RISQUE RYTHMIQUE ET INSUFFISANCE RISQUE RYTHMIQUE ET INSUFFISANCE CARDIAQUE: ROLE DE LIMAGERIE CARDIAQUE: ROLE DE LIMAGERIE Pr. Hubert Cochet Pr. Hubert Cochet University of Bordeaux, France University of Bordeaux, France Email:

slide-1
SLIDE 1
  • Pr. Hubert Cochet
  • Pr. Hubert Cochet

University of Bordeaux, France University of Bordeaux, France Email: hubert.cochet@chu Email: hubert.cochet@chu-

  • bordeaux.fr

bordeaux.fr

RISQUE RYTHMIQUE ET INSUFFISANCE CARDIAQUE: ROLE DE L’IMAGERIE RISQUE RYTHMIQUE ET INSUFFISANCE CARDIAQUE: ROLE DE L’IMAGERIE

slide-2
SLIDE 2

DISCLOSURES

Shareholder: Co-founder of inHEART Grant/Research Support: Siemens Healthineers Guerbet Medtronic Speaker/Consultant fees: Siemens Healthineers Biosense Webster Boston Scientific Abbott Fineheart Farapulse

slide-3
SLIDE 3

RATIONAL

Albert CM. Circulation. 1996;93:1170-1176

Etiologies of lethal arrhythmias

slide-4
SLIDE 4

RATIONAL

Ursell PC et al. Circ Res. 1985;56:436-51 Wagner A et al.

  • Lancet. 2003;361:374-9
slide-5
SLIDE 5

IMAGING & VENTRICULAR ARRHYTHMIAS

slide-6
SLIDE 6
  • > 4 millions/yr worldwide (1/5 of all deaths…)
  • 70% due to arrhythmias
  • 90% of arrhythmias occur on a substrate visible on CMR

CURRENT PREVENTION ICDs in LVEF <35%

Covers only a small minority of SCDs (<10%) Most implanted pts do not need ICDs (2/3)

CLINICAL ISSUE OF SUDDEN CARDIAC DEATH

slide-7
SLIDE 7

PROGNOSTIC ROLE OF LGE CMR IN ISCHEMIC HEART DISEASE

Watanabe, E., et al. Circ. Cardiovasc. Imaging. 2014; 7: 887–894 Signal intensity n pixels

slide-8
SLIDE 8

PROGNOSTIC ROLE OF LGE CMR IN NON-ISCHEMIC DCM

Di Marco A, et al. JACC Heart Fail. 2017 Jan;5(1):28-38.

Meta-analysis 2948 patients LVEF<35% Prospective study 399 patients LVEF>40%

B.P. Halliday,et al. Circulation, 135 (2017), pp. 2106-2115

slide-9
SLIDE 9

PROGNOSTIC ROLE OF LGE CMR IN HCM

Prior SCD Spontaneous sustained VT Family history of SCD Unexplained syncope Non-sustained VT on Holter Abnormal exercise blood pressure LV thickness 30 mm Prior SCD Spontaneous sustained VT Family history of SCD Unexplained syncope Non-sustained VT on Holter Abnormal exercise blood pressure LV thickness 30 mm

slide-10
SLIDE 10

PROGNOSTIC ROLE OF LGE CMR IN HCM

N P V

  • v

e r e s t i m a t e d b y r e t r

  • s

p e c t i v e s t u d i e s P P V t

  • l
  • w

t

  • j

u s t i f y c

  • s

t s & c

  • m

p l i c a t i

  • n

s N P V

  • v

e r e s t i m a t e d b y r e t r

  • s

p e c t i v e s t u d i e s P P V t

  • l
  • w

t

  • j

u s t i f y c

  • s

t s & c

  • m

p l i c a t i

  • n

s

Prior SCD Spontaneous sustained VT Family history of SCD Unexplained syncope Non-sustained VT on Holter Abnormal exercise blood pressure LV thickness >30 mm

slide-11
SLIDE 11

PROGNOSTIC ROLE OF LGE CMR IN HCM

Prospective study 1293 patients

Chan RH, et al.

  • Circulation. 2014 Aug 5;130(6):484-95.
slide-12
SLIDE 12

PROGNOSTIC ROLE OF LGE CMR ONGOING TRIALS

slide-13
SLIDE 13

RISK STRATIFICATION ROLE OF T1 MAPPING?

Prospective study 130 ICM&DCM patients, LVEF<35%

Chan RH, et al.

  • Circulation. 2014 Aug 5;130(6):484-95.
slide-14
SLIDE 14

IMAGING & VENTRICULAR ARRHYTHMIAS

slide-15
SLIDE 15

157 pts with VT or VF CMR alters diagnosis in 38% of pts with no history of SHD negative echo & angio

Hennig et al. Eur Heart J Cardiovasc Imaging 2017

IMAGING TO IDENTIFY THE UNDERLYING VT/VF ETIOLOGY

slide-16
SLIDE 16

44 yo man with monomorphic sustained VT of RBBB morphology Negative TTE & coronary angiography

ED ES LGE

CARDIAC SARCOID

IMAGING TO IDENTIFY THE UNDERLYING VT/VF ETIOLOGY

slide-17
SLIDE 17

34 yo man with VT of unknown morphology Negative TTE. Non-specific T wave changes on ECG.

APICAL FORM OF HCM

ED ES LGE

IMAGING TO IDENTIFY THE UNDERLYING VT/VF ETIOLOGY

slide-18
SLIDE 18

58 yo women with sustained VT of RBBB morphology Negative TTE & coronary angiography

CHURG-STRAUSS VASCULITIS

ED ES LGE

IMAGING TO IDENTIFY THE UNDERLYING VT/VF ETIOLOGY

slide-19
SLIDE 19

35 yo man with frequent PVCs and sustained VT. Negative coronary CTA. TTE: mild dilatation suggesting arrhythmia-induced cardiomyopathy

LAMINOPATHY

ED ES LGE

IMAGING TO IDENTIFY THE UNDERLYING VT/VF ETIOLOGY

slide-20
SLIDE 20

62 yo. Woman with symptomatic PVCs & negative T waves V1-V3

ARVC

IMAGING TO IDENTIFY THE UNDERLYING VT/VF ETIOLOGY

slide-21
SLIDE 21

HIGH-RES LGE => better detection of SHD (17% à 38%, P<0.001). HIGH-RES LGE => better detection of SHD (17% à 38%, P<0.001).

THE SMALLER THE PIXEL THE BETTER

CONVENTIONAL LGE HIGH-RES. LGE Hennig et al. Eur Heart J Cardiovasc Imaging 2017

slide-22
SLIDE 22

IMAGING & VENTRICULAR ARRHYTHMIAS

slide-23
SLIDE 23

Signal intensity n pixels

  • Ursell. Circ Res. 1985

SUBSTRATE MAPPING FROM MRI: LATE GADOLINIUM ENHANCEMENT

slide-24
SLIDE 24

Fat Wall thinning Calcification

ARTERIAL

Late iodine enhancement

LATE

SUBSTRATE MAPPING FROM CT: MULTI-PARAMETRIC

slide-25
SLIDE 25

CT arterial CT late Fusion Scar CT MRI Scar MRI

SUBSTRATE MAPPING FROM CT: POST-INFARCTION

slide-26
SLIDE 26

CT-thickness CT-fat CT-late iodine MR-late gadolinium

< 5 < 4 < 3 < 2 < 1 mm Dense scar Grey zone Dense scar Grey zone

EXAMPLE: POST-MI VT (CT/MRI)

slide-27
SLIDE 27

PROCEDURAL INTEGRATION

Improved efficacy Shorter procedures Simpler & more standardized procedures

slide-28
SLIDE 28
  • Hendriks. EP Europace. 2017 Jun;19(3):483.

VT-FREE SURVIVAL OVERALL SURVIVAL

IMPACT ON OUTCOME

slide-29
SLIDE 29
slide-30
SLIDE 30

IMAGE INTEGRATION STRATEGY

Improved anatomy and substrate definition

  • Impact on procedure time +
  • Impact on efficacy +

CURRENT: IMAGING TO GUIDE MAPPING

Dedicate the entire procedure to ablation

  • Impact on procedure time +++
  • Impact on efficacy +++
  • Simplification / standardization of procedures +++

SOON: IMAGING TO DEFINE ABLATION TARGETS

slide-31
SLIDE 31

57 yo man with prior infarct in LAD territory Multiple ICD shocks on monomorphic VT

Nicolas Cedilnik et al. Europace 2018

HD VT map Simulation endo Simulation epi

Thickness

5mm 0mm

PERSPECTIVE IMAGE-BASED SIMULATION

slide-32
SLIDE 32
slide-33
SLIDE 33

CONCLUSIONS

IMAGING & VENTRICULAR ARRHYTHMIAS

ablation guidance

CT/MR for enhanced definition of substrate/anatomy identifying structures at risk (coronaries, phrenic) direct definition of ablation targets

perspective

fully non-invasive cardiac ablation

slide-34
SLIDE 34

TAKE HOME MESSAGES

Ventricular arrhythmia without known structural heart disease?

Get an MRI even if echo and angio are negative

Ventricular arrhythmia without known structural heart disease?

Get an MRI even if echo and angio are negative

Patient considered for ICD implantation for primary prevention?

Use MRI to measure LVEF: gold standard + LGE data in case of future shocks

Patient considered for ICD implantation for primary prevention?

Use MRI to measure LVEF: gold standard + LGE data in case of future shocks

Patient referred for VT ablation?

Develop a close collaboration between EP & imaging teams Seek for image processing solutions to get optimal imaging information in the lab

Patient referred for VT ablation?

Develop a close collaboration between EP & imaging teams Seek for image processing solutions to get optimal imaging information in the lab
