IRM dans la quantification de linsuffisance mitrale Elie Mousseaux Cardiovascular Imaging, Radiology Department Hpital Europen Georges Pompidou Universit Paris Descartes, INSERM U 970, PARCC Insuffisance Mitrale Quantification
SLIDE 2
SLIDE 3
Mitral Regurgitation : multimodal MR imaging Echo + CT ?
SLIDE 4
Quantification?
SLIDE 5
Quantification en IRM
SLIDE 6
Mitral Regurgitation: quantification
Kar, Sharma, JACC 2015
SLIDE 7
MR Volume = Left ventricle Stroke Volume – Ao Volume
SLIDE 8
Left ventricle Stroke Volume
SLIDE 9
Aortic Stroke Volume
MR volume = LVSV - AoSV = 92.6 – 30,6 RV = 62ml RF = 62 / 92 = 66%
SLIDE 10
Gold Standard?
SLIDE 11
Gold Standard
Hemodynamic response of the LV Clinical Outcomes
SLIDE 12
From Uretsky CMR 2018
SLIDE 13
Impact sur le VG: pas de relation entre quantification de l’IM écho et le remodelage post
- p (5-7 mois)
N = 103 Asymptomatic Patients Mild <30 ml ; Moderate 30 to 60 ml; Severe > 60 ml in CMR Urestky et al JACC 2015
SLIDE 14
Uretsky et al JACC 2015
Patients with incomplete or suboptimal echocardiographic studies were excluded
Biner et al
SLIDE 15
Volumic vs Full Phase Contrast approach
Le Goffic et al , AJC 2015
SLIDE 16
Le Goffic et al , AJC 2015 The Reference method =
Volumic vs Full Phase Contrast approach
SLIDE 17
IRM
- Seuil de dilatation VG ?
- Rvol >= 60 ml
- RF >= 50% (why not 40% ??)
Sévérité IM à l’écho vs à l’IRM
SLIDE 18
Sévérité de l’IM à l’échocardiographie
SLIDE 19
Asymptomatic Patients MR Moderate to severe on Echo- derived integrative approach n=109 CMR Mean F/u 2.5 y Class I Indication for Surgery
- Symptoms (n=19)
- ESD> 40 mm (n=4)
- Onset of sPAP> 50 (n=2)
Surgery n=25 No surgery n=84
End Point Severe OMR defined as RV > 60 ml Myerson et al Circulation 2016
SLIDE 20
Rvol >= 60 ml 55 ml ? RF >= 50% 40 % ?? EDV > 100 ml/m² ? ESV ?? Myerson et al Circulation 2016
SLIDE 21
Asymptomatic Patients MR Moderate to severe on Echo- derived integrative approach n=258 CMR Mean F/u 5 y Or Class I or IIa of Indication for Surgery
- Symptoms
- ESD> 45 mm or LV EF < 60%
- PAPS>50mmHg
- New onset of Atrial Fibrillation
- Onset of PHT (sPAP> 50 at rest)
Surgery n=25 No surgery n=84
End Point All cause Mortality Penicka et al Circulation 2018
SLIDE 22
Penicka et al Circulation 2018
SLIDE 23
Good Agreement only if holosystolic MR central and single jet
Penicka et al Circulation 2018
SLIDE 24
Ce résultat pose problème en raison du nombre de surestimation de l’IM à l’écho (35%)
Good Agreement only if holosystolic MR central and single jet
SLIDE 25
Penicka et al Circulation 2018
Determinant de la mortalité en présence d’une IRM modérée ou sévère écho
Per 10 ml / m² > 35 ml/m²
SLIDE 26
Penicka et al Circulation 2018
SLIDE 27
Pitfall with MR quantification in CMR
- Error in ventricular volume ( especially basal slice)
- Phase Contrast slice orthogonal to vessel
- Background phase offset: vessel at isocenter, background or
phantom correction
- Well choose velocity encoding
- Arrhythmia?
- Usual CMR limitations: Implanted devices, claustrophobia
SLIDE 28
Going Further? Flux 4D, LGE, T1 ??
- 4D phase Contrast:
- 10 minutes
- Volumic Information
- No Validation For MR
- More Pitfalls than 2D PC
SLIDE 29
Special Thanks:
- G. Soulat, F.Pitocco, E. Charpentier, K.Dang Tran, U.Gencer,
P.Garrigoux. J Jouan, C Latremouille, A Berrebi service de chirurgie cardiaque HEGP
