NICI The new Gemini South AO facility coronagraph by M. Hartung & T. Hayward, and E. Artigau, N. Zarate, G. Trancho, R. Galves, J. Luhrs, C. Urrutia, E. Christensen, M. Chun, D. Toomey, J. Jensen Background image courtesy: K. Davidson

slide-1
SLIDE 1

NICI – The new Gemini South AO facility coronagraph

by M. Hartung & T. Hayward,

and E. Artigau, N. Zarate, G. Trancho, R. Galves, J. Luhrs, C. Urrutia, E. Christensen, M. Chun, D. Toomey, J. Jensen Background image courtesy: K. Davidson

slide-2
SLIDE 2

Kyoto, May 2009 NICI – the GS AO facility coronagraph

Gemini international community Optimized for: Thermal IR High angular resolution Optimization choices: silver coating low emissivity (2.5% M1+M2) F/16 narrow field Thin spiders low diffraction LLT space planed behind M2 Cass: 3 instr.+Cal unit + AO system 90% Queue

Gemini: A specialized telescope

Slide courtesy F. Rigaut

slide-3
SLIDE 3

NICI: AO System + Lyot Coronagraph + Dual-channel Near-IR Camera

–

Optimized for high-contrast imaging

(no lenses, minimal static aberrations, differential imaging)

–

  • AO System: 85-element curvature system
  • natural guide stars
  • H-band Strehl ratio between 0.2 (V ~ 13) to ~ 0.4 (bright stars)

Science Camera: Dual-channel InSb (1-5 µm, only 1 – 2.5 offered) – Focal-plane and pupil masks – Beamsplitting elements, filters in each channel.

3/25/09 3 NICI Technical Assessment

NICI Overview

www.gemini.edu, see NICI

slide-4
SLIDE 4

Observing Modes

Angular Differential Imaging (ADI): Ideal PSF subtraction

  • Cass Rotator fixed, static pupil  stable speckle pattern

Spectral Differential Imaging (SDI)

  • Simultaneous dual-wavelength imaging
  • contrast gain for targets with CH4 absorption (T_eff < 1300 K)

NICI combines both techniques (ASDI)

  • Meanwhile 1 semester experience

–

Planet-finding campaign (M. Liu et al.)

–

Special DD programs on bright targets

3/25/09 4 NICI Technical Assessment

NICI Overview

www.gemini.edu, see NICI

slide-5
SLIDE 5

Kyoto, May 2009 NICI – the GS AO facility coronagraph

NICI for 2009B

  • 17 proposals for a total of 257 hours for 2009B.

Given oversubscription rates, up to 130 hours of awarded PI NICI time for 2009B

  • 120 hour commitment for NICI Campaign
  • Mostly used as summer instrument (good weather and seeing conditions)

NICI Campaign: ~190 observed already, close to 40% of full awarded Campaign time (500 h)

slide-6
SLIDE 6

Kyoto, May 2009 NICI – the GS AO facility coronagraph

Something to touch (from Chris Ftaclas' laboratory, Univ. Hawaii)

  • DM (bimorph), Hokupa'a 85 electrode pattern, as in NICI now
  • ground between the plates
  • curvature AO system: circular arrangement
  • front electrode (to apply a strong focus)
  • ~ 15 m radius (or ~30 fringes or stroke of 20 to 30 microns)

corresponding lenslet array

slide-7
SLIDE 7

Kyoto, May 2009 NICI – the GS AO facility coronagraph Chun et al., SPIE, 2008 http://www.gemini.edu/sciops/instruments/nici/itc-sensitivity-and-overheads

slide-8
SLIDE 8

Kyoto, May 2009 NICI – the GS AO facility coronagraph Chun et al., SPIE, 2008 http://www.gemini.edu/sciops/instruments/nici/itc-sensitivity-and-overheads

slide-9
SLIDE 9

Kyoto, May 2009 NICI – the GS AO facility coronagraph

slide-10
SLIDE 10

Kyoto, May 2009 NICI – the GS AO facility coronagraph

slide-11
SLIDE 11

Kyoto, May 2009 NICI – the GS AO facility coronagraph

slide-12
SLIDE 12

Kyoto, May 2009 NICI – the GS AO facility coronagraph

Bottom port

slide-13
SLIDE 13

Kyoto, May 2009 NICI – the GS AO facility coronagraph

Side port

slide-14
SLIDE 14

Kyoto, May 2009 NICI – the GS AO facility coronagraph

NICI PSF in H-Band NICI PSF in H-Band without coronagraphic mask

slide-15
SLIDE 15

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-16
SLIDE 16

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-17
SLIDE 17

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV Linear stretch

slide-18
SLIDE 18

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV PSF without cow PSF with cow Log stretch ...

slide-19
SLIDE 19

Kyoto, May 2009 NICI – the GS AO facility coronagraph Thick spider arm (30 x the imaged M2 support arm)

slide-20
SLIDE 20

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-21
SLIDE 21

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-22
SLIDE 22

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-23
SLIDE 23

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-24
SLIDE 24

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-25
SLIDE 25

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-26
SLIDE 26

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-27
SLIDE 27

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-28
SLIDE 28

Kyoto, May 2009 NICI – the GS AO facility coronagraph

2.3” x 2.3” FOV

slide-29
SLIDE 29

Kyoto, May 2009 NICI – the GS AO facility coronagraph

ADI reduction

(Angular Differential Imaging – Cassegrain rotator fixed, pupil fixed =>

  • ptimal PSF subtraction)

For the red arm, for the blue arm separately:

  • dark, flat, bad pixel corr
  • Register (subpixel shift) to central star (below the occulting mask, if not

saturated, spot can be used for centering, Strehl, and flux esitation!)

  • Highpass (looking for point sources!)
  • match speckles (e.g. simplex minimization), scale intensity
  • median ADI cube to get PSF frame (potential companions cancel out if

enough field rotation)

  • subtract PSF frame from cube (matching speckles of individual frames)

SDI reduction (Simultaneous or Spectral Differential Imaging - cancel primary, keep cool methane containing object)

  • shift, adjust image scale according to filter wavelength of red and blue

channel

  • subtract final results of both arms
  • Lit. ADI/SDI e.g. from GDPS, authors e.g. Marois, Lafreniere, Artigau, Biller, etc.
slide-30
SLIDE 30

Kyoto, May 2009 NICI – the GS AO facility coronagraph

0.3” 1”

slide-31
SLIDE 31

Kyoto, May 2009 NICI – the GS AO facility coronagraph

1” 0.3”

slide-32
SLIDE 32

Kyoto, May 2009 NICI – the GS AO facility coronagraph

0.3” 1”

slide-33
SLIDE 33

Kyoto, May 2009 NICI – the GS AO facility coronagraph Artigeau et al., SPIE, 2008

slide-34
SLIDE 34

Kyoto, May 2009 NICI – the GS AO facility coronagraph Artigeau et al., SPIE, 2008

Contrast Gain applying SDI (on top of ADI)

SDI most effective inside 1”. Efficiency for ADI increases for larger radii.

slide-35
SLIDE 35

Kyoto, May 2009 NICI – the GS AO facility coronagraph

LOCI

Locally Optimized Combination of Images OT Region of image for which reference PSF is reconstructed Ok Same Region of kth reference image i Pixel index of this region

Artigeau et al., SPIE, 2008 Lafreniere, Marois, Doyon, Nadeau, Artigau, A&A, 2007

slide-36
SLIDE 36

Kyoto, May 2009 NICI – the GS AO facility coronagraph Lafreniere, Marois, Doyon, Nadeau, Artigau, A&A, 2007

slide-37
SLIDE 37

Kyoto, May 2009 NICI – the GS AO facility coronagraph

NICI Pipeline release

  • Pyraf (but using python only for NICI)
  • Beta release July 2009, Nelson Zarate
  • Update February 2010, Nelson Zarate

www.gemini.edu , see DATA, Gemini IRAF package Pipeline will output many intermediate products (standard reduction, ADI, SDI, ASDI, LOCI, etc.)

slide-38
SLIDE 38

Kyoto, May 2009 NICI – the GS AO facility coronagraph

Summary

  • Contrast up to dH = 13.5 @ 0.5” (90 min) “bad house number”
  • Verify pipelines (fake planets, simulations, photometry)
  • Do it yourself, pipeline releases no grant for being science proof
  • Solid understanding of PSF and its artifacts needed
  • And ...
slide-39
SLIDE 39

Kyoto, May 2009 NICI – the GS AO facility coronagraph

Summary

  • Contrast up to dH = 13.5 @ 0.5” (90 min) “bad house number”
  • Verify pipelines (fake planets, simulations, photometry)
  • Do it yourself, pipeline releases no grant for being science proof
  • Solid understanding of PSF and its artifacts needed
  • And check your telescope for a cow
