URLs to Origins

  • General form of a URL


scheme://user:pass@host:port/path?querystring#fragment

  • Most parts are optional giving URLs like


https://www.cs.oberlin.edu/~csmc/
 https://google.com?q=hello+world

  • Origins are the triple (scheme, host, port)


What's the origin for https://www.cs.oberlin.edu/~csmc/?


 What's the origin for https://google.com?q=hello+world?

slide-7
SLIDE 7

From URLs to Origins

  • General form of a URL


scheme://user:pass@host:port/path?querystring#fragment

  • Most parts are optional giving URLs like


https://www.cs.oberlin.edu/~csmc/
 https://google.com?q=hello+world

  • Origins are the triple (scheme, host, port)


What's the origin for https://www.cs.oberlin.edu/~csmc/?


 What's the origin for https://google.com?q=hello+world? (https, www.cs.oberlin.edu, 443)

slide-8
SLIDE 8

From URLs to Origins

  • General form of a URL


scheme://user:pass@host:port/path?querystring#fragment

  • Most parts are optional giving URLs like


https://www.cs.oberlin.edu/~csmc/
 https://google.com?q=hello+world

  • Origins are the triple (scheme, host, port)


What's the origin for https://www.cs.oberlin.edu/~csmc/?


 What's the origin for https://google.com?q=hello+world? (https, www.cs.oberlin.edu, 443) (https, google.com, 443)

slide-9
SLIDE 9

Origins

slide-10
SLIDE 10

Origins

  • Why does the origin include the host?
slide-11
SLIDE 11

Origins

  • Why does the origin include the host?
  • To prevent attacker.com from scripting bank.com
slide-12
SLIDE 12

Origins

  • Why does the origin include the host?
  • To prevent attacker.com from scripting bank.com
  • Why does the origin include the scheme?
slide-13
SLIDE 13

Origins

  • Why does the origin include the host?
  • To prevent attacker.com from scripting bank.com
  • Why does the origin include the scheme?
  • If not, then http://bank.com can script https://bank.com. An "on-path"

attacker could inject <script>…</script> into http://bank.com which affects https://bank.com

slide-14
SLIDE 14

Origins

  • Why does the origin include the host?
  • To prevent attacker.com from scripting bank.com
  • Why does the origin include the scheme?
  • If not, then http://bank.com can script https://bank.com. An "on-path"

attacker could inject <script>…</script> into http://bank.com which affects https://bank.com

  • Why does the origin include the port?
slide-15
SLIDE 15

Origins

  • Why does the origin include the host?
  • To prevent attacker.com from scripting bank.com
  • Why does the origin include the scheme?
  • If not, then http://bank.com can script https://bank.com. An "on-path"

attacker could inject <script>…</script> into http://bank.com which affects https://bank.com

  • Why does the origin include the port?
  • Think about multiple web servers run by different users on the same
  • machine. Without including the port, https://host.com:8443 could script

the entirely unrelated https://host.com

slide-16
SLIDE 16

Not the end of the story

  • Documents (and thus scripts) can load elements from other origins

including images, scripts, style sheets, and flash objects

  • Loading these elements endorses their content and the included

elements are considered to be in the loading document's origin

  • Conversely, documents (and thus scripts) can submit forms which sends

data from the document to some server

  • Submitting forms declassifies the data sent
  • Cross-Origin Resource Sharing (CORS) can enable cross-origin requests
slide-17
SLIDE 17

Web Review | HTTP

gmail.com

slide-18
SLIDE 18

Web Review | HTTP

GET / HTTP/1.1
 Host: gmail.com gmail.com

slide-19
SLIDE 19

Web Review | HTTP

GET / HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 …
 <html> <head> <script>alert(‘Hi!’)</script> </head> <img src=“//gmail.com/img.png”/>

slide-20
SLIDE 20

Web Review | HTTP

GET / HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 …
 <html> <head> <script>alert(‘Hi!’)</script> </head> <img src=“//gmail.com/img.png”/> http://gmail.com/ says:
 Hi!

slide-21
SLIDE 21

Web Review | HTTP

GET / HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 …
 <html> <head> <script>alert(‘Hi!’)</script> </head> <img src=“//gmail.com/img.png”/> GET /img.png HTTP/1.1
 Host: gmail.com http://gmail.com/ says:
 Hi!

slide-22
SLIDE 22

Web Review | HTTP

GET / HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 …
 <html> <head> <script>alert(‘Hi!’)</script> </head> <img src=“//gmail.com/img.png”/> GET /img.png HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 <89>PNG^M ... http://gmail.com/ says:
 Hi!

slide-23
SLIDE 23

Web Review | HTTP

GET / HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 …
 <html> <head> <script>alert(‘Hi!’)</script> </head> <img src=“//gmail.com/img.png”/> GET /img.png HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 <89>PNG^M ... http://gmail.com/ says:
 Hi!

slide-24
SLIDE 24

Web Review | AJAX (jQuery style)

gmail.com

slide-25
SLIDE 25

Web Review | AJAX (jQuery style)

GET / HTTP/1.1
 Host: gmail.com gmail.com

slide-26
SLIDE 26

Web Review | AJAX (jQuery style)

GET / HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 … <script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data) });
 </script>

slide-27
SLIDE 27

$.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data) });

Web Review | AJAX (jQuery style)

GET / HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 … <script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data) });
 </script>

slide-28
SLIDE 28

$.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data) });

Web Review | AJAX (jQuery style)

GET / HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 … <script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data) });
 </script> GET /msgs.json HTTP/1.1
 Host: gmail.com

slide-29
SLIDE 29

$.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data) });

Web Review | AJAX (jQuery style)

GET / HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 … <script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data) });
 </script> GET /msgs.json HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 { new_msgs: 3 }

slide-30
SLIDE 30

$.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data) });

Web Review | AJAX (jQuery style)

GET / HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 … <script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data) });
 </script> GET /msgs.json HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 { new_msgs: 3 } http://gmail.com/ says:
 { new_msgs: 3}

slide-31
SLIDE 31

Web Review | Same-Origin Policy (SOP)

(evil!)
 facebook.com gmail.com

slide-32
SLIDE 32

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com gmail.com

slide-33
SLIDE 33

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com HTTP/1.1 200 OK
 …
 <script>
 $.get(‘http://gmail.com/msgs.json’, function (data) { alert(data); } </script> gmail.com

slide-34
SLIDE 34

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com HTTP/1.1 200 OK
 …
 <script>
 $.get(‘http://gmail.com/msgs.json’, function (data) { alert(data); } </script> gmail.com $.get(‘http://gmail.com/msgs.json’, function (data) { alert(data); }

slide-35
SLIDE 35

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com HTTP/1.1 200 OK
 …
 <script>
 $.get(‘http://gmail.com/msgs.json’, function (data) { alert(data); } </script> GET /msgs.json HTTP/1.1
 Host: gmail.com gmail.com $.get(‘http://gmail.com/msgs.json’, function (data) { alert(data); }

slide-36
SLIDE 36

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com HTTP/1.1 200 OK
 …
 <script>
 $.get(‘http://gmail.com/msgs.json’, function (data) { alert(data); } </script> GET /msgs.json HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 { new_msgs: 3 } gmail.com $.get(‘http://gmail.com/msgs.json’, function (data) { alert(data); }

slide-37
SLIDE 37

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com HTTP/1.1 200 OK
 …
 <script>
 $.get(‘http://gmail.com/msgs.json’, function (data) { alert(data); } </script> GET /msgs.json HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 { new_msgs: 3 } gmail.com $.get(‘http://gmail.com/msgs.json’, function (data) { alert(data); }

slide-38
SLIDE 38

Web Review | Same-Origin Policy (SOP)

facebook.com gmail.com

slide-39
SLIDE 39

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com

slide-40
SLIDE 40

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com HTTP/1.1 200 OK
 …
 <img src=“http://gmail.com/img.png”/> gmail.com

slide-41
SLIDE 41

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com HTTP/1.1 200 OK
 …
 <img src=“http://gmail.com/img.png”/> gmail.com

?

slide-42
SLIDE 42

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com HTTP/1.1 200 OK
 …
 <img src=“http://gmail.com/img.png”/> GET /img.png HTTP/1.1
 Host: gmail.com gmail.com

slide-43
SLIDE 43

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com HTTP/1.1 200 OK
 …
 <img src=“http://gmail.com/img.png”/> GET /img.png HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 <89>PNG^M ... gmail.com

slide-44
SLIDE 44

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com HTTP/1.1 200 OK
 …
 <img src=“http://gmail.com/img.png”/> GET /img.png HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 <89>PNG^M ... gmail.com

slide-45
SLIDE 45

Web Review | Same-Origin Policy (SOP)

facebook.com gmail.com

slide-46
SLIDE 46

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com

slide-47
SLIDE 47

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com HTTP/1.1 200 OK
 …
 <script src=“http://gmail.com/chat.js”/>

slide-48
SLIDE 48

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com

?

HTTP/1.1 200 OK
 …
 <script src=“http://gmail.com/chat.js”/>

slide-49
SLIDE 49

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com GET /chat.js HTTP/1.1
 Host: gmail.com gmail.com HTTP/1.1 200 OK
 …
 <script src=“http://gmail.com/chat.js”/>

slide-50
SLIDE 50

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com GET /chat.js HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 $.get(‘http://gmail.com/chat.json’,
 function (data){ alert(data); }) gmail.com HTTP/1.1 200 OK
 …
 <script src=“http://gmail.com/chat.js”/>

slide-51
SLIDE 51

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com GET /chat.js HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 $.get(‘http://gmail.com/chat.json’,
 function (data){ alert(data); }) gmail.com $.get(‘http://gmail.com/chat.json’,
 function (data) { alert(data); }) HTTP/1.1 200 OK
 …
 <script src=“http://gmail.com/chat.js”/>

slide-52
SLIDE 52

Web Review | Same-Origin Policy (SOP)

gmail.com $.get(‘http://gmail.com/chat.json’,
 function (data) { alert(data); })

slide-53
SLIDE 53

Web Review | Same-Origin Policy (SOP)

gmail.com GET /chat.json HTTP/1.1
 Host: gmail.com $.get(‘http://gmail.com/chat.json’,
 function (data) { alert(data); })

slide-54
SLIDE 54

Web Review | Same-Origin Policy (SOP)

gmail.com GET /chat.json HTTP/1.1
 Host: gmail.com $.get(‘http://gmail.com/chat.json’,
 function (data) { alert(data); })

HTTP/1.1 200 OK
 …
 { new_msg: { from: “Bob”, msg: “Hi!”}}

slide-55
SLIDE 55

Web Review | Same-Origin Policy (SOP)

gmail.com GET /chat.json HTTP/1.1
 Host: gmail.com $.get(‘http://gmail.com/chat.json’,
 function (data) { alert(data); })

HTTP/1.1 200 OK
 …
 { new_msg: { from: “Bob”, msg: “Hi!”}}

slide-56
SLIDE 56

iframes

  • Complete document inside a document


<iframe src="https://somewhere.com/page.html"></iframe>

  • The contents of each iframe belong to its source origin


(https, somewhere.com, 443) for the iframe above

  • The iframe element itself belongs to its containing document
  • iframes obey the SOP
slide-57
SLIDE 57

Web Review | Same-Origin Policy (SOP)

facebook.com gmail.com

slide-58
SLIDE 58

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com

slide-59
SLIDE 59

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/chat”/>

slide-60
SLIDE 60

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com

?

HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/chat”/>

slide-61
SLIDE 61

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/chat”/>

slide-62
SLIDE 62

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/chat”/> GET /chat HTTP/1.1
 Host: gmail.com

slide-63
SLIDE 63

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/chat”/> GET /chat HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 <script>
 $.get(‘http://gmail.com/chat.json/’,
 function (data) { alert(data); });
 </script>

slide-64
SLIDE 64

Web Review | Same-Origin Policy (SOP)

GET / HTTP/1.1
 Host: facebook.com facebook.com gmail.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/chat”/> GET /chat HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 <script>
 $.get(‘http://gmail.com/chat.json/’,
 function (data) { alert(data); });
 </script>

$.get(‘http://gmail.com/chat.json’,
 function (data) { alert(data); })

slide-65
SLIDE 65

Web Review | Same-Origin Policy (SOP)

gmail.com

$.get(‘http://gmail.com/chat.json’,
 function (data) { alert(data); })

slide-66
SLIDE 66

Web Review | Same-Origin Policy (SOP)

gmail.com GET /chat.json HTTP/1.1
 Host: gmail.com

$.get(‘http://gmail.com/chat.json’,
 function (data) { alert(data); })

slide-67
SLIDE 67

Web Review | Same-Origin Policy (SOP)

gmail.com GET /chat.json HTTP/1.1
 Host: gmail.com

$.get(‘http://gmail.com/chat.json’,
 function (data) { alert(data); }) HTTP/1.1 200 OK
 …
 { new_msg: { from: “Bob”, msg: “Hi!”}}

slide-68
SLIDE 68

Web Review | Same-Origin Policy (SOP)

gmail.com GET /chat.json HTTP/1.1
 Host: gmail.com

$.get(‘http://gmail.com/chat.json’,
 function (data) { alert(data); }) HTTP/1.1 200 OK
 …
 { new_msg: { from: “Bob”, msg: “Hi!”}}

http://gmail.com/ says:

 { new_msgs: { from: “Bob”, msg: “Hi!”}}

slide-69
SLIDE 69

Beware finer-grained origins

  • Not all web features respect the SOP
  • Example: Cookies can include a path
  • In order to read a cookie with a path, the path of the document's URL

must extend the path of the cookie
 Cookie path: /a/b/c
 Document path: /a/b <- Cannot read the cookie
 /a/b/c/d <- Can read the cookie

  • This is "finer-grained" than the standard SOP
  • Is this a problem?
slide-70
SLIDE 70

Cookie paths example cont.

  • Since documents in the same page can script each other, page /a/b can

still read the cookie:

  • Create an iframe with src set to /a/b/c/d (where this the path of some

real document that can read the cookie value)

  • Since the iframe is in the same origin, page /a/b can inject a script

element into the iframe's document

  • The injected script reads the cookie value and sends it back to the

containing page

  • Cookie paths should not be used as a security boundary
slide-71
SLIDE 71

Mixed content

  • Documents can contain elements loaded over both http and https
  • Browsers indicate that this is insecure (by not displaying a lock icon) on

the page with mixed content

  • Other documents in the same origin are not similarly marked as insecure
slide-72
SLIDE 72

Mixed content

  • Documents can contain elements loaded over both http and https
  • Browsers indicate that this is insecure (by not displaying a lock icon) on

the page with mixed content

  • Other documents in the same origin are not similarly marked as insecure

Loaded over http

slide-73
SLIDE 73

Mixed content

  • Documents can contain elements loaded over both http and https
  • Browsers indicate that this is insecure (by not displaying a lock icon) on

the page with mixed content

  • Other documents in the same origin are not similarly marked as insecure

Loaded over http No lock

slide-74
SLIDE 74

Mixed content

  • Documents can contain elements loaded over both http and https
  • Browsers indicate that this is insecure (by not displaying a lock icon) on

the page with mixed content

  • Other documents in the same origin are not similarly marked as insecure

Loaded over http No lock Lock

slide-75
SLIDE 75

Mixed content

slide-76
SLIDE 76

Mixed content

  • Is that an issue?
slide-77
SLIDE 77

Mixed content

  • Is that an issue?
  • Yes, script injected from the element loaded over http could script other

pages in the same origin…

slide-78
SLIDE 78

Mixed content

  • Is that an issue?
  • Yes, script injected from the element loaded over http could script other

pages in the same origin…

  • …except modern browsers explicitly do not run scripts loaded via http in

an https page, so not really any more

slide-79
SLIDE 79

Cross-origin attacks

slide-80
SLIDE 80

Setup

  • Web attacker
  • Controls one or more domains (e.g., attacker.com, evil.com)
  • Can cause the victim to browse to a page serving JavaScript at one of

these domains

  • Victim is logged in to bank.com (or any other interesting site)
slide-81
SLIDE 81

Quick review

slide-82
SLIDE 82

Quick review

  • Can the attacker's JavaScript read bank.com?
slide-83
SLIDE 83

Quick review

  • Can the attacker's JavaScript read bank.com?
  • No. Same origin policy
slide-84
SLIDE 84

Quick review

  • Can the attacker's JavaScript read bank.com?
  • No. Same origin policy
  • The attacker's script uses XMLHttpRequest("https://bank.com") which

causes the browser to fetch https://bank.com and return its contents. Can the attacker's script read the response?

slide-85
SLIDE 85

Quick review

  • Can the attacker's JavaScript read bank.com?
  • No. Same origin policy
  • The attacker's script uses XMLHttpRequest("https://bank.com") which

causes the browser to fetch https://bank.com and return its contents. Can the attacker's script read the response?

  • No. Same origin policy
slide-86
SLIDE 86

Quick review

  • Can the attacker's JavaScript read bank.com?
  • No. Same origin policy
  • The attacker's script uses XMLHttpRequest("https://bank.com") which

causes the browser to fetch https://bank.com and return its contents. Can the attacker's script read the response?

  • No. Same origin policy
  • Can the attacker's script use


XMLHttpRequest("https://bank.com/transfer?from=victim&to=attacker")?

slide-87
SLIDE 87

Quick review

  • Can the attacker's JavaScript read bank.com?
  • No. Same origin policy
  • The attacker's script uses XMLHttpRequest("https://bank.com") which

causes the browser to fetch https://bank.com and return its contents. Can the attacker's script read the response?

  • No. Same origin policy
  • Can the attacker's script use


XMLHttpRequest("https://bank.com/transfer?from=victim&to=attacker")?

  • Yes! Same origin policy doesn't prevent this. The script just cannot read

the response

slide-88
SLIDE 88

Cross-site request forgery (CSRF)

  • The attacker's site instructs the victim's browser to make a request to an

honest site (e.g., using XMLHttpRequest or even just an enticing link)

  • An XMLHttpRequest allows both GET and POST
  • The browser sends all relevant cookies, including any sessions cookies

identifying the logged in victim

  • From the server's perspective, it looks exactly like a normal request from

the victim's browser

slide-89
SLIDE 89

Cross-site Request Forgery (CSRF)

bank.com POST /login?user=bob&pass=abc123 HTTP/1.1
 Host: bank.com HTTP/1.1 200 OK
 Set-Cookie: login=fde874
 ….

slide-90
SLIDE 90

Cross-site Request Forgery (CSRF)

bank.com POST /login?user=bob&pass=abc123 HTTP/1.1
 Host: bank.com HTTP/1.1 200 OK
 Set-Cookie: login=fde874
 …. fde874 = bob

slide-91
SLIDE 91

Cross-site Request Forgery (CSRF)

bank.com GET /account HTTP/1.1
 Host: bank.com Cookie: login=fde874 fde874 = bob

slide-92
SLIDE 92

Cross-site Request Forgery (CSRF)

bank.com GET /account HTTP/1.1
 Host: bank.com Cookie: login=fde874 HTTP/1.1 200 OK
 …. $378.42 fde874 = bob

slide-93
SLIDE 93

Cross-site Request Forgery (CSRF)

bank.com fde874 = bob Click me!!!
 http://bank.com/transfer?to=badguy&amt=100

slide-94
SLIDE 94

Cross-site Request Forgery (CSRF)

bank.com GET /transfer?to=badguy&amt=100 HTTP/1.1
 Host: bank.com Cookie: login=fde874 fde874 = bob Click me!!!
 http://bank.com/transfer?to=badguy&amt=100

slide-95
SLIDE 95

Cross-site Request Forgery (CSRF)

bank.com GET /transfer?to=badguy&amt=100 HTTP/1.1
 Host: bank.com Cookie: login=fde874 HTTP/1.1 200 OK
 …. Transfer complete: -$100.00 fde874 = bob Click me!!!
 http://bank.com/transfer?to=badguy&amt=100

slide-96
SLIDE 96

Why not make requests directly?

  • Use the browser's state: The browser sends cookies, client certificates,

basic auth credentials in the request

  • Set the browser's state: The browser parses and acts on responses, even

if the JavaScript cannot read the responses

  • Leverage the browser's network connectivity: The browser can connect to

servers the malicious site cannot reach (e.g., those behind a firewall)

slide-97
SLIDE 97

CSRF Defenses

  • Need to “authenticate” each user action originates from the legitimate site
  • Only needed for actions that change state (E.g., POST but not GET)
  • Why isn't it needed for GET?
  • Possibilities
  • Secret token
  • HTTP Referer header (yes, Referer not Referrer, it was misspelled)
  • Custom HTTP header
  • Origin header
slide-98
SLIDE 98

Secret token

  • Hidden form field with the token value
  • The token should be unpredictable to attackers
  • Random numbers work, but then need to be stored server side
  • Using crypto, we can do better (HMAC)
  • The token should be sent along with every POST and checked by the

server

  • This is a hassle for dynamically-generated content since it needs to

include the tokens

  • What prevents malicious script from fetching the page (e.g., with

XMLHttpRequest), reading the token, and then sending a response with the token?

slide-99
SLIDE 99

Example CSRF token

<form action="/transfer" method="post"> <input type="hidden" name="token" value="8d64"> To <input type="text" name="to"><br> Amount <input type="text" name="amount"><br> <input type="submit" value="Transfer"> </form>

slide-100
SLIDE 100

CSRF Defenses

bank.com fde874 = bob HTTP/1.1 200 OK
 Set-Cookie: login=fde874 <form action="/transfer" method="post"> <input type="hidden" name="token" value="8d64"> …

This is not actually how POST data is encoded and sent, but the principle is the same

slide-101
SLIDE 101

CSRF Defenses

bank.com POST /transfer?to=joe&amt=25&token=8d64 HTTP/1.1
 Host: bank.com Cookie: login=fde874 fde874 = bob HTTP/1.1 200 OK
 Set-Cookie: login=fde874 <form action="/transfer" method="post"> <input type="hidden" name="token" value="8d64"> …

This is not actually how POST data is encoded and sent, but the principle is the same

slide-102
SLIDE 102

CSRF Defenses

bank.com POST /transfer?to=joe&amt=25&token=8d64 HTTP/1.1
 Host: bank.com Cookie: login=fde874 HTTP/1.1 200 OK
 …. Transfer complete: -$25.00 fde874 = bob HTTP/1.1 200 OK
 Set-Cookie: login=fde874 <form action="/transfer" method="post"> <input type="hidden" name="token" value="8d64"> …

This is not actually how POST data is encoded and sent, but the principle is the same

slide-103
SLIDE 103

Referer header

  • Sent by the browser and contains the URL of the page containing the link

that was clicked or form that was submitted

  • Easy to handle server side, just check that the request comes with the

correct Referer header

  • However, it is frequently stripped by the browser or middle boxes (for

privacy reasons)

  • It's stripped less often over HTTPS since middle boxes can't modify

content

slide-104
SLIDE 104

Custom HTTP header

  • XMLHttpRequest supports adding custom headers but browsers disallow

them on cross-origin requests

  • Server can check that the custom header is present
slide-105
SLIDE 105

Origin header

  • The evolution of the Referer header but only contains the scheme, host,

and port, not the full URL

  • As with the Referer and custom headers, the server checks the Origin is

correct

  • Supported by all major browsers
  • Unlike custom headers, it's part of the standard
slide-106
SLIDE 106

Cross-site scripting (XSS)

  • XSS is a method for attackers to embed content (often JavaScript) in

another page

  • Two basic types
  • Reflected XSS
  • Stored XSS
slide-107
SLIDE 107

Reflected XSS

  • Web attacker causes the victim to click a link to a legitimate page where

the link contains some script

  • The server includes the script verbatim in the legitimate page which is

sent back to the browser

  • The browser interprets it as script coming from the legitimate origin
slide-108
SLIDE 108

Cross-Site Scripting (XSS)

<?php echo “Hello, ” . $_GET[“user”] . “!”;

slide-109
SLIDE 109

Cross-Site Scripting (XSS)

<?php echo “Hello, ” . $_GET[“user”] . “!”; GET /?user=Bob HTTP/1.1

slide-110
SLIDE 110

Cross-Site Scripting (XSS)

<?php echo “Hello, ” . $_GET[“user”] . “!”; GET /?user=Bob HTTP/1.1 HTTP/1.1 200 OK
 …
 Hello, Bob!

slide-111
SLIDE 111

Cross-Site Scripting (XSS)

<?php echo “Hello, ” . $_GET[“user”] . “!”; GET /?user=<u>Bob</u> HTTP/1.1

slide-112
SLIDE 112

Cross-Site Scripting (XSS)

<?php echo “Hello, ” . $_GET[“user”] . “!”; GET /?user=<u>Bob</u> HTTP/1.1 HTTP/1.1 200 OK
 …
 Hello, <u>Bob</u>!

slide-113
SLIDE 113

Cross-Site Scripting (XSS)

<?php echo “Hello, ” . $_GET[“user”] . “!”; GET /?user=<script>alert(‘XSS’)</script> HTTP/1.1

slide-114
SLIDE 114

Cross-Site Scripting (XSS)

<?php echo “Hello, ” . $_GET[“user”] . “!”; GET /?user=<script>alert(‘XSS’)</script> HTTP/1.1 HTTP/1.1 200 OK
 …
 Hello, <script>alert(‘XSS’)</script>!

slide-115
SLIDE 115

Cross-Site Scripting (XSS)

<?php echo “Hello, ” . $_GET[“user”] . “!”; GET /?user=<script>alert(‘XSS’)</script> HTTP/1.1 HTTP/1.1 200 OK
 …
 Hello, <script>alert(‘XSS’)</script>! http://vuln.com/ says:
 XSS

slide-116
SLIDE 116

Cross-Site Scripting (XSS)

<?php echo “Hello, ” . $_GET[“user”] . “!”; GET /?user=<script>alert(‘XSS’)</script> HTTP/1.1 HTTP/1.1 200 OK
 …
 Hello, <script>alert(‘XSS’)</script>! http://vuln.com/ says:
 XSS Click me!!!
 http://vuln.com/?user=<script>alert(‘XSS’)</script>

slide-117
SLIDE 117

Cross-Site Scripting (XSS) Attack

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/?user=<script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); })
 </script>”></iframe> gmail.com

slide-118
SLIDE 118

Cross-Site Scripting (XSS) Attack

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/?user=<script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); })
 </script>”></iframe> gmail.com

slide-119
SLIDE 119

Cross-Site Scripting (XSS) Attack

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/?user=<script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); })
 </script>”></iframe> GET /?user=<script>$.get(‘ … </script> HTTP/1.1
 Host: gmail.com gmail.com

slide-120
SLIDE 120

Cross-Site Scripting (XSS) Attack

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/?user=<script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); })
 </script>”></iframe> GET /?user=<script>$.get(‘ … </script> HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 Hello, <script>$.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); }) </script> gmail.com

slide-121
SLIDE 121

$.get(‘http://gmail.com/
 msgs.json’, function (data)
 { alert(data); })

Cross-Site Scripting (XSS) Attack

GET / HTTP/1.1
 Host: facebook.com (evil!)
 facebook.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/?user=<script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); })
 </script>”></iframe> GET /?user=<script>$.get(‘ … </script> HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 Hello, <script>$.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); }) </script> gmail.com

slide-122
SLIDE 122

Cross-Site Scripting (XSS) Attack

GET / HTTP/1.1
 Host: facebook.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/?user=<script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); })
 </script>”></iframe> gmail.com

$.get(‘http://gmail.com/
 msgs.json’, function (data) { alert(data); })

(evil!)
 facebook.com

slide-123
SLIDE 123

Cross-Site Scripting (XSS) Attack

GET / HTTP/1.1
 Host: facebook.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/?user=<script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); })
 </script>”></iframe> GET /msgs.json HTTP/1.1
 Host: gmail.com gmail.com

$.get(‘http://gmail.com/
 msgs.json’, function (data) { alert(data); })

(evil!)
 facebook.com

slide-124
SLIDE 124

Cross-Site Scripting (XSS) Attack

GET / HTTP/1.1
 Host: facebook.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/?user=<script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); })
 </script>”></iframe> GET /msgs.json HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 { new_msgs: 3 } gmail.com

$.get(‘http://gmail.com/
 msgs.json’, function (data) { alert(data); })

(evil!)
 facebook.com

slide-125
SLIDE 125

Cross-Site Scripting (XSS) Attack

GET / HTTP/1.1
 Host: facebook.com HTTP/1.1 200 OK
 …
 <iframe src=“http://gmail.com/?user=<script>
 $.get(‘http://gmail.com/msgs.json’,
 function (data) { alert(data); })
 </script>”></iframe> GET /msgs.json HTTP/1.1
 Host: gmail.com HTTP/1.1 200 OK
 …
 { new_msgs: 3 } gmail.com

$.get(‘http://gmail.com/
 msgs.json’, function (data) { alert(data); })

(evil!)
 facebook.com http://gmail.com/ says:
 { new_msgs: 3 }

slide-126
SLIDE 126

XSS capabilities

  • Execute arbitrary scripts in the context (i.e., Origin) of the vulnerable

server

  • Manipulate the DOM of the vulnerable page
  • Submit/read forms (including any CSRF tokens)
  • Read cookies
  • Install event handlers
  • In essence, anything that JavaScript can do!
slide-127
SLIDE 127

Stored XSS

  • Some web sites serve user-generated content but fail to properly sanitize

the user's input

  • The attacker POSTs some HTML with JavaScript on the page (e.g., a post
  • n a forum)
  • When victims visit the page, the attacker's script is served and the

browser (not realizing it came from the attacker) executes it as normal

  • The script can do anything JavaScript can do!
slide-128
SLIDE 128

Example: Samy worm

  • Myspace allowed users to insert HTML in their profiles, but disallowed

<script>

  • Some browsers support JavaScript inside CSS


<div style="background:url('javascript: eval(...)')">

  • Myspace disallowed the word javascript but Internet Explorer (at the time

anyway) allowed
 java
 script
 which bypassed their filter

  • Other filters were bypassed by using eval()
slide-129
SLIDE 129

Example: Samy worm

  • Samy Kamkar discovered this and put some script in his profile
  • When his page was viewed by a victim, the victim's browser would run the

script which would modify the victim's profile to include "but most of all, samy is my hero" as well as the script itself

  • Within 20 hours, over one million people's profiles were infected
  • Myspace had to go offline to fix the problem
  • Kamkar pleaded guilty to a felony and got 3 years probation, a fine, and

restricted computer use (now he makes cool YouTube videos!)
