Introducing the Quadrotor Introducing the Quadrotor Flying Robot Flying Robot

Roy Brewer Organizer Phila ilade delph lphia ia Robo Robotic ics s Meet etup up Group up Phila ilade delph lphia ia Robo Robotic ics s Meet etup up Group up August 13, 2009

slide-2
SLIDE 2

13 Aug 09 2

  • R. Brewer - Philly Meetup Quadrotor

What is a Quadrotor?

  • A vehicle having 4 rotors

(propellers) at each end of a square cross

  • Typically remote controlled;

can be autonomous or semi- autonomous

  • Home built, research, and

professional versions exist

  • Typically built using r/c

components, electric motors, microprocessors, servos, sensors, batteries

slide-3
SLIDE 3

13 Aug 09 3

  • R. Brewer - Philly Meetup Quadrotor

What is a Quadrotor Used For?

  • Fun radio controlled “toy”
  • Aerial Photography / Video
  • Surveillance
  • Robotics and/or Control Systems Research
slide-4
SLIDE 4

13 Aug 09 4

  • R. Brewer - Philly Meetup Quadrotor

How Does a Quadrotor Fly?

  • Rotor thrust and torque proportional

to rotor speed squared

  • 2 sets of counter rotating blades.
  • Torque inherently balanced
  • 4 inputs allow independent

actuation of pitch, roll, yaw and thrust

Controlling Roll/Pitch Controlling Roll/Pitch Controlling Altitude Controlling Altitude Controlling Yaw Controlling Yaw

slide-5
SLIDE 5

13 Aug 09 5

  • R. Brewer - Philly Meetup Quadrotor

How to Obtain a Quadrotor?

  • Buy

– http://www.asctec.de – http://www.microdrones.com – http://www.draganfly.com

  • Build (existing kits & plans)

– http://aeroquad.info/bin/view/Main/WebHome – http://mikrokopter.de – http://uavp.ch/moin (Why are there so many German quads? :-)

  • Comprehesive list:

– http://multicopter.org/wiki/Multicopter_Table

  • Design Our Own!
slide-6
SLIDE 6

13 Aug 09 6

  • R. Brewer - Philly Meetup Quadrotor

University Research

  • STARMAC – Stanford

– http://hybrid.eecs.berkeley.edu/index.php?section=37

  • MIT

– http://vertol.mit.edu/index.html

  • EPFL

– http://asl.epfl.ch/research/projects/VtolIndoorFlying/indoorFly

ing.php

  • Brigham Young

– http://www.ece.byu.edu/roboticvision/HelicopterPlatform/Heli

copterPlatform.html

  • Many more...
  • Many technical research papers available on-line
  • Task is equivalent to B.S Eng Project up to PhD Thesis!
slide-7
SLIDE 7

13 Aug 09 7

  • R. Brewer - Philly Meetup Quadrotor

Skills / Knowledge

My contribution:

  • Control Theory & Algorithms (PID etc.)

I Have Some Knowledge of:

  • Sensors (MEMs, GPS, Compass)
  • Microcontrollers, Embedded Systems, & Software
  • DSP / Filtering

What I need to learn:

  • Radio Control Equipment
  • (Brushless) Motors & Servos
  • Vision processing
  • Airframe Design & Construction
  • PC / ground station programming
slide-8
SLIDE 8

13 Aug 09 8

  • R. Brewer - Philly Meetup Quadrotor

Personal Goals:

  • Professional Development

– UAV – Advanced Controls – Sensor Processing / Sensor Fusion

  • Kalman, Complementary Filters, etc
  • Personal

– Microcontrollers – Embedded S/W – Electronics – Radio Control – Website / Blog / Magazine Articles

slide-9
SLIDE 9

13 Aug 09 9

  • R. Brewer - Philly Meetup Quadrotor

Project Goals:

  • Manual (Radio Control) Operation

– Acrobatic mode: angular rate & thrust command – Stable Mode: Translational rate command / position and

altitude hold

  • Semi Autonomous Operation

– Telemetry to Laptop-based ground station – Voice operation

  • Fully Acrobatic
  • Automatic P.I.D. Gain tuning
  • Other

– Provide Write-ups of Quad Dynamics, Control Loops (and theory),

& S/W Design

– Use Open Souce / Free S/W tools where possible

slide-10
SLIDE 10

13 Aug 09 10

  • R. Brewer - Philly Meetup Quadrotor

Project Status

  • Software

– Math / Simulation Model

  • Needs some work – drag models, etc.
  • Good enough to begin code prototyping

– Code

  • About to prototype control ideas
  • Hardware

– Controller

  • My friend Brijesh has designed, built and is testing a

custom AVR ATMega644p based board:

– Airframe, motors, ESCs, R/C gear, propellers, etc.

  • Some ideas, but nothing yet purchased
slide-11
SLIDE 11

13 Aug 09 11

  • R. Brewer - Philly Meetup Quadrotor

Math Model / Scicos Simulation

slide-12
SLIDE 12

13 Aug 09 12

  • R. Brewer - Philly Meetup Quadrotor

Custom Controller Card

* ATMEGA644p processor ( Same as Sanguino). * 20 MHz clock rate. * Serial port 1 : USB or Xbee link.

  • Arduino bootloader supported on both USB

and Xbee links. * Serial port 2 : Venus GPS module from Sparkfun. * 4 Channel RC receiver input. Interrupt based de- coding. * 4 Channel Hardware PWM/Servo pulse. * Terminals to distribute power to 4 ESC's from battery. * 4 pole Butterworth Anti-aliasing filters on all sensors inputs. * Gyros

  • IDG500 Break out board connector (X and Y

axis) + IDG500 output selectable between 100 Deg/sec or 500 Deg/sec via a jumper.

  • LISY300AL break out board connector (Z

axis) * Accelerometer: Two options available

  • MMA7260 breakout board connector. (Ana-

log outputs).

  • LIS302DL breakout board connector, (I2C in-

terface). * Battery voltage monitoring. * 3inx3in Dimensions with 4 mountings holes.

  • http://sites.google.com/site/pushpakquadrotor
slide-13
SLIDE 13

13 Aug 09 13

  • R. Brewer - Philly Meetup Quadrotor

Technical Challenges - Control

  • Airframe Dynamics Are:

– Non-linear:

  • 3-D Attitude (orientation): Trig functions,

Singularities, Quaternions

– Coupled:

  • Translation requires attitude changes
  • Attitude change requires thrust change to avoid

altitude (height) change

  • Many control schemes are employed

– “Simple” Proportional Integral Derivative (PID) – More advanced non-linear concepts – Distributed control – split on-board and laptop

slide-14
SLIDE 14

13 Aug 09 14

  • R. Brewer - Philly Meetup Quadrotor

Control Concept

  • Acrobatic mode: Rate command/attitude hold; direct thrust command
  • Precision mode: Velocity command/position hold;rate of climb command / altitude hold
  • Autonomous commands (possibly via laptop over telemetry)
  • Automatic or manual switching between modes

Quadrotor Sensors Comp. Filters R/C Joystick Or Laptop Attitude Command Rotor Mixing PID/ Other Feedback Velocity Command PID/ Other Feedback + - + -

Software

slide-15
SLIDE 15

13 Aug 09 15

  • R. Brewer - Philly Meetup Quadrotor

Technical Challenges - Sensors

  • Must sense position & orientation to control them
  • Gyroscopes

– Sense angular rates – Suffer from bias – Must be integrated to determine attitude – Usable only in a medium frequency range

  • Accelerometers

– Sense linear acceleration – Very noisy – Gravity must be handled carefully – Useable only in a low frequency range

  • Other sensors:

– GPS, Sonar, Magnetometer/Compass, Vision, etc.

slide-16
SLIDE 16

13 Aug 09 16

  • R. Brewer - Philly Meetup Quadrotor

Sensor Fusion

  • Complementary Filter

– Concept: utilize each sensor over the frequency range

where they provide good attitude data

– Integrate and High Pass filter gyro data – Low Pass Filter accelerometer ATAN data – Tune filter based on data – Inverse of stereo woofer/tweeter network

  • Kalman Filter

– Contains model/observer/predictor – And corrector feedback loop with varying gain – Uses statistical parameters – Much more complicated to understand and implement

slide-17
SLIDE 17

13 Aug 09 17

  • R. Brewer - Philly Meetup Quadrotor

Complementary Filter Design - 1

1/s 1/s

+ + + +

  • k

*k 2*k

1 2 1

Gyro (deg/s) Gyro (deg/s) Accel (deg) Accel (deg)

SCICOS Model

slide-18
SLIDE 18

13 Aug 09 18

  • R. Brewer - Philly Meetup Quadrotor

37.0 37.5 38.0 38.5 39.0 39.5 40.0 40.5 41.0

  • 1.5
  • 1.0
  • 0.5

0.0 0.5 1.0 1.5 2.0 2.5 T im e (sec) Attitude (deg) & Rate (deg/s) Gyro Accel Filter T rue Angle

Complementary Filter Design - 2

slide-19
SLIDE 19

13 Aug 09 19

  • R. Brewer - Philly Meetup Quadrotor

The Bigger Picture

slide-20
SLIDE 20

13 Aug 09 20

  • R. Brewer - Philly Meetup Quadrotor

Other Links from the Meetup

  • DIY Drones – UAVs - http://diydrones.com
  • Sparkfun – Electronic Parts & tutorials - http://www.sparkfun.com
  • Arduino – Microprocessors simplified - http://www.arduino.cc/
  • AVR Freaks – lots of info for AVR microprocessors

http://www.avrfreaks.net

  • Scilab/Scicos – Free Matlab clone - http://www.scilab.org;

http://scicos.org; http://scicoslab.com

  • Open Office – MS Office “clone” - http://www.openoffice.org
  • Magazines

– Nuts and Volts – general electronics - http://www.nutsvolts.com – Servo – robotics - http://www.servomagazine.com – Circuit Cellar – pro electronics - http://www.circellar.com – Elektor – UK electronics -http://www.elektor.com/magazines.46742.lynkx – Robot – robotics - http://www.botmag.com
