INTRODUCING UNDERCOUNTER CUBERS

COMPACT DESIGN, RELIABILITY, AND INTUITIVE CONTROLS.

The Essential IceTM Series

Product Offering

 Reliability  Ease of Use  Compact Design  High Production  Clear Ice Cubes  Environmentally Friendly

Features & Benefits

Reliability - Essential Ice machines will last

long and help reduce repair expense

• Industry leading Warranty
• 3 year parts and labor on all

components Quality

• Assembled in the USA
• Award winning Fairfax, South Carolina

Facility

• ISO9001:2015 accredited
• All machines run tested before

shipment

The Essential IceTM Series

Features & Benefits

Ease of Use - Essential Ice allows

• perators to efficiently get ice they need
• Slide Up Door
• Large Access Area
• Ice Scoop Included

Intuitive Controls

• On/Off/Clean Switch
• Ice Thickness Adjustment
• Harvest Time Adjustment

The Essential IceTM Series

Features & Benefits

Compact Design - Essential Ice can fit in

virtually any location

• Only 15” or 20” cm wide
• 37.5” tall with 6” legs
• 32” tall with floor mount kit (KUFM15 or

KUFM20)

• For ADA Applications - Fits underneath

a 34” counter

• S3 Metallic Alloy side and top panels
• Corrosion resistant
• Easy to clean, smudge resistant
• Durable hard plastic front with curved

door

The Essential IceTM Series

31.9”

Features & Benefits

Clear Cubes - Essential provides ice that customers like to see

• Made with innovative horizontal evaporator
• Minerals don’t freeze in cube
• Spray jets helps keep them washed away

Environmentally Friendly - Essential Ice is designed

responsibly and lowers energy costs

• Uses R-134a refrigerant
• Does not deplete ozone layer
• Lower energy consumption
• Recyclable aluminum alloy side panels
• Same durability and corrosion resistance as stainless

The Essential IceTM Series

Meets the Following Regulations:

 ETL Safety  ETL Sanitation  Air Conditioning, Heating and Refrigeration Institute (AHRI)  CE (50 Hz)  InMetro (Brazil – 230/60/1)  Low Lead – Safe Drinking Water Act  United States Department Of Energy Federal Energy Efficiency Minimums

The Essential IceTM Series

Applications:

 Restaurants  Café  Bar  Offices  Break Rooms  Cooler Filling

• Construction, HVAC workers

 Schools  Health Club/Spa

The Essential IceTM Series

Model Number Naming

Example: CU0920MA-1A Cuber Undercounter 09 : x10 = lb per day, Medium cube Air cooled

• 1: 115V/60/1
• 6: 230V/60/1

A: Revision level – not always published CUR0920MA-32 R: InMetro certified – Portuguese, English labels, docs

• 32: 220/60/1

The Essential IceTM Series

Recommended Spare Parts:

• 15 inch door
• 20 inch door
• Door rollers
• Curtain
• Water pump – not new
• Inlet water solenoid valve
• Spray platform
• Controller
• Bin thermostat

The Prodigy Self Contained Cuber

Product Offering

 Easy Servicing  Easy Cleaning  Easy Operation  Compact Design  High Production  Intuitive Controls

Features & Benefits

• AutoAlert control board communicates
• perating status for easy diagnostics and

maintenance

• Adaptive WaterSense optimizes water

usage based on water quality

• Manufactured in Fairfax, South Carolina
• Warranty
• 1 year parts and labor
• 5 year parts on compressor
• Certified by AHRI, UL and NSF

The Prodigy Self Contained Cuber

Patented WaterSense Technology

• Automatically adjusts based on water supply

quality

• Exclusive feature helps reduce scale buildup

for more sanitary ice

• Reliable sensor adjusts water purge at end
• f each cycle to flush excess minerals
• Automatically flushes the system to extend

time between cleanings

• Operators can save water and energy where

water conditions are better filtered by recirculating clean, pre-chilled water back into the ice-making process

The Prodigy Self Contained Cuber

• Two models available

– CU50PA-1A

Cuber Undercounter, 50# production, Pump drain, Air cooled, 115V/60/1,A revision

– CU50GA-1A

Cuber Undercounter, 50# production, Gravity drain, Air cooled, 115V/60/1,A revision

• Replaces CS0415 models
• Up to 49 pounds/day production
• Up to 26 pounds of storage
• Stainless Steel Finish
• UL,NSF and AHRI certified
• Approved for outdoor use with

stainless steel kickplate

The CU50 Commercial Gourmet Cuber

Features & Benefits

Small Footprint

• 1” Adjustable legs
• 15” W x 24”D x 34 3/8”H

Attractive Aesthetics

• Reversible door
• Optional stainless steel kickplate
• Available with built in Drain Pump

Water Efficient

• Water Sensor

User Friendly Control Panel Unique Gourmet Ice

• Crystal Clear
• Slow melting

The CU50 Commercial Gourmet Cuber

Features & Benefits

Electronic Control Board - Easy to use and understand

• On/Off Button
• Clean/Reset Button
• Ice Making Indicator Light
• Check Water Indicator Light
• Time to Clean Indicator Light

Water Sensor

• Measures water conditions
• Automatically adjusts water purge
• Extends time between cleanings

The CU50 Commercial Gourmet Cuber

Individual Gourmet Cubes

• Crystal Clear
• Slow melting
• Ideal for cocktails

Cube Dimensions

• 1” x 1 1/8” x 1 1/4”

Applications:

• Break Rooms
• Office Kitchens
• Stadium Suites
• Bid Projects

The CU50 Commercial Gourmet Cuber
