How are the GTO teams implementing their coronagraph programs?

Laurent Pueyo, Chris is Stark, Marshall Perrin, Remi Soummer.

slide-2
SLIDE 2

How are the GTO teams implementing their coronagraph programs?

Laurent Pueyo, Chris

is Stark, Marshall

Perrin, Remi Soummer.

slide-3
SLIDE 3

3 Tools You Will Want for Coronagraphic Observation Planning

JWST Exposure Time Calculator (ETC) JWST Coronagraph Visibility Tool (CVT) Astronomer’s Proposal Tool (APT)

slide-4
SLIDE 4

3 Tools You Will Want for Coronagraphic Observation Planning

Recommended Sequence:

  • 1. JWST Coronagraph Visibility Tool (CVT)
  • 2. JWST Exposure Time Calculator (ETC)
  • 3. Astronomer’s Proposal Tool (APT)
slide-5
SLIDE 5

Step 1: JWST Corongraph Visibility Tool (CVT)

slide-6
SLIDE 6

Allowable JWST Orientations

Solar elongations from 85° – 135°

slide-7
SLIDE 7

Rotating about Sun axis forms stripe on ecliptic sphere

Creating a PA Visibility Tool

Allowable JWST Orientations

slide-8
SLIDE 8

Visibility Depends on Ecliptic Latitude 2 Semi-Annual Viewing Blocks 1 Annual Viewing Block Continuous Viewing Zone

Creating a PA Visibility Tool

V3 PA varies over the course of a viewing block

slide-9
SLIDE 9

Allowable JWST Orientations

Solar elongations from 85° – 135°, V1 roll angles range from ±3.5° to ±7°

±7° ±3.5°

slide-10
SLIDE 10

Example of 1 Annual Viewing Block

HD 10647 Wide range of possible PAs

Observable Window Solar Elongation Allowed PAs

slide-11
SLIDE 11

Example of 2 Semi-annual Viewing Blocks

HD 141569

~14° ~7°

Limited range of PAs, larger roll dither allowed at elongation ~ 135°

slide-12
SLIDE 12

Step 1: JWST Corongraph Visibility Tool (CVT) Example

slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17

Step 2: JWST Exposure Time Calculator (ETC)

slide-18
SLIDE 18

Step 2: JWST Exposure Time Calculator (ETC)

The ETC not yet a full coronagraph simulator with all bells and whistles... If that is what you want go here: https://github.com/kvangorkom/pandeia-coronagraphy

slide-19
SLIDE 19

Step 2: JWST Exposure Time Calculator (ETC)

Key questions the ETC addresses for now: Will I be able to see an astrophysical source is my PSF subtraction is “perfect”?E.g. what is the photon noise on the speckles. Will I saturate? These are the two questions that depend on exposure time.

slide-20
SLIDE 20

Step 2: JWST Exposure Time Calculator (ETC) Example

slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26
slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34

Step 3: Astronomer’s Proposal Tool (APT)

slide-35
SLIDE 35

Guidelines to Follow:

  • 1. Thou shalt observe your science target at 2 roll angles,

differing by at least one degree (a “roll dither”)

  • 2. Thou shalt observe a reference star to measure the PSF

(for PSF subtraction by the pipeline)

  • 3. Thou shalt make these a non-interruptible sequence.

Figure credit: M. Perrin

slide-36
SLIDE 36
  • 1. Thou shalt observe your science target at 2 roll angles,

differing by at least one degree (a “roll dither”) Mitigates bad pixels in science image Rotates speckles wrt astrophysical scene

Guidelines to Follow:

slide-37
SLIDE 37

Guidelines to Follow:

  • Increases contrast by subtracting reference PSF from science image
  • Reference PSF star should be uncontaminated
  • Reference PSF should be close in spectral type (see supporting docs)
  • Reference PSF should be bright (shorter exposure time)
  • Reference PSF should be close to the science target (shorter slew time)
  • NOTE: Reference PSF observations are non-proprietary!
  • 2. Thou shalt observe a reference star to measure the PSF

(for PSF subtraction by the pipeline)

slide-38
SLIDE 38

Guidelines to Follow:

PSF spectral type selection guidelines: a future JDOX page Currently at http://www.starkspace.com/JWST_PSF_references.pdf

Credi: Jarron Leisenring

slide-39
SLIDE 39

Guidelines to Follow:

  • Reduces PSF changes between science and reference observations;

higher contrast

  • Science target & reference must be simultaneously visible
  • 3. Thou shalt make these a non-interruptible sequence.
slide-40
SLIDE 40

The Basic Coronagraphic Sequence

Obs ¡# ¡ Target ¡ Roll ¡ Inst ¡ Mask ¡ Filter ¡ 1 ¡ Science ¡ θ0 2 ¡ Science ¡ θ0 ¡+ ¡Δθ 3 ¡ Reference ¡ N/A ¡

Non-interruptible

Figure credit: M. Perrin

slide-41
SLIDE 41

A Multi-Filter Coronagraphic Sequence

Obs ¡# ¡ Target ¡ Roll ¡ Inst ¡ Mask ¡ Filter ¡ 1 ¡ Science ¡ θ0 NIRCam ¡ 210R ¡ F182M, ¡ F210M ¡ 2 ¡ Science ¡ θ0 ¡+ ¡Δθ NIRCam ¡ 210R ¡ F182M, ¡ F210M ¡ 3 ¡ Reference ¡ N/A ¡ NIRCam ¡ 210R ¡ F182M, ¡ F210M ¡

Non-interruptible

slide-42
SLIDE 42

A Multi-Instrument Coronagraphic Sequence

Obs ¡# ¡ Target ¡ Roll ¡ Inst ¡ Mask ¡ Filter ¡ 1 ¡ Science ¡ θ0 NIRCam ¡ 210R ¡ F182M ¡ 2 ¡ Science ¡ θ1 MIRI ¡ LYOT ¡ F2300C ¡ 3 ¡ Science ¡ θ0 ¡+ ¡Δθ NIRCam ¡ 210R ¡ F182M ¡ 4 ¡ Science ¡ θ1 ¡+ ¡Δθ MIRI ¡ LYOT ¡ F2300C ¡ 5 ¡ Reference ¡ N/A ¡ NIRCam ¡ 210R ¡ F182M ¡ 6 ¡ Reference ¡ N/A ¡ MIRI ¡ LYOT ¡ F2300C ¡

Non-interruptible

slide-43
SLIDE 43

A Multi-Epoch Coronagraphic Sequence

Obs ¡# ¡ Target ¡ Roll ¡ Inst ¡ Mask ¡ Filter ¡ 1 ¡ Science ¡ θ0 NIRCam ¡ SWB ¡ F210M ¡ 2 ¡ Science ¡ θ0 ¡+ ¡Δθ NIRCam ¡ SWB ¡ F210M ¡ 3 ¡ Reference ¡ N/A ¡ NIRCam ¡ SWB ¡ F210M ¡ 4 ¡ Science ¡ θ1 NIRCam ¡ SWB ¡ F210M ¡ 5 ¡ Science ¡ θ1 ¡+ ¡Δθ NIRCam ¡ SWB ¡ F210M ¡ 6 ¡ Reference ¡ N/A ¡ NIRCam ¡ SWB ¡ F210M ¡ Non-interruptible Non-interruptible

slide-44
SLIDE 44
slide-45
SLIDE 45
slide-46
SLIDE 46
slide-47
SLIDE 47
slide-48
SLIDE 48
slide-49
SLIDE 49

How about performances?

Contrast limits due to thermal drifts. Contrast limits due to pointing. Observing efficiency.

slide-50
SLIDE 50

McElwain et al., this conference ¡

Contrast limits due to thermal drifts.

slide-51
SLIDE 51

McElwain et al., this conference ¡

Contrast limits due to thermal drifts.

slide-52
SLIDE 52

McElwain et al., this conference ¡

Contrast limits due to thermal drifts.

slide-53
SLIDE 53

Lajoie et al., 2016 ¡

Contrast limits due to pointing.

slide-54
SLIDE 54

Lajoie et al., 2016 ¡

Contrast limits due to pointing.

slide-55
SLIDE 55

Lajoie et al., 2016 ¡

Contrast limits due to pointing.

slide-56
SLIDE 56

Lajoie et al., 2016 ¡

Contrast limits due to pointing.

slide-57
SLIDE 57

Lajoie et al., 2016 ¡

Contrast limits due to pointing.

slide-58
SLIDE 58

Lajoie et al., 2016 ¡

Contrast limits due to pointing.

  • Proc. of SPIE Vol. 9143 91433V-5
slide-59
SLIDE 59

Step 2: JWST Exposure Time Calculator (ETC)

The ETC not yet a full coronagraph simulator with all bells and whistles... If that is what you want go here: https://github.com/kvangorkom/pandeia-coronagraphy

slide-60
SLIDE 60

Observing Efficiency: timing

slide-61
SLIDE 61

Observing Efficiency: timing

slide-62
SLIDE 62

Observing Efficiency: timing

slide-63
SLIDE 63

Observing Efficiency: timing

slide-64
SLIDE 64

Observing Efficiency: timing

slide-65
SLIDE 65

Observing Efficiency: ordering

slide-66
SLIDE 66

Takeaways:

  • JWST Coronagraph planning takes time and attention to detail.

Remember to check target visibility before diving in.

  • Tools have now been released, with GTOs using them to plan
  • bservations. Feedback will be included in further versions.
  • If you are interested in detailed performance simulations we will

make our calculations public as we go along. We will not know everything until we get data.

  • When using APT, remember export .times and .smartaccounting

files to optimize efficiency.
