IPIN competition 2016 Track 3: Smartphone based (off-site) Sponsored by Chaired by J. Torres, F. Seco, R. Montoliu, A. R. Jimnez Organized by International Conference EvAAL on Indoor Positioning and Indoor Navigation Track3:

slide-1
SLIDE 1
  • J. Torres, F. Seco,
  • R. Montoliu, A. R. Jiménez

International Conference

  • n Indoor Positioning

and Indoor Navigation

EvAAL

IPIN competition 2016

Track 3: Smartphone based (off-site)

Sponsored by Chaired by Organized by

slide-2
SLIDE 2

Track3: Smartphone-based (off-site)

  • The goal:
  • To localize a pedestrian walking under realistic conditions:
  • in several multi-floor buildings
  • using a conventional smartphone and its available signals (WiFi,

inertial, magnetic, GPS, pressure, light,...)

  • Competitors:
  • Calibrate their algorithms with some logfiles data recordings

with inserted ground truth marks (~1000 marks)

  • Compete using new unreferenced logfile data
  • Award:
  • TECNALIA awards a €1.500 cash prize to the winner
slide-3
SLIDE 3

Challenges (1/2)

  • Multiple buildings:
  • Multiple sources of information:
  • WiFi RSS, Inertial data (Accelerometer and

Gyroscope), Magnetic, GPS, AHRS, Pressure, Temperature, Humidity, Sound intensity and Light intensity

  • Continuous motion & recording:
  • Different sampling time (WiFi every~6s),
  • Acc (~50Hz), different for others

CAR (ID 10) 1 floor UAH (ID 20) 4 floors UJIB (ID 30) 6 floors UJITI (ID 40) 4 floors

slide-4
SLIDE 4

Challenges (2/2)

  • Realistic walking style:
  • Mainly forward, also lateral/backwards, turns 90º&

180º, elevators/stairs, giving way to other people.

  • Limited info of buildings:
  • Multiple WiFi AP, but position of each AP is unknown.
  • Geo-referenced floor-map bitmaps (no vector format)
slide-5
SLIDE 5

Competitors

Yair Beer Block Dox (UK) Viet Cuong Ta Inria/U.Hanoi (France) Filipe Meneses

  • U. Minho

(Portugal)

  • S. Knauth

HFTS (Germany) Toni Fetzer FHWS (Germany)

slide-6
SLIDE 6

Results: Recording Ground Truth

  • UAH Route3:
  • Logfile 7(signals captured

with a Samsung S4 phone) Sample video

  • f route recording

Some ground-truth points of route 3 (UAH)

slide-7
SLIDE 7

Results: Evaluating results

Example of competitor’s trajectory estimation & error w.r.t GT

slide-8
SLIDE 8

Results: Building & Floor Identification

Errors => 50 m penalty

slide-9
SLIDE 9

Results: Building & Floor Identification

Errors => 15 m penalty

slide-10
SLIDE 10

Results: Position estimation errors (1/3)

slide-11
SLIDE 11

Results: Position estimation errors (2/3)

Cumulative Error Distribution Function (CDF) Position Error (m) Percentage (%) 5.8m 7.3m 7.8m 8.8m Who is who?

slide-12
SLIDE 12

Results: Position estimation errors (3/3)

# Competition metric

Podium:

slide-13
SLIDE 13

Results: Position estimation errors (3/3)

# Competition metric 3rd 7.826 m

Podium:

slide-14
SLIDE 14

Results: Position estimation errors (3/3)

# Competition metric 3rd 7.826 m Yair

Podium:

slide-15
SLIDE 15

Results: Position estimation errors (3/3)

# Competition metric 2nd 7.317 m 3rd 7.826 m Yair

Podium:

slide-16
SLIDE 16

Results: Position estimation errors (3/3)

# Competition metric 2nd 7.317 m UMinho 3rd 7.826 m Yair

Podium:

slide-17
SLIDE 17

Results: Position estimation errors (3/3)

# Competition metric 1st 5.846 m 2nd 7.317 m UMinho 3rd 7.826 m Yair

Podium:

slide-18
SLIDE 18

Results: Position estimation errors (3/3)

# Competition metric 1st 5.846 m HFTS 2nd 7.317 m UMinho 3rd 7.826 m Yair

Podium:

slide-19
SLIDE 19

The winner of Track 3 IPIN 2016 is…..

  • A. Koukofikis and S. Knauth

unsere Glückwünsche!

International Conference

  • n Indoor Positioning

and Indoor Navigation (IPIN)
