Improving Industry Health & Safety Performance

Simon Schubach Acting CEO, NOPSA Aug 2009

2009 National Oil & Gas Safety Conference

2

NOPSA’s functions

Monitor & Enforce Co-operate Investigate Advise Promote

Balanced judgment is required for these functions

3

Proactive

27 OHS Inspectors ► 89 Inspections 163 Facilities (68 pipelines)

Reactive

Assessments ~ 220 Accident & DO Notifications ~ 400 Complaints ~ 25 Enforcement

Improvement Notices ~ 40 Prohibition Notices

~ 10

NOPSA Activities 2 0 0 8 -0 9

(Based on current data Jul 2008 – Jun 2009)

4

NOPSA focus areas: 2 0 0 9 -2 0 1 0

• Industry safety leadership
• Asset integrity
• Emergency preparedness
• Contractors

5

Safety Leadership & Asset I ntegrity

Themed Audits

What is a themed audit?

Company-wide critical examination

• f operator

systems and facilities

To be conducted this year:

• 5 safety leadership audits
• 5 asset integrity audits

6

Them ed Audits

Elem ents Safety Leadership Audits

• draw on Baker Panel & Buncefield reports and consider:
• Process safety expectations,
• Communications & visibility,
• Involvement in process safety audits,
• Employee empowerment,
• Resources & positioning,
• Process safety in decision-making

Asset Integrity Audits

• draw on NOPSA FI results and sources such as OGP Asset Integrity question set:
• Facility major incidents & barriers
• Critical equipment
• People & processes
• Projects
• Culture

7

W e are VULNERABLE … so be VI GI LANT

21st Anniversary of the Piper Alpha tragedy 6 July 1988

8

Texas City Refinery 1 5 Fatalities – March 2 0 0 5

$US ~1 Billion

Victim Compensation

$US ~1 Billion

Renewal Plan

9

US Chem ical Safety Board

• Mistakes made in Texas City have their roots in

decisions made by managers, sometimes years earlier

• Safety culture is first and foremost about how

managerial decisions are made

• Are production and cost control being rewarded at

the expense of safety and risk management?

• Recommended BP set up independent panel

10

Major Accident Prevention – US CSB

Ask yourself these questions:

• Is it an engineering problem?
• Is it a problem of employee

compliance?

• Is it a matter of corporate policy and

behaviors?

11

Baker Report Findings Jan 2 0 0 7 Corporate safety culture

• effective process safety leadership
• perating discipline: no toleration of deviations from safe operating practice

Process safety management systems

• process safety standards & good engineering practices
• translate corporate expectations into process safety criteria

Performance evaluation, corrective action and oversight

• effective root cause analysis of incidents & audits to ensure performance
• senior management oversight of process safety

Pre ve nting pro c e ss ac c idents requires

vigilanc e… Pe o ple c an fo rge t to be

afraid!

12

Buncefield Oil Storage Depot

United Kingdom

Dec 2 0 0 5

₤1 Billion

Economic Impact

13

Buncefield I nvestigation Findings

• Leadership and Culture
• Collate and communicate data
• high potential incidents
• solutions and control measures
• Undertake thorough root cause investigation
• Share lessons learned and best practices

14

Offshore Petroleum I ndustry Health & Safety Perform ance Collected since NOPSA commenced

• Accidents and Dangerous Occurrences
• Planned Inspections
• National Programmes

15

MAJOR A + DOs include: Death/serious injury Could cause death/serious injury Fires or explosions Collision marine vessel & facility Hydrocarbon gas release >300 kg Petroleum liquid release >12 500 L

MAJOR Accidents & Dangerous Occurrences

Major Incidents - rolling 12-month totals 10 20 30 40 50 60 70 80 90 100

Jan05- Dec05 Jul05- Jun06 Jan06- Dec06 Jul06- Jun07 Jan07- Dec07 Jul07- Jun08 Jan08- Dec08 Jul08- Jun09 The International Regulators Forum (IRF) has devised a severity rating. ‘Major’ is considered more serious, followed by ‘Significant’.

16

SIGNIFICANT Accident & Dangerous Occurrences

SIGNIFICANT A + DOs include: Incapacitation LTI ≥3 days Could cause an LTI ≥3 days Other kind needing immediate investigation Damage to Safety-critical Equipment HC gas release >1-300 kg PL release >80 -12 500 L Well kick >50 barrels Unplanned Event - Implement ERP Significant Incidents - rolling 12-month totals 50 100 150 200 250 300 350

Jan05- Dec05 Jul05- Jun06 Jan06- Dec06 Jul06- Jun07 Jan07- Dec07 Jul07- Jun08 Jan08- Dec08 Jul08- Jun09 The International Regulators Forum (IRF) has devised a severity rating. ‘Major’ is considered more serious, followed by ‘Significant’.

17

Accidents & Dangerous Occurrences

Top 5 Root Causes

Data from Jul 2008 – Jun 2009

2 4 6 8 10 12

Preventive Maintenance Procedures - Not Followed Design Specs Design Review Procedures - Wrong

Per cent

18

Root Causes

Com parison w ith previous years

2005 2006 2007 2008 YTD 2009 Procedures - Not Followed Preventive Maintenance Preventive Maintenance Preventive Maintenance Procedures - Wrong Preventive Maintenance Procedures - Not Followed Design Specs Procedures - Not Followed Design Specs Design Specs Human Engineering - Machine Interface Procedures - Not Followed Design Specs Preventive Maintenance Work Direction - Preparation Design Specs Procedures - Wrong Equipment / Parts Defective - Handling Equipment - Design Review Other Work Direction - Preparation Equipment - Design Review Procedures - Followed Incorrectly Procedures - Not Followed

19

Accidents

Top 5 Root Causes

Data from Jul 2008 – Jun 2009

Top 5 most common Root Causes of Accidents (LTIs and Major Injuries)

2 4 6 8 10 12 14 16 18

Procedures - Followed Incorrectly Procedures - Not Followed Procedures - Wrong Work Direction - Preparation Human Engineering - Work Environment

Per cent

20

Comparison with IRF injury rates

(ADI + LTI) Rate ≥1 day

2004 2005 2006 2007 2008

Australian Rate

4.94 6.99 8.35 7.81

IRF Average Rate (Benchmark)*

3.28 3.74 3.68 3.19

IRF Best Rate

2.93 2.23 2.75 2.06

US

Netherlands Netherlands

US

21

Hydrocarbon Gas Releases

Num ber per year

Gas Releases 12-month totals

5 10 15 20 25

Jul05-Jun06 Jul06-Jun07 Jul07- Jun08 Jul08- Jun09

Number

Major (>300 kg) Significant (>1 - 300 kg)

22

Even taking into account higher levels of activity …

As per IRF guidelines – process-related releases only. i.e. NOPSA Gas Release Rates only include data from the following facility types: Platforms, FPSOs, FSOs, MOPUs

Gas Release Rates

(per 100 Production Facilities per month) 0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0

Jan05- Dec05 Jul05- Jun06 Jan06- Dec06 Jul06- Jun07 Jan07- Dec07 Jul07- Jun08 Jan08- Dec08 Jul08- Jun09

Rate

23

Com parison w ith I RF gas release rates

Australia Total Rate International Benchmark Total Rate

2005 1.85 3.08 2006 2.73 3.46 2007 3.27 5.16 2008 3.02

not yet available

24

Hydrocarbon Gas Releases

Root Causes

Top 5 most common Root Causes of Gas Releases (Jan 2005 - Jun 2009)

5 10 15 20

Preventive Maintenance Design Specs Procedures - Not Followed Design Review Quality Control

Per cent

25

Gas Releases per Facility for Production Operators Jan 2005 - Jun 2009

2 4 6 8 10 12

1 2 3 4 5 6 7 8 9 10 11 12

Number

Production Operators

Gas releases per Facility per Operator

26

Production Operator # 2

Root Causes

Top 5 Root Causes per Operator #2 for Gas Releases 10 20 30 40 Quality Control Design Review Preventive Maintenance Design Specs Procedures - Not Followed

Per cent

27

Production Operator # 3

Root Causes

Top 5 Root Causes for Operator #3 for Gas Releases 5 10 15 20 Preventive Maintenance Procedures - Not Followed Design Specs Procedures - Wrong Management System

Per cent

28

Overall Proportion of FI Releases Jan 2005 - Jun 2009 % Other Incidents % FI Incidents

0% 20% 40% 60% 80% 100%

Facility I ntegrity

National Program m es

• NOPSA Inspections

(FI Prompt sheets)

• Analysis of Accident

& Dangerous Occurrences

29

FI : I nspection Results by Focus Areas

Percentage Facilities at each FI Expectation Level at Jun 2009

0% 20% 40% 60% 80% 100%

Facility Integrity Mgmt System - Onshore Topsides Maintenance System - Onshore Topsides Maintenance System - Offshore Topsides Process Integrity Topsides Pressure Integrity Topsides Corrosion and Erosion Topsides Structures SmallBore Piping/Tubing, Flexible Hoses

Does not meet FI Expectations Partially meets FI Expectations Meets FI Expectations

30

0% 20% 40% 60% 80% 100%

Facility Integrity Mgmt System - Onshore Topsides Maintenance System - Onshore Topsides Maintenance System - Offshore SmallBore Piping/Tubing, Flexible Hoses

Does not meet FI Expectations Partially meets FI Expectations Meets FI Expectations

FI : Focus Area Elem ents that require attention

Audit & Review Compliance with Performance Stds System Test of SCE Field Installation

8 areas, also; process pressure corrosion structures

31

Key Findings from National Program m es

• 1. NOPSA Inspections (FI Prompt sheets)
• Backlogs in testing & maintenance of safety critical

elements

• Monitoring, independent auditing and review
• 2. Analysis of Accident & Dangerous Occurrences
• Safety Critical Elements: inadequate testing &

maintenance

• Equipment and Parts Defects

32

Parts and Equipment involved in FI Incidents

Hydrocarbon Releases Parts and Equipment Involved Jan 2005 - Jun 2009

5 10 15 20 25 30

V a l v e s / V e n t s P i p e s / T u b e s O t h e r J

• i

n t s / F l a n g e s G a s k e t s / S e a l s P u m p s / C

• m

p r e s s

• r

s I n s t r u m e n t s T a n k E n g i n e s

Per cent

33

HSE ( UK) Asset I ntegrity Program m e ( KP3 )

Maintenance Management System areas of concern:

– Maintenance of SCEs – Backlog – Deferrals – Measuring compliance with Performance Stds – Corrective Maintenance

34

Process safety indicators

• APPEA has taken the initiative to trial 3 leading

indicators: safety tours, high potential incidents and audit action close-outs

• AIChE CCPS (www.ccpsonline.org) has proposed a

series of leading process safety indicators, including one for mechanical integrity: SCE inspections completed/Total SCE inspections due

35

Accidents & Dangerous Occurrences Root Causes Overall Top 3 (Jan 2005 – Jun 2009)

• 1. Preventive maintenance

needs improvement

• 2. Procedures

not used/not followed

• 3. Design specifications

needs improvement

36

2 0 0 9 National Oil & Gas Safety Conference

Thank you
